CloudSIMkitManual Formoreinformation,pleasedownloadthecompleteguideon https://www.glocalme.com/support/user-manual/Thismanualisforreferenceonly,the actualproductshallprevail.Theinformationissubjecttochangewithoutnotice Copyright©2025uCloudlinkAllRightsReserved 1.ProductIntroduction 1.Indicatorlight2.Type-Cport3.On/Offbutton Indicatorlightstatus DevicestatuslightdisplayDescription WhenconnectingaSIM card GreenFlashLoggingin Greenslowflash LoginsuccessfulSplitcard orreplacecard GreenConstantRegistrationsuccessful Extinguish 5secondsaftersuccessful registration Whencharging GreenslowflashCharging Alwaysonfullof Abnormal/StartingupGreenFlash 2.Howtouse ？ Devicebinding： 1.ScantheQRcodeonthedevice,packaging,orimagebelowwithyourmobilephoneto downloadtheapp. 2.RegisterforaGlocalMeaccount:Opentheappandregisterforanaccount。 3.Logintoyouraccountonthemobileappinterface,thenclick“MyDevices”—“Bind Device”andscantheQRcodeonthedevicetobindit.。 4.Turnonthedevice:ConnecttheType-CadaptertotheCloudSIMkitandinsertthe correspondingcardtrayintotheterminaldevice.。 5.Afterwaitingforthegreenlighttostayon,theterminaldevicecansuccessfullyregisterfor Internetaccess.。 Note： 1.Chargethedevicefor20to30minutesbeforeinsertingtheSIMcard. 2.Ensurethatthecardslotoftheadaptercablematchesthedevice. Specialreminder： Itisrecommendedtousethedeviceinanambienttemperaturerangeof0°Cto+35°C. Avoidusingthedeviceinenvironmentswithextremelyhighorlowtemperatures.Donot leavethedeviceexposedtodirectsunlightforextendedperiodsoftime.Donotsealthe deviceinpackaging.Avoidusingthedeviceinhumidenvironments.。 Adaptercableaccessories： DependingontheSIMcardslottype(2FF,3FF,4FF,orcardtrayslot),differenttypesof adaptercablesareavailable.Pleaseselecttheappropriateadaptercablebeforeuse. 2.Technicalspecifications ProductModel:GLMU24A02Brand:GlocalMe PackingList:Device*1,QuickGuide*1,AdapterCable*1 Productdimensions：38*31.4*9mm FDD-LTE：B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/66 TDD-LTE：B38/41 Battery：152mAh（TypicalCapacity）/3.7V Input：5V/500mA Interface：Type-C 4 ． Q&A 1.Q：WhatshouldIdoiftheworkindicatorlightisflashing? A:Ifthedeviceisstillflashingafter5minutesofstartup,1.Checkiftheconnectionis normalandiftheterminaldevicecanreadthecard.Ifthecardisreadbutcannotbe registered,checkifthepackageisstillvalid.Ifthepackageisstillvalid,removethecloudsim kit,chargeitfor20minutes,andthenre-verify.Considermovingtoalocationwithbetter signalstrengthandrestartingthedevice. 2.Q：WhatshouldIdoiftheworkindicatorlightisnoton? A:Checkthattheconnectioncableisproperlyconnected.Orrechargefor20minutes andthenreconnectthedevice. 3.Q:Theterminaldisplaysthatthecardhasbeenread,butregistrationfails.WhatshouldI do? A:Checkwhetherthepackageisstillvalid.Ifitisvalid,removethecloudsimkit,chargeit for20minutes,andthenre-verifyit.Considermovingtoalocationwithbettersignal strengthandrestartingthedevice. CAUTION Riskofexplosionifthebatteryisreplacedbyanincorrecttypedisposalofabatteryintofire orahotoven,ormechanicallycrushingorcuttingofabattery,thatcanresultinan explosion; leavingabatteryinanextremelyhightemperaturesurroundingenvironmentthatcanresult inanexplosionortheleakageofflammableliquidorgas; abatterysubjectedtoextremelylowairpressurethatmayresultinanexplosionorthe leakageofflammableliquidorgas. Warning SpecificAbsorptionRate(SAR)referstotherateatwhichthebodyabsorbsRFenergy.The SARlimitis1.6wattsperkilogramincountriesthatsetthelimitaveragedover1gramof tissueand2.0wattsperkilogramincountriesthatsetthelimitaveragedover10gramsof tissue.Duringtesting,thedevicearesettotheirhighesttransmissionlevelsinalltested frequencybands,althoughtheSARisdeterminedatthehighestcertifiedpowerlevel,the actualSARlevelofthedevicewhileoperatingcanbewellbelowthemaximumvalue. EURegulatoryconformance ThedevicecomplieswithRFspecificationsandwhenusedwithanaccessorythatcontainsno metalandthatpositionsthedeviceaminimumof0.5cmfromthebody. TheSARlimitadoptedis2.0W/kgaveragedover10gramsoftissue.ThehighestSARvalue reportedforthedevicewhenproperlywornonthebodycomplieswiththelimit.Hereby, UCLOUDLINK（SINGAPORE）PTE.LTD.declaresthatthisdeviceisincompliancewiththe essentialrequirementsandotherrelevantprovisionsofDirective(RED)2014/53/EU. FCCRegulatoryconformance Forbodywornoperation,thedevicecomplieswithFCCRFexposureguidelinesandwhen usedwithanaccessorythatcontainsnometalandthatpositionsthedeviceaminimumof 0.5cmfromthebody. TheSARlimitadoptedbytheFCCis1.6W/kgaveragedover1gramoftissue.Thehighest SARvaluereportedforthedevicewhenproperlywornonthebodycomplieswiththelimit. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust acceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser’sauthoritytooperatetheequipment. Note:ThisequipmenthasbeentestedandcomplieswiththelimitsforaClassBdigital device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance withtheinstructions,maycauseharmfulinterferencetoradiocommunications.However, thereisnoguaranteethatinterferencewillnotoccurduringinstallation.Ifthedevicedoes causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby turningtheequipmentoffandon,theuserissuggestedtotrytocorrecttheinterferenceby thefollowingmeasures: --Reorientorrelocatethereceivingantenna. --Increasethedistancebetweentheequipmentandreceiver. --Connecttheequipmenttoanoutletonadifferentcircuittothereceiver. --Consultthemanufactureroranexperiencedradio/TVtechnicianforhelp. InformationonthedisposalandrecyclingofthedeviceThissymbol(withorwithout asolidbar)onthedevice,batteries(ifincluded),and/orthepackaging,indicates thatthedeviceanditselectricalaccessories(forexample,aheadset,adapter,orcable)and batteriesshouldnotbedis…
