2AYGCVNA-LX3Smart Phone

Quick Start Guide VNA-LX2 VNA-LX3 Know Your Device Before using the device, familiarize yourself with its basic operations. •To power on your device, press and hold the power button until the screen turns on. •To power off your device, press and hold the power button, and then touch . •To restart your device, press and hold the power button, and then touch . •Press and hold the power button for 8 or more seconds to force restart your device. Volume buttonPower button Micro-USB portHeadset jack Card slot 1 Getting Started •Be careful not to scratch your device or hurt yourself when using the eject pin. •Store the eject pin out of the reach of children to prevent accidental swallowing or injury. •Do not use cut or modified SIM or microSD cards with your device as these may not be recognized and could damage the card tray (slot). •If your SIM card does not match your device, please contact your carrier. Follow the instructions in the following figures to set up your device. Please use the eject pin included. Ensure that the card is correctly aligned and that the card tray is level when you insert it into your device. Single-SIM card: Dual-SIM card: SIM Card Management Select the default mobile data card and calling card as needed. For details, check out the pre-installed Tips app. 2 •4G service depends on the support of your network carrier and its deployment of relevant services. Please contact your carrier to activate 4G service. •4G service may be unavailable in certain areas due to network interference. •If this guide is inconsistent with the description on the official website, the latter prevails. For More Information If you encounter any problems while using your device, you can obtain help from the following resources: •Visit https://www.hihonor.com to view device information and other information. •Visit https://www.hihonor.com/global/support/ for the most up-to-date contact information for your country or region. •Go to Settings and enter the following keywords in the search box to view the corresponding information. E.g. Legal information, Certification label. •Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can go to Settings and touch System > Regulatory information to view FCC ID. If your device does not have an FCC ID, the device has not been authorized for sale in the U.S. or its territories and may only be brought to the U.S. for the owner's personal use. Safety Information Please read all of the safety information carefully before using your device to ensure its safe and proper operation and to learn how to dispose of your device properly. Operation and safety • To prevent possible hearing damage, do not listen at high volume levels for long periods. •Using an unapproved or incompatible power adapter, charger, or battery may damage your device, shorten its lifespan, or cause a fire, explosion, or other hazards. 3 •Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to +45 °C. •Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. •Keep the device and the battery away from excessive heat and direct sunlight. Do not place them on or in heating devices, such as microwave ovens, stoves, or radiators. •Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving. •While flying in an aircraft or immediately before boarding, only use your device according to instructions provided. Use of a wireless device in an aircraft may disrupt wireless networks, present a hazard to aircraft operation, or be illegal. •In order to avoid damaging the internal circuit of the device or charger, do not use the device in a dusty, damp, or dirty place, or near a magnetic field. •When charging the device, make sure the power adapter is plugged into a socket near the devices and is easily accessible. •Unplug the charger from electrical outlets and the device when not in use. •Do not use, store or transport the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. •Keep the battery away from fire, and do not disassemble, modify, throw, or squeeze it. Do not insert foreign objects into it, submerge it in water or other liquids, or expose it to external force or pressure, as this may cause the battery to leak, overheat, catch fire, or even explode. •Dispose of this device, the battery, and accessories according to local regulations. They should not be disposed of in normal household waste. Improper 4 battery use may lead to fire, explosion, or other hazards. •This device contains a built-in battery. Do not attempt to replace the battery by yourself. Otherwise, the device may not run properly or it may damage the battery. For your personal safety and to ensure that your device runs properly, you are strongly advised to contact an authorized service center for a replacement. Disposal and Recycling Information The symbol on the product, battery, literature, or packaging means that the products and batteries should be taken to separate waste collection points designated by local authorities at the end of the lifespan. This will ensure that EEE waste is recycled and treated in a manner that conserves valuable materials and protects human health and the environment. For more information, please contact your local authorities, retailer, or household waste disposal service or visit the website https://www.hihonor.com/ . Reduction of hazardous substances This device and its electrical accessories comply with loca…

Text truncated - open the document above for the full version.

HONOR HONOR Confidential Authorization Letter Date:23 November 2022 Federal Communications Commission Oakland Mills Road Columbia MD 21046 To whom it may concern: We the undersigned, hereby authorize TÜV Rheinland (Shenzhen) Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by TÜV Rheinland (Shenzhen) Co., Ltd. on our behalf shall have the same affect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from Honor Device Co., Ltd. . Name, Surname: Liming Position/Title:Certification Manager Honor Device Co., Ltd. Address: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, China E-mail: [email protected] Tel: 0755-61886688

HONOR HONOR Confidential Confidentiality Letter Date: October 31, 2022 Federal Communications Commission Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2AYGCVNA-LX3 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure KDB Inquiry Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2023-5-1 External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards HONOR HONOR Confidential Name, Surname: Liming Position/Title:Certification Manager Honor Device Co., Ltd. Address: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, China E-mail: [email protected] Tel: 0755-61886688

HONOR HONOR Confidential Electronic Label Letter Date: November 31, 2022 Federal Communications Commission Oakland Mills Road Columbia MD 21046 Subject:Electronic Label Letter FCC ID:2AYGCVNA-LX3. To Whom It May Concern: Pursuant to the provisions of KDB 784748 D02 e labeling v02, we hereby provide the following statement: This device have a integrated display screen can present the required label information electronically (e-label) in lieu of a physical label or nameplate. The end user can access the electronic label with three steps. The information of electronic label is programmed by Honor, any can’t be modified by any third party. If have any questions concerning the above, please contact the undersigned. Best Regards Name, Surname: Liming Position/Title:Certification Manager Honor Device Co., Ltd. Address: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, China E-mail: [email protected] Tel: 0755-61886688

HONOR HONOR Confidential External Photos of VNA-LX3 HONOR HONOR Confidential Front: Back: HONOR HONOR Confidential Left Side: Right Side: Top: HONOR HONOR Confidential Bottom:

HONOR HONOR Confidential Label and Label Location of VNA-LX3 HONOR HONOR Confidential FCC ID electronic label: Settings-->System-->Regulatory information

HONOR HONOR Confidential Internal Photos of VNE-LX3 HONOR HONOR Confidential HONOR HONOR Confidential HONOR HONOR Confidential HONOR HONOR Confidential

©Copyright. All rights reserved by CTTL. TEST REPORT No. I22Z61923-EMC01 for Honor Device Co., Ltd. Smart Phone Model Name: VNA-LX3 FCC ID: 2AYGCVNA-LX3 with Hardware Version: HL2VNEM Software Version: VNA-LX3 6.1.0.29(C605E1R1P1) Issued Date: 2022-10-28 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I22Z61923-EMC01 ©Copyright. All rights reserved by CTTL. Page 2 of 47 REPORT HISTORY Report Number Revision Description Issue Date I22Z61923-EMC01 Rev.0 1 st edition 2022-10-28 Note: the latest revision of the test report supersedes all previous version. No.I22Z61923-EMC01 ©Copyright. All rights reserved by CTTL. Page 3 of 47 CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. INTRODUCTION & ACCREDITATION ................................................................................. 4 1.2. TESTING LOCATION ........................................................................................................... 4 1.3. TESTING ENVIRONMENT ................................................................................................... 4 1.4. PROJECT DATA ................................................................................................................... 4 1.5. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 ANNEX B: PERSONS INVOLVED IN THIS TESTING ................................................................. 47 No.I22Z61923-EMC01 ©Copyright. All rights reserved by CTTL. Page 4 of 47 1. Test Laboratory 1.1. Introduction & Accreditation Telecommunication Technology Labs, CAICT is an ISO/IEC 17025:2005 accredited test laboratory under NATIONAL VOLUNTARY LABORATORY ACCREDITATION PROGRAM (NVLAP) with lab code 600118-0, and is also an FCC accredited test laboratory (CN5017), and ISED accredited test laboratory (CN0066). The detail accreditation scope can be found on NVLAP website. 1.2. Testing Location CTTL (BDA) Address: No.18A, Kangding Street, Beijing Economic-Technology Development Area, Beijing, P. R. China 100176 1.3. Testing Environment Normal Temperature: 15-35ºC Relative Humidity: 20-75% 1.4. Project data Testing Start Date: 2022-10-26 Testing End Date: 2022-10-28 1.5. Signature Zhang Ying (Prepared this test report) An Hui (Reviewed this test report) Shi Suolan (Approved this test report) No.I22Z61923-EMC01 ©Copyright. All rights reserved by CTTL. Page 5 of 47 2. Client Information 2.1. Applicant Information Company Name: Honor Device Co., Ltd. Address /Post: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, China 2.2. Manufacturer Information Company Name: Honor Device Co., Ltd. Address /Post: Shum Yip Sky Park, No. 8089, Hongli West Road, Shenzhen, China No.I22Z61923-EMC01 ©Copyright. All rights reserved by CTTL. Page 6 of 47 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Smart Phone Model Name VNA-LX3 FCC ID 2AYGCVNA-LX3 Extreme vol. Limits 3.6VDC to 4.45VDC (Normal: 3.87VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of CTTL, Telecommunication Technology Labs, CAICT. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version UT03a 868254060009606/ 868254060025008 HL2VNEM VNA-LX3 6.1.0.29(C605E1R1P1) UT20a 868254060006966/ 868254060022369 HL2VNEM VNA-LX3 6.1.0.29(C605E1R1P1) UT11a 868254060008533/ 868254060023938 HL2VNEM VNA-LX3 6.1.0.29(C605E1R1P1) UT06a 868254060008129/ 868254060023524 HL2VNEM VNA-LX3 6.1.0.29(C605E1R1P1) *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Name…

Text truncated - open the document above for the full version.

RE L Charger RE L Charger RE H Charger RE L USB RE H USB CE Charger USB
