2AYCW-MALLYA2NNsmart cap for pen injector

3.1. Press and hold down Mallya D2 dose dialing button. Watch as the dose counter returns to 0. The 0 must line up with the pen dose pointer. During a dose injection, Mallya D2 ’s light is green. NOTE: Do not pause during the injection, you may experience harm due to miscalculation of doses. 3.2. At the end of injection, keep the pressure on the button and the needle in your skin until the green rapid flashing turns off (6 seconds) (Figure S). Indication for use The Mallya ®D2 Injection Pen Adapter is indicated for the capture and wireless transmission of dosing information of compatible reusable and disposable pen injectors. Device features Mallya D2 is able to : • be assembled with Novo Nordisk ® pen injector designed for diabetes treatment, • record the amount of dose increments injected by the pen, • record the timestamp (date & time) of each injection, • transmit information relating to dose, time, and date of each injection to a mobile app on a smartphone, when the device is connected to it, using Bluetooth ® technology. Mallya D2 x1 USB cable x1 User instructions x1 NOTE: the USB charger is not included. Use a Class II USB wall charger, with output 5V and at least 500mA (Figure B). 5V ≥ 500mA Novo Nordisk ® pen injector Mallya D2 Download a connectable App with Mallya D2 Preliminary Check Attach Mallya D2 to your pen Dose Selection Lock Mallya D2 to your pen Dose Injection Wake up your Mallya D2 Pair your Mallya D2 Mallya D2 is turned off when it is shipped. You will need to wake it up and make sure it is charged enough before use. NOTE: You will also need to wake up Mallya D2 after it has been reset, because resetting Mallya D2 will turn it off. 4.1. Connect Mallya D2 to the supplied USB cable and connect the cable to a powered USB wall charger (Figure J). This will wake up the device. Mallya D2 light signal will turn blue indicating that the device is in pairing mode but not yet paired. 4.2. Charge the battery for at least 2 hours for a full charge (Figure J). The blue light will disappear when fully charged. 4.3. Unplug Mallya D2 from the USB cable (Figure K) and then unplug the wall charger. 5.1. Pair Mallya D2 by following the guidance in the App to : • Turn on your smartphone’s Bluetooth ® (if not already on). • Pair the Mallya D2 with the App NOTE: Check that your Mallya D2 light signal is blue and keep Mallya D2 within 4 inches of the smartphone during pairing (Figure L). At the end of the pairing step, you may notice the light signal turn green and then turn off (Figure M). Mallya D2 is now is in standby mode. Getting to know Mallya D2 and the penIntended use How to setup your Mallya D2 Package contents Before you can use your Mallya D2 , you will need to pair it with a mobile application on your smartphone. 1.1. Please refer to Mallya D2 internet website https://my-mallya.com/ us/diabetes, or by scanning this QR Code (Figure E). 1.2. Download the application from Google Play™ (Android) or the App Store ® (Apple) (Figure F). 2.1. Hold the pen with one hand, keeping the dose button accessible, and protect the needle with the pen cap (if already mounted). 2.2. With your other hand, hold Mallya D2 by the body (Figure G). 2.3. Align the notch of Mallya D2 with the pen dose counter (Figure G). 2.4. Insert Mallya D2 fully over the pen dose button until you see the green indicator for correct assembly (Figure H). 3.1. Lock Mallya D2 by pushing the locking ring until you hear a “click” and you see the green indicator for correct locking (Figure I). < 10 cm < 4 inches Injecting a dose with Mallya D2 attached to your pen 1 1 45 2 2 3 3 PN : 0373707 Injection button Dose selector Dose pointer Dose counter Dose dialing button Micro-USB port (charging) Body Light signal Notch All exterior plastic parts to the device constitutes its applied part Error: the solid red light will come on when Mallya D2 is in an error state and needs to be reset. In this state, Mallya D2 is not ready to record injections. Follow the instructions in the “Resetting Mallya D2 ” section on the back side of these instructions to reset Mallya D2 . If the problem persists, contact the Support service. The red signal is not an alarm at meaning of IEC 60601-1-8. Red Solid (Figure V) Mallya D2 ’s battery is low. Mallya D2 's light is orange during injections if the battery is low. Charge your Mallya D2 following the instructions in the “Charging Mallya D2 ” section. Do not give an injection with Mallya D2 while it is charging. Orange Solid (Figure U) Device is lost. Make sure the device is correctly assembled and correctly locked (see Preliminary check in the section “Injecting a dose with Mallya D2 attached to your pen“). Align the pen dose pointer with the number 0 and press the dose button for 2 seconds until Mallya D2 ’s light turns green. Orange Rapid Flashing (Figure T) TroubleshootingCharging Mallya D2 After a full charge, if you use Mallya D2 every day, it will only need recharging once every 2 weeks. If you use it once a week, it will only need recharging once a month. When the battery is low, the orange light will show (Figure W). Charge Mallya D2 by connecting it to a powered USB wall charger (not supplied) using the supplied USB cable (Figure X). Do not use any other cable. Please connect the supplied USB cable to the USB port of a power adapter (IEC / UL 60950-1 or IEC / UL 62368-1 certified with CE or UL marking) suitable for your region (Figure X). The light signal will slowly flash green when Mallya D2 is charging. Do not give an injection with Mallya D2 when it is charging. NOTE: Let the device charge for at least 2 hours for a full charge (Figure Y). The green flashing light will disappear when fully charged. 6 s USER MANUAL PN : 0274580 Unsure if the dose is delivered TURN OVER: • Transfer • Reset • Indicator Lights • Cleaning IFU_MAL_D2_FDA_EN_1.2_2025_09 0574573 Clinical environment The Mallya D2 device is intended to be used by patients in the same use environment as their compatible pen inject…

Text truncated - open the document above for the full version.

V01222025 Certification for Designating a U.S. Agent for Service of Process In compliance with section 2.911(d)(7), all applicants are required to appoint a U.S.-based contact to serve as their agent for service of process. This requirement applies to both domestic and foreign applicants. Entities located within the United States are permitted to designate themselves as their own agent for this purpose. Regardless of the applicant’s status, the designation of the U.S. agent must be included as an attachment to the equipment authorization application. The written certification must adhere to the following requirements: 1. It must bear the signatures of both the applicant and the designated U.S. agent for service of process, provided the agent is a separate entity from the applicant. 2. It must clearly state the applicant’s consent and confirm the agent’s obligation to accept service of process on the applicant’s behalf. 3. It must include a physical address and email address located in the United States for the designated agent. 4. It must acknowledge that the applicant will maintain the designated agent’s role for at least one year after ceasing all marketing and importation activities or upon the conclusion of any FCC-related proceedings involving the equipment. Key Details Regarding the U.S. Agent for Service of Process: ● The agent cannot be a Telecommunication Certification Body (TCB) or have affiliations with one (e.g., the agent cannot work for or be owned by a TCB or a related company). ● The agent must not be an FCC-recognized testing laboratory or have affiliations with one (e.g., the agent cannot work for or be owned by a test lab or a related company). ● The agent may be an individual or a company entity. ● The designated agent entity must have a physical U.S. address and phone number. ● It is recommended that the agent possess a Federal Registration Number (FRN), and including the FRN in the agent letter is considered best practice. ● The agent designation letter may be general for the grantee and is not required to be FCC ID-specific. If there is a change in the U.S. Agent for Service of Process for devices that are still being marketed or have ceased marketing for less than one year, the TCB must request the FCC to place the application in Audit Mode for every relevant TC Number. The updated agent letter will then need to supersede the previous version. Important Note: The role of the U.S. Agent for Service of Process should not be confused with the authorized agent responsible for signing the FCC Form 731, cover letters included in the application, or the agent who interacts directly with the TCB. Note for Attestation Letter: Print the attestation letter onto the manufacturer's corporate letterhead prior to submission. V01222025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 United States Date: 30/10/2025 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID: 2AYCW-MALLYA2NN BIOCORP certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. BIOCORP accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: Name Americas Compliance consulting, LLC dba iCertifi FCC FRN 0033399411 Address 2445 NE Division Street, Suite 202 Bend, OR 97703 United States Contact Person Paul Preston Telephone +1-866-885-4575 Email [email protected] Sincerely, BIOCORP Americas Compliance Consulting LLC dba iCertifi FRN: 0030249189 0033399411 Contact name Alexia GARIN Paul Preston Title : Quality & Regulatory Affairs Director President/CEO Signature

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 10/30/2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AYCW-MALLYA2NN BIOCORP (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. BIOCORP (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, BIOCORP Alexia GARIN Signature: Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 10/30/2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AYCW-MALLYA2NN BIOCORP (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Link: List of Equipment and Services Covered By Section 2 of The Secure Networks Act Sincerely, BIOCORP Alexia GARIN Signature:

Letter of Agency 10/30/2025 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Timco Engineering, Inc. 13146 NW 86th Drive, Suite 400 Alachua, FL 32615- United States We, the undersigned BIOCORP hereby authorizes Majid MOURZAGH, LCIE SUD EST, to act on our behalf in all matters relating to all processes required for FCC certification of our devices. Any and all acts carried out by the above agent on our behalf shall have the same effects as acts of our own. This authorization is valid until: March 31, 2026 If you have any questions regarding this authorization, let us know please. Sincerely, Alexia GARIN Signature:

COVER LETTER BIOCORP – CND2 FCC ID: 2AYCW-MALLYA2NN 10/30/2025 This report concerns: File : Original Grant SubPart: SubPart 15C Equipment type : Injection Pen Adapter Request issue of grant : __ Immediately upon completion of review ___ Defer grant per 47 CFR 0.457(d)(1)(ii) until ____ date _____. Company Name agrees to notify the Commission by _____date_____ of the intended date of announcement of the product so that the grant can be issued on that date. Confidentiality of grant : __ Applicant requests the existence of this grant to be kept confidential until ____date____. The announcement of this product before this date via freedom of information would be detrimental to Company Name, and therefore must be considered a business secret. Public announcement of this product will not be made prior to this date. (Max. 60 days after grant issued). Limits used : (check one) CISPR 22: ______ Part15: ______ Measurement procedure used is ANSI C63.4-2014 / C63.10-2013 unless another is specified. Other test procedure : ____________________________________________________ Application for verification Applicant for this device Prepared by : Majid MOURZAGH LCIE Sud-Est ZI Centr’Alp – 170, rue de Chatagnon 38430 MOIRANS - France Ph. : 33 4 76 07 36 36 Fax : 33 4 76 55 90 88 e-mail : [email protected] FRN : 0005-0971-18 Alexia GARIN BIOCORP ZI de Lavaur - La Bechade 63500 - ISSOIRE - France Ph. : +33 +33645620362 Fax : +33 / e-mail: [email protected] FRN : 0030249189 Signature : Signature : *Not to be filed with Equipment Authorization Branch of FCC unless requested Report format prepared by the Information Technology Industry Council (ITI) ESC-5 and reviewed by FCC staff in 1994

CONFIDENTIALITY REQUEST To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Timco Engineering, Inc. 13146 NW 86th Drive, Suite 400 Alachua, FL 32615- United States 10/30/2025 Subject: Confidentiality request FCC ID: 2AYCW-MALLYA2NN BIOCORP requests, pursuant to 47CFR 0.457 and 0.459, post grant confidentiality for portions of the material contained in this application. The following document regarding this submission for FCC ID: 2AYCW-MALLYA2NN shall be kept confidential: LONG-TERM CONFIDENTIALITY: 1. Block Diagram description of the equipment (file: Block Diagram - 2AYCW-MALLYA2NN.pdf) 2. Schematic Diagram of the equipment (file: Schematic -2AYCW-MALLYA2NN.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Responsible party: Alexia GARIN Title: Quality & Regulatory Affairs Director Signature:

LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS – France Page 1/2 EXTERNAL PHOTOS OF EQUIPMENT FCCID: 2AYCW-MALLYA2NN LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS – France Page 2/2

LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE Page 1/2 PRODUCT LABELING FCCID: 2AYCW-MALLYA2NN LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE Page 2/2 Id label Location on packaging

LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS – France Page 1/2 INTERNAL PHOTOS OF EQUIPMENT FCCID: 2AYCW-MALLYA2NN RF ANTENNA LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS – France Page 2/2

LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE GENERAL INFORMATION FCCID: 2AYCW-MALLYA2NN 1.1. Product description • record the amount of dose increments injected by the pen, • record the timestamp (date & time) of each injection, • transmit information relating to dose, time, and date of each injection to a mobile app on asmartphone, when the device is connected to it, using Bluetooth® technology. Communication technology Technologie de communication Bluetooth communication between MallyaD2 and the smartphone Overall dimensions 0,3 mm diameter & 46,6 mm height / 1.18 in diameter & 1.81 in height Charging time & autonomy MallyaD2 battery is rechargeable through USB connection (USB charging cable). Charging time (full charge): up to 2 hours Autonomy: 2 weeks for daily injection(s) / 4 weeks for weekly injection Weight Total weight : 13 g / 0.46 oz Usage conditions Temperature: +2°C to +35°C / +36°F to +95°F Atmospheric pressure: 700 hPa to 1060 hPa Relative humidity: 15% to 90% LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE 1.2. Tested System Details LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS - FRANCE 1.3. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4 or/and ANSI C63.10, FCC Part 15 SubPart 15C. Radiated testing was performed at an antenna to EUT distance of 10 meters. During testing, all equipment’s and cables were moved relative to each other in order to identify the worst case set-up. 1.4. Test facility Tests have been performed: September 23, 2025 to October 22, 2025 This test facility has been fully described in a report and accepted by FCC as compliant with the radiated and AC line conducted test site criteria in ANSI C63.4 or/and ANSI C63.10. This test facility has also been accredited by COFRAC (French accreditation authority for European Union test lab accreditation organization) according to NF EN ISO/IEC 17025, as compliant with test site criteria and competence in 47 CFR Part 15/ANSI C63.4 and EN55032/CISPR32 norms for 89/336/EEC European EMC Directive application. All pertinent data for this test facility remains unchanged.

LCIE SUD EST Laboratoire de Moirans Z.I. Centr’Alp 170, Rue de Chatagnon 38430 MOIRANS – FRANCE RF Exposure Considerations for FCC ID: 2AYCW-MALLYA2NN Per FCC KDB 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. Minimum test separation distance: 5 mm Step a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm The 1-g and 10-g SAR test exclusion thresholds are determined by the following: (max푝표푤푒푟표푓 푐ℎ푎푛푛푒푙 ( 푚푊 ) ) (min푡푒푠푡푠푒푝푎푟푎푡푖표푛 푑푖푠푡푎푛푐푒 ( 푚푚 ) ) × √ 푓 ( 퐺퐻푧 ) ≤3.0 푓표푟 1−푔 푆퐴푅 표푟 ≤7.5 푓표푟 10−푔 푒푥푡푟푒푚푖푡푦 푆퐴푅 Where: ▪ f(GHz) is the RF channel transmit frequency in GHz ▪ Power and distance are rounded to the nearest mW and mm before calculation31 ▪ The result is rounded to one decimal place for comparison ▪ The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. (dBm) (mW) Min 2.402 -0.79 0.83 5 0.26 3 7.5 Exempt from SAR Mid 2.442 -0.99 0.80 5 0.25 3 7.5 Exempt from SAR Max 2.480 -1.14 0.77 5 0.24 3 7.5 Exempt from SAR Limit for 10-g extremity SAR Verdict Maximum source-based time averaged conducted output power or EIRP (worst case) including tune-up tolerance Channel Frequency (GHz) Minimum separation distance (mm) Result of Eq. 1 Limit for 1-g SAR Conclusion: Therefore our device complies with FCC’s RF radiation exposure limits for general population without SAR evaluation.
