2AZB9-QWFGJ002HOTO Laser Level

A HOTO Laser Level 3*360 B C 扫码观看使用视 频百分百有礼 D 1 Warning! • Please read all safety warnings, instructions, illustrations, and prescriptions in this Manual carefully before using the product. • Before using the product, please carefully read the safety regulations and instructions for use. Your failure to follow the instructions for use provided in this Manual may cause the product to be damaged, the measurement precision to be affected, or personal injury to the user or others. • Do not disassemble or repair the product by yourself in any way. Illegal modification or change of the performance of the laser emitter of the product is strictly prohibited. • Please properly keep the product. Keep the product out of the reach of children, and also prevent it from being used by irrelevant persons. • Do not expose your own or other people's eyes or other body parts to the laser emitter of the product. Do not expose the highly reflective surface of any object to the laser emitter. • The electromagnetic radiation of the product may interfere with other equipment or devices. Do not use the product near aircraft or medical equipment. Do not use the product in inflammable or explosive environments. • Used batteries removed from the product cannot be discarded together with household garbage. So as the product if it is obsolete. Please discard used batteries and the obsolete product according to relevant national or local laws and regulations. • In case of product quality problems or any questions about the use of the product, please contact your local distributor or manufacturer in time. We will respond immediately. 01.Safety Instructions 2 Please carefully read this Manual before using the product and keep it properly. Thanks for using HOTO Laser Level 3*360. The product picture is for illustrative purposes only. Please refer to the actual product. The product can emit visible laser vertically or horizontally. It can be used to mark horizontal or vertical lines on the target surface. 02. Product Description Front laser emitter Front laser control button Top laser emitter Top laser control button Side laser emitter Side laser control button Switch/mode button Type-C charging port Battery indicator light Pulse indicator light 1 5 10 3 3 1 2 7 2 6 6 9 4 8 9 10 7 8 5 4 3 One quarter screw mouth Movement locking push button 11 12 11 12 4 Remote control Mode button Front laser control button Side laser control button Top laser control button 1 2 3 4 1 3 2 4 03.Fittings Remote control × 1, indexer stand × 1, target plate storage bag × 1, charging cable × 1 5 04.Instructions for Use Battery indicator and charging Charging Tips 75%<Battery≤100%: Four battery indicator lights are on 50%<Battery≤75%: Three battery indicator lights are on 25%<Battery≤50%: Two battery indicator lights are on Battery≤25%: One battery indicator light is on Please fully charge the product before using it for the first time. Charge the product by connecting it to a 5V USB adapter with a Type-C charger cable. Charging status: Battery≤25%: The first battery indicator light flashes 25%<Battery≤50%: The first battery indicator light is long on and the second one flashes 50%<Battery≤75%: The first and second battery indicator lights are long on and the third one flashes 75%<Battery≤100%: The first, second, and third battery indicator lights are long on and the fourth one flashes When the battery level reaches 100%, the indicator remains on for 3 minutes and then goes off. The product can be used normally during charging. Please buy a safe and compliant adapter. 6 Power on/off with the movement locked Power on/off Remark: Power off 1. Under the power-on mode, press and hold the "Switch/mode button" for 1.5 s to power off the product with the movement locked. The battery indicator light is off. 2. When the three laser emitters are turned off via the corresponding laser control buttons, the power indicator light automatically goes off after two hours of no operation. 1. The product cannot automatically calibrate for leveling when working with the movement locked. 2. When working with the movement locked, the currently illuminated laser flashes every 7 s to alert the user to the current non-leveling state. 3. Under the pulse mode, the pulse indicator light is on synchronously, the laser is a little darker than the full bright mode, and the product can be used with a laser receiver (supports 10K frequency). Power on 1. Under the power-off mode, press and hold the "Switch/mode button" for 1.5 s to power on the product with the movement locked. 2. All three lasers are on after the product is powered on, and the lasers can be powered off or back on by using the control buttons corresponding to the lasers. 3. Short press the "Switch/mode button" to switch the laser full bright mode and pulse mode. 7 Power on/off with the movement unlocked Toggle the "Movement locking push button" to unlock the movement Power on Power off Remark: 1. Toggle the "Movement locking push button" to unlock the movement and power on the product with the movement unlocked. 2. All three lasers are on after the product is powered on, and the lasers can be powered off or back on by using the control buttons corresponding to the lasers. 3. Short press the "Switch/mode button" to switch the laser full bright mode and pulse mode. 1. Movement unlock & laser off: Press and hold the "Switch/mode button" for 1.5 s to turn off all the lasers currently working, but the power indicator light remains on as a reminder. 2. Movement lock & laser off: Toggle the "Movement locking push button" to lock the movement and enter the full shutdown state, laser and power indicator lights off. When working with the movement unlocked, if the product tilts over 3°±1°, i.e., beyond the automatic leveling angle, an alarm will be issued. 1. If all three lasers are off, they will flash until the product's automatic leveling angle returns to its normal range. 2. If there is a laser on, the current laser fl…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Shanghai HOTO Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-07-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AZB9-QWFGJ002 Shanghai HOTO Technology Co., Ltd. ("the applicant")certifies that the equipment for which authorization is sought is not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicantsignature) (Applicant printed name) Yong Zhang Rev 1/26/2023 Shanghai HOTO Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-07-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AZB9-QWFGJ002 Shanghai HOTO Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List(as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Yong Zhang

[Shanghai HOTO Technology Co., Ltd.] [Building 45, No.50 Moganshan Road, Shanghai, China.] Date: [2024-03-07] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: [2AZB9-QWFGJ002] FRN: [0030701106] US Agent – Attestation Statement / Part 2.911(d)(7) [ Shanghai HOTO Technology Co., Ltd.]certifies, that as of [2024-03-07], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: [2AZB9-QWFGJ002]. [Shanghai HOTO Technology Co., Ltd.], accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Shanghai HOTO Technology Co., Ltd.] for FCC ID: [2AZB9-QWFGJ002]. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: [Shanghai HOTO Technology Co., Ltd.] Designated Agent: FCC US Agent, LLC Company Representative: [Yong Zhang] Designated Agent Representative: Tim Payne Signature: Signature:

Rev 11/20/07 Shanghai HOTO Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AZB9-QWFGJ002 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit T ype File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Yong Zhang Shanghai HOTO Technology Co., Ltd.

Shanghai HOTO Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 03-07-2024 SUBJECT: FCC Application for FCC ID: 2AZB9-QWFGJ002 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Yong Zhang Shanghai HOTO Technology Co., Ltd.

Shanghai HOTO Technology Co., Ltd. Date: 03-07-2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AZB9-QWFGJ002 To Whom It May Concern: This letter is to ascertain that Shanghai HOTO Technology Co., Ltd. EUT：HOTO Laser Level 3*360 MODEL No.: QWFGJ002 Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Yong Zhang Contact information / address: Shanghai HOTO Technology Co., Ltd./Building 45, No.50 Moganshan Road, Shanghai, China.

Page 1 of 3 EXTERNAL PHOTOS Page 2 of 3 Page 3 of 3 ----- The End -----

12.53 7.07 5.78 7.84 11.30 3.47 6.45 34.52 Unit：mm 居中

Page 1 of 3 INTERNAL PHOTOS Page 2 of 3 433.92MHz Module 433.92MHz Antenna Page 3 of 3 ----- The End -----

FCC ID : 2AZB9-QWFGJ002 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500- 100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500- 100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. RF Exposure Information: The radiated output power of this device meets the limits of FCC/IC radio frequency exposure limits.This device should be operated with a minimum separation distance of 20cm (8 inches) between the equipment and a person's body. 11.2 Measurement Result 433.92MHz Antenna gain: -15.5 dBi Emission Level(dBuV/m) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 78.21 dBuV/m 0 0.07 0.000014 1 Note:

Testing Report Customer Name: Shanghai Qiwai Cultural Technology Co., Ltd Product Name: Remote Controller Antenna Sample Model: XHYKZB Reference Standard: GB/T 9410-2008; ANSI/IEEE Std 149- 1979 Issue Date: 2024.2.7 Version Version No. Date Description Formulate Approval A0 2024.2.7 For the first time, formulate 1.General Information 1.1 General information of testing institutions Name Yinghuada (Nanjing) Technology Co., Ltd Address 133 Jiangjun Avenue, Jiangning District, Nanjing City Tel 025-52262313 18913802852 E-mail [email protected] 1.2 Testing principle Multi-Probe OTA Measurement System 1.3 Test equipment Equipment Model No. Serial No. Manufacturer Calibration date Next calibration date 16 probe microwave chamber 3*3*2.5 RFI-LAB- RF -A00 SUNYIELD 2023.3.15 2024.3.14 Network Analyzer E5071C RFI-LAB- RF -A02 Agilent 2023.5.13 2024.5.12 1.4 Test environment Temperature 24.6°C Humidity 59%RH Pressure 100.19kPa 1.5 Statement (1) The test results in the report are only applicable to the tested samples and the tested samples work under the environment described in the report. (2) Any objection to this report shall be raised within 30 days after formal confirmation of the report. (3) This report is invalid if there is any evidence that the sample information provided is falsified. (4) The report is invalid without the signature of the auditor and approver. 2. Sample Information 2.1 Client information Name Shanghai Qiwai Cultural Technology Co., Ltd Address Contacts Tel E-mail 2.2 Description of EUT(S) Product Name Remote Controller Antenna Sample Model XHYKZB Test Item Antenna gain; Radiation pattern and efficiency Frequency Range 400MHz-480MHz Test Date 2024.2.7 Remark 2.3 EUT appearance 3.Test Results 3.1 Test standard Name Parameter Method Standard no. Mobile communication antenna Antenna gain Generic specification for antennas used in the mobile communications GB/T9410- 2008 Radiation pattern Antenna Radiation efficiency IEEE Standard Test Procedures for Antennas ANSI/IEEE Std 149-1979 Gain and directivity 3.2 Test uncertainty The uncertainty was calculated on the basis of the GUM published by ISO, using the inclusion factor of K=2 and the 95% confidence level to express the extended uncertainty. Item Uncertainty Antenna gain ±1dB Radiation efficiency ±10% 3.3 Test data 3.3.1 Typical free space efficiency and gain Frequency/MHz 400 410 420 430 440 450 460 470 480 Peak Gain/dB -16.7 -16.1 -15.9 -15.5 -17.0 -19.8 -23.4 -26.7 -28.1 Efficiency/% -25.1 -24 -23.1 -22.3 -23.5 -25.8 -29.0 -32.4 -34.6 3.3.2 Typical free space radiation pattern phi=90deg phi=0deg Theta=90deg

Report No. ENS2312220065W00801R Page 1 of 25 Ver.1.0 $印章$ TEST REPORT Product Name ： HOTO Laser Level 3*360 Model Number ： QWFGJ002 FCC ID ：2AZB9-QWFGJ002 Prepared for : Shanghai HOTO Technology Co., Ltd. Address : Building 45, No.50 Moganshan Road, Shanghai, China. Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guan gdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Numbe r : ENS2312220065W00801R Date (s) of Tests : December 23, 2023 to February 26, 2024 Date of issue : February 27, 2024 $二维码$ Report No. ENS2312220065W00801R Page 2 of 25 Ver.1.0 TEST RESULT CERTIFICATION Applicant : Shanghai HOTO Technology Co., Ltd. Address : Building 45, No.50 Moganshan Road, Shanghai, China. Manufacturer : Shanghai HOTO Technology Co., Ltd. Address : Building 45, No.50 Moganshan Road, Shanghai, China. EUT : HOTO Laser Level 3*360 Model Name : QWFGJ002 Trademark : N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.231 REQUIREMENTS. The test results of this report relate only to the tested sample identified in this report. Date of Test : December 23, 2023 to Februar y 26, 2024 Prepared b y : Una Yu/Editor Reviewer : Joe Xia/Supervisor Approved & Authorized Signer : Lisa Wan g/Manager Report No. ENS2312220065W00801R Page 3 of 25 Ver.1.0 Table of Contents 1 EUT TECHNICAL DESCRIPTION ........................................................................................................ 4 2 SUMMARY OF TEST RESULT ............................................................................................................ 5 3 TEST METHODOLOGY ........................................................................................................................ 6 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................................................... 6 3.2 MEASUREMENT EQUIPMENT USED ................................................................................................. 6 3.3 DESCRIPTION OF TEST MODES ....................................................................................................... 7 4 FACILITIES AND ACCREDITATIONS ................................................................................................. 8 4.1 FACILITIES ........................................................................................................................................... 8 4.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................... 8 5 TEST SYSTEM UNCERTAINTY ........................................................................................................... 9 6 SETUP OF EQUIPMENT UNDER TEST ............................................................................................ 10 6.1 RADIO FREQUENCY TEST SETUP 1 ............................................................................................... 10 6.2 RADIO FREQUENCY TEST SETUP 2 ............................................................................................... 10 6.3 CONDUCTED EMISSION TEST SETUP ............................................................................................ 12 6.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ............................................................... 13 6.5 SUPPORT EQUIPMENT ..................................................................................................................... 13 7 TEST REQUIREMENTS ..................................................................................................................... 14 7.1 OCCUPIED BANDWIDTH ................................................................................................................... 14 7.2 FREQUENCY STABILITY ................................................................................................................... 16 7.3 RADIATED SPURIOUS EMISSION .................................................................................................... 17 7.4 TRANSMISSION REQUIREMENT ..................................................................................................... 22 7.5 CONDUCTED EMISSION TEST ......................................................................................................... 24 7.6 ANTENNA APPLICATION .................................................................................................................. 25 Report No. ENS2312220065W00801R Page 4 of 25 Ver.1.0 1 EUT TECHNICAL DESCRIPTION Characteristics Description Product: HOTO Laser Level 3*360 Model Number: QWFGJ002 Modulation: FSK modulation Operating Frequency Range(s): 433.92MHz Number of Channels: 1 channel Max Transmit Power: 78.21 dBuV/m Antenna Type : PCB Antenna Power supply: For Remote Control: DC 3V from Battery Temperature Range -10°C ~ +40°C Note: for more details, please refer to the User’s manual of the EUT. Report No. ENS2312220065W00801R Page 5 of 25 Ver.1.0 2 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.231(c) Occupied Bandwidth PASS 15.231(d) Frequency stability N/A 15.231(b) Radiated Spurious Emissions PASS 15.231(a) Transmission Requirement PASS 15.203 Antenna Requirement PASS 15.207(a) Conducted Emission N/A NOTE1: N/A (Not Applicable) RELATED SUBMITTAL(S) / GRANT(S): This submittal(s) (test report) is intended for FCC ID: 2AZB9-QWFGJ002 filing to comply with Section 15.231 of the FCC Part 15, Subpart C Rules Report No. ENS2312220065W00801R Page 6 of 25 Ver.1.0 3 TEST METHODOLOGY 3.1 GE…

Text truncated - open the document above for the full version.

Page 1 of 1 TEST SETUP PHOTOS 1.1. Photos of Radiation Emission Measurement Spurious Emission Test Setup (30MHz-1GHz) Spurious Emission Test Setup (Above 1GHz) ----- The End -----
