Shenzhen Atongmu Technology Co., LTD Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 [March 16, 2026] U.S. Agent Designation [Shenzhen Atongmu Technology Co., LTD] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought FCC ID: 2BAAR-AE211 Name and company of U.S. agent: [GLOCERTS TECHNOLOGY INC] Physical U.S. address of agent: [19784 SUNKISSED RIDGE DR, RIVERSIDE, CA 92507] FRN of U.S. agent: [0036339737] Email address of U.S. agent: [[email protected]] Telephone of U.S.agent: (626) 588-8039 [GLOCERTS TECHNOLOGY INC] acknowledges their obligation to accept service of process on behalf of [Shenzhen Atongmu Technology Co., LTD]. [Shenzhen Atongmu Technology Co., LTD] with the FRN [0033410853] accepts its obligation to maintain an agent for service of process in the United States for no less than 1 year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Signature [Owen Hu] [Huiying Fan] [Operations Director] [Director] [Shenzhen Atongmu Technology Co., LTD] [GLOCERTS TECHNOLOGY INC]

Shenzhen Atongmu Technology Co., LTD 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Product Name: Projector FCC ID: 2BAAR-AE211 Model(s): AE211B, AE211, AE211B, AE211G, AE211C, AE211D, AA211B, AA211G, AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C, AA212D 2.911(d)(5)(i) Equipment Type We, [Shenzhen Atongmu Technology Co., LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Owen Hu Date: 2026.03.12 Title and Company name: Operations Director / Shenzhen Atongmu Technology Co., LTD NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Atongmu Technology Co., LTD 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Product Name: Projector FCC ID: 2BAAR-AE211 Model(s): AE211B, AE211, AE211B, AE211G, AE211C, AE211D, AA211B, AA211G, AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C, AA212D 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Atongmu Technology Co., LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Owen Hu Date: 2026.03.12 Title and Company name: Operations Director / Shenzhen Atongmu Technology Co., LTD NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 Shenzhen Atongmu Technology Co., LTD 2.911 (d)(5)(ii) Applicant Attestation v1.2 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen Atongmu Technology Co., LTD Agent Authorization Company: Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Product Name: Projector Model Number(s): AE211B, AE211, AE211B, AE211G, AE211C, AE211D, AA211B, AA211G, AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C, AA212D Product Description: Projector We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: March 12, 2026 Name: Owen Hu Title: Operations Director Company: Shenzhen Atongmu Technology Co., LTD

Shenzhen Atongmu Technology Co., LTD Model Difference Data：March 12, 2026 Product description: Projector Model name: AE211B, AE211, AE211B, AE211G, AE211C, AE211D, AA211B, AA211G, AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C, AA212D Trade Name: FCC ID: 2BAAR-AE211 All the model are the same circuit and RF module, only the color and shell are different. Regards Sincerely Client’s signature : Client’s name / title : Owen Hu（Operations Director） Contact information / address：Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China

Shenzhen Atongmu Technology Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March 12, 2026 Subject; Request for Confidentiality FCC ID: 2BAAR-AE211 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description FCC Software Security Requirements for UNII devices Rev 2.1 In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Owen Hu Title: Operations Director

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 5 Model: AE211B External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 5 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 5 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 5 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 5

FCC ID LABEL: 40*20mm Label Location:

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 5 Model: AE211B Internal Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 5 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 5 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 5 ANT Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 5

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2BAAR-AE211 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation BT+WIFI supported simultaneous transmission: BLE+2.4GWIFI: ∑MPE Ratio =0.0023/1+0.0228/1=0.0251≤1, BLE+5GWIFI: ∑MPE Ratio =0.0023/1+0.0175/1=0.0198≤1, So passed. Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result BLE GFSK& HCH 8±1 9 7.9433 1.4421 (1.59dBi) 0.0023 1 Pass EDR 8DPSK& HCH 3±1 4 2.5119 1.4421 (1.59dBi) 0.0007 1 Pass 2.4G WIFI 802.11ax( HE20)& MCH 18±1 19 79.4328 1.4421 (1.59dBi) 0.0228 1 Pass 5.2GWIFI 802.11ac4 0&5190 14±1 15 31.6228 2.6977 (4.31dBi) 0.017 1 Pass 5.8GWIFI 802.11ax4 0&5795 14±1 15 31.6228 2.7861 (4.45dBi) 0.0175 1 Pass

Report Tel : 4008-707- 283Web: http://www.ctb-lab.net Page 1 of 84 TEST REPORT Compiled by:Reviewed by:Approved by: KaiChenMartinFengBin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description:Projector FCC ID:2BAAR-AE211 Trademark(s): Model/Type reference: AE211B,AE211,AE211G,AE211C,AE211D,AA211B,AA211G,AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C,AA212D Applicant’s name:Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Manufacturer:Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Prepared By:Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F.,BuildingA,No.26,XinheRoad,Xinqiao,XinqiaoStreet,Bao'anDistrict, Shenzhen,Guangdong,China Sample Received Date:Jan. 05, 2026 Sample tested Date:Jan. 05, 2026 to Mar. 17, 2026 Issue Date:Mar. 17, 2026 Report No.:CTB26010505705RF03 Test Standards FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2020 Test ResultsPASS Remark:This is WIFI-2.4GHz band radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB26010505705RF03 Report Tel: 4008-707- 283 Web: http://www.ctb-lab.net Page 2 of 84 TABLE OF CONTENT Test Report Declaration Page 1. VERSION .......................................................................... 3 2. TEST SUMMARY ................................................................... 4 3.MEASUREMENT UNCERTAINTY.....................................................5 4.PRODUCT INFORMATION AND TEST SETUP..........................................6 4.1 Product Information .................................................................... 6 4.2 Test Setup Configuration ............................................................... 6 4.3 Support Equipment .................................................................... 6 4.4 Channel List .......................................................................... 6 4.5 Test Mode ............................................................................ 7 4.6 Test Environment ...................................................................... 7 5.TEST FACILITYAND TEST INSTRUMENT USED.......................................8 5.1 Test Facility ........................................................................... 8 5.2 Test Instrument Used .................................................................. 8 6. AC POWER LINE CONDUCTED EMISSION............................................11 6.1 Block Diagram Of Test Setup .......................................................... 11 6.2 Limit ................................................................................ 11 6.3 Test procedure ....................................................................... 11 6.4 Test Result .......................................................................... 13 7. RADIATED SPURIOUS EMISSION................................................... 15 7.1 Block Diagram Of Test Setup .......................................................... 15 7.2 Limit ................................................................................ 15 7.3 Test procedure ....................................................................... 16 7.4 Test Result .......................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS .......................... 49 8.1 Block Diagram Of Test Setup .......................................................... 49 8.2 Limit ................................................................................ 49 8.3 Test procedure ....................................................................... 49 8.4 Test Result .......................................................................... 50 9. CONDUCTED OUTPUT POWER . .................................................... 62 9.1 Block Diagram Of Test Setup .......................................................... 62 9.2 Limit ................................................................................ 62 9.3 Test procedure ....................................................................... 62 9.4 Test Result .......................................................................... 63 10.6DB OCCUPIED BANDWIDTH ....................................................... 66 10.1 Block Diagram Of Test Setup ......................................................... 66 10.2 Limit ............................................................................... 66 10.3 Test procedure ...................................................................... 66 10.4 Test Result ......................................................................... 67 11.POWER SPECTRAL DENSITY ...................................................... 74 11.1 Block Diagram Of Test Setup ......................................................... 74 11.2 Limit ............................................................................... 74 11.3 Test procedure ...................................................................... 74 11.4 Test Result ..............................................................…

Text truncated - open the document above for the full version.

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 43 TEST REPORT Compiled by: Reviewed by: Approved by: Kai Chen Martin Feng Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description: Projector FCC ID: 2BAAR-AE211 Trademark(s): Model/Type reference: AE211B, AE211, AE211G, AE211C, AE211D, AA211B, AA211G, AA211C, AA211D, AE212, AE212B, AE212G, AE212C, AE212D, AA212B, AA212G, AA212C, AA212D Applicant’s name: Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Manufacturer: Shenzhen Atongmu Technology Co., LTD Address: Room 605, Office A Dong, Qiaohongsheng Wenhua Chuangyiyuan, Yintian Gongyequ, Yantian Shequ, Xixiang Jiedao, Baoan Qu, Shenzhen Shi, Guangdong, 518000, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jan. 05, 2026 Sample tested Date: Jan. 05, 2026 to Mar. 12, 2026 Issue Date: Mar. 12, 2026 Report No.: CTB26010505705RF01 Test Standards FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2020 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB26010505705RF01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 43 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 3 2. TEST SUMMARY ........................................................................................................................... 4 3. MEASUREMENT UNCERTAINTY ................................................................................................. 5 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 6 4.1 Product Information .......................................................................................................................... 6 4.2 Test Setup Configuration .................................................................................................................. 6 4.3 Support Equipment........................................................................................................................... 6 4.4 Channel List ..................................................................................................................................... 7 4.5 Test Mode ........................................................................................................................................ 7 4.6 Test Environment ............................................................................................................................. 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 8 5.1 Test Facility ...................................................................................................................................... 8 5.2 Test Instrument Used ....................................................................................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 11 6.1 Block Diagram Of Test Setup ......................................................................................................... 11 6.2 Limit ................................................................................................................................................ 11 6.3 Test procedure ............................................................................................................................... 11 6.4 Test Result ..................................................................................................................................... 13 7. RADIATED SPURIOUS EMISSION ............................................................................................. 15 7.1 Block Diagram Of Test Setup ......................................................................................................... 15 7.2 Limit ................................................................................................................................................ 15 7.3 Test procedure ............................................................................................................................... 16 7.4 Test Result ..................................................................................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 24 8.1 Block Diagram Of Test Setup ......................................................................................................... 24 8.2 Limit ................................................................................................................................................ 24 8.3 Test procedure ............................................................................................................................... 24 8.4 Test Result ............…

Text truncated - open the document above for the full version.

Page1 AntennaApproval Sheet For AE211B-723AntennaProject （ TX-WIFITXO003 ） CustomerProject AE211B-723 BandWiFi2.4GHZ/5GHZ/BT2.4GHZ ZCPNAE005-PA-96 VersionR:AData2025-12-16 RFME CheckedBy ConfirmedBy CustConfirm Page2 1. Summary of the DUT Antenna Picture 2. Electrical Specification: Antenna typesBuilt-in WIFI Antenna Frequency2400-2500 MHz,5150-5350MHZ，5725-5850MHz Impedance 50 Ω VSWR< 2.0 Peak Gain 2.4GHZ 1.73dbi, 5.1GHZ 4.31dbi, 5.8GHZ 4.45dbi Efficiency>35 % Antenna MaterialPCB+Coaxial line Connector Type1.13 MHF-1-Plug 3. Test Condition 3.1 TEST ITEMTESTING INSTRUMENT REMARK S ACTIVE TEST 1.Antenna Gain 2. S.W.R 3. Return Loss 4. Radiation Pattern 1.Network analyzer （ R&S ZVL6 ） 2. Network analyzer （ HP8753D ） 3.2 Matching CircuitThe matching circuit was Default Page3 4.1 RFPerformance-WIFIAntenna 4.1.1 Passive parameters Freq.(MHz)24002410242024302440245024602470248024902500 Gain (dBi) 0.580.661.11.021.171.590.720.080.721.191.73 Freq.(MHz)51505170519052105230525052705290531053305350 Gain (dBi) 3.133.453.564.114.314.214.13.823.283.193.04 Freq.(MHz)572057405760578058005820584058605880 Gain (dBi) 2.514.453.324.182.544.011.412.471.09 4.1.2 S Parameter Frequency (MHz)240024502480 Return Loss(dB)-20.58-22.74-15.39 VSWR1.631.281.81 Page4 4.1.3 Radiation Gain:0.58(dBi) Gain:1.59(dBi) Gain:1.73(dBi) Page5 Gain:3.13(dBi) Gain:4.31(dBi) Gain:3.04(dBi) Page6 Gain:2.51(dBi) Gain:4.45(dBi) Gain:2.47(dBi) Page7 4.2 RFPerformance-BTAntenna 4.2.1 Passive parameters Freq.(MHz)24002410242024302440245024602470248024902500 Gain (dBi)0.580.661.11.021.171.590.720.080.721.191.73 4.2.2 S Parameter 4.2.3 Radiation Gain:0.58(dBi) Gain:1.59(dBi) Gain:1.73(dBi) Frequency (MHz)240024502480 VSWR1.631.281.81 Page8 5. ME Drawing for the antenna

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: AE211B Radiated Emission Below 1G Above 1G Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Conducted emissions
