2AZNY-T7106-AWireless microphone

Troubleshooting Guide If the a6ove mentioned suggestions do not improve ide situation, consult your out company. Problem Cause Solution The BROADCASTING indicator does not up. The cordless microphone is not turned on.Turn on the cordlerr microphone. The microphone receiver is not turned on. Turn on the microphone receiver and the connected AV equipment. The microphone receiver is not connected properly. See the “connections”in this manual and correct the connections. No Sound The battery in the cordless microphone is weak Replace the battery. The microphone receiver is not turned on. Turn on the microphone receiver and the connected AV equipment. The connected AV dquipment is not turned on. Turn up the AV equipment. The connected AV dquipment is turned down. Turn up the volume of the AV equipment. The speakers/headphones are not conneceted to the AV equipment. Connect the speakers/head phones. The sound is distorted. The bettery in the cordless microphone is weak. Replace the battery. The AUDIO OUT selector switch on the receiver is not set correctly. See the "parts identification" in this manual and set it correctly. A howing noise is heard from the speakers The distance between the cordkess microphone aned speakers are too close. Move the cordless microphone away from the speakers of chang the direction of the microphone. A loud hissing noise is heard from the speakers. The battery in the cordless microphone is weak. Replace the battery. SPECIFICATIONS: OVERALL SYSTEM Carrier Frequency Range Frequency Stability Modulation Mode Maximum Deviation Range Frequency Response S/N Ratio T.H.D Audio Dynami c Range Service Areas 657.35MHz UHF HIGH band +/-0.005% with quar tz controlled. FM +/-15KHz,with Limiting comperssor. 40Hzto 20KHz. Better than 100dB.(A) Less than 0.5% Over 100dB .Over 118dB with Limiting 30 meters. RECEIVER Receiving System S/N Ratio Image and Spurious Rejection Power Supply Dual channels fixed frequency by quartz. Over 108dB at 15KHz deviation. 80dB minimun AC 110/220 V,50/60Hz Techonology ofU. S. A Operati ng Instructions VHF WIRELESS MICROPHONE SYSTEM Thank you for buying this VHF WIRELESS MI CROPHONE SYSTEM product. Please read through These opera tion instructions so you will know how to operate your model properly. After you have fini shed reading the ins tructions, put them away in a safe place of future reference. WARNING **To prevent fire or shock hazard, do not expose the uni t to rain or moisture. **To a void electrial shock, do not oper the cabinet. Refer serviving to qualified personnel only. PRECAUTIONS **Do not drop or give any physical shocks to the wireless microphone. **Do no t use the sys tem where i t may be sub jec ted to : --direct or indirect sunligh t. --excess i ve hea t from radia tors or o th er hea t sources. --excessive dust or humidity. -一Mechanical or other vibrations. **Shoule any liquid or foreign ob jec t fall in to the uni t, disconnec t the uni t from the power source and have i t checked by quulifed personnel before opera ting i t any futher. you have any questions or problems concerning this system which are no t covered in this manlal, please consult the nearest out company. **Be sure to bing the cordless microphone and the receiver (the whole system) to out company when requiring repair work. Manual NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment of and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which there receiver is connected. -Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Page 1 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6

Page 1 of 1 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L: 2.0cm x W: 1.5cm) Label Location Wireless microphone Model: T7106 FCC ID: 2AZNY-T7106-A

Page 1 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Antenna

Page 1 of 2 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID 2AZNY-T7106-A Product name Wireless microphone Test Model T7106 Power supply DC 3.0V by 2*AAA Batteries Hardware Version V1.0-T1.0-200415/V3.0-T1.0-190903 Software Version U2 Frequency Range 657.35MHz Channel Number 1 Modulation Type FM Antenne Description Internal antenna, 3dBi (Max.) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Portable Device Channel List and Frequency Channel Frequency(MHz) Channel Frequency(MHz) 1 657.35 -- -- 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)+ · *√f (GHz)+ ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. Page 2 of 2 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices 4. Conducted Power Results Test Mode Channel Frequency (MHz) EIRP(dBm) Limits (dBm) Verdict FM 1 657.35 7.129 17 PASS 5. Manufacturing tolerance FM Channel (EIRP) Channel Channel 1 (657.35 MHz) Target (dBm) 7 Tolerance ±(dB) 1.0 6. Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power SAR Test Exclusion Threshold SAR Test Exclusion dBm mW FM 0.65735 5 8.0 6.3096 1.0231< 3.0 Yes Remark: 1. Output power including tune up tolerance; 2. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 of KDB447498 is applied to determine SAR test exclusion. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. .......................THE END OF REPORT.........................

Page 1 of 28 FCC ID: 2AZNY-T7106-A Report No.: LCSA092722173EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Fujian EastWest Lifewit Technology Co., LTD Wireless microphone Test Model: T7106 Prepared for : Fujian EastWest Lifewit Technology Co., LTD Address : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : October 08, 2022 Number of tested samples : 2 Sample No : A092722173-1, A092722173-2 Serial number : Prototype Date of Test : October 08, 2022 ~ November 08, 2022 Date of Report : November 09, 2022 Page 2 of 28 FCC ID: 2AZNY-T7106-A Report No.: LCSA092722173EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.236) Report Reference No. ................ : LCSA092722173EA Date of Issue .................................. : November 09, 2022 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Fujian EastWest Lifewit Technology Co., LTD Address .......................................... : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.236) / ANSI C63.10: 2013 Test Report Form No. .................. : LCSEMC-1.0 TRF Originator ............................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2019-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Wireless microphone Trade Mark ..................................... : N/A Test Model...................................... : T7106 Ratings ........................................... : DC 3.0V by 2*AAA Batteries Result ........................................... : Positive Compiled by: Supervised by: Approved by: Li Huan/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 28 FCC ID: 2AZNY-T7106-A Report No.: LCSA092722173EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT Test Model.............................. : T7106 EUT......................................... : Wireless microphone Applicant............................... : Fujian EastWest Lifewit Technology Co., LTD Address.................................. : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Fujian EastWest Lifewit Technology Co., LTD Address................................... : Rm 1201-1205, Bld 18, 2nd Phase of Innovation Park, no.7, Wulongjiang Mid-Ave, Fuzhou High-tech Zone, Fuzhou, Fujian Province Telephone............................... : / Fax.......................................... : / Factory................................... : Guangzhou Jie Li Electron Co., Ltd. Address................................... : No.5, Xinke Kejia Yuanxing Rd., Baiyun District, Guangzhou. Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA092722173EA November 09, 2022 Date of issue Page 4 of 28 FCC ID: 2AZNY-T7106-A Report No.: LCSA092722173EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Revision Issue Date Revision Content Revised By 000 November 09, 2022 Initial Issue -- Page 5 of 28 FCC ID: 2AZNY-T7106-A Report No.: LCSA092722173EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Ind…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: 2AZNY-T7106-A Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2
