2AZNY-K6Karaoke System

INSTRUCCIONES MANUAL FAIR LIGHT KARAOKE PARTY SPEAKER K6 DEAR CUSTOMER In order to achieve the best performance of your product, please read this instruction manual carefully before using, and keep it for future reference. NOTE This unit may be submitted for changes in specifications, characteristics and/or operation without prior notice to user, in order to continue improving and developing its technology. Contents 1. Important Notice Before Use this Speaker 2. Your Party Speaker Introduction What’s in the box Overview of the Top control panel Overview of the Rear panel 3. Get started Connect power Prepare the remote control Turn ON/OFF the speaker Charging the internal Battery Internal Battery Level indicator 4. Play Basic key play operations 5. Connect with Bluetooth 6. Connect with AUX Line in 7. Listen to external audio device Connect with Wired Microphone/Guitar 8. Production information Specification 9. Troubleshooting CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN Caution: To reduce the risk of electric shock do not open this device, there are no serviceable parts for customers. Please refer any maintenance or repair to qualified personnel. This sign means the existence of dangerous voltage inside the unit, which states a risk of electric shock. This sign means that there are important instructions of operation and handling in the manual that comes with this device. 1. Important Notice Before Use this Speaker ① Read these instructions. ② Keep these instructions. ③ Heed all warnings. ④ Follow all warnings. ⑤ Do not use this apparatus near water. ⑥ Clean only with dry cloth. ⑦ Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. ⑧ Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. ⑨ Only use attachments/accessories specified by the manufacturer. ⑩ Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. ⑪ Unplug this apparatus during lightning Storms or when unused for long periods of time. ⑫ Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way. Such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. ⑬ Battery usage CAUTION-TO prevent battery leakage which may result in bodily injury, property damage, or damage to the remote control.  Install all batteries correctly,+ and - as marked on the remote control.  Do not mix batteries(old and new or carbon and alkaline, etc.)  Remove batteries when the remote control is not used for a long time.  Batteries (battery pack or batteries excessive heat such as sunshine, f ire, or the like). ⑭ Apparatus shall not be exposed to dripping or splashing. ⑮ Do not place any sources of danger on the apparatus(e.g. liquid filled objects, lighted candles ). ⑯ Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. Warning  Never remove the casing of this apparatus.  Never lubricate any part of this apparatus.  Never place this apparatus on other electrical equipment.  Never look into the laser beam inside this apparatus.  Make sure that you always have easy access to the power cord, or adaptor to disconnect the apparatus from the power. Caution Hearing safety  Listen at a moderate volume.  Using headphones at a high volume can impair your Hearing.  Sound can be deceiving. Over time your hearing ‘comfort level’ adapts to higher volumes of sound. so after prolonged listening. What sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.  Use of controls or adjustment or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation. To establish a safe volume level: Set your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and clearly without distortion. Listen for reasonable periods of time: Prolonged exposure to sound, even at normal ‘safe’ levels, can also cause hearing loss.. Be sure to us your equipment reasonably and take appropriate breaks. Be sure to observe the following guidelines when using your headphones. Listen at reasonable volumes for reasonable periods of time. Be careful not to adjust the volume as your hearing adapts. Do not turn up the volume so high that you can’t hear what’s around you. You should use caution or temporarily discontinue use in potentially hazardous situations. Do not use headphones while operating a m otorized vehicle, cycling, skateboarding, etc., it may create a traffic hazard and is illegal in many areas. Notice Any changes or modifications made to this device that are not expressly approved by Consumer Lifestyle may void the user’s authority to operate the equipment. 2. Your Party Speaker Introduction With this unit, you can: Enjoy audio from Bluetooth and other external device; What’s in the box Check and identify the contents of your package: Speaker Remote control User manual Aux In/ FM Antenna Cable Adapter Overview of the Top control panel 1.MIC/GT button 2.Mode Switching button 3.LED button 4.Record button 5.Volume button 6.Next button 7.Previous button 8.Play/Pause/TWS button 9.Tone button 1 2 3 4 5 6 7 8 9 Overview of the Rear panel Overview of the remote control 3. Get started Caution  Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation. Always follow the instructions in this chapter in sequence.…

Text truncated - open the document above for the full version.

Page 1 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9

Page 1 of 1 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L 4.0cm x 3.0cm) Label Location Karaoke System Model: K6 FCC ID: 2AZNY-K6

Page 1 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11 Fig. 12 Page 7 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 13 Fig. 14 Page 8 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 15 Fig. 16 Antenna Page 9 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 17 Fig. 18 Page 10 of 10 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 19 Fig. 20

Page 1 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2AZNY-K6 EUT : Karaoke System Test Model : K6 Additional Model No. : K8, K16 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: 9V2000mA For AC Adapter Input: 100-240V~, 50/60Hz, 0.5A MAX Adapter Output: 9V2000mA DC 7.4V by Rechargeable Li-ion Battery, 4000mAh Hardware Version : F139-V4.1.PCB Software Version : MVsB1_BT_Audio_SDK_v0.2.0_beta19_P08 Bluetooth Frequency Range : 2402MHz ~ 2480MHz Channel Number : 79 channels for Bluetooth V5.0(DSS) 40 channels for Bluetooth V5.0 (DTS) Channel Spacing : 1MHz for Bluetooth V5.0 (DSS) 2MHz for Bluetooth V5.0 (DTS) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V5.0(DSS) GFSK for Bluetooth V5.0 (DTS) Bluetooth Version : V5.0 Antenna Description : PCB Antenna, 2.81dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device Page 2 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. Page 3 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Internal/External Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Antenna PCB Antenna 2402-2480 MHz 2.81dBi BT Antenna Page 4 of 5 FCC ID: 2AZNY-K6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 6. Conducted Power [BT] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 00 2402 6.55 39 2441 5.84 79 2480 3.49 π/4-DQPSK 00 2402 6.42 39 2441 5.70 79 2480 3.50 8-DPSK 00 2402 6.55 39 2441 5.82 79 2480 3.50 [BT LE] …

Text truncated - open the document above for the full version.

MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 1 Inverted F Antenna Specification MANUFACTURE :SHANGHAI MOUNTAIN VIEW SILICON CO,. LTD PRODUCT NAME :MV_BP10xx PCB Antenna DATE:2019-10-30 MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 2 1. Antenna describe Antenna plate ： Inverted F Antenna Frequency range ： 2.4GHz-2.48GHz ITEM Name Inverted F Antenna Specification Model Name2.4GHz Antenna PolarizationHorizontal and Vertical Azimuth Beam PattemOmni-directional Impedance50 Ohm Antenna Lengh14.4mm Gain(Max) 2.81(±1 dBi ） 2. Antenna Photo& Lengh （ mm ） MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 3 3. Gain Frequency Gain （ dBi ） 2400MHz2.81 2410MHz2.74 2420MHz2.70 2430MHz2.73 2440MHz1.01 2450MHz1.26 2460MHz1.50 2470MHz1.49 2480MHz1.42 2490MHz0.36 2500MHz0.33 4. Return Loss/VSWR/Input Impedance Frequency Return Loss (dB)VSWR Input Impedance( Ω） 2400MHz-7.232.5325.37 2400MHz-6.472.8017.99 2450MHz-6.222.9017.18 2480MHz-5.183.4415.55 2500MHz-4.563.8915.48 MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 4 Annex A Photographs 1. Test Setup Annex B Figures 1.2D Radiation Pattern Phi=0° MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 5 Phi=90° Theta=90° MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 6 2.3D Radiation Pattern 2400MHz 2450MHz MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 7 2500MH 3.Return Loss MVSILICON 上海山景集成电路股份有限公司 Shanghai Mountain View Silicon Co., Ltd 8 4.VSWR END

Page 1 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for BT (Conducted Measurement) Product Name: Karaoke System Test Model: K6 Environmental Conditions Temperature: 23.9 C Relative Humidity: 52.1% ATM Pressure: 100.0 kPa Test Engineer: Ling Zhu Supervised by: Li Huan Page 2 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Verdict DH5 Ant1 2402 0.900 2401.526 2402.426 --- 2441 1.008 2440.475 2441.483 --- 2480 1.032 2479.481 2480.513 --- 2DH5 Ant1 2402 1.305 2401.358 2402.663 --- 2441 1.314 2440.346 2441.660 --- 2480 1.305 2479.349 2480.654 --- 3DH5 Ant1 2402 1.320 2401.343 2402.663 --- 2441 1.290 2440.367 2441.657 --- 2480 1.272 2479.361 2480.633 --- Page 3 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page 4 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2402 2DH5_Ant1_2441 Page 5 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2480 3DH5_Ant1_2402 Page 6 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant1_2441 3DH5_Ant1_2480 Page 7 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant1 2402 6.55 ≤21 PASS 2441 5.84 ≤21 PASS 2480 3.49 ≤21 PASS 2DH5 Ant1 2402 6.42 ≤21 PASS 2441 5.70 ≤21 PASS 2480 3.50 ≤21 PASS 3DH5 Ant1 2402 6.55 ≤21 PASS 2441 5.82 ≤21 PASS 2480 3.50 ≤21 PASS Page 9 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page 10 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2402 2DH5_Ant1_2441 Page 11 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant1_2480 3DH5_Ant1_2402 Page 12 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant1_2441 3DH5_Ant1_2480 Page 13 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 55 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, …

Text truncated - open the document above for the full version.

Page 1 of 36 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FOR Fujian EastWest Lifewit Technology Co., LTD Karaoke System Test Model: K6 Additional Model No.: K8, K16 Prepared for : Fujian EastWest Lifewit Technology Co., LTD Address : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : October 08, 2022 Number of tested samples : 2 Sample No. ： A092722177-1, A092722177-2 Serial number : Prototype Date of Test : October 08, 2022 ~ November 08, 2022 Date of Report : November 09, 2022 Page 2 of 36 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ................. : LCSA092722177EA Date of Issue ................................... : November 09, 2022 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Fujian EastWest Lifewit Technology Co., LTD Address ........................................... : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Test Specification Standard.......................................... : FCC CFR 47 PART 15 C (15.247) Test Report Form No. ..................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .................. : Karaoke System Trade Mark ...................................... : TONOR Test Model ...................................... : K6 Ratings ............................................ : Input: 9V2000mA For AC Adapter Input: 100-240V~, 50/60Hz, 0.5A MAX Adapter Output: 9V2000mA DC 7.4V by Rechargeable Li-ion Battery, 4000mAh Result ........................................... : Positive Compiled by: Supervised by: Approved by: Li Huan/ Administrator Cary Luo/ Technique principal Gavin Liang / Manager Page 3 of 36 FCC ID: 2AZNY-K6 Report No.: LCSA092722177EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA092722177EA November 09, 2022 Date of issue Test Model.............................. : K6 EUT......................................... : Karaoke System Applicant............................... : Fujian EastWest Lifewit Technology Co., LTD Address................................... : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Telephone............................... : / Fax.......................................... : / Manufacturer......................... : Fujian EastWest Lifewit Technology Co., LTD Address................................... : …
