2BACV-MIC204Wireless microphone

1.Please don’t play music while charging. 2.When the microphone is turned on, do not point it strait to the speaker to avoid howling. Charging Instruction: Both speaker and wireless microphone are charged by usb charging cable. The red light is always on when charging, and it will be o when speaker and microphone are fully charged Note: Speaker Power Supply: Built-in 7.4V 1200mAh 18650 Li-batery Mic Power Supply: Built-in 3.7V 500mAh 14500 Li-battery. Frequency: 100HZ---18KHZ Driver unit: 3”*2 Driver Power output: 10W+10W, each driver 10W, total 20W Material : Plastic + Metal mesh Product Parametes: Packing list: Description: 1. Speaker..........1PC 2. Microphone.............2pcs 3. User Manual.............1pc 4. USB charging cable............1pc 5. Aux-in cable............1pc pause & play NEXT song PREVIOUS song V+V- ON/OFF TF DC 5V AUX-IN USB Karaoke Speaker Manual ISK204-BLK 1.Microphone ON/OFF press and hold 3 seconds to turn on and o the microphone 2.Auto-pairing microphone, when both the speaker and microphone is turned on, microphone will automatically connect to the speaker by bluetooth technology working range:10m 3.Double click on/o button to be with/without reverberation, single click is Mute 4 .Charging time for microphone is 2.5 hours, and playtime is 8 hours 5.The light indicator will be red all the time when charging, and will be o when fully charged. Turn on the speaker, find paring name: on your phone, the speaker will say “Let’s sing” after paring successfully. Microphone bluetooth paring: turn on the microphone by long pressing the on/o button for 3 seconds, the indicator will be flashing between blue and red light before paring, and the microphone bluetooth will automatically connect to the speaker after paring successfully the indicator will be red Lighting function: 5 color LED light eect, changing all the time at the front of the speaker Bluetooth Paring: Colorful Karaoke Lights Design: Power/ Reverberation Button function: +: Short press “+”, it will be NEXT song, long press “+” to increase the volume _: Short press “_”, it will be PREVIOUS song, long press “_” to decrease the volume : short press to pause and play music ISK204 Karaoke Speaker Lighting area Lighting area Model: MIC204 FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates , uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

DongguanUnityWinElectronicTechCo.,Limited 2.911(d)(7)USAAgentv1.4 Section2.911(d)(7)USAAgentforServiceofProcess Companyname:DongguanUnityWinElectronicTechCo.,Limited Address:F501,Building2,No.30XinHuaRd,WanJiangStreet,Dongguan, Guangdong,China ProductName:Wirelessmicrophone FCCID:2BACV-MIC204 Model(s):MIC204,MIC204-BLK, 2.911(d)(7)USADesignatedAgentforServiceofProcess We,[DongguanUnityWinElectronicTechCo.,Limited](“theapplicant”)designate [SakarInternationalInc.] NOTE1 forthepurposeofacceptingserviceofprocesson behalfoftheapplicant. Applicantconsent:Weacknowledgeourconsenttoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipment,andatthephysicalU.S. addressandemailaddressofthedesignatedagentandacknowledgeour acceptanceofourobligationtomaintainanagentforserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherwethegranteehavepermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S., orattheconclusionofanyCommission-relatedadministrativeorjudicialproceeding involvingtheequipment,whicheverislater. Agentobligation:Weacknowledgeourobligationtoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipmentatourphysicalU.S. addressandemailaddressfornolessthanoneyearaftereitherthegranteehas permanentlyterminatedallmarketingandimportationoftheapplicableequipment withintheU.S.,orattheconclusionofanyCommission-relatedadministrativeor judicialproceedinginvolvingtheequipment,whicheverislater. DongguanUnityWinElectronicTechCo.,Limited 2.911(d)(7)USAAgentv1.4 USAAgent Companyname:SakarInternationalInc. USAAddress:195CarterDrive,Edison,New Jersey,08817UnitedStates FRNNumber:0028102671 ContactName:DAWNLEITAO TelephoneNo:8006371090 Email:[email protected] Applicant Companyname:DongguanUnityWin ElectronicTechCo.,Limited Address:F501,Building2,No.30XinHua Rd,WanJiangStreet,Dongguan, Guangdong,China FCCGranteeCode:2BACV ContactName:MaryChen TelephoneNo:+86-0769-22224037 Email:[email protected] Signature: Title:ProjectManager Signature: Title:Manager Date:2023-05-12Date:2023-05-12 NOTE1:AnapplicantlocatedintheUnitedStatesmaydesignateitselfastheagentforservice ofprocess. Reference;FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Dongguan Unity Win Electronic Tech Co., Limited Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 24, 2023 FCC ID: 2BACV-MIC204 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Dongguan Unity Win Electronic Tech Co., Limited certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Dongguan Unity Win Electronic Tech Co., Limited certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Dongguan Unity Win Electronic Tech Co., Limited Address: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China Contact Person: Mary Chen Tel.: +86-0769-22224037 Email: [email protected] Sincerely, Signature:

Dongguan Unity Win Electronic Tech Co., Limited Date: May 24, 2023 Product Model Number: MIC204, MIC204-BLK FCC ID: 2BACV-MIC204 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +86-0769-22224037 On behalf of: Dongguan Unity Win Electronic Tech Co., Limited

Dongguan Unity Win Electronic Tech Co., Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 24, 2023 Subject; Request for Confidentiality FCC ID: 2BACV-MIC204 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mary Chen Title: Manager

Dongguan Unity Win Electronic Tech Co., Limited Model Difference Statement Dear Sir/Madam, Added models MIC204-BLK basis of the original product MIC204. The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, Name: Mary Chen Title: Manager Company name: Dongguan Unity Win Electronic Tech Co., Limited Address: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China

Report No: SSP23050051A Antenna Test Report Page 1 of 4 Antenna Test Report Test Standard: IEEE 149-1979 Manufacturer: Dongguan Unity Win Electronic Tech Co., Limited Product Name: 2.4GHz Antenna Model: MIC204 Report No.: SSP23050051A Tested Date: 2023-05-05 Issued Date: 2023-05-09 Tested By: William Liu (Engineer) Approved By: Lahm Peng (Manager) Prepared By: Shenzhen ZRLK Testing Technology Co., Ltd. 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Tel.: +86-755-33019599 Fax.: +86-755-33019599 Website: www.zrlklab.com Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen ZRLK Testing Technology Co., Ltd. Report No: SSP23050051A Antenna Test Report Page 2 of 4 1. General Information 1.1 Product Information Manufacturer Manufacturer: Dongguan Unity Win Electronic Tech Co., Limited Address of Manufacturer: F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China General Description of Antenna Product Name: 2.4GHz Antenna Model No.: MIC204 Frequency Range: 2400MHz-2483.5MHz Type of Antenna: PCB Antenna Antenna Gain: 0dBi (Max.) Impedance: 50 ohm Antenna View (15mm*5mm) 1.2 Test Methodology All measurements contained in this report were conducted with standards IEEE 149-1979 for IEEE Standard Test Procedures for Antennas. 1.3 Test Facilities Testing Lab: Shenzhen ZRLK Testing Technology Co., Ltd. All measurement facilities used to collect the measurement data are located at 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Report No: SSP23050051A Antenna Test Report Page 3 of 4 2. OTA Test 2.1 Gain Frequency Peak Gain (dBi) Polarity 2402MHz 0 Horizontal 2402MHz -0.85 Vertical 2442MHz -1.67 Horizontal 2442MHz -2.23 Vertical 2480MHz -2.44 Horizontal 2480MHz -2.93 Vertical 2.2 Radiation Pattern View Report No: SSP23050051A Antenna Test Report Page 4 of 4

FCC ID: 2BACV-MIC204 EUT PHOTO(External Photos)

Page 1 of 1 Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

FCC ID: 2BACV-MIC204 EUT PHOTO(Internal Photos) BT ANT

FCC ID: 2BACV-MIC204 RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093， Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BR+EDR Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 1.64 1(±1) 2 1.585 2480 5 0.499212 3.0 So a SAR test is not required

Project No.: ZKT-230518L3654E Page 1 of 58 FCC TEST REPORT FCC ID: 2BACV-MIC204 Report Number. .............................. : ZKT-230518L3654E Date of Test ..................................................: May 11 2023 to May 22, 2023 Date of issue ..................................... : May 23, 2023 Total number of pages ....................... 58 Test Result ...................................... : PASS Testing Laboratory......................... : Shenzhen ZKT Technology Co., Ltd. Address ........................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : Dongguan Unity Win Electronic Tech Co., Limited Address ........................................... : F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China Manufacturer's name ................... : Dongguan Unity Win Electronic Tech Co., Limited Address ........................................... : F501, Building 2, No.30 XinHua Rd, WanJiang Street, Dongguan, Guangdong, China Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method .............. : N/A Test Report Form No. .................... : TRF-EL-112_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF ................................... : Dated: 2021-07-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : Wireless microphone Trademark ....................................... : VIVITAR Model/Type reference ....................... : MIC204, MIC204-BLK Ratings.............................................. : DC 3.7V by battery, USB 5V charging Testing procedure a nd testing location: Testing Laboratory ..................................... :Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Jim Liu Tested by (name + signature) .................... : Jackson Fan g Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-230518L3654E Page 2 of 58 Project No.: ZKT-230518L3654E Page 3 of 58 Table of Contents Page 1. VERSION .............................................................. 5 2. TEST SUMMARY ........................................................ 6 2.1 TEST FACILITY ......................................................... 7 2.2 MEASUREMENT UNCERTAINTY.......................................... 7 3. GENERAL INFORMATION ............................................... 8 3.1 GENERAL DESCRIPTION OF EUT ........................................ 8 3.2 Test Setup Configuration .................................................. 9 3.3 Support Equipment ....................................................... 9 3.4 Test Mode ............................................................. 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS ................................ 11 4. EMC EMISSION TEST .................................................. 13 4.1 Conducted emissions .................................................... 13 4.1.1 POWER LINE CONDUCTED EMISSION Limits ........................... 13 4.1.2 TEST PROCEDURE ................................................... 13 4.1.3 DEVIATION FROM TEST STANDARD ................................... 13 4.1.4 TEST SETUP ......................................................... 13 4.1.5 EUT OPERATING CONDITIONS ........................................ 14 4.1.6 Test Result ........................................................... 15 4.2 Radiated emissions ..................................................... 17 4.2.1 Radiated Emission Limits ............................................... 17 4.2.2 TEST PROCEDURE ................................................... 17 4.2.3 DEVIATION FROM TEST STANDARD ................................... 18 4.2.4 TEST SETUP ......................................................... 18 4.2.5 EUT OPERATING CONDITIONS ........................................ 19 4.2.6 TEST RESULTS ...................................................... 19 5. RADIATED BAND EMISSION MEASUREMENT ............................ 26 5.1 Test Requirement: ...................................................... 26 5.2 TEST PROCEDURE .................................................... 26 5.3 DEVIATION FROM TEST STANDARD .................................... 27 5.4 TEST SETUP .......................................................... 27 5.5 EUT OPERATING CONDITIONS ......................................... 27 5.6 TEST RESULT ......................................................... 28 6. CONDUCTED BAND EDGE AND SPURIOUS EMISSION .................... 29 6.1 Limit ................................................................... 29 6.2 Test Setup ............................................................. 29 6.3 Test procedure ......................................................... 29 6.4 DEVIATION FROM STANDARD .......................................... 29 6.5 CSE Test Result ........................................................ 30 7. 20DB&99% BANDWIDTH ............................................... 38 7.1 Test Setup ............................................................. 38 7.2 Limit ................................................................... 3…

Text truncated - open the document above for the full version.

EUT TEST PHOTO FCC ID: 2BACV-MIC204 Radiated band emission (30MHz-1GHz): Conducted emission: Radiated band emission (Above 1GHz):
