2AZB9-QWCFC001HOTO Smart Kitchen Scale

20210407 陈姝彤 V1.0 器外文化 小猴智能厨房秤_使用说明书_中文版 105g 金东哑粉过哑油 小猴智能厨房秤6972140850330QWCFC00121001HLE0003CN 器外文化产品包装图纸 折叠方式 6 789 05 Specifications 3000g Maximum weighing capacity: 1g Minimum weighing capacity: 0.1-0.5g Measurement accuracy: g/ml /oz/l b:oz Measurement unit: AAA batteries × 3 Power source: approx. 8m Bluetooth transmission distance: Bluetooth 4.0 Wireless connectivity: 180s Automatic shutdown time: 10-40°C Operating temperature: -10°C~50°C Storage temperature: ≤90%RH Storage humidity: 181.8x168x26.8 Dimensions: Net weight:approx. 342g Android4.4/ios8.0 and above systems, supports Bluetooth 4.0 Equipment requirement: 5 03 How to Use 02 Screen Display Turning the product on/off Press the “switch/unit switching knob” for 3s when the product is on, the screen will go off automatically, and the product will enter shutdown status. If no operation is performed within 180s, the product will automatically shut down. Change metering units The product supports three metering units, and the default unit is “g”. Display Switch/unit switching knob Battery compartment cover 1 2 3 4 2 3 4 1 01 Product Overview Read this manual carefully before use, and retain it for future reference. Thank you for choosing HOTO Smart Kitchen Scale. Please do not use this product on a table having water. Rotate the battery compartment cover until the unlocking mark is aligned, and then remove the battery compartment cover, and put the battery in the battery compartment. 06 Warnings During use, the following prompt messages may be displayed on the main display area: Troubleshooting The display fails to reset after turning on Note: If the QR code on the manual cannot be scanned, search for the product name and add it. In addition, due to updates of the Mi Home/Xiaomi Home app, the actual operation may slightly differ from the preceding description. Please follow the prompts of the app. Connect to Mi Home App Scan the QR code on the right or search “Mi Home” in the APP store to download and install the Mi Home/ Xiaomi Home app. If installed, you will be directed to the device connection page. This product works with Mi Home. You can control it via the Mi Home app. “Works with Mijia” is for software verification only. Xiaomi is not responsible for the production, standard implementation, quality supervision and other aspects of the product and the company. Low battery voltage Initialization and zero calibration failure of device Cause Solution Please replace the battery Please put the device on a hard horizontal plane Message Flashing battery symbol Battery Weighing data Weighing unit Bluetooth connection status 模切： 折痕： This product cannot be used for trade weighing. Press the “switch/unit switching knob” when the product is off, and then a 3s countdown will be displayed on the screen. When 0.0g is displayed, weighing can be performed. Net weight and reset Press the“switch/unit switching knob”when the product is on, and then the screen will display“0000” and turn to“0 . 0 g”, and reset is successful at this time. Please put this product on a hard and flat horizontal plane before turning it on for use. You can wipe the product with wet cloth, but do not let any water enter the product; 04 Troubleshooting Maintenance Do not clean the product with corrosive lotion; Please do not place the product vertically during storage; Please remove the battery if you will not use this product for a long time. 12 456 Bluetooth/connection The product supports Bluetooth connection. When it is started, Bluetooth automatically turns on with the “ ” icon flashing. Then, open the Mi Home/Xiaomi Home app, click the “Add Device” button at upper right and connect devices as per the APP guide. When the product is connected, the “ ” icon will be always on. If the connection fails within 180s, Bluetooth will automatically turn off to save energy. Note: This product is a smart home appliance, a complete, non-independent module with a built-in complete Bluetooth module (CMIIT ID:2019DP6424). Performance standard:GB4706.1-2005,GB4806.5-2016 Note: Please do not turn off the product before it is completely turned on. It can be switched among “g”, “ml”, “oz” and “lb:oz” by rotating the “switch/unit switching knob”. When the Bluetooth is connected, real-time data synchronization can be kept between the software terminal and the hardware. In addition, the following additional functions are available at the software terminal: Pour-over coffee mode (Timer function is supported, so you can record the ratio of coffee powder to water, brewing time & water injection rate, and save every brewing strategy. Besides, auxiliary pour-over coffee study and daily brewing records are also supported.) Data notes (You can save and name weighing data; check, edit or delete saved data) Recipe generation (A recipe can be generated when you tick this function; picture adding & data editing, addition of comment & score, sharing of long recipe data picture, etc. are supported) D6000053 3 1 2 3 4 4 5 5 5 5 6 6 6 6 7 7 7 7 FCC WARNING:This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter…

Text truncated - open the document above for the full version.

EUTEXTERNALPHOTOGRAPHS ----------------Theend----------------

小猴智能厨房秤_国际版 器外文化 V1.4 20210422 陈姝彤 小猴智能厨房秤6974370800000 器外文化产品包装图纸 83.2mm 5.5mm 2.76mm 21001HLE0003GLQWCFC001 产品外线框 浅灰色镭雕 深灰色镭雕 浅灰色镭雕 图纸变更： 贴纸与 产品中心轴对齐，在旋钮对侧斜面处粘贴 中心轴

EUTINTERNALPHOTOGRAPHS ----------------Theend----------------

FCCID:2AZB9-QWCFC001 Portabledevice Accordingto§15.247(i)and§1.1307(b)(1),systemsoperatingundertheprovisionsofthissection shallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergy levelinexcessoftheCommission’sguidelines. AccordingtoKDB447498D01GeneralRFExposureGuidanceV06 The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparationdistances ≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance,mm)]* [√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz ； PoweranddistanceareroundedtothenearestmWandmmbeforecalculation ； Theresultisroundedtoonedecimalplaceforcomparison； Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis ≤ 50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. Weuse5mmasseparationdistancetocalculate. Themaxconductedpoweris8.82dBmincludingtune-uptoleranceis9dBm(7.943mW). [(max.powerofchannel,mw)/(min.testseparationdistance,mm)][√f(GHz)] =7.943/5*(√2.44)=2.482<3.0 Conclusion: Forthemaxresult:2.482≤3.0for1-gSARextremitySAR,NoSARisrequired.

Report No. ES210401029WPage 1 of 42Ver.1.0 TEST REPORT Product Name ：： HOTO Smart Kitchen Scale Model Number：：QWCFC001 FCC ID：：2AZB9-QWCFC001 Prepared for:Shanghai HOTO Technology Co., Ltd. Address:Room 502, Building 7A, M50 Park, No.50 Moganshan Road, Shanghai Prepared by:EMTEK (SHENZHEN) CO., LTD. Address:Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number:ES210401029W Date(s) of Tests:April 2, 2021 to April 16, 2021 Date of issue:April 17, 2021 Report No. ES210401029WPage 2 of 42Ver.1.0 Table of Contents 1 TEST RESULTCERTIFICATION......................................................................................................................................3 2 EUT TECHNICALDESCRIPTION....................................................................................................................................5 3 SUMMARYOFTEST RESULT...........................................................................................................................................6 4 TEST METHODOLOGY......................................................................................................................................................7 4.1 GENERAL DESCRIPTION OFAPPLIED STANDARDS..........................................................................7 4.2 MEASUREMENT EQUIPMENT USED......................................................................................................7 4.3 DESCRIPTION OF TEST MODES..............................................................................................................8 5 FACILITIESANDACCREDITATIONS.............................................................................................................................9 5.1 FACILITIES...................................................................................................................................................9 5.2 LABORATORYACCREDITATIONSAND LISTINGS.............................................................................. 9 6 TEST SYSTEM UNCERTAINTY......................................................................................................................................10 7 SETUPOF EQUIPMENT UNDER TEST.........................................................................................................................11 7.1 RADIO FREQUENCYTEST SETUP1......................................................................................................11 7.2 RADIO FREQUENCYTEST SETUP2......................................................................................................11 7.3 CONDUCTED EMISSION TEST SETUP..................................................................................................12 7.4 SUPPORT EQUIPMENT............................................................................................................................ 13 8 TEST REQUIREMENTS....................................................................................................................................................14 8.1 DTS 6DB BANDWIDTH............................................................................................................................14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER............................................................................17 8.3 MAXIMUM POWER SPECTRAL DENSITY...........................................................................................20 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS.........................................23 8.5 RADIATED SPURIOUS EMISSION..........................................................................................................28 8.6 CONDUCTED EMISSIONS TEST.............................................................................................................40 8.7 ANTENNAAPPLICATION........................................................................................................................41 Report No. ES210401029WPage 3 of 42Ver.1.0 1 TEST RESULT CERTIFICATION Applicant:Shanghai HOTO Technology Co., Ltd. Address:Room 502, Building 7A, M50 Park, No.50 Moganshan Road, Shanghai Manufacturer:Shanghai HOTO Technology Co., Ltd. Address:Room 502, Building 7A, M50 Park, No.50 Moganshan Road, Shanghai EUT:HOTO Smart Kitchen Scale Model Name:QWCFC001 Trademark:HOTO Measurement Procedure Used: APPLICABLE STANDARDS STANDARDTEST RESULT FCC47CFRPart2,SubpartJ FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data,data evaluation, test procedures, and equipment configurations shown in this report were made in accordancewith the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identifiedin this report Date of Test :April 2, 2021 to April 16, 2021 Prepared by : Mill Chen /Editor Reviewer : Sewen Guo / Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ES210401029WPage 4 of 42Ver.1.0 Modified History VersionReport No.Revision DateSummary Ver.1.0ES210401029W/Original Report Report No. ES210401029WPage 5 of 42Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product HOTO Smart Kitchen Scale Model Number QWCFC001 Sample Number 2# Device Type Bluetooth V5.0 Data Rate :GFSK modulation for BLE (1Mbps) Modulation:GFSK Operating Frequency Range:2402-2480MHz Number of Channels:40 Channels for Bluetooth DTS Transmit Power Max:8.82 dBm Antenna Type:PCB Antenna Antenna Gain:0.18 dBi Power supply: DC 4.5V Temperature Range:-10°C ~ +50°C Date of Received:April 2, 2021 Note: for more details, please refer to the User’s manual of the EUT. Report No. ES210401029WPage 6 of 42Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part ClauseTest ParameterVerdictRemark 15.247(a)(2)DTS (6dB) BandwidthPA…
