2AYGCARG-B39Smart Band

Quick Start Guide ARG-B39 1 1. Charging Connect the metal contacts on the charging dock to those on the back of the device, then put them on a flat surface. Connect the charging dock to a power supply, the device's screen will light up and display the battery level. • The device will power on automatically upon charging. • The charging dock is not water resistant. Wipe the port, metal contacts, and the device dry during charging. Heart rate sensor Button Press and hold the button to power on, power off, or restart the device. Screen Charging port Quick Start Guide 2. Downloading Health To download and install the Health app, scan the QR code on the right, or search for Health in AppGallery or other app stores. 3. Pairing your device with your phone 4. Getting help From the device list in the Health app, select the device and follow the onscreen instructions to complete the pairing. View the online help in the Health app for more information about connection and functions, as well as usage tips. This product is not designed to be a medical device, and is not intended to diagnose, treat, cure or prevent any disease. All data and measurements should be used for personal reference only. If you experience skin discomfort when wearing the device, take it off and consult a doctor. Quick release 2 Copyright © Honor Device Co., Ltd 2021. All rights reserved. THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE ANY KIND OF WARRANTIES. Trademarks and Permissions The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of this mark by Honor Device Co., Ltd. is under license. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Privacy Policy To better understand how we protect your personal information, please see the privacy policy at https://www.hihonor.com/privacy-policy/worldwide/. Blasting Caps and Areas Turn off your mobile phone or wireless device when in a blasting area or in areas posted turn off "two-way radios" or "electronic devices" to avoid interfering with blasting operations. Areas with flammables and explosives Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols. Do not store or transport the device in containers with flammable liquids, gases, or explosives. Operation and safety • Using an unapproved or incompatible power adapter, charger or battery may cause fire, explosion or other hazards. • Ideal temperatures are -10°C to +45°C. • Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information. • Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. • Keep the device and the battery away from excessive heat and direct sunlight. Do not place them on or in heating devices, such as microwave ovens, stoves, or radiators. • Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving. • To prevent damage to your device's parts or internal circuits, do not use it in dusty, smoky, damp or dirty environments 3 or near magnetic fields. • Do not use, store or transport the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. • Dispose of this device, the battery, and accessories according to local regulations. They should not be disposed of in normal household waste.Improper battery use may lead to fire, explosion, or other hazards. • The device has undergone testing and has demonstrated water and dust resistance in certain environments. • The device has a built-in, non-removable battery, do not attempt to remove the battery, otherwise the device may be damaged. • If the battery leaks, ensure that the electrolyte does not make direct contact with your skin or eyes. If the electrolyte touches your skin or splashes into your eyes, immediately flush with clean water and consult a doctor. • When charging the device, make sure the power adapter is plugged into a socket near the devices and is easily accessible. • Unplug the charger from electrical outlets and the device when not in use. • Adult supervision is advised if children are to use or come into contact with this product. • Please consult your doctor and the device manufacturer to determine if operation of your device may interfere with the operation of your medical device. • Switch off your wireless device when requested to do so in hospitals, clinics or health care facilities. These requests are designed to prevent possible interference with sensitive medical equipment. • Switch off your wireless device whenever you are instructed to do so by airport or airline staff. Consult the airline staff about the use of wireless devices on board the aircraft, if your device offers a ‘flight mode’ this must be enabled prior to boarding an aircraft. • Ensure that the power adapter meets the requirements of Clause 2.5 in IEC60950-1/EN60950-1/UL60950-1 and has been tested and approved according to national or local standards. Disposal and recycling information The crossed-out wheeled-bin symbol on your product, battery, literature or packaging reminds you that all electronic products and batteries must be taken to separate waste collection points at the end of their working lives; they must not be disposed of in the normal waste stream with household garbage. It is the responsibility of the user …

Text truncated - open the document above for the full version.

18_Confidentiality Letter V1.0 Honor Device Co., Ltd. Federal Communications Commission 2021-02-18 Oakland Mills Road Columbia MD 21046 Su bject: Request for Confidentiality FCC ID: 2AYGCARG-B39 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Sch ematic Diagram Block Diagram Operational Description Bom List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2021-08-15 External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Bes t Regards 18_Confidentiality Letter V1.0 Liming Certification Manager Honor Device Co., Ltd. E- mail: [email protected] Tel: 8613760231984 Fax: NA

23_Electronic Label Letter V1.0 HONOR Honor Device Co., Ltd. Federal Communications Commission 2021-02-23 Oakland Mills Road Columbia MD 21046 Subject: Electronic Label Letter FCC ID: 2AYGCARG-B39 To Whom It May Concern: Pursuant to the provisions of KDB 784748 D02 e labeling v02r01, we hereby provide the following statement: This device has an integrated display screen can present the required label information electronically (e-label) in lieu of a physical label or nameplate. The end user can access the electronic label with three steps. The information of electronic label is programmed by Honor, any can’t be modified by any third party. If have any questions concerning the above, please contact the undersigned. Best Regards Liming Certification Manager Honor Device Co., Ltd. E- mail: [email protected] Tel: 8613760231984 Fax: NA

01_External Photos V1.0 External Photos of ARG-B39 Front Back 01_External Photos V1.0 Left Side (including launch port, interface, etc.) 01_External Photos V1.0 Right Side (including launch port, interface, etc.)

03_Label and Label Location V1.0 Label and Label Location of ARG-B39 Please go to Settings > About > Regulatory Information on the device to view the E-label screen.

02_Internal Photos V1.0 Internal Photos of ARG-B39 Front Back

TEST REPORT No.B20N03097-EMC for Honor Device Co., Ltd. Smart Band Model Name：ARG-B39 With Hardware Version:LTAM230 Software Version:1.1.0.1 FCC ID: 2AYGCARG-B39 Issued Date: 2020-12-08 Designation Number: CN1210 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of SAICT. Test Laboratory: SAICT, Shenzhen Academy of Information and Communications Technology Building G, Shenzhen International Innovation Center, No.1006 Shennan Road, Futian District, Shenzhen, Guangdong, P. R. China 518000. Tel:+86(0)755-33322000, Fax:+86(0)755-33322001 Email: [email protected]. www.saict.ac.cn No.B20N03097-EMC ©Copyright. All rights reserved by SAICT. Page 2 of 31 REPORT HISTORY Report Number Revision Description Issue Date B20N03097-EMC Rev.0 1st edition 2020-12-08 Note: the latest revision of the test report supersedes all previous version. No.B20N03097-EMC ©Copyright. All rights reserved by SAICT. Page 3 of 31 CONTENTS 1. SUMMARY OF TEST REPORT ............................................................................................... 4 1.1. TEST ITEMS .......................................................................................................................... 4 1.2. TEST STANDARDS .............................................................................................................. 4 1.3. TEST RESULT ...................................................................................................................... 4 1.4. TESTING LOCATION ........................................................................................................... 4 1.5. PROJECT DATA ................................................................................................................... 4 1.6. SIGNATURE .......................................................................................................................... 4 2. CLIENTINFORMATION ............................................................................................................ 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDERTEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT ................................................................................ 6 3.3. INTERNAL IDENTIFICATION OF AE ................................................................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 7 3.5. GENERAL DESCRIPTION ................................................................................................... 8 4. REFERENCE DOCUMENTS .................................................................................................... 9 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 9 5. LABORATORY ENVIRONMENT ............................................................................................ 10 6. SUMMARY OF TEST RESULTS ............................................................................................ 11 6.1. TESTING ENVIRONMENT ................................................................................................. 11 6.2. SUMMARY OF MEASUREMENT RESULTS ..................................................................... 11 6.3. STATEMENT ....................................................................................................................... 11 7. MEASUREMENT UNCERTAINTY ......................................................................................... 12 8. TEST FACILITIES UTILIZED ................................................................................................. 12 9. TEST ACCESSORY UTILIZED .............................................................................................. 12 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 13 A.1 RADIATED EMISSION (§15.109(A)) ...................................................................................... 13 A.2 CONDUCTED EMISSION (§15.107(A)) ................................................................................. 22 No.B20N03097-EMC ©Copyright. All rights reserved by SAICT. Page 5 of 31 2. ClientInformation 2.1. Applicant Information Company Name: Honor Device Co., Ltd. Address: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, Guangdong, China 2.2. Manufacturer Information Company Name: Honor Device Co., Ltd. Address: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, Guangdong, China No.B20N03097-EMC ©Copyright. All rights reserved by SAICT. Page 6 of 31 3. Equipment UnderTest (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Smart Band Model Name ARG-B39 FCC ID 2AYGCARG-B39 Antenna Type Internal Antenna Condition of EUT as received No obvious damage in appearance Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Shenzhen Academy of Information and Communications Technology. 3.2. Internal Identification of EUT EUT ID* SN or IMEI HW Version SW Version Receive Date UT01aa 189E2C3A9C91 LTAM230 1.1.0.1 2020-12-01 UT03aa 2CC54603681D LTAM230 1.1.0.1 2020-12-01 UT05aa 2CC546036A07 LTAM230 1.1.0.1 2020-12-01 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE AE ID* Description AE1 Li-ion Battery AE2 Charge AE3 Charging dock AE1-1 Model HB351731EFW Manufactur…

Text truncated - open the document above for the full version.

Test Setup Photos 1. Radiated Emissions (Part 15B Bluetooth ,30MHz-1GHz) 2. Radiated Emissions (Part 15B Bluetooth ,1GHz-18GHz) 3. Radiated Emissions (Part 15C, 9kHz-30MHz) 4. Radiated Emissions (Part 15C,30MHz-1GHz) 5. Radiated Emissions (Part 15C, 1GHz -18GHz) 6. Radiated Emissions (Part 15C, 18GHz -26.5GHz) 7. Conducted Emission (Part 15B，Bluetooth) 8. Conducted Emission (Part 15C，Bluetooth)
