2AXYP-OSW-34Smart Watch

Charge Cable X 1 Smart Watch X 1Welcome Guide X1 Please read this Guide carefully before using the product Product Overview WELCOME GUIDE * For safety issue, the product remains low capacity during shipping. Please fully charge the product before initial use! For the best experience we recommend using the updated oraimo Health App for iOS and Android. iOS 11.0 or above Android 6.0 or above OSW-34 oraimo Watch 3 Pro Home Button Full Touchscreen Wrist Strap Charging PortHeart Rate Sensor Setting Up Your Smart Watch Pair With Your Phone 1. Get ready with the oraimo Health App, scan the QR code on your watch or nd the oraimo Health App in one of these locations, depending on your device: 2. When the App is installed, open it and follow the instructions that help you create your account, or login to your existing account. 3. Your account asks for information such as height, weight, and gender to make various calculations and tailor your experience using the app. You can modify your information in oraimo Health – Account - User. 4. Long press the home button of the watch to turn it on, follow the onscreen instructions to setup the language, and get ready pairing with the phone. The Apple App Store for iPhone. The Google Play Store for Android phone. Scan the QR code to pair: Use oraimo Health APP to scan QR code Binding successfully done Binding... BT Call Before pairing your phone and the watch for the BT Call function, make sure the BT for call on the watch is switched on: Method 1: Press the home button in the main dial, tap the Phone menu item to switch on the BT for call on the watch. Device QR code If you can't pair successfully, try the following methods: 1. Make sure the BT permission is allowed for the app; 2. Make sure the watch is not connected with another phone; 3. Try turning off and on again the BT switch on your phone; 4. If none of these work, try rebooting your phone and the watch, and repeat the above steps again. After pairing with your phone, read through this guide to explore the various functions! Method 2: Swipe down from the main dial to enter the below interface, follow the picture to turn on the BT for call. In the BT list of the mobile system, connect to "oraimo Watch 3 Pro_Calling" and you can use the watch to make calls. In Android In iOS oraimo Watch 3 Pro_Callingoraimo Watch 3 Pro_Calling oraimo Watch 3 Pro_Calling oraimo Watch 3 Pro_Calling Getting To Know Your Smart Watch Wrist Placement For all-day wear, your watch should usually rest a nger’s width below your wrist bone and lay at, as you would normally wear a watch. Charge Your Watch Connect the metal contacts on the charging dock to those on the back of the device, then put them on a at surface. Connect the charging cradle to a power supply, the device's screen will light up and display the battery level. Please dry the port, metal contacts, and the device before charging. Using The Clock And Menus The home screen is a clock. From here you can swipe to see data about your steps, activity time, calories, heart rate, and functions like training modes, weather, message, music, etc. Power On/Off • When the watch is powered off, charge the watch or long press the home button for 3 seconds to power it on. • When the watch is turned on, press and hold the home button for 3 seconds. Choose Power Off and tap again to conrm. The watch vibrates and turns off. You can also power off from the “Settings” menu. (Settings – System Settings – Power Off) When there is something wrong on the watch, please press and hold the home button for more than 12 seconds to hard reset. Wake Up the Watch When you’re not using this product, the display is off. To wake it up: • Press the home button. • Turn your wrist towards you. This function, known as “Raise to Wake”, can be turned off in Settings – Raise to wake. You can also schedule when it’s activated during the day. 1. Make sure your device supports BT 5.3. Make sure your device’s software is or above iOS 11.0 or Android 6.0. 2. Restart BT and reconnect after 20 seconds. 3. Restart your phone. 4. Make sure your phone is not connected with other devices. 5. Make sure oraimo Health App is running in your phone’s system. To ensure accuracy of monitoring, please wear the smart watch tightly with a distance of at least one nger from the wrist bone. Place the optical monitoring sensor on the skin without any blockage. Trouble Shooting Can’t connect with BT. Can't monitor heart rate, oxygen, and pressure. Can’t find the watch through BT. Make sure your location services are enabled (GPS is working), the product has enough power, it’s not connected with another phone and is powered on, then keep it close to your phone. If you still can not nd it, please turn off your phone’s BT function and reconnect after 20 seconds. Can’t receive notifications after enabling it. Android phone: Make sure the product is connected with your phone. Allow oraimo Health App to access notications. If any security App installed, add oraimo Health to trust list. iPh: Make sure the product is connected with your phone. Reboot your phone and try to reconnect with the product. Is the product waterproof ? This product supports IP68 waterproof which allows the product to be held in water for a maximum of 30 minutes at a depth of 1 metre. You can wear it while washing your hands, having a cold shower or washing your car. Please do not wear it while diving or scuba diving. Do I need to connect BT all the time? Will my health and sleep data stored if not connected to the phone? Data will be kept in the watch for seven days. When it is reconnected to the phone, your health and sleep data will be synced automatically. Please remember to synchronize data with the phone in time to get maximized utility. Note: Call and message notications only work when BT is connected. Trouble Shooting Basic Product Specifications Display Screen 1.83''TFT240*284 BT Version V5.3 Battery Capacity 250mAh Battery Type Lithium polymer b…
