2AZRBWT82WIFI SENSOR

1 EN Leak Alert Sensor Sensor de alerta de filtración Capteur d’alerte de fuite Sensore di avviso perdita Leckwarnsensor EN Quick Start Guide ES Guía de inicio rápido FR Guide de démarrage rapide IT Guida rapida DE Schnellstartanleitung 2 EN OVERVIEW Cable length 1.9m (6ft 3”) Water-sensing metal contacts Status light Sensor Cover screw Remove to access battery compartment and QR code (located under cover) 3 EN BATTERY INSTALLATION 1 Unscrew the sensor cover with the supplied screwdriver and lift it off. 2 Insert the supplied two AAA batteries into the battery compartment according to the polarity markings (+ and -) shown. Pairing mode will automatically activate on the sensor for 3 minutes when batteries are inserted. The sensor status light will blink blue slowly during pairing mode. If you have downloaded the Swann Security app on your mobile device (see page 4), you can proceed to the pairing process (see page 5). Note: Pairing mode on the sensor can be activated at any time by re-inserting the batteries. 3 After you have paired the sensor, replace the cover and screw it firmly in place. 4 Should you need to replace the batteries in the future, there is no need to re-pair the sensor. Simply wait for pairing mode to timeout (3 minutes), after which the sensor will automatically reconnect to the previously configured Wi-Fi network. 4 EN DOWNLOAD THE SWANN SECURITY APP 1 Download the latest version of the Swann Security app from the Apple App Store® or Google Play™ Store on your iOS or Android device. Simply search for "Swann Security". 2 Open the app and create your Swann Security account by tapping “Not yet registered? Sign Up” at the bottom of the screen. Then, activate your Swann Security account by confirming the verification email that is sent to the registered email address. 5 EN Open the Swann Security app and tap the Pair Device button on the screen. If you have already paired a device, tap the menu icon in the top left and select “Pair Device”. The app will now guide you through the pairing process and set up the sensor. Before you begin, have the sensor with you and be close to your router. Please note that the sensor can connect to a 2.4GHz Wi-Fi network only. SET UP THE SENSOR 6 EN • Place the sensor using the included double-sided tape in areas around your home where there is the potential for water leaks, for example, under the kitchen sink, near the washing machine, next to the toilet, water heater, etc. Also included is a pack of cable clips to keep the cable tidy and out of the way. • Make sure the sensor location has strong, reliable Wi-Fi reception available so you can get timely alerts. As a general rule, the nearer your sensor is to your Wi-Fi router, the better the wireless connection quality. You can expand the Wi-Fi coverage of your current network by installing a Wi-Fi range extender. • For reliable bonding, clean the mounting surface with an alcohol/cleaning wipe, and let dry. When mounting the sensor, press firmly to the surface for 60 seconds to ensure proper adhesion. • Make sure the sensor cover will be accessible in the final position (in case of battery replacement/re-pairing). For the sensor to activate, the water-sensing metal contacts should always be placed flat, facing down on the floor. • To test the sensor, put a drop of water on your finger and touch the water-sensing metal contacts. The app will send you a push notification, for example, “Leak has been detected on Laundry Room”. The sensor tile will also automatically update its status in the app, as shown on the right. Pat dry the water-sensing metal contacts. The app will send you another notification, for example, “Leak has been fixed on Laundry Room”. MOUNTING THE SENSOR 7 EN HELP AND RESOURCES Status Light Guide The status light on the sensor tells you what is happening with the device connection. When the sensor is functioning normally, the status light will be off (unless it is out of battery/unpaired). Mounting Examples Swann Security App Manual Access the Swann Security app manual (Menu > User Manual) at any time to learn more about navigating through the various screens and functions in the app. Sensor Battery Level You can check the battery level of the sensor in the app: Devices tab > Sensor > Battery % Slow Blinking BluePairing mode Solid Blue (5 seconds)Leak Detected. Connecting to Wi-Fi. Laundry room Toilet 32 EN M odel: WT82 QSGSWIFILEAKVER15L FCC STATEMENT This equipm ent has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and the receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons. WARNING: Modifications not approved by the p…

Text truncated - open the document above for the full version.

Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesameRFmoduleand antenna,PCBlayout,schematicsandcomponent.Onlydifferentonmodelnumberandcolorofappearance. ProductionnameFCCIDModelno. WIFISENSOR2AZRBWT82 WT04,WT82,WT84,SWIFI-LEAK Confirmedby: Williamma 2021-07-16

RF_160,Issue04 NASS(HK)LIMITED DeclarationofAuthorization We Name:NASS(HK)LIMITED Address:2/FONTINCENTRE1SHEUNGHEISTREETSANPOKONGKOWLOON City:HONGKONG. Country:China. Declarethat: NameRepresentativeofagent:EMTEK(DONGGUAN)CO.,LTD.. (1) AgentCompanyname:SamLv. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnologyReserchand DevelopmentBase,No.9,XinchengAvenue,SongshanhuHigh-technologyIndustrialDevelopmentZone,.. City:Dongguan,Guangdong,.. CountryChina. isauthorizedtoapplyforCertificationofthefollowingproduct(s): Productdescription:WIFISENSOR. Typedesignation:WT04,WT82,WT84,SWIFI-LEAK. Trademark:N/A. Validity/expirydate onourbehalf. Date:2021-7-16.. City:HOGGKONG.. Name:Williamma.. (2) Function:...Manager............................ Signature:. Notes: (1):RequiredforFCCapplication (2):ForFCCitmustbetheGranteeCode“owner”ortheauthorizedagent.

FCC,Requestfornon-disclosureDate:21-Nov-2018 RF_501,Issue8Page1of1 CompanyName:NASS(HK)LIMITED Address:2/FONTINCENTRE1SHEUNGHEISTREETSAN POKONGKOWLOONHONGKONG City:HONGKONG Country:China To:TeleficationB.V.,Dept.FCCTCB Edisonstraat12A 6902PKZEVENAAR TheNetherlands Subject:RequestforconfidentialityFCCID:2AZRBWT82 Referencenumber:WT04,WT82,WT84,SWIFI-LEAK DearFCCTCB, 1.Long-TermConfidentiality Pursuantto47CFRSection0.459(a)&(b),weherebyrequestsnon-disclosureandconfidentialtreatment ofthefollowingmaterialssubmittedinsupportofFCCcertificationapplication: Bill(s)ofMaterialBlockDiagrams OperationalDescriptionSchematicDiagramsTune-upProcedure Abovematerialscontainsecrets,proprietaryandtechnicalinformation,whichwouldcustomarilybe guardedfromcompetitorsunder47CFR,section0.457(d)(2).Disclosureorpublicationoranyportionof thiscompanyconfidentialmaterialtootherpartiescouldcausesubstantialcompetitiveharmandprovide unjustifiedbenefitsforcompetitors. 2.Short-TermConfidentiality(STC) PursuanttoPublicNoticeDA04-1705oftheCommission’spolicy,inordertocomplywiththemarketing regulationsin47CFR§2.803andtheimportationrulesin47CFR§2.1204,applicantherebyrequests Short-TermConfidentialtreatmentofthefollowingmaterials(Seenotesbelow): InternalPhotosUser’sManualTestSet-upPhotosExternalPhotos Justification:Theproducthasnotyetbeenreleasedtopreventothermerchantsfromcopyingit Date:2021-07-16Nameandsignatureofapplicant:Williamma Notes: 1)AdocumentortypeofdocumentcanonlyhaveONEtypeofconfidentiality! 2)Short-Termconfidentialityisinprinciplefor45daysfromdateofgrant;itcanbeextendedmax3times(totaltime180daysmax.)! TheplanneddateshouldstatedintheRF731applicationform. 3)FCCmustbeinformedwhenmarketingbeginsearlier. 4)Releasetakesplaceautomaticallythusextensionmustberequestedintime.Teleficationdoesnotremindyouofthis! 5)RequestforextensionorforreleasemustbereceivedbyTeleficationatleast7daysbeforedateofactualmarketingorbefore expirationoftheSTCperiod

FCC ID:2AZRBWT82

FCC ID: 2AZRBWT82 ANT

RFEXPOSUREEVALUATION EUTSpecification EUTWIFISENSOR ModelNumber WT04,WT82,WT84,SWIFI-LEAK FCCID2AZRBWT82 Antennagain(Max)0dBi OperationFrequencyWIFI:2412MHz-2462MHz InputRatingDC3V ClassificationPer StipulatedTestStandard §15.247(i),§2.1093 ModulationDSSSwithDBPSK/DQPSK/CCKfor802.11b; OFDMwithBPSK/QPSK/16QAM/64QAMfor802.11g/n; Max.outputpower8.91dBm EvaluationappliedMPEEvaluation SAREvaluation TestRequirement: RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiationas specifiedin§1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 1Friistransmissionformula:Pd=(Pout*G)\(4*pi*R 2 ) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainmW G=Numericgainoftheantennarelativetoisotropicantenna Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainofthendtotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancewheretheMPElimitis reached. 2MeasurementResult Antennagain:0dBi Operation Mode Channel Number Channel Frequency (MHz) Measurement Level(dBm) Limit (dBm)Verdict 802.11b 124128.9130PASS 624378.2230PASS 1124628.3430PASS 802.11g 124128.0130PASS 624377.8330PASS 1124627.7830PASS 802.11n (HT20) 124127.4430PASS 624377.6930PASS 1124627.9830PASS 802.11n (HT40) 324226.8530PASS 624376.5430PASS 924526.6230PASS Signature: SamLv Date:2021-07-05

Report No.: ED210508068WPage 1 of 57 Ver.1.0 $印章$ TEST REPORT Product Name ： WIFI SENSOR Model Number ： WT04, WT82, WT84, SWIFI-LEAK FCC ID ： 2AZRBWT82 Prepared for: NASS (HK) LIMITED Address: 2/F ON TIN CENTRE 1 SHEUNG HEI STREET SAN PO KONG KOWLOON HONG KONG Prepared by: EMTEK(DONGGUAN) CO., LTD. Address: -1&2/F.,Buiding 2,Zone A,Zhongda Marine Biotechnology Research and Development Base,N.9,Xincheng Avenue,Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China TEL: +86-0769-22807078 FAX: +86-0769-22807079 Report Number: ED210508068W Date(s) of Tests: May 29, 2021 to Jul 05, 2021 Date of issue: Jul 05, 2021 $二维码$ Report No.: ED210508068WPage 2 of 57 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULTCERTIFICATION.............................................................................................................................................3 2 EUT TECHNICALDESCRIPTION...........................................................................................................................................4 3 SUMMARYOFTEST RESULT..................................................................................................................................................5 4 TEST METHODOLOGY.............................................................................................................................................................6 4.1 GENERAL DESCRIPTION OFAPPLIED STANDARDS....................................................................................................6 4.2 MEASUREMENT EQUIPMENT USED................................................................................................................................6 4.3 DESCRIPTION OF TEST MODES........................................................................................................................................7 4.4 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING...........................................................................................8 5 FACILITIESANDACCREDITATIONS....................................................................................................................................9 5.1 FACILITIES.............................................................................................................................................................................9 5.2 LABORATORYACCREDITATIONSAND LISTINGS........................................................................................................9 6 TEST SYSTEM UNCERTAINTY.............................................................................................................................................10 7 SETUPOFEQUIPMENT UNDER TEST................................................................................................................................11 7.1 RADIO FREQUENCYTEST SETUP1................................................................................................................................11 7.2 RADIO FREQUENCYTEST SETUP2................................................................................................................................11 7.3 CONDUCTED EMISSION TEST SETUP........................................................................................................................... 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM...........................................................................................13 7.5 SUPPORT EQUIPMENT......................................................................................................................................................13 8 TEST REQUIREMENTS...........................................................................................................................................................14 8.1 DTS (6DB)BANDWIDTH....................................................................................................................................................14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER......................................................................................................21 8.3 MAXIMUM POWER SPECTRAL DENSITY.....................................................................................................................22 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS...................................................................29 8.5 RADIATED SPURIOUS EMISSION...................................................................................................................................46 8.6 CONDUCTED EMISSIONS TEST......................................................................................................................................54 8.7ANTENNAAPPLICATION..................................................................................................................................................55 Report No.: ED210508068WPage 3 of 57 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant:NASS (HK) LIMITED. 2/F., On Tin Centre, 1 Sheung Hei Street, San Po Kong, Kowloon, Hong Kong. Manufacturer:NASS (HK) LIMITED. 2/F., On Tin Centre, 1 Sheung Hei Street, San Po Kong, Kowloon, Hong Kong. EUT Description:WIFI SENSOR Model Number:WT04, WT82, WT84, SWIFI-LEAK Trade Mark:N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARDTEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK (DONGGUAN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test :May 29, 2021 to Jul 05, 2021 Prepared by : Loren Luo / Editor Reviewer : Tomas Yang/Supervisor Approve …
