2AZHH-WRT101Combination Lock

WRT01 User Manual Specifications: Input Voltage: DC 6V (4 AA batteries); Operating Current: ≤ 35mA Sleep Current: ≤ 25uA Undervoltage: 3.1V±0.2V Operating Frequency: 433.92MHz; Operating Environment: Temperature -20°C ~ +70°C; Humidity 20% ~ 93%; Storage Environment: Temperature -30°C ~ +80°C; Humidity 20% ~ 93%; Encoding Format: HCS301 rolling code (two channels); Transmission Distance: ≤ 100 meters Installation Step 1:Fix the installation sticker to the desired location, drill a 6mm diameter hole to install the expansion tube, and use 4×30 self-tapping screws to secure the bottom of the combination lock box. Step 2:Install four AA batteries, with the "-" side of the batteries facing the spring. Step 3:Secure the bottom screws of the combination lock with 3×8 self-tapping screws. sticker s Instructions 1.Method of use Channel 1 initial password: 1111. Enter the password and press the "#" key to confirm. Channel 2 initial password: 2222. Enter the password and press the "#" key to confirm. Green indicator light on: Password correct. No indicator light on: Password incorrect. Red indicator light on: Keyboard locked. No response will be given to any key presses within 2 minutes. After 2 minutes, the buzzer will sound once, the red indicator light will turn off, and the system will be unlocked. 2.Add password Channel 1:1) Enter the programming mode password "0000", press the "*" key to confirm. The buzzer will sound once, and the blue indicator light will illuminate. 2)Enter the channel 1 command “01” and press the “#” key to confirm. 3)Enter the new four-digit password for channel 1, then press the "#" key to confirm. The buzzer will sound twice. Save the password and exit. Channel 2:1) Enter the programming mode password "0000", press the "*" key to confirm. The buzzer will sound once, and the blue indicator light will illuminate. 2)Enter the channel 2 command "02", press the "#" key to confirm. 3)Enter the new four-digit password for channel 2, then press the "#" key to confirm. The buzzer will sound two long beeps. Save the password and exit. Note: Once you add a password for any channel, the initial password will automatically become invalid. 3.Restore factory settings If you forget your previously set password, you can use the programming mode to delete it and restore the initial password. 1)Enter the programming mode password "0000", press the "*" key to confirm, the buzzer will sound a long beep, and the blue indicator light will light up. 2) Enter the password deletion command "00", press the "#" key to confirm, the buzzer will sound twice, the password will be deleted and you will exit. 4.Change the programming mode password To reduce the risk of password leakage, please follow these steps to change your programming mode password: 1) Enter the programming mode password "0000", press the "*" key to confirm. The buzzer will sound once, and the blue indicator light will illuminate. 2)Enter the command to change the programming password, "69", and press the "#" key to confirm. 3)Enter the new four-digit programming password, then press the "#" key to confirm. The buzzer will sound twice. Save the password and exit. FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

(Zhejiang Joytech Electronics Co.,Ltd) (2026.01.27) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2AZHH-WRT101) [Zhejiang Joytech Electronics Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Louis mao (Zhejiang Joytech Electronics Co.,Ltd) (2026.01.27) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2AZHH-WRT101) [Zhejiang Joytech Electronics Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Louis mao

Zhejiang Joytech Electronics Co.,Ltd 2026.01.27 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Combination Lock MODEL : WRT101 FCC ID : 2AZHH-WRT101 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Louis mao/Manager Contact information / address: NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China

Zhejiang Joytech Electronics Co.,Ltd 2026.01.27 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Louis mao/Manager Contact information / address: NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China

FCC ID:2AZHH-WRT101 External Photos FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101

Label & label location Size:20*10mm FCC ID: 2AZHH-WRT101

FCC ID:2AZHH-WRT101 Internal Photos Antenna FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101 FCC ID:2AZHH-WRT101

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2601354H01 Issued for Zhejiang Joytech Electronics Co.,Ltd NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Product Name: Combination Lock Brand Name: N/A Model Name: WRT101 Series Model(s): N/A FCC ID: 2AZHH-WRT101 Test Standards: FCC 47CFR §2.1093 Page 2 of 8 Report No.: STS2601354H01 TEST REPORT Applicant’s Name ................. : Zhejiang Joytech Electronics Co.,Ltd Address ................................. : NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Manufacturer's Name ........... : Zhejiang Joytech Electronics Co.,Ltd Address ................................. : NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Product Description Product Name ........................ : Combination Lock Brand Name .......................... : N/A Model Name .......................... : WRT101 Series Model(s) ...................... : N/A Test Standards ..................... : FCC 47CFR §2.1093 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 21 Jan. 2026 Date (s) of performance of tests ............. : 21 Jan. 2026 to 23 Jan. 2026 Date of Issue .......................................... : 23 Jan. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2601354H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2601354H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 Jan. 2026 STS2601354H01 ALL Initial Issue Page 5 of 8 Report No.: STS2601354H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Combination Lock Brand Name N/A Model Name WRT101 Series Model(s) N/A Model Difference N/A Product Description The EUT is a Combination Lock Operation Frequency: 433.92MHz 304.25MHz Modulation Type: OOK ASK Antenna Designation: Internal antenna PCB antenna Antenna Gain(Peak) 0 dbi 0 dbi Power Rating DC 6V From Battery Adapter N/A Battery DC 6V Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 8 Report No.: STS2601354H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Page 7 of 8 Report No.: STS2601354H01 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 8 of 8 Report No.: STS2601354H01 2.3 TEST RESULT Trun up Mode Detector Power (dBuV/m) @3m Power (dBm) Max Tune up (dBm) SRD PK 63.63 -31.57 -31±1 Note: Power(dBm)= dBuV/m@3m -95.2 Evaluation Result Mode Frequency MHz Separation distance (cm) Power (dBm) ERP (mW) SAR Test Exclusion Threshold SAR Test Exclusion Estimated SAR SRD 433.92 0.5 -30 0.000001 0.0000001 Yes / Note: 1. Remark: The worst case gain of the antenna is 0dBi. 2. Threshold at which no SAR required is 0.0000001≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm. ※※※※※END OF THE REPORT※※※※※

CO PABT101 PABT102 COBT1 PAC102PAC101 COC1 PAC201 PAC202 COC2 PAC301PAC302 COC3 PAC402PAC401 COC4 PAC502PAC501 COC5 PAC602 PAC601 COC6 PAC702PAC701 COC7 PAC802 PAC801 COC8 PAC902PAC901 COC9 PAC1002 PAC1001 COC10 PAC1102 PAC1101 COC11 PAC1202 PAC1201 COC12 PAC1302PAC1301 COC13 PAC1401 PAC1402 COC14 PAC1502 PAC1501 COC15 PAC9001 PAC9002 COC90 PAJ302 PAJ301 PAJ305 PAJ303 PAJ304 COJ3 PAK102 PAK101 COK1 PAL102 PAL101 COL1 PAL202 PAL201 COL2 PAL302PAL301 COL3 PAL402 PAL401 COL4 PAQ103 PAQ101 PAQ102 COQ1 PAQ203 PAQ202 PAQ201 COQ2 PAQ302 PAQ303 PAQ301 COQ3 PAQ503 PAQ502 PAQ501 COQ5 PAQ601 PAQ602 PAQ603 COQ6 PAR201PAR202 COR2 PAR301PAR302 COR3 PAR501PAR502 COR5 PAR601PAR602 COR6 PAR702 PAR701 COR7 PAR801PAR802 COR8 PAR1002PAR1001 COR10 PAR1101PAR1102 COR11 PAR1301PAR1302 COR13 PAR1402 PAR1401 COR14 PAR1502 PAR1501 COR15 PAR2701PAR2702 COR27 PAR2902PAR2901 COR29 PAR3002PAR3001 COR30 PAR3102 PAR3101 COR31 PAU2020 PAU209 PAU2017 PAU2018 PAU2013 PAU2014 PAU204 PAU2011 PAU2019 PAU2016 PAU2015 PAU2010 PAU208 PAU201 PAU202 PAU203 PAU205 PAU207 PAU206 PAU2012 COU2 PAU30GND PAU30VCC PAU302 COU3 PAY102PAY103PAY101 COY1 PA02 PABT102 PAC102 PAC202 PAC301 PAC401 PAC602 PAC902 PAC1001 PAC1102 PAC1202 PAC1302 PAC1401 PAC9001 PAJ302 PAK102 PAL202 PAQ202 PAQ502PAQ602 PAR801 PAR2701 PAU207 PAU30GND PAY102PAY103 PAQ203 PAC501 PAQ102 PAQ503 PAR1101 PAC702 PAL201 PAL302 PAC1502 PAC9002 PAL301PAC701 PAC801 PAL102 PAQ303 PAC802PAC901 PAQ302 PAR802 PAQ501 PAR2902 PAC201 PAC601 PAC1101 PAL101 PAL402 PAR201 PAU302 PAC502 PAQ101 PAR202 PAR301PAR302 PAR1102 PA04 PAU205 PAC1201 PAR502 PAR702 PAQ201 PAR601 PAQ301 PAR701 PAY101 PA08 PAU203 PA08 PAU202 PAQ601 PAR2702 PAR3002 PAR2901 PAU201 PAC101 PAU208 PAK101 PAR3101 PAU2010 PAR501 PAU2015 PAR602 PAU2016 PAR3001 PAU2019 PA03 PAU2011 PAC1301 PAJ305 PAR1301 PAU204 PA06 PAR1502 PAU2014 PA05 PAR1402 PAU2013 PAJ304 PAU2018 PAJ303 PAU2017 PA01 PAC302 PAC402 PAC1402 PAJ301 PAR1002 PAR1302 PAR1401 PAR1501 PAR3102 PAU209 PAU30VCC PABT101 PAQ103 PAR1001 PAU2020 Manufacturer : Zhejiang Joytech Electronics Co.,Ltd Gain:0 dbi

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2601354W01 Issued for Zhejiang Joytech Electronics Co.,Ltd NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Product Name: Combination Lock Brand Name: N/A Model Name: WRT101 Series Model(s): N/A FCC ID: 2AZHH-WRT101 Test Standards: FCC Part 15.231 Page 2 of 31 Report No.: STS2601354W01 TEST REPORT Applicant’s Name .................: Zhejiang Joytech Electronics Co.,Ltd Address ..................................: NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Manufacturer's Name ...........: Zhejiang Joytech Electronics Co.,Ltd Address ..................................: NO.651 HENGXING ROAD, PUYUAN TOWN, TONGXIANG, ZHEJIANG, China Product Description Product Name ............................ : Combination Lock Brand Name ............................... : N/A Model Name ...........................: WRT101 Series Model(s) ....................: N/A Test Standards .......................... : FCC Part 15.231 Test Procedure ........................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................: Date of Receipt of Test Item ...: 21 Jan. 2026 Date of performance of tests ..: 21 Jan. 2026 to 23 Jan. 2026 Date of Issue ..........................: 23 Jan. 2026 Test Result .............................: Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 31 Report No.: STS2601354W01 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.5 EQUIPMENTS LIST 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 TEST RESULTS 12 4. RADIATED EMISSION MEASUREMENT 13 4.1 RADIATED EMISSION LIMITS 13 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 16 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULTS 17 4.7 FIELD STRENGTH CALCULATION 18 5. BANDWIDTH TEST 22 5.1 LIMIT 22 5.2 TEST REQUIREMENTS 22 5.3 TEST PROCEDURE 22 5.4 TEST SETUP 22 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 23 6. DUTY CYCLE 24 6.1 TEST PROCEDURE 24 6.2 TEST SETUP 24 6.3 EUT OPERATION CONDITIONS 24 6.4 TEST RESULTS 25 7. AUTOMATICALLY DEACTIVATE 28 Page 4 of 31 Report No.: STS2601354W01 TABLE OF CONTENTS Page 7.1 STANDARD REQUIREMENT 28 7.2 TEST PROCEDURE 28 8. ANTENNA REQUIREMENT 30 8.1 STANDARD REQUIREMENT 30 8.2 EUT ANTENNA 30 APPENDIX 1-PHOTOS OF TEST SETUP 31 Page 5 of 31 Report No.: STS2601354W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 Jan. 2026 STS2601354W01 ALL Initial Issue Page 6 of 31 Report No.: STS2601354W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- Note: (1) “N/A” denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. :101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuh ai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 7 of 31 Report No.: STS2601354W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Combination Lock Trade Name N/A Model Name WRT101 Series Model N/A Model Difference N/A Product Description The EUT is a Combination Lock Operation Frequency: 433.92MHz Modulation Type: OOK Antenna Designation: Internal antenna Antenna Gain(Peak) 0 dbi More details of EUT technical specification, please refer to the User Manual. Channel List Please refer to the Note 3. Power Rating DC 6V From Battery Adapter N/A Battery DC 6V Hardware version number N/A Software version number/FVIN N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. Table for filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 - WRT101 Internal antenna N/A 0 Antenna Note: The antenna information refer the manufacturer provide report, applicable only to the tested sample identified in the report. 3.…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID:2AZHH-WRT101 30MHz-1GHz Spurious emissions
