2AXWG-RDT500BActive Safety Intelligent Control System

DT500B Active Safety Intelligent Control System User Manual 1 System Introduction RDT500B is an active safety intelligent control system developed on the basis of the image recognition algorithm, which integrates driver status early-warning analysis and forward active safety warning with a main function of safety drive assistant, so as to avoid road accidents caused by poor driver status or improper operation. As split design is applied in the product, different camera solutions can be selected according to the vehicle models. The product can communicate with the platform independently and can also be used with other on-board terminals through ethernet to provide a complete set of solutions for vehicle active safety control. Fully considering the requirements of active safety terminals proposed by JT/T 883, JT/T 26773, JT/T 794, JT/T 1076, TJSATL13-2017 and other standards in designing the product has not only ensured the product conforming to the requirement, but also enhanced the stability, compatibility and maintainability of the system. 1.1 System diagram Product model Product name Note System components RDT500B Active safety intelligent control system RD-CAM-AD500 ADAS camera for road ahead Bottom outlet RD-CAM-AD501 ADAS camera for road ahead Top outlet Note 1: Since RD-CAM-AD500 and RD-CAM-AD501 have different outlet modes, which can be selected according to different models and different installation methods. 1.2 Introduction of system components 1) RDT500B Integrating the camera for analyzing driver status, RDT500B is acted as an operation processing center of the whole system to calculate the high-definition digital video information input by the forward road surveillance camera. RDT500B appearance 2) RD-CAM-AD500 / RD-CAM-AD501 The RD-CAM-AD500 is an ADAS camera for road ahead, which is targeted road in front to monitor the road ahead. Video data obtained will be sent to RDT500B machine for analyzing and processing. With bottom outlet, it's generally applicable for large vehicles. While RD-CAM-AD501 is generally applicable for small passenger cars with top outlet. RD-CAM-AD500 RD-CAM-AD501 2 Product list Product list No. Accessory name Quantity ① RDT500B active safety intelligent control host 1 ② Surveillance camera for road ahead RD-CAM-AD500, RD-CAM-AD501 (alternative) 1 Product list ③ Stand 1 ④ Screws for the stand 4 ⑤ Allen wrench 1 ⑥ RDT500B power supply and CAN extension cord 1 ⑦ Instruction 1 ⑧ RDT500B turn signal cord 1 ⑨ GPS antenna (option) 1 3 Specification and Function 3.1 Active safety Function Alarm type Description Voice prompt Fatigue warning (level 1) When the driver is found to be sleepy, exceeding the level-1 warning threshold, an alarm will be raised. "Toot~ toot~ toot~" Fatigue warning (level 2) When the driver is found to be sleepy, exceeding the level-2 warning threshold, an alarm will be raised. "Toot, toot, toot, toot, attention please" Obstruction When an obstruction covering the camera for monitoring the driver's condition over the set time, an obstruction warning will issued. "Dang~dang~" Leaving the post When the driver deviates from the driving position and the driver's face cannot be detected by the device, an alarm will be raised. "Dang~dang~" Distraction prompt When the driver is distracted from the road ahead, such as looking up, looking down and looking around, an alarm will be raised. "Watch out road conditions ahead" Smoking When the driver smokes while driving, an alarm will be raised. "No smoking" Make a phone call When the driver makes a call while driving, an alarm will be raised. "Drive carefully" Yawn When the driver yawns while driving, an alarm will be raised. "You are sleepy. Take a rest please" Substitution prompt After the vehicle moves and reaches the set speed, the driver's identity will be monitored. If the driver change is detected, a voice prompt will be made. "Driver has changed" When RD-CAM-AD500 or RD-CAM-AD501 is equipped, the system can achieve active safety warning in the forward direction Alarm type Description Voice prompt Forward collision warning When the vehicle speed exceeds the set speed, and the collision time with the preceding vehicle is lower than the safety time threshold, an alarm will be raised. "Toot, toot, toot, toot, toot~" Low speed collision warning When the vehicle speed is less than the set speed, and the collision time with the preceding vehicle is lower than the safety time threshold, an alarm will be raised. Sharp "Tick, tick, tick" Excessively-close vehicle distance level 1 When the vehicle speed exceeds the set value with the distance maintained less than the set minimum level-1 distance, an alarm will be raised. "Ding~" Excessively closed distance level 2 When the vehicle speed exceeds the set value with the distance maintained less than the set minimum level-2 distance, an alarm will be raised. "Dingding~" Lane deviation warning When the vehicle speed exceeds the set value, and the driver deviates from the lane unintentionally, an alarm will be raised. "Tick, tick, tick, tick, tick, tick, tick, tick" 3.2 Other major function 1) Driver identification If the vehicle has just started or stopped for over a certain period of time, a substitution will be triggered. The driver identification function will be triggered if either condition is met. The driver's photo will be captured by the device and uploaded to the cloud platform for analyzing, identifying and processing through the server of the cloud end, so as to compare with the driver information bound in the platform previously. In this way, the driver identity can be determined. 2) Self calibration of driver feature posture When the vehicle speed exceeds the set value after the device starts, the system will enter the self-calibration time of driving posture. Core parameters of the system will be calibrated based on drivers' characteristics and their driving postures in the process. On this basis, posture alarm (incl. looking up, looking down…

Text truncated - open the document above for the full version.

Roadefend Intelligence Technology (Shanghai) Co., Ltd. 1/1 Letter of Authorization Company: Roadefend Intelligence Technology (Shanghai) Co., Ltd. Address: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Product Name: Active Safety Intelligent Control System Model Number: RDT500B FCC Identifier: 2AXWG-RDT500B We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Xiaojun Hu Date: 2021-02-19 Title: Manager Signature of applicant:

Roadefend Intelligence Technology (Shanghai) Co., Ltd. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-02-19 Subject: Request for Confidentiality FCC ID: 2AXWG-RDT500B To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☒ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Xiaojun Hu Title: Manager

Size:15*10mm M/N: RDT500B FCC ID: 2AXWG-RDT500B Label location

4G antenna location WIFI antenna location WIFI MODULE 4G MODULE

FCC §15.247 (i), §2.1091,RSS-102 – RF Exposure FCC ID: 2AXWG-RDT500B Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), RSS-102, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m TEST RESULTS max. output power(dBm) max. output power(mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit of Power Density (S) (mW/ cm2) Result 2.4g WIFI 17.71 59.02 1.58 (2.00dBi) 0.01861 1 Pass LTE BAND 5 23.23 210.38 1.58 (2.00dBi) 0.06633 0.549 Pass LTE BAND 41 22.61 182.39 1.58 (2.00dBi) 0.05751 1 Pass Note: The device can't transmit simultaneously.

Global United Technology Services Co., Ltd. Report No.: GTSL202012000202-1 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 57 1 Cover Page TEST REPORT Applicant: Roadefend Intelligence Technology (Shanghai) Co., Ltd. Address of Applicant: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Manufacturer/Factory: Roadefend Intelligence Technology (Shanghai) Co., Ltd. Address of Manufacturer/Factory: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Equipment Under Test (EUT) Product Name: Active Safety Intelligent Control System Model No.: RDT500B Trade mark: N/A FCC ID: 2AXWG-RDT500B Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Date of sample receipt: 2021-01-05 Date of Test: 2021-01-05-2021-01-25 Date of report issued: 2021-02-01 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 57 2 Version Version No. Date Description 00 2021-02-01 Original Prepared By: Date: 2021-02-01 Project Engineer Check By: Date: 2021-02-01 Reviewer Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 57 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................... 7 5.3 TEST METHODOLOGY ......................................................................................................................... 7 5.4 TEST FACILITY .................................................................................................................................... 7 5.5 TEST LOCATION .................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 SYSTEM TEST CONFIGURATION ....................................................................................................... 10 7.1 TEST MODE ...................................................................................................................................... 10 7.2 CONFIGURATION OF TESTED SYSTEM ................................................................................................ 10 7.3 CONDUCTED OUTPUT POWER ........................................................................................................... 11 7.4 PEAK-TO-AVERAGE RATIO ................................................................................................................ 16 7.5 OCCUPY BANDWIDTH ........................................................................................................................ 22 7.6 MODULATION CHARACTERISTIC ............................................................................................... 28 7.7 OUT OF BAND EMISSION AT ANTENNA TERMINALS ................................................................................ 28 7.8 ERP, EIRP MEASUREMENT .............................................................................................................. 45 7.9 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ................................................................. 49 7.10 FREQUENCY STABILITY ...................................................................................................................... 51 8 TEST SETUP PHOTO ............................................................................................................................ 56 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 57 Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 57 4 Test Summary Test Item Section in CFR 47 Result RF Exposure (SAR) Part 1.1307 Part 2.1093 Pass* (Please refer to SAR Report) RF Output Power Part 2.1046 Part 22.913 (a) Pass Peak-to-Average Ratio Part 22.913(d) Pass Modulation Characteristics Part 2.1047 N/A 99% & -26 dB Occupied Band…

Text truncated - open the document above for the full version.

Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 29 of 57 LTE FDD Band 5– 1.4 MHz Channel Bandwidth Modulation: QPSK, 1RB#0 Low Channel Modulation:16QAM, 1RB#0 Low Channel Modulation: QPSK, 1RB#0 High Channel Modulation:16QAM, 1RB#0 High Channel Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 30 of 57 LTE FDD Band 5– 3 MHz Channel Bandwidth Modulation: QPSK, 1RB#0 Low Channel Modulation:16QAM, 1RB#0 Low Channel Modulation: QPSK, 1RB#0 High Channel Modulation:16QAM, 1RB#0 High Channel Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 31 of 57 LTE FDD Band 5– 5 MHz Channel Bandwidth Modulation: QPSK, 1RB#0 Low Channel Modulation:16QAM, 1RB#0 Low Channel Modulation: QPSK, 1RB#0 High Channel Modulation:16QAM, 1RB#0 High Channel Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 32 of 57 LTE FDD Band 5– 10 MHz Channel Bandwidth Modulation: QPSK, 1RB#0 Low Channel Modulation:16QAM, 1RB#0 Low Channel Modulation: QPSK, 1RB#0 High Channel Modulation:16QAM, 1RB#0 High Channel Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 33 of 57 Spurious Emission Antenna Port LTE FDD Band 5– 1.4 MHz Channel Bandwidth Modulation: QPSK, Low Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 34 of 57 LTE FDD Band 5– 1.4 MHz Channel Bandwidth Modulation: QPSK, Middle Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 35 of 57 LTE FDD Band 5– 1.4 MHz Channel Bandwidth Modulation: QPSK, H igh Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 36 of 57 LTE FDD Band 5– 3 MHz Channel Bandwidth Modulation: QPSK, Low Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 37 of 57 LTE FDD Band 5– 3 MHz Channel Bandwidth Modulation: QPSK, Middle Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 38 of 57 LTE FDD Band 5– 3 MHz Channel Bandwidth Modulation: QPSK, H igh Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 39 of 57 LTE FDD Band 5– 5 MHz Channel Bandwidth Modulation: QPSK, Low Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 40 of 57 LTE FDD Band 5– 5 MHz Channel Bandwidth Modulation: QPSK, Middle Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 41 of 57 LTE FDD Band 5– 5 MHz Channel Bandwidth Modulation: QPSK, H igh Channel 10MHz~3GHz 3GHz ~9GHz 9 GHz ~15 GHz 15 GHz ~20GHz Report No.: GTSL202012000202-1 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 42 of 57 LTE FDD Band 5– 10M…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTSL202012000202-2 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 57 1 Cover Page TEST REPORT Applicant: Roadefend Intelligence Technology (Shanghai) Co., Ltd. Address of Applicant: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Manufacturer/Factory: Roadefend Intelligence Technology (Shanghai) Co., Ltd. Address of Manufacturer/Factory: Room 01, level3, block B3, lane221, Huangxing Road Yangpu District, Shanghai, China Equipment Under Test (EUT) Product Name: Active Safety Intelligent Control System Model No.: RDT500B Trade mark: N/A FCC ID: 2AXWG-RDT500B Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 27 Date of sample receipt: 2021-01-05 Date of Test: 2021-01-05-2021-01-25 Date of report issued: 2021-02-01 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202012000202-2 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 57 2 Version Version No. Date Description 00 2021-02-01 Original Prepared By: Date: 2021-02-01 Project Engineer Check By: Date: 2021-02-01 Reviewer Report No.: GTSL202012000202-2 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 57 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................... 7 5.3 TEST METHODOLOGY ......................................................................................................................... 7 5.4 TEST FACILITY .................................................................................................................................... 7 5.5 TEST LOCATION .................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 SYSTEM TEST CONFIGURATION ....................................................................................................... 10 7.1 TEST MODE ...................................................................................................................................... 10 7.2 CONFIGURATION OF TESTED SYSTEM ................................................................................................ 10 7.3 CONDUCTED OUTPUT POWER ........................................................................................................... 11 7.4 PEAK-TO-AVERAGE RATIO ................................................................................................................ 16 7.5 OCCUPY BANDWIDTH ........................................................................................................................ 22 7.6 MODULATION CHARACTERISTIC ............................................................................................... 28 7.7 OUT OF BAND EMISSION AT ANTENNA TERMINALS ................................................................................ 28 7.8 ERP, EIRP MEASUREMENT .............................................................................................................. 45 7.9 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ................................................................. 49 7.10 FREQUENCY STABILITY ...................................................................................................................... 51 8 TEST SETUP PHOTO ............................................................................................................................ 56 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 57 Report No.: GTSL202012000202-2 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 57 4 Test Summary Test Item Section in CFR 47 Result RF Exposure (SAR) Part 1.1307 Part 2.1093 Pass* (Please refer to SAR Report) RF Output Power Part 2.1046 Part 27.50(c)(10)/(d)(4) Pass Peak-to-Average Ratio FCC Part 27.50(a) Pass Modulation Characteristics Part 2.1047 N/A 99% & -26 dB O…

Text truncated - open the document above for the full version.

Report No.: GTSL202012000202-2 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 28 of 57 7.6 MODULATION CHARACTERISTIC According to FCC § 2.1047(d), Part 27 there is no specific requirement for digital modulation, therefore modulation characteristic is not presented. 7.7 Out of band emission at antenna terminals Test Requirement: Part 27.53 Test Method: FCC part2.1051 Test setup: Test Procedure: 1 The RF output of the transceiver was connected to a spectrum analyzer through appropriate attenuation. 2 The resolution bandwidth of the spectrum analyzer was set at 1MHz, sufficient scans were taken to show the out of band Emissions if any up to 10th harmonic. 3 For the out of band: Set the RBW, VBW = 1MHz, Start=10MHz, Stop= 10th harmonic. 4 Band Edge Requirements: In the 1 MHz bands immediately outside and adjacent to the frequency block, a resolution bandwidth of at…

Text truncated - open the document above for the full version.
