2BATE-WG1-1Wireless Gaming Headset

FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: ЬReorient or relocate the receiving antenna. ЬIncrease the separation between the equipment and receiver. ЬConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Shenzhen wei bo technology co., LTD Room 601, Tower A, Yousuowei Building, No. 2000, Jiaxian Road, Bantian street, Longgang District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023/09/27 U.S. Agent Designation Shenzhen wei bo technology co., LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BATE-WG1-1): Name and company of U.S. agent: Wilson Tech Service LLC Physical U.S. address of agent: 1312 17th Street Suite 692 Denver 80202 United States FRN of U.S. agent: 0033402033 Email address of U.S. agent: [email protected] Wilson Tech Service LLC acknowledges their obligation to accept service of process on behalf of Shenzhen wei bo technology co., LTD Shenzhen wei bo technology co., LTD with the FRN [0033641028] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Wei Chen Manager Shenzhen wei bo technology co., LTD Signature Wilson Cheung Manager Wilson Tech Service LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Sincerely, Name/Title： Wei Chen/Manager Company: Shenzhen wei bo technology co., LTD Address: Room 601,Tower A,Yousuowei Building,No.2000, Jiaxian Road,Bantian street,Longgang District, Shenzhen China Phone: 13620214161 Fax: N/A E-Mail: [email protected]

FCC ID: 2BATE-WG1-1 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BATE-WG1-1 Photo 4 Photo 5 Photo 6 FCC ID: 2BATE-WG1-1 Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BATE-WG1-1

FCC ID: 2BATE-WG1-1 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 Chip Antenna FCC ID: 2BATE-WG1-1 Photo 4 Photo 5

RF Exposure evaluation FCC ID: 2BATE-WG1-1 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance Freq. (MHz) Field strength(max)(dBuV/m) EIRP (max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] 2402MHz 99.62 4.36 4.0±1 5.0 Note: EIRP=E-104.8+20logD, D=3 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW SRD 2.450 5 5.0 3.1623 0.9899<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 1 OF 11 5.0 x 2.2 x 1.0 (mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification 1. Product Number YF 5022 H1 R 2G45 1 2 3 4 5 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 2 OF 11 2. Features *Stable and reliable in performances *Low temperature coefficient of frequency *Low profile, compact size *RoHS compliance *SMT processes compatible 3. Applications *Bluetooth earphone systems *Hand-held devices when WiFi /Bluetooth functions are needed, e.g., Smart phone. *IEEE802.11 b/g/n *ZigBee *Wireless PCMCIA cards or USB dongle 4. Description Ying feng chip antenna series are specially designed for WiFi/Bluetooth applications. Based on yingfeng proprietary design and processes, this chip antenna has excellent stability and sensitivity to consistently provide high signal reception efficiency. 5. Electrical Specifications (40 x 40 mm 2 ground plane) 5-1. Electrical Table Characteristics Specifications Unit Outline Dimensions 5.0x2.2x1.0 mm Working Frequency 2400~2500 MHz VSWR 2 Max. Impedance 50  Polarization Linear Polarization Gain Peak 2.5 (typical) dBi Efficiency 78 (typical) % 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 3 OF 11 5-2. Return Loss & VSWR Return Loss (S 11 ) Smith Chart(S 11 ) 6 Outline Dimensions of Antenna & Evaluation Board (unit: mm) 6-1. Antenna Dimensions Configuration and Dimensions: 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 4 OF 11 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 5 OF 11 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 6 OF 11 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 7 OF 11 7.Radiation Pattern (40x 40 mm 2 ground plane) 7-1. 3D Gain Pattern @ 2450 MHz 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 8 OF 11 Z X Y Y X Y X Z Z 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 9 OF 11 7-2. 3D Efficiency Table Frequency( MHz) 2400 2410 2420 2430 2442 2450 2460 2470 2480 2490 2500 Efficiency (dB) -1.4 -1.0 -0.9 -0.7 -0.7 -0.8 -0.9 -1.1 -1.2 -1.3 -1.4 Efficiency (%) 70.8 71.7 72.3 74.4 74.5 75.0 74.0 73.6 72.1 71.6 70.5 Gain (dBi) 1.9 2.1 2.3 2.4 2.5 2.5 2.4 2.3 2.2 2.1 1.8 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 10 OF 11 深圳市迎丰天线技术有限公司 HEN ZHEN YINGFENG ANTENNA TECHNOLOGY CO.,LTD Prepared by : harry Designed by : andy Checked by : andy Approved by：oliver TITLE：5.0 x2.2 x 1.0mm) WiFi/Bluetooth Ceramic Chip Antenna (YF5022H1) Engineering Specification DOCUMENT YF5022H1R2G45 REV. NO. B PAGE 11 OF 11

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China TEST REPORT FCC Rules and Regulations Part PART 15.249 Report Reference No..............: CTA23091401501 FCC ID...................................: 2BATE-WG1-1 Compiled by ( position+printed name+signature ... : File administrators Zoey Cao Supervised by ( position+printed name+signature ... : Project Engineer Amy Wen Approved by ( position+printed name+signature ... : RF Manager Eric Wang Date of issue ..................................... : Sep. 20, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen,China Applicant’s name ............................ : Shenzhen wei bo technology co., LTD Address ............................................ : Room 601, Tower A, Yousuowei Building, No. 2000, Jiaxian Road, Bantian street, Longgang District, Shenzhen, China Standard ........................................... : FCC Rules and Regulations PART 15.249 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Gaming Headset Trade Mark ....................................... : N/A Manufacturer .................................... : Dongguan Huawei Technology Co., Ltd Model/Type reference....................... : WG1 Listed Models .................................. : WG2, WG4, PH1, PH2, KGH1, KGH2, KGH3, NYH1, NYH2, NYH3, PG3, PG4, PH3, PH4, FC-300, FC-400 Modulation ....................................... : GFSK Frequency .......................................... 2402-2480MHz Ratings ............................................. : DC 5V From PC Result................................................ : PASS Report No.: CTA23091401501 Page 2 of 27 T E S T R E P O R T Equipment under Test : Wireless Gaming Headset Model /Type : WG1 Listed Models : WG2, WG4, PH1, PH2, KGH1, KGH2, KGH3, NYH1, NYH2, NYH3, PG3, PG4, PH3, PH4, FC-300, FC-400 Applicant : Shenzhen wei bo technology co., LTD Address : Room 601, Tower A, Yousuowei Building, No. 2000, Jiaxian Road, Bantian street, Longgang District, Shenzhen, China Manufacturer : Dongguan Huawei Technology Co., Ltd Address : Room 101, Building 1, No. 39 Yongping Lane, Dongshan, Qishi Town, Dongguan City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23091401501 Page 3 of 27 Contents 1. 0BT E S T S T A N D A R D S................................................................. 4 2. 1BS U M M A R Y ............................................................................ 5 2.1. General Remarks 5 2.2. 7BProduct Description 5 2.3. 8BEquipment Under Test 5 2.4. 9BShort description of the Equipment under Test (EUT) 5 2.5. 10BEUT operation mode 6 2.6. 11BBlock Diagram of Test Setup 6 2.7. Modifications 7 3. 2BT E S T E N V I R O N M E N T ............................................................. 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. 17BEnvironmental conditions 8 3.4. 18BSummary of measurement results 9 3.5. Statement of the measurement uncertainty 9 3.6. 20BEquipments Used during the Test 9 4. 3BT E S T C O N D I T I O N S A N D R E S U L T S .......................................... 11 4.1. 21BAC Power Conducted Emission ................................................................................... 11 4.2. Radiated Emission and Band Edges ............................................................................ 14 4.3. 20dB Bandwidth Measurement .................................................................................... 20 4.4. 31BAntenna Requirement ................................................................................................... 22 5. 4BT E S T S E T U P P H O T O S O F T H E E U T ........................................ 23 6. 4BT E S T P H O T O S O F T H E E U T .................................................. 24 Report No.: CTA23091401501 Page 4 of 27 1. 0BT E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices ANSI C63.4: 2014: –American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz Range of 9 kHz to 40GHz Report No.: CTA23091401501 Page 5 of 27 2. 1BS U M M A R Y 2.1. General Remarks Date of receipt of test sample : Sep. 14, 2023 Testing commenced on : Sep. 14, 2023 Testing concluded on : Sep. 20, 2023 2.2. 7BProduct Description Name of EUT Wireless Gaming Headset Model Number WG1 Power Rating DC 5V From PC PC information (Auxiliary test supplied by testing Lab)： Model: E470C Trade Mark: thinkpad Sample ID: CTA230914015-1#(Engineer sample) CTA230914015-2#(Normal sample) Operation frequency 2402-2480MHz Modulation GFSK Antenna Type Chip antenna Antenna Gain 2.5 dBi(Max) 2.3. 8BEquipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 5V From PC 2.4. …
