QUICK START GUIDE Introduction X3.0 is standard powerful trial camera. It can feature high resolution video and high-dynamic-range (HDR) imaging, which brings out details in the shadows and highlights. The products support below main feature. LTE: Cat-1 B2/4/5/12/13/14/25/66 WIFI 2.4G GNSS Bluetooth Support fully size SD card Type-C connector Temperature and humidity: -25C to +60C, 5%-90% Size：149.75 x 95.01 x 95 mm (60.5 is thickness of the main body) Installing Process: Use the accompanying straps to mount the device on the tree, as shown in the picture. Install a class 10 U3 SD card - Optional Install 12 AA batteries – Lithium AA’s recommended Reveal X 3.0 cameras will automatically select the carrier with the strongest signal. Power camera on so it can start the signal search. Press the button on Pro 3.0 or slide the power switch to “SETUP” on the X 3.0. Notes: •No SIM card needed, internal SIM is preinstalled •Verified SD card Brands: Tactacam, Lexar, SanDisk •The camera will automatically search for the strongest carrier signal any time it is powered on. During the search, the signal strength indicator bars will scroll. When complete, the signal bars will stay lit. •If the camera is switched to work mode before the carrier search is complete, the carrier search will continue. In 1 to 3 minutes, the search will be complete and the camera will be active in work mode. Set up a REVEAL account and purchase a plan at: account.revealcellcam.com Download the Tactacam REVEAL mobile app Use the app to expand the navigation menu at the top left corner, and select “ADD A CAMERA” KEEP YOUR CAMERAS ACTIVE WITH UPGRADED POWER ACCESSORIES. SOLAR PANEL LITHIUM CARTRIDGE Learn more at Tactacam.com TACTACAM REWARDS EXCLUSIVE PERKS. EARLY ACCESS. VIP SERVICE. Tactacam Rewards is home to exclusive perks, promotions, and VIP service benefits. Scan the QR Code to learn more. Tactacam.com/Rewards Join us on social media and subscribe to our email to stay up to date on all things TACTACAM! FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with FCC RF Exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for the transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co - located or operating in conjunction with any other antenna or transmitter. ISED Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. In order to avoid the possibility of exceeding the IC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. Afin d'éviter la possibilité de dépasser les limites d'exposition aux fréquences radio de la IC CNR102, la proximité humaine à l'antenne ne doit pas être inférieure à 20 cm (8 pouces) pendant le fonctionnement normal.
