2BB4N-DT01AVibe Dot

Report No.: TSEA26040038513 Appendix B WIFI 2.4G WIFI 5G BT Scans Setup Area ScanZoom Scan Grid Extents [mm]60.0 x 100.030.0 x 30.0 x 30.0 Grid Steps [mm]12.0 x 12.05.0 x 5.0 x 5.0 Sensor Surface [mm]3.01.4 Graded GridN/AYes Grading RatioN/A1.5 MAIAYY Surface DetectionVMS + 6pVMS + 6p Scan MethodMeasuredMeasured Measurement Results Area ScanZoom Scan Date2026-06-26, 15:052026-06-26, 15:10 psSAR1g [W/Kg]0.0150.013 psSAR10g [W/Kg]0.0070.007 Power Drift [dB]-0.06-0.4 Power ScalingDisabledDisabled Scaling Factor [dB] TSL CorrectionNo correctionNo correction M2/M1 [%]34.0 Dist 3dB Peak [mm]8.1 Test Laboratory: TOWE Lab Measurement Report for Device, EDGE TOP, WLAN 2.4GHz, IEEE 802.11b WiFi 2.4 GHz (DSSS, 1 Mbps), Channel 11 (2462.000 MHz) Device Under Test Properties ModelDimensions [mm] Device60.0 x 60.0 x 5.0 Exposure Conditions Phantom Section, TSLPosition, Test Distance [mm] BandGroup, UIDFrequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Head Simulating Liquid EDGE TOP, 5.00WLAN 2.4GHz WLAN, 10012- CAB 2462.000, 116.971.8340.1 Hardware Setup PhantomTSLProbe, Calibration DateDAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2168HSL2450EX3DV4 - SN7858, 2026-02-20DAE4ip Sn1846, 2026-01-07 Scans Setup Area ScanZoom Scan Grid Extents [mm]40.0 x 100.024.0 x 24.0 x 22.0 Grid Steps [mm]10.0 x 10.04.0 x 4.0 x 2.0 Sensor Surface [mm]3.01.4 Graded GridN/AYes Grading RatioN/A1.4 MAIAYY Surface DetectionVMS + 6pVMS + 6p Scan MethodMeasuredMeasured Measurement Results Area ScanZoom Scan Date2026-06-27, 15:402026-06-27, 15:47 psSAR1g [W/Kg]0.3390.333 psSAR10g [W/Kg]0.0850.076 Power Drift [dB]-0.040.05 Power ScalingDisabledDisabled Scaling Factor [dB] TSL CorrectionNo correctionNo correction M2/M1 [%]49.2 Dist 3dB Peak [mm]4.7 Test Laboratory: TOWE Lab Measurement Report for Device, EDGE TOP, WLAN 5GHz, IEEE 802.11a WiFi 5 GHz (OFDM, 6 Mbps), Channel 60 (5300.000 MHz) Device Under Test Properties ModelDimensions [mm] Device60.0 x 60.0 x 5.0 Exposure Conditions Phantom Section, TSLPosition, Test Distance [mm] BandGroup, UIDFrequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Head Simulating Liquid EDGE TOP, 5.00WLAN 5GHz WLAN, 10062- CAE 5300.000, 605.054.7636.1 Hardware Setup PhantomTSLProbe, Calibration DateDAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2168HSL5GHzEX3DV4 - SN7812, 2026-01-19DAE4ip Sn1846, 2026-01-07 Scans Setup Area ScanZoom Scan Grid Extents [mm]40.0 x 100.024.0 x 24.0 x 22.0 Grid Steps [mm]10.0 x 10.04.0 x 4.0 x 2.0 Sensor Surface [mm]3.01.4 Graded GridN/AYes Grading RatioN/A1.4 MAIAYY Surface DetectionVMS + 6pVMS + 6p Scan MethodMeasuredMeasured Measurement Results Area ScanZoom Scan Date2026-06-27, 16:192026-06-27, 16:26 psSAR1g [W/Kg]0.3410.337 psSAR10g [W/Kg]0.0890.076 Power Drift [dB]-0.04-0.08 Power ScalingDisabledDisabled Scaling Factor [dB] TSL CorrectionNo correctionNo correction M2/M1 [%]48.5 Dist 3dB Peak [mm]5.1 Test Laboratory: TOWE Lab Measurement Report for Device, EDGE TOP, WLAN 5GHz, IEEE 802.11a WiFi 5 GHz (OFDM, 6 Mbps), Channel 140 (5700.000 MHz) Device Under Test Properties ModelDimensions [mm] Device60.0 x 60.0 x 5.0 Exposure Conditions Phantom Section, TSLPosition, Test Distance [mm] BandGroup, UIDFrequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Head Simulating Liquid EDGE TOP, 5.00WLAN 5GHz WLAN, 10062- CAE 5700.000, 1404.465.2135.1 Hardware Setup PhantomTSLProbe, Calibration DateDAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2168HSL5GHzEX3DV4 - SN7812, 2026-01-19DAE4ip Sn1846, 2026-01-07 Scans Setup Area ScanZoom Scan Grid Extents [mm]40.0 x 100.024.0 x 24.0 x 22.0 Grid Steps [mm]10.0 x 10.04.0 x 4.0 x 2.0 Sensor Surface [mm]3.01.4 Graded GridN/AYes Grading RatioN/A1.4 MAIAYY Surface DetectionVMS + 6pVMS + 6p Scan MethodMeasuredMeasured Measurement Results Area ScanZoom Scan Date2026-06-27, 16:432026-06-27, 16:50 psSAR1g [W/Kg]0.3990.432 psSAR10g [W/Kg]0.1030.095 Power Drift [dB]-0.07-0.17 Power ScalingDisabledDisabled Scaling Factor [dB] TSL CorrectionNo correctionNo correction M2/M1 [%]46.7 Dist 3dB Peak [mm]5.1 Test Laboratory: TOWE Lab Measurement Report for Device, EDGE TOP, WLAN 5GHz, IEEE 802.11a WiFi 5 GHz (OFDM, 6 Mbps), Channel 165 (5825.000 MHz) Device Under Test Properties ModelDimensions [mm] Device60.0 x 60.0 x 5.0 Exposure Conditions Phantom Section, TSLPosition, Test Distance [mm] BandGroup, UIDFrequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Head Simulating Liquid EDGE TOP, 5.00WLAN 5GHz WLAN, 10062- CAE 5825.000, 1654.525.3534.8 Hardware Setup PhantomTSLProbe, Calibration DateDAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2168HSL5GHzEX3DV4 - SN7812, 2026-01-19DAE4ip Sn1846, 2026-01-07 Scans Setup Area ScanZoom Scan Grid Extents [mm]40.0 x 96.030.0 x 30.0 x 30.0 Grid Steps [mm]5.0 x 12.05.0 x 5.0 x 5.0 Sensor Surface [mm]3.01.4 Graded GridN/AYes Grading RatioN/A1.5 MAIAYY Surface DetectionVMS + 6pVMS + 6p Scan MethodMeasuredMeasured Measurement Results Area ScanZoom Scan Date2026-06-26, 16:572026-06-26, 16:41 psSAR1g [W/Kg]0.0240.021 psSAR10g [W/Kg]0.0090.012 Power Drift [dB]-0.18-0.02 Power ScalingDisabledDisabled Scaling Factor [dB] TSL CorrectionNo correctionNo correction M2/M1 [%]32.6 Dist 3dB Peak [mm]5.3 Test Laboratory: TOWE Lab Measurement Report for Device, EDGE TOP, ISM 2.4 GHz Band, IEEE 802.15.1 Bluetooth (GFSK, DH5), Channel 78 (2480.000 MHz) Device Under Test Properties ModelDimensions [mm] Device60.0 x 60.0 x 5.0 Exposure Conditions Phantom Section, TSLPosition, Test Distance [mm] BandGroup, UIDFrequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Head Simulating Liquid EDGE TOP, 0.00ISM 2.4 GHz Band Bluetooth, 10032- CAA 2480.000, 786.971.8540.0 Hardware Setup PhantomTSLProbe, Calibration DateDAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2168HSL2450EX3DV4 - SN…

Text truncated - open the document above for the full version.

Sushi TOWE Wireless Testing (Shenzhen) Co., Ltd. Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. TEST REPORT Applicant: SHENZHEN ZHOUGUANG TECHNOLOGY CO.LTD. EUT Description: Vibe Dot Model: DT01A Brand: Vibe FCC ID: 2BB4N-DT01A Standards: FCC 47 CFR Part 15 Subpart E Date of Receipt: 2026/04/27 Date of Test: 2026/04/27 to 2026/06/26 Date of Issue: 2026/06/29 TOWE. Tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer’s responsibility to assure that additional production units of the model are manufactured with identical electrical and mechanical components. All sample tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. Without written approval of TOWE, the test report shall not be reproduced except in full. Jim Huang Approved By: Carey Chen Reviewed By: Page 2 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Revision History Rev. Issue Date Description Revised by 01 2026/06/29 Original Carey Chen Page 3 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Summary of Test Results Clause FCC Part Test Items Test Bands Result 4.1 §15.203 Antenna Requirement --- PASS 4.2 §15.407(g) Frequency Stability --- --- 4.3 §15.207 AC Power Line Conducted Emission Section 2.2 PASS 4.4 §15.407(a)(1)(iv) §15.407(a)(2) §15.407(a)(3)(i) Maximum Conducted Output Power U-NII-1 U-NII-2A U-NII-2C U-NII-3 PASS 4.5 §KDB 789033 II.C.1 Emission Bandwidth U-NII-1 U-NII-2A U-NII-2C Reporting purposes only 4.6 §15.407(e) Minimum Emission Bandwidth U-NII-3 PASS 4.7 §KDB 789033 II.D Occupied Bandwidth U-NII-1 U-NII-2A U-NII-2C U-NII-3 Reporting purposes only 4.8 §5.407(a)(1)(iv) §15.407(a)(2) §15.407(a)(3)(i) Maximum Power Spectral Density U-NII-1 U-NII-2A U-NII-2C U-NII-3 PASS 4.9 §15.407(b) §15.209(d) Unwanted Emissions U-NII-1 U-NII-2A U-NII-2C U-NII-3 PASS Test Method: ANSI C63.10-2020+Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024, KDB 789033 D02 General UNII Test Procedures New Rules v02r01 Remark: Pass is EUT meets standard requirements. Page 4 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Table of Contents 1 General Description ............................................................................................................................5 1.1 Lab Information .....................................................................................................................5 1.1.1 Testing Location ..............................................................................................................5 1.1.2 Test Facility / Accreditations ............................................................................................5 1.2 Client Information .................................................................................................................5 1.2.1 Applicant ..........................................................................................................................5 1.2.2 Manufacturer ....................................................................................................................5 1.3 Product Information ..............................................................................................................6 2 Test Configuration ..............................................................................................................................7 2.1 Test Channel .........................................................................................................................7 2.2 Worst-case configuration and Mode ...................................................................................9 2.3 Support Unit used in test .....................................................................................................9 2.4 Test Environment ..................................................................................................................9 2.5 Test RF Cable ........................................................................................................................9 2.6 Modifications .........................................................................................................................9 2.7 Test Setup Diagram .…

Text truncated - open the document above for the full version.

品名 : History List 版本 REV. 修訂者 EDITOR 修訂頁次 PAGE 修訂內容 ITEMS OF CHANGE 申請日期 DATE 生效日期 VALID DATE ECN 编号 ECN NO V01 毛豪 ALL 发行正式 B.1.01.Y.1016 Specification UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 1 OF 5 1. Explanation of part number : B.1 . 01 . Y . 1016 (1) (2) (3) (4) (1) Product Type：Wireless Antenna (2) Material : FPC (3) State : DVT (4) Serial number:1016 2. Electrical Specification : 2-1. Frequency Band: Frequency Band MHz GPS,WIFI 1575.42Mhz , 2400-2500Mhz,5150-5850Mhz 2-2. Impedance 50 ohm nominal 2-3. S11 ,Efficiency , and Active Data： UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 2 OF 5 2-3.1 S11: Frequency Band 1575.42 2400 2500 5200 5800 2-3-1. Typical Value: -8.4 -12.7 -9.2 -7.1 -15.2 2-3-2Measurin g Method 1. A 50Ωcoaxial cable is connected to the fpcb antenna. Then this cable is connected to a network analyzer to measure the VSWR. 2. Keeping this jig away from metal at least 20 cm. 2-3-3Picture 2-4. Measure and Chamber UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 3 OF 5 2-4-1 Measure method 1. Using a low loss coaxial cable to link a standard handset jig 2. Fixed this handset jig on chamber’s rotator plane 3. Linking jig into network analyzer port and using a probing horn antenna to collect data. 4. Using another standard gain horn antenna to calibrated those data 2-4-2 Chamber definition 1. An anechoic chamber (8mx4mx3.5m) which satisfied far-field condition was applied to avoid multi-path effect 2. The quite room region is 40cmx40cmx40cm at the center of rotator 3. The distance between DUT and standard antenna is 4.38 m 4. Probing antenna (9120D horn antenna) and standard gain horn antenna (BBHA9120 LPF 700MHz ~6GHz) 4.38 m Rotatory controller Vector Network Aanlyzer Port 2 Port 1 DUT Far-Field Chamber Std. Ant. UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 4 OF 5 2-4-3 Antenna Efficiency Frequency Efficiency Efficiency(dB) Gain(dBi) 1550 22% -6.6 -2.1 1555 23% -6.4 -1.8 1560 24% -6.2 -1.6 1565 25% -6.0 -1.4 1570 26% -5.9 -1.1 1575 26% -5.8 -1.0 1580 27% -5.7 -0.9 1585 27% -5.6 -0.9 1590 27% -5.6 -0.8 1595 28% -5.6 -0.8 1600 28% -5.6 -0.7 2400 30% -5.2 -1.5 2410 32% -5.0 -1.5 2420 33% -4.8 -1.5 2430 33% -4.8 -1.6 2440 33% -4.8 -1.6 2450 33% -4.8 -1.6 2460 32% -4.9 -1.7 2470 31% -5.1 -1.7 2480 30% -5.2 -1.7 2490 30% -5.3 -1.8 2500 29% -5.4 -2.0 UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 5 OF 5 Frequency Efficiency Efficiency(dB) Gain(dBi) 5100 16% -8.1 -0.4 5120 18% -7.4 0.3 5140 19% -7.2 0.9 5160 21% -6.7 0.1 5180 24% -6.1 0.9 5200 25% -6.0 0.2 5220 26% -5.8 0.7 5240 28% -5.6 0.7 5260 28% -5.5 0.7 5280 28% -5.5 0.3 5300 29% -5.4 0.5 5320 30% -5.2 1.0 5340 31% -5.1 1.2 5360 30% -5.2 1.2 5380 30% -5.2 1.5 5400 29% -5.3 1.4 5420 28% -5.5 1.4 5440 27% -5.7 1.3 5460 26% -5.8 1.4 5480 25% -6.0 1.3 5500 25% -6.1 1.5 5520 25% -6.1 1.3 5540 26% -5.8 1.2 5560 27% -5.7 1.0 5580 27% -5.6 1.0 5600 27% -5.7 1.0 5620 28% -5.5 1.1 5640 27% -5.7 1.1 5660 28% -5.6 1.1 5680 27% -5.7 1.2 5700 28% -5.5 1.0 5720 26% -5.8 1.2 5740 25% -6.0 0.9 5760 25% -5.9 0.9 5780 24% -6.2 0.8 5800 23% -6.4 0.8 3. Antenna Dimensions: UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 6 OF 5 4. Testing Environment Passive Test Active Test UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：曾传新 CHECKED BY： 郑由强 DESIGNED BY： 谢广权 APPROVED BY： 周振邦 TITLE： Specification DOCUMENT PAGE REV. NO. A0 PAGE 7 OF 5 5. 3D Radiation Pattern GPS [1575MHz] UNLESS OTHER SPECIFIED TOLERANCES ON： 浙江海通通讯电子股份有限公司 X＝±2 X.X＝±0.1 X.XX＝±0.05 AN…

Text truncated - open the document above for the full version.

Sushi TOWE Wireless Testing (Shenzhen) Co., Ltd. Report No.: TSEA26040038505 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. TEST REPORT Applicant: SHENZHEN ZHOUGUANG TECHNOLOGY CO.LTD. EUT Description: Vibe Dot Model: DT01A Brand: Vibe FCC ID: 2BB4N-DT01A Standards: FCC 47 CFR Part 15 Subpart E Date of Receipt: 2026/04/27 Date of Test: 2026/04/27 to 2026/06/26 Date of Issue: 2026/06/29 TOWE. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. the results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer's responsibility to assure that additional production units of the model are manufactured with identical electrical and mechanical components. All sample tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. without written approval of TOWE, the test report shall not be reproduced except in full. Jim Huang Approved By: Carey Chen Reviewed By: Page 2 / 27 Report No.: TSEA26040038505 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Revision History Rev. Issue Date Description Revised by 01 2026/06/29 Original Carey Chen Page 3 / 27 Report No.: TSEA26040038505 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Summary of Test Results Clause Test Items Test Standard Result 4.3.1 U-NII Detection Bandwidth KDB 905462 Clause7.8.1 N/A 4.3.3 Initial Channel Availability Check Time KDB 905462 Clause7.8.2.1 N/A 4.3.4 Radar Burst at the Beginning of the Channel Availability Check Time KDB 905462 Clause7.8.2.2 N/A 4.3.5 Radar Burst at the End of the Channel Availability Check Time KDB 905462 Clause7.8.2.3 N/A 4.3.6 In-Service Monitoring for Channel Move Time KDB 905462 Clause7.8.3 PASS 4.3.6 In-Service Monitoring for Channel Closing Transmission Time KDB 905462 Clause7.8.3 PASS 4.3.6 In-Service Monitoring for Non-Occupancy Period KDB 905462 Clause7.8.3 PASS 4.3.7 Statistical Performance Check KDB 905462 Clause7.8.4 N/A 4.2.4 User Access Restrictions KDB 905462 Clause8.1 N/A Test Method: ANSI C63.10-2020+Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024, KDB 789033 D02 General UNII Test Procedures New Rules v02r01 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 Remark: Pass is EUT meets standard requirements; N/A does not support Page 4 / 27 Report No.: TSEA26040038505 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Table of Contents 1 General Description ............................................................................................................................5 1.1 Lab Information .....................................................................................................................5 1.1.1 Testing Location ..............................................................................................................5 1.1.2 Test Facility / Accreditations ............................................................................................5 1.2 Client Information .................................................................................................................5 1.2.1 Applicant ..........................................................................................................................5 1.2.2 Manufacturer ....................................................................................................................5 1.3 Product Information ..............................................................................................................6 2 Test Configuration ..............................................................................................................................7 2.1 Test Channel .........................................................................................................................7 2.2 Worst-case configuration and Mode ...................................................................................8 2.3 Support Unit used in test .....................................................................................................8 2.4 Test Environment ..................................................................................................................8 2.5 Test RF Cable ........................................................................................................................8 2.6 Modifications .........................................................................................…

Text truncated - open the document above for the full version.

Page 99 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Project Information Mode: 802.11n20 Band: U-NII-3 Bandwidth 20MHz Channel 157 SN: - Engineer: Tian shuo Remark: X;Powersetting 102 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 7460.62 31.44 17.15 48.59 54.00 5.41 RMS Horizontal PASS 2 11571.67 35.39 6.55 41.94 54.00 12.06 RMS Horizontal PASS 3 17990.33 30.12 16.79 46.91 54.00 7.09 RMS Horizontal PASS 4 5780.54 83.46 14.17 97.63 - - PK Horizontal NA 5 7516.28 39.60 17.24 56.84 74.00 17.16 PK Horizontal PASS 6 11610.00 42.35 6.55 48.90 74.00 25.10 PK Horizontal PASS 7 17901.67 38.54 16.12 54.66 74.00 19.34 PK Horizontal PASS Page 100 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Project Information Mode: 802.11n20 Band: U-NII-3 Bandwidth 20MHz Channel 157 SN: - Engineer: Tian shuo Remark: X;Powersetting 102 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 7731.89 30.52 17.09 47.61 54.00 6.39 RMS Vertical PASS 2 11571.33 38.71 6.55 45.26 54.00 8.74 RMS Vertical PASS 3 17979.00 30.14 16.70 46.84 54.00 7.16 RMS Vertical PASS 4 5781.59 85.01 14.17 99.18 - - PK Vertical NA 5 7462.37 38.72 17.16 55.88 74.00 18.12 PK Vertical PASS 6 11568.67 46.03 6.55 52.58 74.00 21.42 PK Vertical PASS 7 17358.67 43.12 13.68 56.80 68.20 11.40 PK Vertical PASS Page 101 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Project Information Mode: 802.11n40 Band: U-NII-3 Bandwidth 40MHz Channel 159 SN: - Engineer: Tian shuo Remark: X;Powersetting 102 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 7488.27 30.40 17.29 47.69 54.00 6.31 RMS Horizontal PASS 2 12222.67 33.99 7.64 41.63 54.00 12.37 RMS Horizontal PASS 3 17974.33 30.02 16.67 46.69 54.00 7.31 RMS Horizontal PASS 4 5787.89 80.50 14.24 94.74 - - PK Horizontal NA 5 7467.62 39.35 17.19 56.54 74.00 17.46 PK Horizontal PASS 6 12446.67 41.84 7.46 49.30 74.00 24.70 PK Horizontal PASS 7 17983.00 37.76 16.73 54.49 74.00 19.51 PK Horizontal PASS Page 102 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Project Information Mode: 802.11n40 Band: U-NII-3 Bandwidth 40MHz Channel 159 SN: - Engineer: Tian shuo Remark: X;Powersetting 102 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 7536.93 30.65 17.11 47.76 54.00 6.24 RMS Vertical PASS 2 11589.00 37.33 6.56 43.89 54.00 10.11 RMS Vertical PASS 3 17917.00 30.32 16.23 46.55 54.00 7.45 RMS Vertical PASS 4 5779.84 81.43 14.16 95.59 - - PK Vertical NA 5 7456.07 39.03 17.13 56.16 74.00 17.84 PK Vertical PASS 6 11589.33 44.02 6.56 50.58 74.00 23.42 PK Vertical PASS 7 17972.67 38.28 16.65 54.93 74.00 19.07 PK Vertical PASS Page 103 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Radiated Band Edge Test Result Project Information Mode: 802.11a Band: U-NII-1 Bandwidth 20MHz Channel 36 SN: - Engineer: Tian shuo Remark: X;Powersetting 113 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 5148.05 38.83 10.97 49.80 54.00 4.20 RMS Horizontal PASS 2 5148.70 38.68 10.97 49.65 54.00 4.35 RMS Horizontal PASS 3 5149.74 39.07 10.97 50.04 54.00 3.96 RMS Horizontal PASS 4 5146.98 54.67 10.97 65.64 74.00 8.36 PK Horizontal PASS 5 5147.57 54.33 10.97 65.30 74.00 8.70 PK Horizontal PASS 6 5149.65 54.05 10.97 65.02 74.00 8.98 PK Horizontal PASS Page 104 / 138 Report No.: TSEA26040038504 Sushi TOWE Wireless Testing(Shenzhen) Co., Ltd. Email: [email protected] Tel.: +86-755-27212361 TOWE-QP-15-F05 Rev.1.1 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from TOWE. Project Information Mode: 802.11a Band: U-NII-1 Bandwidth 20MHz Channel 36 SN: - Engineer: Tian shuo Remark: X;Powersetting 113 Test Graph Data List NO. Freq. [MHz] Reading [dBμV] Factor [dB/m] Level [dBμV/m] Limit [dBμV/m] Margin [dB] Trace Polarity Verdict 1 5147.21 …

Text truncated - open the document above for the full version.
