2AXOX-N5Karaoke Speaker

USER MANUAL N5 Multifunctional Amplified Karaoke Speaker Warning 01 English ◆ Please read the instructions first. ◆ Please follow the instructions carefully. ◆ Please store and use this product at room temperature. ◆ Do not use this product near heat sources such as radiators, heat registers, stoves, or other apparatuses (including amplifiers) that produce heat. ◆ Do not block the opening of the speaker, and do not insert objects into the vents or slots of the speaker. ◆ Do not throw or drop the product to avoid damage. ◆ Please charge the speaker with the product-rated voltage. ◆ If the connection line does not match your device, please contact the dealer. ◆ Please keep the speaker volume at a moderate level to avoid temporary or permanent hearing impairment. ◆ If the equipment is damaged for any reason, it must be repaired by professional maintenance personnel in a timely manner. Unauthorized disassembly will invalidate the warranty. ◆ If the battery is not properly replaced, there may be a risk of explosion. It must only be replaced with the same type of battery. ◆ Do not disassemble, impact, squeeze, or throw the battery into fire. If severe swelling occurs, stop using it immediately. Do not place it in a high-temperature environment, and do not use it after the battery has been soaked in water. ◆ The battery (battery pack or combined battery) must not be exposed to conditions such as direct sunlight, fire, or other overheating environments. ◆ If consumers use a power adapter to charge, they should use a certified power adapter that has obtained CCC certification and meets standard requirements. Packing list 02 English SpeakerWireless MicrophoneWireless Headset Actual packing contents depend on the purchased version. Product images are for reference only. User Manual USB Type-C Charging Cable Single Track Loop: During TF card/U-disk playback, long press the M button to enable single-track loop. The will light up when activated. Volume Adjustment: Rotate to increase or decrease the volume. Short Press: Previous Track Record Key Short Press: Next Track Power Key: Long press to turn on/off Play Button: Short press to play/pause Microphone Reverb Adjustment 0‒9 Numeric Song Selection Keys: Mode Button Microphone Volume Adjustment: Rotate to increase or decrease the volume. Button Function Indicator 03 English Mode Switching: Short press to switch modes: U-disk mode / Bluetooth mode / TF card mode / AUX mode. Note: The device defaults to Bluetooth mode when powered on. Local Recording: Short press to enter recording mode. Short press again to stop, save, and exit the recording. Long press to enter recording playback mode. Mic Button Wireless Microphone Pairing: Long press to enter microphone pairing mode. The microphone icon flashes. When connected successfully, the icon remains lit. Long press again to exit pairing mode. Microphone Priority: Short press to enable microphone priority. When speaking, music volume is automatically reduced. 1. The operation is effective only when a U-disk or TF card is inserted. 2. If both a U-disk and TF card are present, recording will be prioritized to the U-disk. 3. During recording, the recording icon on the screen will flash. 4. During playback, the recording icon on the screen will remain steadily lit. Delete Recording: During recording playback, long press the Record button to delete the currently playing recording file. TF Card/U-Disk Playback Mode: Enter the numbers directly to quickly play the corresponding track in sequence. If the entered number exceeds the total number of songs in the current folder of the TF card/U-disk, the input will be invalid. Bluetooth Disconnection: Long press the M button for 2 seconds to disconnect from the current device and enter pairing mode. Press the Play button again to reconnect. MICRO SD Charging Indicator Light: Red light stays on while charging. Red light turns off when fully charged. AUX External Audio Input: Connect the audio cable to switch the speaker to AUX mode. The device has a built-in reset button; press it using a thin tool. TF Card / USB Flash Drive Playback: Insert a TF card or USB flash drive while the speaker is powered on, and it will automatically play the audio files stored on the TF card or USB drive. Power Charging: Connect a 5V DC, 1‒3A USB power adapter for charging. Electronic Wind Instrument (EWI) Acoustic Guitar Interface Function Indicators 04 English 6.35 mm Instrument Input Mode Indicator / Time Display Battery Level Indicator Local Recording Single Track Repea Wireless Microphone Pairing USB Flash Drive Mode Bluetooth Mode TF Card Mode AUX Mode Screen Display Instructions 05 English 1. Power On the Speaker: Press and hold the power button to turn on the speaker. After the startup prompt sound, the LED Bluetooth icon will flash, indicating it is ready for Bluetooth pairing. 2. Connect to a Mobile Device: Turn on the Bluetooth function on your mobile device. In the list of available Bluetooth devices, select "Mlove N5." Once successfully connected, you will hear a prompt sound, and the Bluetooth indicator will remain steadily lit. For future use: As long as the Bluetooth on your mobile device remains turned on, the connection will be established automatically. Bluetooth Disconnection: Press and hold the M button for 2 seconds to disconnect from the current device. The speaker will enter pairing mode and wait for a new connection. Bluetooth Audio Connection 06 English Microphone Indicator Light Short Press / Long Press to Increase Microphone Volume Short Press / Long Press to Decrease Microphone Volume Power Button: Press and hold for 2 seconds to turn the wireless microphone on/off. Reverb Adjustment: Short press to switch the reverb level. Three levels are available. Charging Port: Connect to a USB power source with an output of DC 5V 1A to charge. USB Wireless Microphone Function Indicator 07 English Wireless Microphone Connection Indicator: When powered on and connecting, the gree…
