IIIIE FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC RF Radiation Exposure and SAR Statements The Smart Phone / F113 has been tested for body-worn Specific Absorption Rate(SAR) compliance. The FCC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has been evaluated under FCC Bulletin C95.1 and IEEE 1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest reported SAR level for usage near the body ( 1 0mm) is 0.721 W/kg, Body Simultaneous transmission is 1. 101 W/kg at the same time. SAR level for usage near the Head is 0.960W/kg and Head simultaneous transmission is 1.535W/kg. SAR level for usage near the Hotspot is 0.721 W/kg and Headsimultaneous transmission is 1.101W/kg.

Ref : ACR.262.12..MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK,No.190, CHONGQINGROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONGCHINA MVG COMOSAR REFERENCE WAVEGUIDE FREQUENCY: 5000-6000 MHZ SERIAL NO.: SN 13/14 WGA32 SAR Reference Waveguide Calibration Report Summary: Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise - 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibretion date: Page: 1/11 2 3 07/04/2023 Accreditations #2-6789 and #2-6814 Scope available on www.cofrac.fr This document presents the method and results from an accredited SAR reference dipole calibration performed in MVG using the COMOSAR test bench. All calibration results are traceable to national metrology institutions. SAR REFERENCE WAVEGUIDE CALIBRATION REPORT Ref: ACR.262.12..MVGB.A Page: 2/13 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Technical Manager Checked by : Jérôme LUC Technical Manager Approved by : Yann Toutain Laboratory Director Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A Initial release Name Jérôme LUC 7/0/202 3 4 7/0/202 3 4 7/0/202 3 4 7/0/202 3 4 2 3 SAR REFERENCE WAVEGUIDE CALIBRATION REPORT Ref: ACR.262.12..MVGB.A TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 4 4.1 Return Loss Requirements __________________________________________________ 4 4.2 Mechanical Requirements ___________________________________________________ 4 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 5 6.1 Return Loss ______________________________________________________________ 5 6.2 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 6 7.1 Head Liquid Measurement __________________________________________________ 7 7.2 Measurement Result _______________________________________________________ 7 7.3 Body Measurement Result _________________________________________________ 10 8 List of Equipment .................................................................................................... 13 Page: 3/13 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH 2 3 SAR REFERENCE WAVEGUIDE CALIBRATION REPORT Ref: ACR.262.12..MVGB.A 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528 and CEI/IEC 62209 standards for reference waveguides used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 5000-6000 MHz REFERENCE WAVEGUIDE Manufacturer MVG Model SWG5500 Serial Number SN 13/14 WGA32 Product Condition (new / used) Used A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION MVG’s COMOSAR Validation Waveguides are built in accordance to the IEEE 1528 and CEI/IEC 62209 standards. 4 MEASUREMENT METHOD The IEEE 1528 and CEI/IEC 62209 standards provide requirements for reference waveguides used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The waveguide used for SAR system validation measurements and checks must have a return loss of -8 dB or better. The return loss measurement shall be performed with matching layer placed in the open end of the waveguide, with the waveguide and matching layer in direct contact with the phantom shell as outlined in the fore mentioned standards. 4.2 MECHANICAL REQUIREMENTS The IEEE 1528 and CEI/IEC 62209 standards specify the mechanical dimensions of the validation waveguide, the specified dimensions are as shown in Section 6.2. Figure 1 shows how the dimensions relate to the physical construction of the waveguide. Page: 4/13 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH 2 3 SAR REFERENCE WAVEGUIDE CALIBRATION REPORT Ref: ACR.262.12..MVGB.A 5 MEASUREMENT UNCERTAINTY All uncertainties listed below represent an expanded uncertainty expressed at approximately the…

Text truncated - open the document above for the full version.

Page 1 of 3 FCC ID: 2BAK2-F113 Conducted emissions 30MHz-1GHz Page 2 of 3 FCC ID: 2BAK2-F113 Spurious emissions

SAR Setup photos for FCC ID: 2BAK2-F113 Right Touch Right Tilt Left Touch Left Tilt Body Front side(separation distance is 10mm) Body Back side(separation distance is 10mm) Body Left side(separation distance is 10mm) Body Right side(separation distance is 10mm) Body Bottom side(separation distance is 10mm) Body Top side(separation distance is 10mm)

ShenZhenQiXinTongDaTechnologyCo.,Ltd. AntennaTestReport 客户:启昌 项目:F13 GSM2/3/5/8+W1/2/4/5/8+LTE1/2/3/4/5/7/8/12/17/18/19/20/25/26/28/3 4/38/39/40/41/66+N1/3/7/8/28/38/41/77/78 工程：傅工（18718936792） 日期：2025-7-24 ADDRESS：Room503-505,Building211, TairanIndustrialandTradePark,Chegongmiao,FutianDistrict,Shenzhen 1.TestProject 2.TestEquipment Agilent5071B（SParameter（RL/VSWR）TestEquipment TestProjectEquipment 1.SParameter1.ReturnLoss(RL) 2.VSWR NetworkAnalyzer： Agilent5071B 2.RFTest （2/3/4/5G） 1.power 2.level 3.TRP/TIS ComprehensiveTest： SP9500/CMW500/8960 TestEnvironment： AnechoicChamber SP9500（5GTestEquipment） Agilent8960（ 2G/3GTestEquipment ） CMW500（2G/3G/4GTestEquipment） 3.TestEnvironment MicrowaveAnechoicChamber 4.TestSteps PassiveVSWR/RLTestSteps: Gain/EfficiencyTestSteps: ActiveTRP/TISTestSteps： 50 Ω CoaxialCable 90mmLength CopperPipe 5071BNetwork Analyzer TestFixture OpenComputerOTA TestSoftware OpenTurntableSwitch AndResetTozero Open8960/CMW500 TestEquipment TestmobilephoneinserttestSIM cardandPutintothemicrowave darkroomtoconnect OTASoftwareautomatic testing OpenComputer Gain/Efficiency TestSoftware OpenTurntableSwitch AndResetTozero Open5071B TestEquipment PuttheTestedobjectintothe microwavedarkroomtoconnect OTASoftwareautomatic testing OutputData 5.Antennafrequencybanddistribution 6.Antennadistributiondiagram 7.AntennaDimensions 8.AntennaGain(dBi) BandMaxGainBandMaxGain GSM850(824-894MHz)-0.28LTE-B38(2570-2620)-1.42 GSM900(880-960MHz)-0.20LTE-B39(1880-1920)-0.03 DCS1800(1710-1880MHz)-0.64LTE-B40(2300-2400)-0.77 PCS1900(1850-1990MHz)-0.03LTE-B41(2496-2690)-1.42 WCDMA1(1920-2170MHz)0.95NR-B1(1920-2170)0.95 WCDMA2(1850-1990MHz)-0.03NR-B3(1710-1880)-0.64 WCDMA4(1712-2153MHz)-0.64NR-B7(2500-2690)-1.42 WCDMA5(826-892MHz)-0.28NR-B8(880-960)-0.20 WCDMA8(882-958MHz)-0.20NR-B28(703-803)-2.62 LTE-B1(1920-2170)0.95NR-B38(2570-2620)-0.22 LTE-B2(1850-1990)-0.03NR-B41(2496-2690)-0.22 LTE-B3(1710-1880)-0.64NR-B77(3300-4200)0.74 LTE-B4(1710-2155)-0.64NR-B78(3300-3800)0.69 LTE-B5(824-894)-0.28 LTE-B7(2500-2690)-1.42 LTE-B8(880-960)-0.20 LTE-B12(699-746)-1.45 LTE-B17(704-746)-1.45 LTE-B18(815-875)-0.28 LTE-B19(830-890)-0.28 LTE-B20(791-862)-0.28 LTE-B25(1850-1995)-0.64 LTE-B26(814-894)-0.28 LTE-B28(703-803)-1.45 LTE-B66(1710-2200)-0.64 LTE-B34(2010-2024)0.03 (L1/BT/WIFI2.4/5-7.125G) BandMaxGain Bluetooth(2402-2480)0.14 WIFI-2.4(2412-2484)0.14 WIFI-5.1(5150-5350)1.10 WIFI-5.8(5725-5850)1.69 GPS-L1(1575.42)-0.36 (L4/WIFI2.4/5-7.125G) BandMaxGain WIFI-2.4(2412-2484)-0.68 WIFI-5.1(5150-5350)1.90 WIFI-5.8(5725-5850)1.61 GPS-L4(1379.91)-0.99 9.2D&3DLobeDiagram BT 2.4GWIFI 5.1GWIFI 5.8GWIFI GPS-L1 2.4GWIFIMIMO 5.1GWIFIMIMO 5.8GWIFIMIMO GPS-L4 10.IntroductiontoAntennaInformation F13 Antennatypeandfrequencyband MAINANTENNA(PIFA):2G/3G/4G/5G DIVANTENNA(PIFA):2G/3G/4G/5G GPS/WIFI/BTANTENNA(PIFA): L1/L4/WIFI(2.4G/5G)/BT AntennamateriaFPC+LDS

Page 108 of 150 Report No.: STS2601367W03 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/10kHz) Limit (dBm/3kHz) Verdict NVNT b 2412 AntB -7.38 8 Pass NVNT b 2437 AntB -5.93 8 Pass NVNT b 2462 AntB -7.07 8 Pass NVNT g 2412 AntB -11.14 8 Pass NVNT g 2437 AntB -10.33 8 Pass NVNT g 2462 AntB -11.06 8 Pass NVNT n20 2412 AntB -12.21 8 Pass NVNT n20 2437 AntB -11.76 8 Pass NVNT n20 2462 AntB -11.55 8 Pass NVNT n40 2422 AntB -15.33 8 Pass NVNT n40 2437 AntB -14.49 8 Pass NVNT n40 2452 AntB -16.06 8 Pass NVNT ax20 2412 AntB -15.18 8 Pass NVNT ax20 2437 AntB -13.35 8 Pass NVNT ax20 2462 AntB -14.02 8 Pass NVNT ax40 2422 AntB -17.47 8 Pass NVNT ax40 2437 AntB -16.47 8 Pass NVNT ax40 2452 AntB -17.57 8 Pass Condition Mode Frequency (MHz) Conducted PSD (dBm/10kHz) Conducted PSD (dBm/3kHz) Verdict Ant. A Ant. B Ant. A Ant. B Total Limit NVNT b 2412 -6.44 -7.38 -11.67 -12.61 / 8 Pass NVNT b 2437 -7.18 -5.93 -12.41 -11.16 / 8 Pass NVNT b 2462 -7.05 -7.07 -12.28 -12.3 / 8 Pass NVNT g 2412 -11.17 -11.14 -16.4 -16.37 / 8 Pass NVNT g 2437 -8.85 -10.33 -14.08 -15.56 / 8 Pass NVNT g 2462 -9.87 -11.06 -15.1 -16.29 / 8 Pass NVNT n20 2412 -10.27 -12.21 -15.5 -17.44 -13.35 8 Pass NVNT n20 2437 -11.6 -11.76 -16.83 -16.99 -13.90 8 Pass NVNT n20 2462 -10.8 -11.55 -16.03 -16.78 -13.38 8 Pass NVNT n40 2422 -15.22 -15.33 -20.45 -20.56 -17.49 8 Pass NVNT n40 2437 -15.35 -14.49 -20.58 -19.72 -17.12 8 Pass NVNT n40 2452 -13.79 -16.06 -19.02 -21.29 -17.00 8 Pass NVNT ax20 2412 -13.27 -15.18 -18.5 -20.41 -16.34 8 Pass NVNT ax20 2437 -12.73 -13.35 -17.96 -18.58 -15.25 8 Pass NVNT ax20 2462 -12.73 -14.02 -17.96 -19.25 -15.55 8 Pass NVNT ax40 2422 -16.59 -17.47 -21.82 -22.7 -19.23 8 Pass NVNT ax40 2437 -16.52 -16.47 -21.75 -21.7 -18.71 8 Pass NVNT ax40 2452 -15.83 -17.57 -21.06 -22.8 -18.83 8 Pass Note: Correction Factor = 10log(3KHz/RBW in measurement) =-5.23 Power Spectral Density (dBm/3kHz)= Power Spectral Density (dBm/10kHz)-5.23 Page 109 of 150 Report No.: STS2601367W03 Test Graphs PSD NVNT b 2412MHz AntB PSD NVNT b 2437MHz AntB Page 110 of 150 Report No.: STS2601367W03 PSD NVNT b 2462MHz AntB PSD NVNT g 2412MHz AntB Page 111 of 150 Report No.: STS2601367W03 PSD NVNT g 2437MHz AntB PSD NVNT g 2462MHz AntB Page 112 of 150 Report No.: STS2601367W03 PSD NVNT n20 2412MHz AntB PSD NVNT n20 2437MHz AntB Page 113 of 150 Report No.: STS2601367W03 PSD NVNT n20 2462MHz AntB PSD NVNT n40 2422MHz AntB Page 114 of 150 Report No.: STS2601367W03 PSD NVNT n40 2437MHz AntB PSD NVNT n40 2452MHz AntB Page 115 of 150 Report No.: STS2601367W03 PSD NVNT ax20 2412MHz AntB PSD NVNT ax20 2437MHz AntB Page 116 of 150 Report No.: STS2601367W03 PSD NVNT ax20 2462MHz AntB PSD NVNT ax40 2422MHz AntB Page 117 of 150 Report No.: STS2601367W03 PSD NVNT ax40 2437MHz AntB PSD NVNT ax40 2452MHz AntB Page 118 of 150 Report No.: STS2601367W03 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 AntB -52.99 -20 Pass 2462 -56.66 -20 Pass g 2412 -42.74 -20 Pass 2462 -51.35 -20 Pass n20 2412 -40.53 -20 Pass 2462 -48.43 -20 Pass n40 2422 -42.03 -20 Pass 2452 -43.98 -20 Pass ax20 2412 -43.79 -20 Pass 2462 -49.86 -20 Pass ax40 2422 -44.08 -20 Pass 2452 -43.84 -20 Pass Page 119 of 150 Report No.: STS2601367W03 Test Graphs Band Edge NVNT b 2412MHz AntB Ref Band Edge NVNT b 2412MHz AntB Emission Page 120 of 150 Report No.: STS2601367W03 Band Edge NVNT b 2462MHz AntB Ref Band Edge NVNT b 2462MHz AntB Emission Page 121 of 150 Report No.: STS2601367W03 Band Edge NVNT g 2412MHz AntB Ref Band Edge NVNT g 2412MHz AntB Emission Page 122 of 150 Report No.: STS2601367W03 Band Edge NVNT g 2462MHz AntB Ref Band Edge NVNT g 2462MHz AntB Emission Page 123 of 150 Report No.: STS2601367W03 Band Edge NVNT n20 2412MHz AntB Ref Band Edge NVNT n20 2412MHz AntB Emission Page 124 of 150 Report No.: STS2601367W03 Band Edge NVNT n20 2462MHz AntB Ref Band Edge NVNT n20 2462MHz AntB Emission Page 125 of 150 Report No.: STS2601367W03 Band Edge NVNT n40 2422MHz AntB Ref Band Edge NVNT n40 2422MHz AntB Emission Page 126 of 150 Report No.: STS2601367W03 Band Edge NVNT n40 2452MHz AntB Ref Band Edge NVNT n40 2452MHz AntB Emission Page 127 of 150 Report No.: STS2601367W03 Band Edge NVNT ax20 2412MHz AntB Ref Band Edge NVNT ax20 2412MHz AntB Emission Page 128 of 150 Report No.: STS2601367W03 Band Edge NVNT ax20 2462MHz AntB Ref Band Edge NVNT ax20 2462MHz AntB Emission Page 129 of 150 Report No.: STS2601367W03 Band Edge NVNT ax40 2422MHz AntB Ref Band Edge NVNT ax40 2422MHz AntB Emission Page 130 of 150 Report No.: STS2601367W03 Band Edge NVNT ax40 2452MHz AntB Ref Band Edge NVNT ax40 2452MHz AntB Emission Page 131 of 150 Report No.: STS2601367W03 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 AntB -36.55 -20 Pass 2437 -39.16 -20 Pass 2462 -39.97 -20 Pass g 2412 -34.27 -20 Pass 2437 -36.53 -20 Pass 2462 -35.88 -20 Pass n20 2412 -35.29 -20 Pass 2437 -35.87 -20 Pass 2462 -34.85 -20 Pass n40 2422 -31.83 -20 Pass 2437 -32.97 -20 Pass 2452 -31.52 -20 Pass ax20 2412 -33.2 -20 Pass 2437 -35.26 -20 Pass 2462 -35.62 -20 Pass ax40 2422 -30.39 -20 Pass 2437 -32.63 -20 Pass 2452 -31.18 -20 Pass Page 132 of 150 Report No.: STS2601367W03 Test Graphs Tx. Spurious NVNT b 2412MHz AntB Ref Tx. Spurious NVNT b 2412MHz AntB Emission Page 133 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT b 2437MHz AntB Ref Tx. Spurious NVNT b 2437MHz AntB Emission Page 134 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT b 2462MHz AntB Ref Tx. Spurious NVNT b 2462MHz AntB Emission Page 135 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2412MHz AntB Ref Tx. Spurious NVNT g 2412MHz AntB Emission Page 136 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2437MHz AntB Ref Tx. Spurious NVNT g 2437MHz AntB Emission Page 137 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2462MHz AntB Ref Tx. Spurious NVNT g 2462MHz AntB Emission Page 138 of 150 Report No.: STS26…

Text truncated - open the document above for the full version.

Page 65 of 150 Report No.: STS2601367W03 Band Edge NVNT g 2462MHz AntA Ref Band Edge NVNT g 2462MHz AntA Emission Page 66 of 150 Report No.: STS2601367W03 Band Edge NVNT n20 2412MHz AntA Ref Band Edge NVNT n20 2412MHz AntA Emission Page 67 of 150 Report No.: STS2601367W03 Band Edge NVNT n20 2462MHz AntA Ref Band Edge NVNT n20 2462MHz AntA Emission Page 68 of 150 Report No.: STS2601367W03 Band Edge NVNT n40 2422MHz AntA Ref Band Edge NVNT n40 2422MHz AntA Emission Page 69 of 150 Report No.: STS2601367W03 Band Edge NVNT n40 2452MHz AntA Ref Band Edge NVNT n40 2452MHz AntA Emission Page 70 of 150 Report No.: STS2601367W03 Band Edge NVNT ax20 2412MHz AntA Ref Band Edge NVNT ax20 2412MHz AntA Emission Page 71 of 150 Report No.: STS2601367W03 Band Edge NVNT ax20 2462MHz AntA Ref Band Edge NVNT ax20 2462MHz AntA Emission Page 72 of 150 Report No.: STS2601367W03 Band Edge NVNT ax40 2422MHz AntA Ref Band Edge NVNT ax40 2422MHz AntA Emission Page 73 of 150 Report No.: STS2601367W03 Band Edge NVNT ax40 2452MHz AntA Ref Band Edge NVNT ax40 2452MHz AntA Emission Page 74 of 150 Report No.: STS2601367W03 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 AntA -40.42 -20 Pass 2437 -40.16 -20 Pass 2462 -39.81 -20 Pass g 2412 -36.65 -20 Pass 2437 -37.45 -20 Pass 2462 -34.34 -20 Pass n20 2412 -33.72 -20 Pass 2437 -34.45 -20 Pass 2462 -34.57 -20 Pass n40 2422 -31.78 -20 Pass 2437 -32.39 -20 Pass 2452 -33.17 -20 Pass ax20 2412 -34.99 -20 Pass 2437 -34.72 -20 Pass 2462 -35.98 -20 Pass ax40 2422 -25.5 -20 Pass 2437 -30.6 -20 Pass 2452 -33.45 -20 Pass Page 75 of 150 Report No.: STS2601367W03 Test Graphs Tx. Spurious NVNT b 2412MHz AntA Ref Tx. Spurious NVNT b 2412MHz AntA Emission Page 76 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT b 2437MHz AntA Ref Tx. Spurious NVNT b 2437MHz AntA Emission Page 77 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT b 2462MHz AntA Ref Tx. Spurious NVNT b 2462MHz AntA Emission Page 78 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2412MHz AntA Ref Tx. Spurious NVNT g 2412MHz AntA Emission Page 79 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2437MHz AntA Ref Tx. Spurious NVNT g 2437MHz AntA Emission Page 80 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT g 2462MHz AntA Ref Tx. Spurious NVNT g 2462MHz AntA Emission Page 81 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n20 2412MHz AntA Ref Tx. Spurious NVNT n20 2412MHz AntA Emission Page 82 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n20 2437MHz AntA Ref Tx. Spurious NVNT n20 2437MHz AntA Emission Page 83 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n20 2462MHz AntA Ref Tx. Spurious NVNT n20 2462MHz AntA Emission Page 84 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n40 2422MHz AntA Ref Tx. Spurious NVNT n40 2422MHz AntA Emission Page 85 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n40 2437MHz AntA Ref Tx. Spurious NVNT n40 2437MHz AntA Emission Page 86 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT n40 2452MHz AntA Ref Tx. Spurious NVNT n40 2452MHz AntA Emission Page 87 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax20 2412MHz AntA Ref Tx. Spurious NVNT ax20 2412MHz AntA Emission Page 88 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax20 2437MHz AntA Ref Tx. Spurious NVNT ax20 2437MHz AntA Emission Page 89 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax20 2462MHz AntA Ref Tx. Spurious NVNT ax20 2462MHz AntA Emission Page 90 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax40 2422MHz AntA Ref Tx. Spurious NVNT ax40 2422MHz AntA Emission Page 91 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax40 2437MHz AntA Ref Tx. Spurious NVNT ax40 2437MHz AntA Emission Page 92 of 150 Report No.: STS2601367W03 Tx. Spurious NVNT ax40 2452MHz AntA Ref Tx. Spurious NVNT ax40 2452MHz AntA Emission Page 93 of 150 Report No.: STS2601367W03 Antenna B Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT b 2412 AntB 100 0 NVNT g 2412 AntB 100 0 NVNT n20 2412 AntB 100 0 NVNT n40 2422 AntB 100 0 NVNT ax20 2412 AntB 100 0 NVNT ax40 2422 AntB 100 0 Page 94 of 150 Report No.: STS2601367W03 Test Graphs Duty Cycle NVNT b 2412MHz AntB Duty Cycle NVNT g 2412MHz AntB Page 95 of 150 Report No.: STS2601367W03 Duty Cycle NVNT n20 2412MHz AntB Duty Cycle NVNT n40 2422MHz AntB Page 96 of 150 Report No.: STS2601367W03 Duty Cycle NVNT ax20 2412MHz AntB Duty Cycle NVNT ax40 2422MHz AntB Page 97 of 150 Report No.: STS2601367W03 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT b 2412 AntB 10.66 30 Pass NVNT b 2437 AntB 11.43 30 Pass NVNT b 2462 AntB 11.3 30 Pass NVNT g 2412 AntB 9.5 30 Pass NVNT g 2437 AntB 9.78 30 Pass NVNT g 2462 AntB 9.47 30 Pass NVNT n20 2412 AntB 8.09 30 Pass NVNT n20 2437 AntB 8.78 30 Pass NVNT n20 2462 AntB 8.54 30 Pass NVNT n40 2422 AntB 7.69 30 Pass NVNT n40 2437 AntB 7.94 30 Pass NVNT n40 2452 AntB 7.77 30 Pass NVNT ax20 2412 AntB 8.26 30 Pass NVNT ax20 2437 AntB 8.89 30 Pass NVNT ax20 2462 AntB 8.51 30 Pass NVNT ax40 2422 AntB 7.7 30 Pass NVNT ax40 2437 AntB 8.15 30 Pass NVNT ax40 2452 AntB 7.77 30 Pass Condition Mode Frequency (MHz) Conducted Power (dBm) Limit (dBm) Ant A Ant B Total NVNT b 2412 11.81 10.66 / 30 NVNT b 2437 11.58 11.43 / 30 NVNT b 2462 11.36 11.3 / 30 NVNT g 2412 10.42 9.5 / 30 NVNT g 2437 10.45 9.78 / 30 NVNT g 2462 10.64 9.47 / 30 NVNT n20 2412 9.2 8.09 11.69 30 NVNT n20 2437 9.38 8.78 12.10 30 NVNT n20 2462 9.45 8.54 12.03 30 NVNT n40 2422 8.19 7.69 10.96 30 NVNT n40 2437 8.26 7.94 11.11 30 NVNT n40 2452 9.09 7.77 11.49 30 NVNT ax20 2412 9.38 8.26 11.87 30 NVNT ax20 2437 9.46 8.89 12.19 30 NVNT ax20 2462 9.39 8.51 11.98 30 NVNT ax40 2422 8.2 7.7 10.97 30 NVNT ax40 2437 8.58 8.15 11.38 30 NVNT ax40 2452 8.95 7.77 11.41 30 For power measurements, The Array gain=0 for NANT≤4， So the directional gain for Power measurements is 0.14 dBi Page 98 of 150 Report No.: STS2601367W03 -6…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2601367W03 Issued for Shenzhen Qichang Intelligent Technology Co., Ltd Room 510, Building 7, Yunli Intelligent Park, No. 7, Bantian Street, Longgang, Shenzhen, China Product Name: Smart Phone Brand Name: Model Name: F113 Series Model(s): F113 Pro, F113 Plus, F113 P FCC ID: 2BAK2-F113 Test Standards: FCC Part15.247 Page 2 of 150 Report No.: STS2601367W03 TEST REPORT Applicant’s Name ................. : Shenzhen Qichang Intelligent Technology Co., Ltd Address ................................. : Room 510, Building 7, Yunli Intelligent Park, No. 7, Bantian Street, Longgang, Shenzhen, China Manufacturer's Name ........... : Shenzhen Qichang Intelligent Technology Co., Ltd Address ................................. : Room 510, Building 7, Yunli Intelligent Park, No. 7, Bantian Street, Longgang, Shenzhen, China Product Description Product Name ........................ : Smart Phone Brand Name ........................... : Model Name .......................... : F113 Series Model(s) .................... : F113 Pro, F113 Plus, F113 P Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 14 Aug. 2025 Date (s) of performance of tests ............. : 14 Aug. 2025 ~ 1 Apr. 2026 Date of Issue .......................................... : 1 Apr. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 150 Report No.: STS2601367W03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 4.1 LIMIT 31 4.2 TEST PROCEDURE 31 4.3 DEVIATION FROM STANDARD 31 4.4 TEST SETUP 31 4.5 EUT OPERATION CONDITIONS 31 4.6 TEST RESULTS 31 5. POWER SPECTRAL DENSITY TEST 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 DEVIATION FROM STANDARD 32 5.4 TEST SETUP 32 5.5 EUT OPERATION CONDITIONS 32 5.6 TEST RESULTS 32 6. BANDWIDTH TEST 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 DEVIATION FROM STANDARD 33 6.4 TEST SETUP 33 6.5 EUT OPERATION CONDITIONS 33 Page 4 of 150 Report No.: STS2601367W03 Table of Contents Page 6.6 TEST RESULTS 33 7. PEAK OUTPUT POWER TEST 34 7.1 LIMIT 34 7.2 TEST PROCEDURE 34 7.3 DEVIATION FROM STANDARD 34 7.4 TEST SETUP 34 7.5 EUT OPERATION CONDITIONS 34 7.6 TEST RESULTS 34 8. ANTENNA REQUIREMENT 35 8.1 STANDARD REQUIREMENT 35 8.2 EUT ANTENNA 35 APPENDIX 1-TEST DATA 36 APPENDIX 2-PHOTOS OF TEST SETUP 150 Page 5 of 150 Report No.: STS2601367W03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 1 Apr. 2026 STS2601367W03 ALL Initial Issue Page 6 of 150 Report No.: STS2601367W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 150 Report No.: STS2601367W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 150 Report No.: STS2601367W03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Phone Brand Name Model Name F113 Series Model(s) F113 Pro, F113 Plus, F113 P Model Difference All models are identical except for the model name, the test model is F113. Product Description The EUT is a Smart Phone. Operation Frequency: 802.11b/g/n/ax 20: 2412~2462 MHz 802.11n/ax…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Rep…
