2AXWG-RDT401BUIntelligent Driving Assist System

Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Product usermanual Product Name: Intelligent Driving Assist System Product number: RDT401BU Product number Address: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Website: www.roadefend.com Table of Contents 1 System Introduction ......................................................................................................... 3 1.1 System diagram ............................................................................................................... 3 1.2 Introduction of system components ................................................................................. 4 2 Product list .......................................................................................................................... 5 3 Specification and Function ............................................................................................. 5 3.1 Active safety Function ..................................................................................................... 5 3.2 Other major function ....................................................................................................... 6 4 User Notes .......................................................................................................................... 8 1 System Introduction RDT401BU is an active safety intelligent control system developed on the basis of the image recognition algorithm, which integrates driver status early-warning analysis and forward active safety warning with a main function of safety drive assistant, so as to avoid road accidents caused by poor driver status or improper operation. As split design is applied in the product, different camera solutions can be selected according to the vehicle models.The product can communicate with the platform independently and can also be used with other on-board terminals through Ethernet to provide a complete set of solutions for vehicle active safety control. Fully considering the requirements of active safety terminals proposed by JT/T 883, JT/T 26773, JT/T 794, JT/T 1076, TJSATL13-2017 and other standards in designing the product has not only ensured the product conforming to the requirement, but also enhanced the stability, compatibility and maintainability of the system. 1.1 System diagram Product model Product name Note System components RDT401B Active safety intelligent control system CAM-ADAS ADAS camera for road ahead Bottom outlet CAM-IPC Monitoringcamera Note 1: CAM-ADAS and CAM-IPC are selectable, which can be selected according to different models and different installation methods. 1.2 Introduction of system components 1) RDT401BU Integrating the camera for analyzing driver status, RDT401BU is acted as an operation processing center of the whole system to calculate the high-definition digital video information input by the forward road surveillance camera. RDT401B DMS 2) CAM-ADAS The CAM-ADAS camera is for road ahead monitoring. Video data obtained will be sent to RDT401BU machine for analyzing and processing. RD-CAM-ADAS 3) CAM-IPC The CAM-IPC is an IP Camera for road vehicle inside monitoring. Video data obtained will be sent to RDT401BU machine for recording. Real time video is recorded to the TF card. CAM-IPC 2 Product list Product list No. Accessory name Quantity ① RDT401BU Device 1 ② CAM-ADAS Camera Selectable ③ CAM_IPCCamera Selectable ④ RDT401Bmain cable 1 ⑤ RDT401BU 4G Antenna 1 ⑥ RDT401BU GPS Antenna 1 ⑦ Installation materials 1set 3 Specification and Function 3.1 Activesafety Function Alarm type Description Voice prompt Fatigue warning (level 1) When the driver is found to be sleepy, exceeding the level-1 warning threshold, an alarm will be raised. "Toot~ toot~ toot~" Fatigue warning (level 2) When the driver is found to be sleepy, exceeding the level-2 warning threshold, an alarm will be raised. "Toot, toot, toot, toot, attention please" Obstruction When an obstruction covering the camera for monitoring the driver's condition over the set time, an obstruction warning will issued. "Dang~dang~" Leaving the post When the driver deviates from the driving position and the driver's face cannot be detected by the device, an alarm will be raised. "Dang~dang~" Distraction prompt When the driver is distracted from the road ahead, such as looking up, looking down and looking around, an alarm will be raised. "Watch out road conditions ahead" Smoking When the driver smokes while driving, an alarm will be raised. "No smoking" Make a phone call When the driver makes a call while driving, an alarm will be raised. "Drive carefully" Alarm type Description Voice prompt Yawn When the driver yawns while driving, an alarm will be raised. "You are sleepy. Take a rest please" Substitution prompt After the vehicle moves and reaches the set speed, the driver's identity will be monitored. If the driver change is detected, a voice prompt will be made. "Driver has changed" When CAM-ADAS is equipped, the system can achieve active safety warning in the forward direction Alarm type Description Voice prompt Forward collision warning When the vehicle speed exceeds the set speed, and the collision time with the preceding vehicle is lower than the safety time threshold, an alarm will be raised. "Toot, toot, toot, toot, toot~" Low speed collision warning When the vehicle speed is less than the set speed, and the collision time with the preceding vehicle is lower than the safety time threshold, an alarm will be raised. Sharp "Tick, tick, tick" Excessively-close vehicle distance level 1 When the vehicle speed exceeds the set value with the distance maintained less than the set minimum level-1 distance, an alarm will be raised. "Ding~" Excessively closed distance level 2 When the vehicle speed exceeds the set value with the distance maintained less than the set minimum level-2 distance, an alarm will be raised. "Ding ding~" Lane deviation warning When the vehicle speed exc…

Text truncated - open the document above for the full version.

Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Family models difference declaration Intelligent Driving Assist System Model: RDT401BU, AI400 Difference declaration: All the model are the same circuit and RF module, except the Model names. Regards, Signature Name: Xiaojun Hu Date: 2021-06-02

Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Room 01, level3, block B3, lane221, Huangxing Road, Yangpu District, Shanghai, China Date: 06/02/2021 FCC ID: 2AXWG-RDT401BU Model Number: RDT401BU, AI400 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Roadefend Intelligence Technology (Shanghai) Co.,Ltd. declare that this EUT (FCC ID: 2AXWG-RDT401BU) will conduct FCC compliance testing, the sDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.). 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Please contact me if you have any question. Sincerely, (Signed) Name / Title: Xiaojun Hu / Manager Company: Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Address: Room 01, level3, block B3, lane221, Huangxing Road, Yangpu District, Shanghai, China Phone: 021-55896781 Fax: 021-55896781 Email: [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization < Roadefend Intelligence Technology (Shanghai) Co.,Ltd. > Company: Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Address: Room 01, level3, block B3, lane221, Huangxing Road, Yangpu District, Shanghai, China Product Name: Intelligent Driving Assist System Model Number: RDT401BU, AI400 FCC Identifier: 2AXWG-RDT401BU We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Xiaojun Hu Date: 06/02/2021 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 < Roadefend Intelligence Technology (Shanghai) Co.,Ltd. > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-06-02 Subject: Request for Confidentiality FCC ID: 2AXWG-RDT401BU To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location Attestation Statement External Photos Block Diagram Schematics Test Report Test Setup Photos User’s Manual NOTE 1 Internal Photos NOTE 1 Parts List / Tune Up / BOM List RF Exposure Info Operational Description Cover Letter(s) SDR Software / Security Info NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. C5266091_X10_Ed.2 1/1 It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Xiaojun Hu Title: Manager

FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU External Photographs Photo1 Photo2 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo3 Photo4 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo5 Photo6 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo7 Photo8 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo9 Photo10 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo11 Photo12 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo13 Photo14 GSM / WCDMA / LTE Main ANT FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo15 GPS ANT

Label Sample and Label Location

FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Internal Photographs Photo1 Photo2 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo3 Photo4 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo5 Photo6 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo7 Photo8 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo9 Photo10 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo11 Photo12 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo13 Photo14 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo15 Photo16 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo17 Photo18 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo19 Photo20 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo21 Photo22 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo23 Photo24 FCC ID: 2AXWG-RDT401BU Model Name: RDT401BU Photo25 Wi-Fi ANT

FCC ID: 2AXWG-RDT401BU RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result Operation Frequency: 2412MHz-2462MHz; 824MHz-849MHz; 1850MHz-1910MHz; 1710MHz- 1755MHz; 2500MHz-2570MHz; Antenna Type: WLAN 2.4G: FPC Antenna; GSM/WCDMA/LTE: Patch Antenna Antenna gain: WLAN 2.4G: 5dBi; GSM/WCDMA/LTE: 2dBi; R=20cm SISO Mode Max EIRPAntennaEvaluation result Pow er density Limits Gain (dBi) Wi-Fi 2.4G215200.0250451PASS GPRS 850342200.4997120.549PASS GPRS 1900322200.3152971PASS WCDMA Band II25.52200.0705861PASS WCDMA Band IV262200.0791991PASS WCDMA Band V25.52200.0705860.551PASS LTE Band 2252200.0629101PASS LTE Band 425.002200.0629101PASS LTE Band 525.52200.0705860.550PASS LTE Band 722.52200.0353771PASS Verdict (mW/cm2)(mW/cm2 ) Band Separation distance (cm)(dBm) SIMULTANEOUS TRANSMISSIONS When a number of sources at different frequencies, and/or broadband sources, contribute to the total exposure, it becomes necessary to weigh each contribution relative to the MPE. To comply with the MPE, the fraction of the MPE in terms of E 2 , H 2 (or power density) incurred within each frequency interval should be determined and the sum of all such fractions should not exceed unity. In order to ensure compliance with the MPE for a controlled environment, the sum of the ratios of the power density to the corresponding MPE should not exceed unity. That is Max. SIMULTANEOUS TRANSMISSIONS MODE Max EIRPAntenna Evaluation result Pow er density Limits Evaluation result Pow er density Limits Gain (dBi) 215200.0250451 342200.4997120.549 (mW/cm2 )(mW/cm2) Separation distance (cm)(dBm) PASS (mW/cm2)(mW/cm2 ) 1 Wi-Fi 2.4G + GPRS 850 Band 0.935267 SISO Verdict MIMO Signature: Date: 2021-06-03 NAME AND TITLE (Please print or type): Alex/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

Report No.: S21032202602002 Version.1.2 Page 1 of 40 FCC RADIO TEST REPORT FCC ID: 2AXWG-RDT401BU Product: Intelligent Driving Assist System Trade Mark: Roadefend Model No.: RDT401BU Family Model: AI400 Report No.: S21032202602002 Issue Date: May 17. 2021 Prepared for Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website:http://www.ntek.org.cn Report No.: S21032202602002 Version.1.2 Page 2 of 40 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................... 9 6.2 SUPPORT EQUIPMENT ............................................................................................................................... 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 11 7 TEST REQUIREMENTS .................................................................................................................................... 12 7.1 FIELD STRENGTH OF SPURIOUS RADIATION ...................................................................................... 12 7.2 EFFECTIVE RADIATED POWER AND EFFECTIVE ISOTROPIC RADIATED POWER ........................ 21 7.3 CONDUCTED OUTPUT POWER ................................................................................................................ 27 7.4 FREQUENCY STABILITY ........................................................................................................................... 29 7.5 PEAK-TO-AVERAGE RATIO ...................................................................................................................... 34 7.6 26DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ..................................................................... 36 7.7 CONDUCTED BAND EDGE ....................................................................................................................... 38 7.8 CONDUCTED SPURIOUS EMISSION AT ANTENNA TERMINAL ......................................................... 39 Report No.: S21032202602002 Version.1.2 Page 3 of 40 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Address ....................................... : Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Manufacturer's Name .................. : Roadefend Intelligence Technology (Shanghai) Co.,Ltd. Address ....................................... : Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Product description Product name .............................. : Intelligent Driving Assist System Model and/or type reference ...... : RDT401BU Family Model ............................... : AI400 Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT 47 CFR Part 2, Part 22H, Part 24E, Part 27 ANSI/TIA-603-E-2016 FCC KDB 971168 D01 Power Meas License Digital Systems v03r01 ANSI C63.26:2015 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test : Apr. 06. 2021 ~ May 17. 2021 Testing Engineer : (Cheng Jiawen) Technical Manager : (Jason Chen) Authorized Signatory : (Alex Li) Report No.: S21032202602002 Version.1.2 Page 4 of 40 2 SUMMARY OF TEST RESULTS FCC Part22H / FCC Part24E / FCC Part 27 & ANSI C63.26-2015 FCC Rule Test Item Verdict Remark 2.1046 Conducted Output Power PASS 24.232 27.50 KDB 971168 D01 Clause 5.7 Peak-to-Average Ratio PASS 2.1049 22.917 24.238 KDB 971168 D01 Clause 4.2 Occupied Bandwidth PASS 2.1051 22.917 24.238 27.53 KDB 971168 D01 Clause 6 Band Edge PASS 22.913 KDB 971168 D01 Clause 5.6 Effective Radiated Power PASS 24.232 27.50 KDB 971168 D01 Clause 5.6 Equivalent Isotropic Radiated Power PASS 2.1053 22.917 24.23…
