2BBNQ-DFDCAM1Defend Cam

INSTRUCTION MANUAL REVEALCELLCAM.COM DEFENDCAM TACTACAM.COM DEER MANAGEMENT SYSTEMS, LLC INSTRUCTION MANUAL 2 DEFEND ApP DOWNLOAD DOWNLOAD THE DEFEND APP VISIT YOUR APP STORE TO DOWN LOAD TACTACAM.COM 3 INTRODUCTION 4 TABLE OF CONTENTS TABLE OF CONTENTS 3 What is in the Box? 4 What you will need 4 QUICK START GUIDE 6 Setting Up Your Account 7 Downloading the App 7 Add Camera to the App 8 Sending a Test Picture 10 Leaving Your Camera Outside 11 SETTINGS & SPECIFICATIONS 12 BEST PRACTICES 14 Proper Camera Placement 14 Batteries and Camera Performance 14 TROUBLESHOOTING 15 Camera Sends Pictures of Nothing 15 Night Vision Flash Range Doesn’t Meet Expectations 15 Camera Stops Taking Images or Won’t Take Images 16 WARRANTY 17 4 TACTACAM.COM INTRODUCTION • (1) Security Camera • (1) Instruction Manual • (1) Mount • (1) Verizon & AT&T SIM Card • Full-size SD Card - Class 10, U3, • 16GB-32GB • Recommended Brands: Tactacam, Lexar, SanDisk (Other brands that are lower end SD cards Reveal X 3.0 and willare incompatible with the Reveal will yield unexpected results) • (12) AA Batteries Required - Lithium Batteries recommended in colder temperatures X-Pro and WHAT IS IN THE BOX? RECOMMENDED CAMERA ACCESSORIES (NOT INCLUDED) SD Card Solar Panel Lithium Cartridge VIEW AND PURCHASE ALL ACCESSORIES AT DEFENDCAM.COM Armoured Solar Cable No Trespassing Sign WHAT YOU WILL NEED 5 INTRODUCTION 6 SETTING UP THE CAMERA QUICK START GUIDE 1.Install camera’s antenna. •Note: Do not over tighten the antenna, once it is secure stop tightening to prevent antenna port damage. 2. Install a Class 10 U3 SD card (16GB or 32GB). •Recommended brands are: SanDisk, Lexar and Tactacam 3. Install 12 AA batteries. •To eject the battery tray, open the battery door latch on the back of the camera. When inserting AA batteries correctly orientate + and - on the front and back of the tray. See battery details on page 13 under Best Practices. Verizon and AT&T SIM Card install Locate the (Verizon and AT&T) Sim card located in the white envelope included in your package. Remove the desired SIM (Verizon or AT&T) from its holder and install into the Sim slot of your camera. Cell Phone Carrier vs. Camera Carrier: The carrier you choose (Verizon or AT&T) does not need to match your cell phone carrier. Just make sure you choose the carrier that has be best signal coverage in the area you will be keeping the camera. https://www.revealcellcam.com/data-plans When activating the camera in the APP will need to select (Verizon or AT&T) depending on which Sim you selected for your camera. Note: The SIM cards are connected to your camera so do not mix or use SIM’s from other cameras including other Reveals. Here is the link to our Data Plans and Coverage Map TACTACAM.COM 7 QUICK START GUIDE In your Apple or Google Play Store, download the DEFEND app and sign in using the same email and password you created on the website. https://account.defend.com DOWNLOADING THE APP If this is the first Defend camera yu will be activiating, please visit the Defend Web Portal at https://account.defend.com/activation to set up your account. You can also access the Web Portal directly from your app, by clicking My Defend on the account page in the app. If you already have a Defend account with ACTIVE cameras, you can simply log in to your app and add your camera following the instructions on page 8. SETTING UP YOUR ACCOUNT 8 QUICK START GUIDE ADD CAMERA TO THE APP 1.Navigate to the Defend app on your device and login using your Defend account credentials. Click the home icon. 2. Click the camera icon at the top. 3. From the camera page click the (+) in the bottom right hand corner. 4.Follow the in-app prompts to activate your Defend cam. Ensure the SIM selected (Verizon or AT&T) mirrors (or is the same as) the SIM card already inserted in the camera. 5. The app will prompt you to scan the QR code located inside the door of the camera. 6.After your camera is activated, turn your camera to setup, you will see the signal status indicator searching, and then connect showing the signal strength. TACTACAM.COM Ɣ QUICK START GUIDE You can automatically change and apply the camera settings when your phone is connected to the camera’s Wi-Fi. This will not work unless you are next to the camera. 1. 2. When the Wi-Fi light is blinking blue, it is ready to pair to your phone or tablet. 3. In the app go to the Account page and click Connect to 4. Follow the in-app instructions and turn ALL slides to the ON position. You can also manually connect in your phone’s Wi-Fi settings, select Defend and enter the password ( DEFEND2024 )This Wi-Fi password is case sensitive, no spaces. 5. See preview on screen a. Red line on preview is point of focus b.To send test picture, press “Test” button on camera Also available in the app while connected to Wi-Fi: a. Instantly apply setting changes from the app b.Formatting SD Card Turn Reveal X to SETUP mode. Reveal X/SK Wi-Fi. PAIRING YOUR CAMERA TO YOUR PHONE THROUGH WI-FI Turn Defedn to SETUP mode. Defend Wi-Fi. 10 TACTACAM.COM QUICK START GUIDE 1.Allow the camera to connect to 4G signal. The LED signal indicator light will be constant green. •After your camera is activated, you will see the signal status indicator searching, and then connect showing the signal strength. •After the camera has connected, push the test button to send a photograph. •You will see the status light blinking as the image is sending. •When the test picture sends successfully, the status light will turn green. •If the status light turns red there may have been an issue trying to send the test photo. This is usually caused by signal strength or the SD Card. SENDING A TEST PICTURE From the camera page click the settings icon to make changes to the cameras settings. Make sure to select “Apply Settings” when done to save your changes. Note: In cameras SETTINGS > Settings Check, Daily will check settings every 24 hours. Instant will Receive settings Instantly but will consume mor…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Deer Management Systems LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024/5/28 FCC ID: 2BBNQ-DFDCAM1 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing Deer Management Systems LLC certifies that the equipment for which authorization is sought is not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing Deer Management Systems LLC certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature： Print name: Brian Wrightsman

[Deer Management Systems LLC] [1668 Jordan West Road Decorah Iowa United States] Date: [2024/5/28] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: [2BBNQ-DFDCAM1]; FRN: 0033881582 US Agent – Attestation Statement / Part 2.911(d)(7) [Deer Management Systems LLC] certifies, that as of [2024/1/9], we have designated Deer Management Systems LLC to accept service of process on our behalf for FCC ID: [2BBNQ- DFDCAM1]. [Deer Management Systems LLC], accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. Deer Management Systems LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Deer Management Systems LLC] for FCC ID: [2BBNQ-DFDCAM1]. Designated Agent Information: Company Name: Deer Management Systems LLC FRN: 0033881582 Address: 1668 Jordan West Road Decorah Iowa United States Contact Person: Brian Wrightsman Telephone: 8122366730 Email: [email protected] Sincerely, Company: [Deer Management Systems LLC] Designated Agent: Deer Management Systems LLC Company Representative: [Brian Wrightsman] Designated Agent Representative: Brian Wrightsman Signature: Signature:

Deer Management Systems LLC POWER OF ATTORNEY DATE: 2024-5-28 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize TA Technology (Shanghai) Co., Ltd. /Yu Hongmei on our behalf, to apply to FCC on our equipment for FCC ID: 2BBNQ-DFDCAM1. Any and all acts carried out by TA Technology (Shanghai) Co., Ltd. / Yu Hongmei on our behalf shall have the same effect as acts of our own. Sincerely, Signature ： Print name: Brian Wrightsman Company：Deer Management Systems LLC

Deer Management Systems LLC Request for Confidentiality Date: _2024-5-28_ Subject: Confidentiality Request for: _ FCC ID: 2BBNQ-DFDCAM1 __ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Schematics Short Term Permanent Tune-Up Procedure Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _ Deer Management Systems LLC has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Brian Wrightsman (Signature/Title 2 ) (Print name)

EUT Appearance Report No.: R2404A0397 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 1 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance EUT Appearance Report No.: R2404A0397 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 2 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. EUT Appearance Report No.: R2404A0397 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 3 of 3 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Picture 1: Constituents of EUT

Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 1 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo Main Antenna Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 2 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 3 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 4 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 5 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 6 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 7 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 8 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 9 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 10 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 11 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 12 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2BBNQ-DFDCAM1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 13 of 13 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd.

Prepared by: Wei Fangying Approved by: Fan Guangchang Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE TEST REPORT Applicant Deer Management Systems LLC FCC ID 2BBNQ-DFDCAM1 Product Defend Cam Brand Tactacam Model Defend Cam Gen 1 Report No. R2404A0397-M1 Issue Date May 28, 2024 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC 47 CFR Part 1 1.1310. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. MPE Test Report Report No.: R2404A0397-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 2 of 9 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ................................................................................................................................. 3 1.1 Notes of the Test Report ............................................................................................................ 3 1.2 Test Facility ................................................................................................................................ 3 1.3 Testing Location......................................................................................................................... 3 1.4 Laboratory Environment ............................................................................................................ 3 2 Description of Equipment Under Test ............................................................................................... 4 3 Maximum Tune up and Antenna Gain .............................................................................................. 5 4 MPE Limit .......................................................................................................................................... 6 5 RF Exposure Evaluation Result ........................................................................................................ 8 ANNEX A: The EUT Appearance ............................................................................................................. 9 MPE Test Report Report No.: R2404A0397-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 3 of 9 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2 Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. 1.3 Testing Location Company: Eurofins TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Fan Guangchang Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: https://www.eurofins.com/electrical-and-electronics E-mail: [email protected] 1.4 Laboratory Environment Temperature Min. = 18  C, Max. = 25  C Relative humidity Min. = 20%, Max. = 80% Ground system resistance < 0.5  Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. MPE Test Report Report No.: R2404A0397-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 4 of 9 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 2 Description of Equipment Under Test Client Information Applicant Deer Management Systems LLC Applicant address 1668 Jordan West Road Decorah Iowa United States Manufacturer Deer Management Systems LLC Manufacturer address 1668 Jordan West Road Decorah Iowa United States General Technologies EUT Description Model Defend Cam Gen 1 Lab internal SN R2404A0397/S01 Hardware Version P3 Software Version 1.0 Frequency Band TX (MHz) RX (MHz) WCDMA Band II 1850 ~ 1910 1930 ~ 1990 WCDMA Band IV 1710 ~ 1755 2110 ~ 2155 WCDMA Band V 824 ~ 849 869 ~ 894 LTE Band 2 1850 ~ 1910 1930 ~ 1990 LTE Band 4 1710 ~ 1755 2110 ~ 2155 LTE Band 5 824 ~ 849 869 ~ 894 LTE Band 12 699 ~ 716 729 ~ 746 LTE Band 13 777 ~ 787 746 ~ 756 LTE Band 25 1850 ~ 1915 1930 ~ 1995 LTE Band 26 814 ~ 849 859 ~ 894 Bluetooth LE 2400 ~ 2483.5 2400 ~ 2483.5 Wi-Fi 2.4G 2400 ~ 2483.5 2400 ~ 2483.5 Date of Testing April 16, 2024 ~ May 7, 2024 Date of Sample Received April 15, 2024 Note: 1. The EUT is sent from the applicant to Eurofins TA and the information of the EUT is declared by the applicant. 2. All indications of Pass/Fail in this report are opinions expressed by Eurofins TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. MPE Test Report Report No.: R2404A0397-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 5 of 9 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 3 Maximum Tune up and Antenna Gain The numeric gain (G) of the antenna with a gain specified in dB i…

Text truncated - open the document above for the full version.

规 格 承 认 书 SPECIFICATION FOR APPROVAL 日期 DATE: 2024.4.12 版本 REV.: V1.0 客户 德明通讯（上海）股份有限公司 CUSTOMER: 客 户 料 号 CUSTOMERP/N: 品名 DC10-BT/WIFIAntenna PARTNAME: 供 方 料 号 SUPPLIERP/N: 送样日期 Date: 送样数量 Q’TY: Pcs 客户确认 CUSTOMER APPROVED BY 工程研发部 生产采购部 承认 ENGINEER R&D DEPTBUSSINESS DEPTAPPROVED BY 供方确认 SUPPLIER SIGNATURE 研发部工程部批准 ENGINEER R&D DEPTENGINEER R&D DEPTAPPROVAL Index 1. RFFixtureExperiment.....................................................................................................1 1.1TestSetup.....................................................................................................................3 1.2UEconfiguration...........................................................................................................4 2. TestResult.......................................................................................................................5 2.1PassiveTestResult(Sparameters)...............................................................................5 3. Mechanicalinstruction...................................................................................................6 1. RFFixtureExperiment 1.1TestSetup 1.1.1VNATestSetup VSWR and Return Loss measurements (S11) were performed using an KeySight E5071C Network Analyzer. The isolation between antennas is also teste. The testing wasperformedwithapparatusinfreespace. 1.1.2AnechoicChamberTestSetup When we test Gain and Efficiency of the antenna, we will use the Multi-Probe OTA MeasurementSystem 3Dchamber. Thechamberprovidestestfrequency from400MHzto6GHz.Therealtestenvironment isshowingasfollowingpicture 1.2UEconfiguration 1.2.1Antennalocationpictures OntherightistheBTantenna,OntheleftistheWIFIantenna. 1.2.2RFmatchingfordifferentantennas 2. TestResult 2.1PassiveTestResult(Sparameters) WIFIAntennaBTAntenna WIFI AntennaBT Antenna frequency (MHz) gain (dBi) efficiency (%) frequency (MHz) gain (dBi) efficiency (%) 24001.3554.7724001.8851.54 24101.453.5824101.8649.9 24201.6456.2124202.2552.39 24301.6158.4924302.5555.94 24401.0955.8524402.3254.45 24500.6754.6524502.1253.73 24600.5855.0224602.1653.99 24700.7256.624702.4455.08 24801.0159.7624802.9858.05 24901.160.0124903.2358.21 2500155.5925002.8853.61

Prepared by: Zhu Chentao Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant Deer Management Systems LLC FCC ID 2BBNQ-DFDCAM1 Product Defend Cam Brand Tactacam Model Defend Cam Gen 1 Report No. R2404A0397-R5 Issue Date May 28, 2024 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C (2023). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: R2404A0397-R5 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 129 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................... 4 1.1. Notes of the Test Report ......................................................................................................... 4 1.2. Test Facility ............................................................................................................................. 4 1.3. Testing Location ...................................................................................................................... 4 2. General Description of Equipment Under Test ............................................................................... 5 2.1. Applicant and Manufacturer Information ................................................................................ 5 2.2. General Information ................................................................................................................ 5 3. Applied Standards ........................................................................................................................... 7 4. Test Configuration ........................................................................................................................... 8 5. Test Case Results ........................................................................................................................... 9 5.1. Maximum output power .......................................................................................................... 9 5.2. 99% Bandwidth and 6dB Bandwidth .................................................................................... 12 5.3. Band Edge ............................................................................................................................ 32 5.4. Power Spectral Density ........................................................................................................ 45 5.5. Spurious RF Conducted Emissions ...................................................................................... 57 5.6. Unwanted Emission .............................................................................................................. 77 5.7. Conducted Emission ........................................................................................................... 122 6. Main Test Instruments................................................................................................................. 127 ANNEX A: The EUT Appearance ....................................................................................................... 128 ANNEX B: Test Setup Photos ............................................................................................................ 129 RF Test Report Report No.: R2404A0397-R5 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 3 of 129 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Summary of Measurement Results Number Test Case Clause in FCC rules Verdict 1 Maximum output power 15.247(b)(3) PASS 2 99% Bandwidth and 6dB Bandwidth 15.247(a)(2) C63.10 6.9 PASS 3 Power spectral density 15.247(e) PASS 4 Band Edge 15.247(d) PASS 5 Spurious RF Conducted Emissions 15.247(d) PASS 6 Unwanted Emissions 15.247(d), 15.205, 15.209 PASS 7 Conducted Emissions 15.207 PASS Date of Testing: April 16, 2024 ~ May 7, 2024 Date of Sample Received: April 15, 2024 Note: All indications of Pass/Fail in this report are opinions expressed by Eurofins TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. RF Test Report Report No.: R2404A0397-R5 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 4 of 129 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. A2LA (Certificate Number: 3857.01) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform measurement. 1.3. Testing Location Company: Eurofins TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Sh…

Text truncated - open the document above for the full version.

RF Test Report Report No.: R2404A0397-R5 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 77 of 129 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 5.6. Unwanted Emission Ambient Condition Temperature Relative humidity 15°C ~ 35°C 20% ~ 80% Method of Measurement The test set-up was made in accordance to the general provisions of ANSI C63.10. The Equipment Under Test (EUT) was set up on a non-conductive table in the semi-anechoic chamber. The test was performed at the distance of 3 m between the EUT and the receiving antenna. The turntable shall be rotated from 0 to 360 degrees for detecting the maximum of radiated spurious signal level. The measurements shall be repeated with orthogonal polarization of the test antenna.The data of cable loss and antenna factor has been calibrated in full testing frequency range before the testing. Sweep the Restricted Band and the emissions less than 20 dB below the permissible value are reported. The radiated emissions measurements were made in a typical installation configuration. Sweep the whole frequency band through the range from 9 kHz to the 10th harmonic of the carrier, and the emissions less than 20 dB below the permissible value are reported. This method refer to ANSI C63.10. The procedure for peak unwanted …
