2AZRBWT06WIFI SENSOR

1 EN Window/Door Alert Sensor Sensor de alerta de ventana/puerta Capteur d’alerte de fenêtre/porte Sensore di allarme finestra/porta Fenster/Tür-Warnsensor EN Quick Start Guide ES Guía de inicio rápido FR Guide de démarrage rapide IT Guida rapida DE Schnellstartanleitung 2 EN OVERVIEW Magnet Sensor Status light < 10mm(3/8”) Cover screw Remove to access battery compartment and QR code (located under cover) 3 EN BATTERY INSTALLATION 1 Unscrew the sensor cover with the supplied screwdriver and lift it off. 2 Insert the supplied two AAA batteries into the battery compartment according to the polarity markings (+ and -) shown. Pairing mode will automatically activate on the sensor for 3 minutes when batteries are inserted. The sensor status light will blink blue slowly during pairing mode. If you have downloaded the Swann Security app on your mobile device (see page 4), you can proceed to the pairing process (see page 5). Note: Pairing mode on the sensor can be activated at any time by re-inserting the batteries. 3 After you have paired the sensor, replace the cover and screw it firmly in place. 4 Should you need to replace the batteries in the future, there is no need to re-pair the sensor. Simply wait for pairing mode to timeout (3 minutes), after which the sensor will automatically reconnect to the previously configured Wi-Fi network. 4 EN DOWNLOAD THE SWANN SECURITY APP 1 Download the latest version of the Swann Security app from the Apple App Store® or Google Play™ Store on your iOS or Android device. Simply search for "Swann Security". 2 Open the app and create your Swann Security account by tapping “Not yet registered? Sign Up” at the bottom of the screen. Then, activate your Swann Security account by confirming the verification email that is sent to the registered email address. 5 EN Open the Swann Security app and tap the Pair Device button on the screen. If you have already paired a device, tap the menu icon in the top left and select “Pair Device”. The app will now guide you through the pairing process and set up your sensor. Before you begin, have the sensor with you and be close to your router. Please note that the sensor can connect to a 2.4GHz Wi-Fi network only. SET UP THE SENSOR 6 EN Take the time to choose a location and properly check the orientation of the sensor and the magnet. The sensor and magnet should ideally be positioned in a way that when the window or door is closed, they are aligned side by side, less than 10mm (3/8”) apart. See Mounting Examples on the next page. Also, make sure the sensor location has strong, reliable Wi-Fi reception available so you can get timely alerts. As a general rule, the nearer your sensor is to your Wi-Fi router, the better the wireless connection quality. You can expand the Wi-Fi coverage of your current network by installing a Wi-Fi range extender. 1 For reliable bonding, clean the surface where the sensor and magnet will be mounted with an alcohol/cleaning wipe, and let dry. 2 Fit the sensor and the magnet with appropriate double-sided tapes. 3 Select a location on the window/door. Attach the sensor to the window/door frame and the magnet to the window/door. Make sure the sensor cover will be accessible in the final position (in case of battery replacement/re-pairing). 4 Press firmly onto surface for 60 seconds each to secure. 5 To test the sensor, simply open the window/door. The app will send you a push notification, for example, “Contact sensor has been opened on Front Door”. Close the window/door. The app will send you another notification, for example, “Contact sensor has been closed on Front Door”. The sensor tile will also automatically update its status in the app, as shown on the right. Note: You can use the Modes feature in the app to configure whether or not to receive “Opened” and “Closed” push notifications when the sensor is in Home, Away or Night mode. MOUNTING THE SENSOR 7 EN HELP AND RESOURCES Status Light Guide The status light on the sensor tells you what is happening with the device connection. When the sensor is functioning normally, the status light will be off (unless it is out of battery/unpaired). Mounting Examples Door installation Cabinet installation Window installation Swann Security App Manual Access the Swann Security app manual (Menu > User Manual) at any time to learn more about navigating through the various screens and functions in the app. Slow Blinking BluePairing mode Sensor Battery Level You can check the battery level of the sensor in the app: Devices tab > Sensor > Battery % Solid Blue (5 seconds)Change in Open/Closed state. Connecting to Wi-Fi. 32 EN RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment. BATTERY SAFETY INFORMATION Replace batteries at the same time. Do not mix new and old batteries or battery types (for example, alkaline and lithium batteries). Keep batteries out of reach of children. Dispose of used batteries promptly in accordance with local regulations. | INFORMACIÓN DE SEGURIDAD DE LA BATERÍA Sustituya las baterías al mismo tiempo. No mezcle baterías nuevas y usadas ni tipos de baterías (por ejemplo, baterías alcalinas y de litio). Mantenga las baterías fuera del alcance de los niños. Deseche las baterías usadas correctamente de acuerdo con las reglamentaciones locales. | INFORMATIONS SUR LA SÉCURITÉ DE LA PILE Remplacez les piles en même temps. Ne mélangez pas des piles ou types de piles neuves et anciennes (par exemple, des piles alcalines et au lithium). Gardez les piles hors de portée des enfants. Débarrassez-vous rapidement des piles usagées conformément aux réglementations locales. | INFORMAZIO…

Text truncated - open the document above for the full version.

RF_160,Issue04 NASS(HK)LIMITED DeclarationofAuthorization We Name:NASS(HK)LIMITED Address:2/FONTINCENTRE1SHEUNGHEISTREETSANPOKONGKOWLOON City:HONGKONG. Country:China. Declarethat: NameRepresentativeofagent:EMTEK(DONGGUAN)CO.,LTD.. (1) AgentCompanyname:SamLv. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnologyReserchand DevelopmentBase,No.9,XinchengAvenue,SongshanhuHigh-technologyIndustrialDevelopmentZone,.. City:Dongguan,Guangdong,.. CountryChina. isauthorizedtoapplyforCertificationofthefollowingproduct(s): Productdescription:WIFISENSOR. Typedesignation:WT06,WT86,SWIFI-WDOOR. Trademark:N/A. Validity/expirydate onourbehalf. Date:2021-7-16.. City:HOGGKONG.. Name:Williamma.. (2) Function:...Manager............................ Signature:. Notes: (1):RequiredforFCCapplication (2):ForFCCitmustbetheGranteeCode“owner”ortheauthorizedagent.

FCC,Requestfornon-disclosureDate:21-Nov-2018 RF_501,Issue8Page1of1 CompanyName:NASS(HK)LIMITED Address:2/FONTINCENTRE1SHEUNGHEISTREETSAN POKONGKOWLOONHONGKONG City:HONGKONG Country:China To:TeleficationB.V.,Dept.FCCTCB Edisonstraat12A 6902PKZEVENAAR TheNetherlands Subject:RequestforconfidentialityFCCID:2AZRBWT06 Referencenumber:WT06,WT86,SWIFI-WDOOR DearFCCTCB, 1.Long-TermConfidentiality Pursuantto47CFRSection0.459(a)&(b),weherebyrequestsnon-disclosureandconfidentialtreatment ofthefollowingmaterialssubmittedinsupportofFCCcertificationapplication: Bill(s)ofMaterialBlockDiagrams OperationalDescriptionSchematicDiagramsTune-upProcedure Abovematerialscontainsecrets,proprietaryandtechnicalinformation,whichwouldcustomarilybe guardedfromcompetitorsunder47CFR,section0.457(d)(2).Disclosureorpublicationoranyportionof thiscompanyconfidentialmaterialtootherpartiescouldcausesubstantialcompetitiveharmandprovide unjustifiedbenefitsforcompetitors. 2.Short-TermConfidentiality(STC) PursuanttoPublicNoticeDA04-1705oftheCommission’spolicy,inordertocomplywiththemarketing regulationsin47CFR§2.803andtheimportationrulesin47CFR§2.1204,applicantherebyrequests Short-TermConfidentialtreatmentofthefollowingmaterials(Seenotesbelow): InternalPhotosUser’sManualTestSet-upPhotosExternalPhotos Justification:Theproducthasnotyetbeenreleasedtopreventothermerchantsfromcopyingit Date:2021-07-16Nameandsignatureofapplicant:Williamma Notes: 1)AdocumentortypeofdocumentcanonlyhaveONEtypeofconfidentiality! 2)Short-Termconfidentialityisinprinciplefor45daysfromdateofgrant;itcanbeextendedmax3times(totaltime180daysmax.)! TheplanneddateshouldstatedintheRF731applicationform. 3)FCCmustbeinformedwhenmarketingbeginsearlier. 4)Releasetakesplaceautomaticallythusextensionmustberequestedintime.Teleficationdoesnotremindyouofthis! 5)RequestforextensionorforreleasemustbereceivedbyTeleficationatleast7daysbeforedateofactualmarketingorbefore expirationoftheSTCperiod

FCC ID:2AZRBWT06

RFEXPOSUREEVALUATION EUTSpecification EUTWIFISENSOR ModelNumber WT06,WT86,SWIFI-WDOOR FCCID2AZRBWT06 Antennagain(Max)0dBi OperationFrequencyWIFI:2412MHz-2462MHz InputRatingDC3V ClassificationPer StipulatedTestStandard §15.247(i),§2.1093 ModulationDSSSwithDBPSK/DQPSK/CCKfor802.11b; OFDMwithBPSK/QPSK/16QAM/64QAMfor802.11g/n; Max.outputpower8.95dBm EvaluationappliedMPEEvaluation SAREvaluation TestRequirement: RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiationas specifiedin§1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 1Friistransmissionformula:Pd=(Pout*G)\(4*pi*R 2 ) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainmW G=Numericgainoftheantennarelativetoisotropicantenna Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainofthendtotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancewheretheMPElimitis reached. 2MeasurementResult Antennagain:0dBi Operation Mode Channel Number Channel Frequency (MHz) Measurement Level(dBm) Limit (dBm)Verdict 802.11b 124128.9530PASS 624378.5430PASS 1124628.3630PASS 802.11g 124127.8130PASS 624378.3730PASS 1124628.2230PASS 802.11n (HT20) 124127.6130PASS 624378.1330PASS 1124628.0230PASS 802.11n (HT40) 324226.0430PASS 624376.8530PASS 924526.6630PASS Signature: SamLv Date:2021-07-05

Report No.: ED210508058WPage 1 of 57 Ver.1.0 $印章$ TEST REPORT Product Name ： WIFI SENSOR Model Number ： WT06, WT86, SWIFI-WDOOR FCC ID ： 2AZRBWT06 Prepared for: NASS (HK) LIMITED Address: 2/F ON TIN CENTRE 1 SHEUNG HEI STREET SAN PO KONG KOWLOON HONG KONG Prepared by: EMTEK(DONGGUAN) CO., LTD. Address: -1&2/F.,Buiding 2,Zone A,Zhongda Marine Biotechnology Research and Development Base,N.9,Xincheng Avenue,Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China TEL: +86-0769-22807078 FAX: +86-0769-22807079 Report Number: ED210508058W Date(s) of Tests: May 29, 2021 to Jul 05, 2021 Date of issue: Jul 05, 2021 $二维码$ Report No.: ED210508058WPage 2 of 57 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION........................................................................................................................3 2 EUT TECHNICALDESCRIPTION......................................................................................................................4 3 SUMMARYOFTEST RESULT............................................................................................................................5 4 TEST METHODOLOGY.......................................................................................................................................6 4.1 GENERAL DESCRIPTION OFAPPLIED STANDARDS..............................................................................6 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................................6 4.3 DESCRIPTION OF TEST MODES..................................................................................................................7 4.4 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING.................................................................... 8 5 FACILITIESANDACCREDITATIONS.............................................................................................................. 9 5.1 FACILITIES......................................................................................................................................................9 5.2 LABORATORYACCREDITATIONSAND LISTINGS..................................................................................9 6 TEST SYSTEM UNCERTAINTY........................................................................................................................10 7 SETUPOFEQUIPMENT UNDER TEST...........................................................................................................11 7.1 RADIO FREQUENCYTEST SETUP1.........................................................................................................11 7.2 RADIO FREQUENCYTEST SETUP2.........................................................................................................11 7.3 CONDUCTED EMISSION TEST SETUP.....................................................................................................12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM.....................................................................13 7.5 SUPPORT EQUIPMENT................................................................................................................................13 8 TEST REQUIREMENTS..................................................................................................................................... 14 8.1 DTS (6DB) BANDWIDTH.............................................................................................................................14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER................................................................................21 8.3 MAXIMUM POWER SPECTRAL DENSITY...............................................................................................22 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS.............................................29 8.5 RADIATED SPURIOUS EMISSION.............................................................................................................46 8.6 CONDUCTED EMISSIONS TEST................................................................................................................54 8.7 ANTENNAAPPLICATION........................................................................................................................... 55 Report No.: ED210508058WPage 3 of 57 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant:NASS (HK) LIMITED. 2/F., On Tin Centre, 1 Sheung Hei Street, San Po Kong, Kowloon, Hong Kong. Manufacturer:NASS (HK) LIMITED. 2/F., On Tin Centre, 1 Sheung Hei Street, San Po Kong, Kowloon, Hong Kong. EUT Description:WIFI SENSOR Model Number:WT06, WT86, SWIFI-WDOOR Trade Mark:N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARDTEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK (DONGGUAN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test :May 29, 2021 to Jul 05, 2021 Prepared by : Loren Luo / Editor Reviewer : Tomas Yang/Supervisor Approve & Authorized Signer : Sam Lv/Manager Report No.: ED210508058WPage 4 of 57 Ver.1.0 2 EUT TECHNICAL DESCRIPTION CharacteristicsDescription IEEE 802.11 WLAN Mode Supported 802.11b 802.11g 802.11n(20MHz channel bandwidth) 802.11n(40MHz channel bandwidth) Data Rate WIFI: 802.11 b:1,2,5.5,11Mbps; 802.11 g:6,9,12,18,24,36,48,54Mbps; 802.11n(HT20): up to 144.4Mbps; 802.11n(HT40): up to 300Mbps; Modulation WIFI: DSSS with DBPSK/DQPSK/CCK for 802.11b; OFDM with BPSK/QPSK/16QAM/64QAM for 802.11g/n; Operating Frequency Range WIFI: 2412-2462MHz for 802.11b/g/n(HT20); 2422-2452MHz for 8…

Text truncated - open the document above for the full version.
