2AZ2X802B4Body composition scale

Unit Conversion Button 成品尺寸：92*92mm，展开尺寸：366*92mm，材质：100g铜版纸，4折页，风琴折，双面单黑印刷_20200423 SCALE FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interf erence , and (2) this device must accept any interference received,including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Howe ver, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or t elevision reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form. SCALE scale with damp cloth. p Scale Don't No user information is issued, and no user is identified（Turn on the Bluetooth of the mobile phone, use the mobile APP to establish a connection with the scale, and then measure again.） Multiple users identified in offline testing（During the offline test, the scale recognizes multiple users by weight, and cannot recognize a specific user parameter. Please connect to APP directly for online test） Questions? Contact Health 855-633-5600 SMART BODY SCALE INSERTING THE BATTERIES: Turn the scale over and place it on a flat surface. Open the battery cover and insert four AAA batteries. Make sure the positive and negative ends are facing the correct polarity directions marked in the battery compartment. Close the battery cover and wait until the digits "0.0" are shown on the LED display. BATTERY REPLACEMENT: In the event that the scale batteries need to be replaced (display shows “Lo”),remove the battery cover.Replace the old batteries with 4 new AAA alkaline batteries. Clean the battery contacts and also those of the device prior to battery installation. Ensure the batteries are installed correctly with regard to polarity,and the supply terminals are not to be short-circuited,then replace the battery cover again. Remove used batteries promptly. Dispose of the old batteries as per legal regulations. Do not attempt to open the scale or to remove any components. Servicing should be done by qualified technicians only.

Guangzhou Daxin Health Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AZ2X802B4 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, June 29, 2021 minjian Jiang / General Manager Guangzhou Daxin Health Technology Co., Ltd.

Guangzhou Daxin Health Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: June 29, 2021 SUBJECT: FCC Application for FCC ID: 2AZ2X802B4 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD.on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, minjian Jiang / General Manager Guangzhou Daxin Health Technology Co., Ltd.

External Photos

S N :B2010300102010000 1 Size: 75x45mm，材质: PVC+光膜 802B4 产品贴纸 编码规则（18位）： 9位 订单号码 （随订单变化） 4位流水号 0001-1000 (随订单数量变化) 内部脂肪秤编号 Model No.: eF-802B4 FCC ID: Rating: 4xAAA batteries,6V SN: B20103001020100001 Manufacturer: Guangzhou Daxin Health Technology Co., Ltd. Made in China (01)06947468500120 (11)2105(10)20103001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference , and (2) this device must accept any interference received, including interference that may cause undesired operation. 刀模设计： 日期： 平面设计： 审核者： 批准者： 1 CHECKED BY: APPROVED BY: DESIGNED BY: DESIGNED BY: TOLERANCE/公差 MATERIAL: SIZE: SCALE: QTY: VER: TUTKE: MODEL/NO: DATE: 日期： DATE: 日期： DATE: 日期： DATE: FILE NO.: V1.0 Model No.: eF-802B4 FCC ID: 2AZ2X802B4 Rating: 4xAAA batteries,6V SN: B20103001020100001 Manufacturer: Guangzhou Daxin Health Technology Co., Ltd. Made in China (01)06947468500120 (11)2105(10)20103001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference , and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos BT ANT

FCC ID: 2AZ2X802B4 Portable device According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: Mode Transmit Frequency (GHz) Max Conducted Power (dBm) tune up maximum power(dBm) Result calculation 1-g SAR GFSK 2.48 3.494 4.0 0.8 3 Conclusion: For the max result : 0.8 ≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Signature: Date: 2021.6.29 NAME AND TITLE (Please print or type): Lisa Wang/Manager COMPANY (Please print or type): Shenzhen EMTEK Co.,Ltd./Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China

Report No.ES210506019W Page 1 of 42 Ver.1.0 TEST REPORT Product Name ： Body Composition Scale Model Number ： ef-802B4 FCC ID ： 2AZ2X802B4 Prepared for : Guangzhou Daxin Health Technology Co., Ltd. Address : Room 810, No.1, Yichuang Street, Huangpu District, Guangzhou, Guangdong. Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES210506019W Date(s) of Tests : May 29, 2021 to June 03, 2021 Date of issue : June 17, 2021 Report No.ES210506019W Page 2 of 42 Ver.1.0 Table of Contents TEST REPORT ....................................................................................................................................................... 1 1 TEST RESULT CERTIFICATION .............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION ............................................................................................................. 4 3 SUMMARY OF TEST RESULT ................................................................................................................... 5 4 TEST METHODOLOGY ............................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .................................................................................................. 6 4.3 DESCRIPTION OF TEST MODES ........................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS ..................................................................................................... 8 5.1 FACILITIES .............................................................................................................................................. 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ......................................................................... 8 6 TEST SYSTEM UNCERTAINTY ................................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST .................................................................................................. 10 7.1 RADIO FREQUENCY TEST SETUP 1 .................................................................................................. 10 7.2 RADIO FREQUENCY TEST SETUP 2 .................................................................................................. 10 7.3 CONDUCTED EMISSION TEST SETUP .............................................................................................. 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM .............................................................. 13 7.5 SUPPORT EQUIPMENT ........................................................................................................................ 13 8 TEST REQUIREMENTS ............................................................................................................................. 14 8.1 DTS 6DB BANDWIDTH ........................................................................................................................ 14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ......................................................................... 17 8.3 MAXIMUM POWER SPECTRAL DENSITY ........................................................................................ 20 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ...................................... 23 8.5 RADIATED SPURIOUS EMISSION ...................................................................................................... 28 8.6 CONDUCTED EMISSIONS TEST ......................................................................................................... 40 8.7 ANTENNA APPLICATION ................................................................................................................... 41 Report No.ES210506019W Page 3 of 42 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Guangzhou Daxin Health Technology Co., Ltd. Address : Room 810, No.1, Yichuang Street, Huangpu District, Guangzhou, Guangdong. Manufacturer : Guangzhou Daxin Health Technology Co., Ltd. Address : Room 810, No.1, Yichuang Street, Huangpu District, Guangzhou, Guangdong. EUT : Body Composition Scale Model Name : ef-802B4 Trademark : N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : May 29, 2021 to June 03, 2021 Prepared by : Lance Li/Editor Reviewer : Sewen Guo /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No.ES210506019W Page 4 of 42 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product Body Composition Scale Model Number ef-802B4 Sample number: 1# Device Type Bluetooth V4.0 Data Rate : 1Mbps for GFSK modulation Modulation: GFSK Operating Frequency Range: 2402-2480MHz Number of Channels: 40 Channels Transmit Power Max: 3.494 dBm Antenna Type: PCB Antenna Antenna Gain: 0 dBi Power supply DC 6V( AAA 1.5V*4) Date of Received May 08, 2021 Note: for more details, please refer to the User’s manual of the EUT. Report No.ES210506019W Page 5 of 42 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.247(a)(2) DTS (6dB) Bandwidth PAS…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1.1. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz)
