2AZDM-HHRK4Nebra Indoor LoRa Gateway ROCK Pi 4 Version / Nebra Indoor Helium Hotspot ROCK Pi 4 Version

FEATURES RK3399 processor (Dual Core Cortex A72 1.8ghz and Quad Core Cortex A53 1.4ghz) WiFi 4 2GB RAMOutput: 12V 1.5A max 32GB eMMCBluetooth 5 Unless otherwise indicated, specifications are measured at TA=25°C, humidity<75%, nominal input voltage and rated output load. GENERAL SPECIFICATIONS SPECIFICATIONROCKPI INDOOR HOTSPOT * Average Power Consumption Measured At Mains ** Maximum TX Power may be capped to a lower amount in some regions. Dimensions Weight Power Requirement Maximum TX Power Network Connectivity Rated Ambient Temperature Base SOM CPU Specification 94x70x53mm (Ex cluding Antenna) 353g 12V 2.5A USB-C 24-27dBm** 1GBit Ethernet, 2.4 WiFi 20-30°C R OCK Pi RK3399 Processor D ual Core Cortex A72 1.8GHz and Quad Core Cortex A53 1.4GHz with onbaord WiFi 4 and Bluetooth 5 High Endurance Storage32GB eMMC RAM2GB NEBRA INDOOR HOTSPOT ROCK PI MINER DATASHEET Scan to view online docs Nebra Indoor Hotspot ROCK Pi Miner Datasheet Green LED Orange LED10/100/1000 EthernetRP-SMA Female Connector for the LoRaWAN 3dbi antenna USB C for power Paring ButtonRP-SMA Female Connector for the WiFi 3dbi antenna CONNECTORS DIMENSIONS Nebra Indoor Hotspot ROCK Pi Miner Datasheet WHAT’S INCLUDED 1x Nebra ROCK Pi Miner1x 3db LoRa Antenna 1x WiFi Antenna 1x Universal Power Supply 1x Ethernet Cable 1x Nebra ECC Key1x Hotspot $40 On Boarding1x First $10 Location Assert SKU AND BARCODES BARCODE SKU ROCKPI INDOOR HOTSPOT 915MHz (US915, AU915, KR920, AS923-1/2/3/4) 646648341299 NBR-0064 FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To comply with FCC RF exposure requirements, a minimum separation distance of 20 cm must be maintained between the user’s body and the transmitter. IC STATEMENT This device complies with Industry Canada licence-exempt RSS standard(s) Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. To comply with RF exposure requirements, a minimum separation distance of 20 cm must be maintained between the user’s body and the transmitter Cedispositifestconformeauxnormesautoriser-exemptesduCanadaRSSd'industrie L'exploitationestautoriséeauxdeuxconditionssuivantes: (1)l'appareilnedoitpasproduiredebrouillage,et (2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesile brouillageestsusceptibled'encompromettrelefonctionnement.Cetéquipement estconformeavecl'expositionauxradiationsICdéfiniespourunenvironnement noncontrôlé.L'utilisateurfinaldoitrespecterlesinstructionsdefonctionnementspécifiques poursatisfairelaconformitéauxexpositionsRF.Cetémetteurnedoitpasêtreco-localisées ouopérantenconjonctionavecuneautreantenneoutransmetteur.
