2AY37-WXHW02Baseus Milky Way Electric Bracket Wireless Charger

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. During the operation of device a distance of 15cm surrounding the device and 20 cm above the top surface of the device must be respected.

Shenzhen Times Innovation Technology Co., Ltd 1/1 Letter of Authorization Company: Shenzhen Times Innovation Technology Co., Ltd Address: 5th Floor, Building B, Baseus Intelligenece Park, No. 2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen Product Name: Baseus Milky Way Electric Bracket Wireless Charger Model Number: WXHW02 FCC Identifier: 2AY37-WXHW02 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Anna Bai Date: 2021-11-05 Title: Certified Engineer Assistant Signature of applicant:

Shenzhen Times Innovation Technology Co., Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-11-05 Subject: Request for Confidentiality FCC ID: 2AY37-WXHW02 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up No ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Anna Bai Title: Certified Engineer Assistant

Size:10*20mm M/N: WXHW02 FCC ID: 2AY37-WXHW02 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

antenna location

、 FCC ID: 2AY37-WXHW02 RF Exposure Evaluation 1 Measuring Standard KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 D01v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 、 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 D01 v03r01.. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Test Results: The EUT does comply with KDB680106 D01 v03r01 section 5(b). (1) Power transfer frequency is less than 1MHz. (Conform) (2) Output power from each primary coil is less than or equal to 15 watts. (Conform) (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. (Conform) (4) Client device is placed directly in contact with the transmitter. (Conform) (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (Conform) (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. (Conform) 、 6 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 24 2021 June. 23 2022 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 24 2021 June. 23 2022 7 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.74 0.74 0.76 0.75 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.75 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.110-0.205 0.12 0.14 0.15 0.14 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.110-0.205 0.15 1.63 Test Engineer: Reviewer: 、 8 Test Set-up Photo Please see setup photos. ------End------

FCC Test Report Report No: FCS202111002W01 Issued for Applicant: Shenzhen Times Innovation Technology Co., Ltd Address: 5th Floor, Building B, Baseus Intelligenece Park, No. 2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen Product Name:Baseus Milky Way Electric Bracket Wireless Charger Brand Name:Baseus Model Name:WXHW02 Series Model:N/A FCC ID:2AY37-WXHW02 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page2of25ReportNo.:FCS202111002W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name......................: Shenzhen Times Innovation Technology Co., Ltd Address ...................................... : 5th Floor, Building B, Baseus Intelligenece Park, No. 2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen Manufacture's Name................: Shenzhen Times Innovation Technology Co., Ltd Address......................................: 5th Floor, Buildin g B, Baseus Intelligenece Park, No. 2008, Xuegang Rd, Gangtou Community, Bantian Street, Longgang District, Shenzhen Product Description Product Name...........................: Baseus Milky Way Electric Bracket Wireless Charger Brand Name ............................. : Baseus Model Name..............................: WXHW02 Series Model .............................. : N/A Test Standards .......................... : FCC Rules and Regulations Part 15 Subpart C, Sec tion 209 Test Procedure..........................: ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revis ion of the document.. Date of Test..................................: Date (s) of performance of tests.: 02 Nov. 2021 ~ 03 Nov. 2021 Date of Issue.................................: 03 Nov. 2021 Test Result.....................................: Pass Tested by: (Scott Shen) Reviewed by : (Duke Qian) Approved by: (Kait Chen) Page3of25ReportNo.:FCS202111002W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of ContentsPage 1. SUMMARY OF TEST RESULTS.......................................................................................................5 1.1 TEST FACTORY...........................................................................................................................6 1.2 MEASUREMENT UNCERTAINTY.............................................................................................6 2. GENERAL INFORMATION ................................................................................................................. 7 2.1 GENERAL DESCRIPTION OF THE EUT ................................................................................. 7 2.2 DESCRIPTION OF THE TEST MODES ................................................................................... 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS .................. 10 2.4 EQUIPMENTS LIST ................................................................................................................... 11 3 CONDUCTED EMISSION MEASUREMENT ................................................................................. 12 3.1 LIMIT ............................................................................................................................................. 12 3.2 TEST PROCEDURE .................................................................................................................. 12 3.3 TEST SETUP .............................................................................................................................. 13 3.4 TEST RESULTS ......................................................................................................................... 14 4. RADIATED EMISSION MEASUREMENT......................................................................................16 4.1 LIMIT.............................................................................................................................................16 4.2 TEST PROCEDURE..................................................................................................................17 4.3 TEST SETUP..............................................................................................................................18 4.4 TEST RESULTS.........................................................................................................................19 5. 20 DB BANDWIDTH TEST ............................................................................................................... 23 5.1 LIMIT ............................................................................................................................................. 23 5.2 TEST PROCEDURE .................................................................................................................. 23 5.3 TEST SETUP .............................................................................................................................. 23 5.4 TEST RESULTS ......................................................................................................................... 24 6. ANTENNA REQUIREMENT .............................................…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emissions MPE
