2BCK5TBV10Tedee Bridge

tedee bridge | page 1www.tedee.com INSTALLATION GUIDE AND USER MANUAL tedee bridge TBV1.0 Read installation guide and user manual and learn how to use your device in a safe and proper manner. EN page 2 | tedee bridge www.tedee.com table of contents ƒtable of contents ƒquick start with tedee bridge ƒsafety information ƒsafety guidelines / warnings ƒcharging and maintenance guidelines / warnings ƒset of items – what’s in the box? ƒdistance / range requirement ƒactivation code ƒsetup - 3 easy steps ƒstep 1: download tedee app, create new account, and log in ƒstep 2: power up your tedee bridge ƒstep 3: use tedee app to activate your tedee bridge ƒfactory reset ƒtechnical information ƒtechnical specification ƒradio frequency ƒUSB charger ƒpower supply ƒsoftware ƒLED signals ƒcompliance and warranty information ƒlegal / environmental notes ƒwarranty ƒtechnical support ƒyour activation code (AC) Page 2 Page 3 Page 4 Page 4 Page 5 Page 6 Page 6 Page 7 Page 8 Page 8 Page 9 Page 12 Page 13 Page 13 Page 13 Page 14 Page 15 Page 15 Page 16 Page 17 Page 18 Page 18 Page 19 Page 19 Page 20 tedee bridge | page 3www.tedee.com quick start with tedee bridge tedee bridge setup - go to page 8 3 easy steps Tedee bridge is a wireless router which works as a hub, connecting your smart- phone with tedee lock and other tedee smart home devices. This booklet will give you an overview of the basic features of tedee bridge and will help you walk through the setup in three easy steps. GET tedee application ACTIVATE it POWER UP your bridge 123 Page 2 Page 3 Page 4 Page 4 Page 5 Page 6 Page 6 Page 7 Page 8 Page 8 Page 9 Page 12 Page 13 Page 13 Page 13 Page 14 Page 15 Page 15 Page 16 Page 17 Page 18 Page 18 Page 19 Page 19 Page 20 page 4 | tedee bridgewww.tedee.com safety information safety guidelines / warnings Do not ƒDo not open, modify or disassemble your device. ƒDo not self-service any part of the device. ƒDo not immerse device in any liquid or expose it to moisture. ƒDo not use the device near extreme heat source or open fi e. ƒDo not use the device in an environment of a high humidity or dust levels, as well as pollution degree 2. ƒDo not insert any conductive objects in device openings and gaps. ƒThe device should not be used by children without adult supervision. Do ƒIf repairs are required, please contact tedee technical support. ƒUse only power supply devices provided or recommended by tedee. ƒRead installation guide in order to learn how to start working with your device and how to pair it with your tedee app and other tedee devices. You can also follow the link: www.tedee.com/installation-guide Other information ƒThis device is safe to use under normal and reasonably foreseeable misuse operating code of conduct. If you notice any signs of errors or hardware malfunction, contact tedee technical sup- port for help. In such case this device should be returned to tedee for necessary repairs under the warranty conditions. Any changes or modifications to the device’s hardware or software which are not approved, recommended, or provided by tedee may void your warranty. WARNING: Read all safety guidelines and warnings. Failure to follow the guidelines and warnings may result in electric shock, fi e, and / or serious injury. tedee bridge | page 5www.tedee.com charging and maintenance guidelines / warnings Charging and maintenance ƒPlease read all precautions before use. ƒDo not insert any conductive objects into the device openings or gaps - this may cause a short circuit. ƒCharge your device only with the provided approved accessories designated for this product. ƒUnplug the product before cleaning. Wipe it only with a dry cloth. ƒDo not use chargers with an output voltage greater than 5V and 2A. ƒWhen disconnecting the power cord or any other accessory, grasp and pull the plug, not the cord. Never use a charger that is damaged. ƒDo not attempt to disassemble the charger or cord, as it may expose you to electric shock. Other information ƒDispose the devices in accordance with your local regulations. If possible, recycle. ƒDo not dispose the device as a household waste and do not burn it. ƒNeither Tedee Sp. z o.o., nor our retailers are responsible for failure to comply with the above warnings and safety guidelines. By purchasing this device, the buyer acknowledges all risks associated with the use of tedee equipment. If you do not agree to these terms, return the device to the manufacturer or distributor before use. WARNING: If the housing (case) or any other energized part of the device is damaged, immediately turn off all fuses (outlet circuits) throughout the house, unplug the device from the outlet with an insulated tool, reconnect the fuses, and contact Tedee to receive further assistance. page 6 | tedee bridge www.tedee.com set of items – what’s in the box? distance / range requirement 1 2 3 4 5 6 Recommended distance between tedee bridge, tedee lock, and a local Wi-Fi network * physical obstacles such as walls, doors, and furniture may weaken the radio signal and affect some of the functionalities of tedee devices. tedee bridgeUSB charger up to 2m* 1. LED 2. Micro USB port 3. The button 4. Activation code (QR) 5. USB port 6. USB charger up to 10m* local Wi-Fi router (in range)(recommended) tedee bridgetedee lock tedee bridge | page 7www.tedee.com REAR SIDE OF TEDEE BRIDGE 2 Activation code (AC) of your tedee bridge is printed on: ƒlast page of this installation guide (1) ƒrear side of your device (2) While adding your device to tedee app you can either: ƒscan the QR Code ƒtype in the AC manually (14 characters) Helpful tip Before plugging tedee bridge into a power outlet, take a photo of your activation code and keep it. Location of a unique activation code (AC) of your tedee bridge ACTIVATION CODE: 184800aabbCCDd activation code LAST PAGE OF THIS GUIDE 1 ACTIVATION CODE page 8 | tedee bridgewww.tedee.com setup - 3 easy steps step 1: download tedee app, create new account, and log in (skip this step if you a…

Text truncated - open the document above for the full version.

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND CFR 47 §2.911 (d)(5) Attestation Date: 08-17-2023 FCC ID: 2BCK5TBV10 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA 1. Tedee Sp. z o.o. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Tedee Sp. z o.o. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

UL International (UK) LtdULID-018088 issue 1 CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: 10-09-2023 FCC ID: 2BCK5TBV10 To:Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Tedee(“the applicant”)as required by section 2.911(d)(7), designatesthe followingagent, located in the United States,for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Robert Jablonski Recharge Consulting LLC 13809 Research Blvd STE 500, Austin, TX 78750 [email protected] Sincerely yours, Name:Wojciech Wojas Job Title:Legal & Compliance Counsel Company Name:Tedee

UL International (UK) LtdULID-018088 issue 1FCC Agent Attestation letter template CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation Date: 10-09-2023 FCC ID: 2BCK5TBV10 To:Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC US Agent Recharge Consulting LLC FRN: 0034332874 Robert Jablonski 13809 Research Blvd STE 500, Austin, TX 78750 [email protected] This letteris to confirm that we have accepted the responsibility to act as US Agent on behalf of Tedee Sp. z o. o.(“the applicant”) for the above referenced FCC ID. Weare aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7)and Report and Order FCC 22-84 paragraph 63. Sincerely yours, Robert Jablonski President Recharge Consulting LLC

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND 08.17.2023 Telecommunication Certification Body UL International (UK) Ltd Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Authorisation Letter To whom it may concern This is to certify that Tedee Sp. z o.o. hereby authorises UL International (UK) Ltd. to act as the TCB for the application of the Tedee Bridge, TBV1.0, FCC ID: 2BCK5TBV10 to the FCC. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours faithfully, Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND 15. 09.2023 Telecommunication Certification Body UL International (UK) Ltd Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Permanent Confidentiality Request Certification Application FCC ID: FCC ID: 2BCK5TBV10 To w hom it may concern Pursuant to Sections 0.457(d) and 0.459 of CFR 47, Tedee Sp. z o.o. request that the following information, provided to support the FCC application for the Tedee Bridge, TBV1.0, FCC ID: 2BCK5TBV10 to be held permanently confidential: •Schematics •Block Diagrams •Operational Description The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. This information should not be available for public disclosure for an indefinite period of time. Yours faithfully Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

A1 Scale: '$$
*%
-BCFM
BOE
-PDBUJPO FCC ID: 2BCK5TBV10 Label Location Label Area: This outline drawing shows the label located in the rear side of the device. The label is visible to the user at the point of device assembly prior to attaching it to the power source (Rear View) 1. Serial number of the device 2. Device Type 3. Device Name 4. Production year 5. FCC ID 6. Manufactuer's logo 7. Manufacturer's address Designed In Europe Wireless Router TEDEE BRIDGE TBV1.0A I 2023 5V 300mA Tedee Sp. z o.o. ul. Karola Bohdanowicza 21/57 02-127 Warszawa, POLAND A NATEL: 06916-23-15521 FCC ID: 2BCK5TBV10 Contains FCC ID: 2AHMR-BW16 Wireless Router TEDEE BRIDGE TBV1.0A I 2023 5V 300mA Tedee Sp. z o.o. ul. K arola Bohdanowicza 21/57 02-127 Warszawa, POLAND ANATEL: 06916-23-15521 FCC ID: 2BCK5TBV10 Contains FCC ID: 2AHMR-BW16

Contact us: www.tedee.com [email protected] (+48) 22185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127Warszawa POLAND RF Exposure Analysis –SAR Test Exemption FCC ID: 2BCK5TBV10 The Tedee Bridge equipment operates using a 2.4GHz BT LE transmitter, together with a pre- certified 2.4GHz/ 5GHz WLAN transmitter. (FCC ID:2AHMR-BW16). The WLAN transmitter is installed and operated in accordance with its certification conditions and DOES NOT operate simultaneously with the BT transmitter. The following FCC Rule Parts are applicable: Part 2.1093 –Radiofrequency radiation exposure evaluation: portable devices Part 1.1307(b)(3)(i)(C) -SAR test exemption (ii) Part 1.1307(b)(3)(i)(B) -SAR test exemption (iii) For the Tedee Bridge –BT Operation Values (as defined in Tedee Operational Description document): BT Operating Frequency: 2402 –2480MHz Tx Power: +6.0dBm max. Antenna gain +2.0dBi EIRP = 8.0dBm ERP = 8.0-2.15dBm = 5.85dBm (3.85mW) Minimum separation distance (R) = 20cm (0.2m) Evaluation From Part 2.1093(c)(1). RF exemption applies if the maximum transmitted power is less than the maximum of the following three criteria: i)Less than 1 mw Blanket exemption. PTH = 0.001 W –(The Tedee Bridge is NOT compliant) ii)determination of exemption under the MPE-based §1.1307(b)(3)(i)(C), if i) not met iii)determination of exemption under the SAR-based §1.1307(b)(3)(i)(B) if both i) and ii) are not met; Determination of threshold power (P TH ) under the MPE-based §1.1307(b)(3)(i)(C) This is only applicable at a separation distance greater than λ/2π For the Tedee Bridge: 2.4GHz operation -λ/2π = 0.02m The Tedee Bridgeseparation distance equals 0.2m therefore this clause IS applicable. From §1.1307(b)(3)(i)(C), Table 1: Threshold ERP PTH (2.4GHz) = 19.2R2 watts (R = metres) ie: Threshold Power PTH = 19.2 x 0.22 ERP = 768mW The Tedee Bridge max. transmitter power @ 2402MHz = 3.85mW ERP, so §1.1307(b)(3)(i)(B is not appliable and the Tedee Bridge is therefore exempt from MPE evaluation in accordance with §1.1307(b)(3)(i)(C).

UL International (UK) LTD Unit 1-4 Horizon, Kingsland Business Park, Wade Road, Basingstoke, Hampshire, RG24 8AH, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP14880601-516A Customer : Tedee Sp. z.o.o. Model No. : TBV1.0 FCC ID : 2BCK5TBV10 Technology : Bluetooth – Low Energy Test Standard(s) : FCC Parts 15.207, 15.209(a) & 15.247 Test Laboratory : UL International (UK) Ltd, Basingstoke, Hampshire, RG24 8AH, United Kingdom 1. This test report shall not be reproduced except in full, without the written approval of UL International (UK) Ltd. 2. The results in this report apply only to the sample(s) tested. 3. The sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 2.0 supersedes all previous versions. Date of Issue: 27 October 2023 Checked by: Ben Mercer Lead Project Engineer, Radio Laboratory Company Signatory: Sarah Williams RF Operations Leader, Radio Laboratory The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by UL International (UK) Ltd is under licence. Other trademarks and trade names are those of their respective owners. TEST REPORT SERIAL NO: UL-RPT-RP14880601-516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 2 of 37 Customer Information Company Name: Tedee Sp. z.o.o. Address: UI. Karola Bohdanowicza 21/57, 02-127 Warsaw, Poland Report Revision History Version Number Issue Date Revision Details Revised By 1.0 23/10/2023 Initial Version Ben Mercer 2.0 27/10/2023 TCB requested updates Ben Mercer TEST REPORT SERIAL NO: UL-RPT-RP14880601-516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 3 of 37 Table of Contents Customer Information ................................................................................................................... 2 Report Revision History ................................................................................................................ 2 Table of Contents ........................................................................................................................... 3 1 Attestation of Test Results ........................................................................................................ 4 1.1 Description of EUT 4 1.2 General Information 4 1.3 Summary of Test Results 5 1.4 Deviations from the Test Specification 5 2 Summary of Testing ................................................................................................................... 6 2.1 Facilities and Accreditation 6 2.2 Methods and Procedures 6 2.3 Calibration and Uncertainty 7 2.4 Test and Measurement Equipment 8 3 Equipment Under Test (EUT) ................................................................................................... 11 3.1 Identification of Equipment Under Test (EUT) 11 3.2 Modifications Incorporated in the EUT 11 3.3 Additional Information Related to Testing 12 3.4 Description of Available Antennas 12 3.5 Description of Test Setup 13 4 Antenna Port Test Results ....................................................................................................... 18 4.1 Transmitter Minimum 6 dB Bandwidth 18 4.2 Transmitter Maximum Peak Output Power 21 5 Radiated Test Results .............................................................................................................. 23 5.1 Transmitter Radiated Emissions <1 GHz 23 5.2 Transmitter Radiated Emissions >1 GHz 25 5.3 Transmitter Band Edge Radiated Emissions 28 6 AC Power Line Conducted Emissions Test Results ............................................................. 33 6.1 Transmitter AC Conducted Spurious Emissions 33 TEST REPORT SERIAL NO: UL-RPT-RP14880601-516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 4 of 37 1 Attestation of Test Results 1.1 Description of EUT The equipment under test was a smart lock wireless bridge incorporating Bluetooth LE and a 2.4 GHz / 5 GHz WLAN module (FCC ID: 2AHMR-BW16). 1.2 General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Section 15.247 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Sections 15.207 and 15.209 Site Registration: FCC: 685609 FCC Lab. Designation No.: UK2011 Location of Testing: Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, G24 8AH, United Kingdom Test Dates: 26 September 2023 to 19 October 2023 TEST REPORT SERIAL NO: UL-RPT-RP14880601-516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 5 of 37 1.3 Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.247(a)(2) Transmitter Minimum 6 dB Bandwidth Part 15.247(b)(3) Transmitter Maximum Peak Output Power Part 15.247(e) Transmitter Power Spectral Density Note 1 Part 15.247(d) & 15.209(a) Transmitter Radiated Emissions Part 15.247(d) & 15.209(a) Transmitter Band Edge Radiated Emissions Part 15.207 Transmitter AC Conducted Emissions Key to Results = Complied = Did not comply Note(s): 1. In accordance with ANSI C63.10 Section 11.10.1, PSD measurements are not required if the maximum conducted output power is less than the PSD limit of 8 dBm / 3 kHz. The PSD level is therefore deemed be equal to the measured output power. 1.4 Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: UL-RPT-RP14880601-516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 6 of 37 2 Summary of Testing 2.1 Facilities and Accreditation The test site and measurement facilities used to collect data are located at Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, RG24 8AH, United Kingdom.…

Text truncated - open the document above for the full version.

Approval sheet Page 1 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RFECA Series – RoHS Compliance CERAMIC ANTENNA Halogens Free Product 2.4 GHz ISM Band RF Application P/N: RFECA3216060A1T *Contents in this sheet are subject to change without prior notice. Approval sheet Page 2 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 FEATURES 1. Surface Mounted Devices with a small dimension of 3.2 X 1.6 X 0.6 mm 3 meet future miniaturization trend. 2. LTCC process. 3. High stability in Temperature / Humidity Change. 4. Superb performance to place on the middle of PCB edge and excellent peak/ average gain observed by field test application. APPLICATIONS 1. ISM Band 2.4GHz applications. 2. Bluetooth.. CONSTRUCTION DIMENSIONS Figure Symbol Dimension (mm) L 3.10 ± 0.20 W 1.60 ± 0.20 T 0.60 ± 0.10 A 0.25 ± 0.20 PINConnection 1 Feeding 2 Soldering terminal Approval sheet Page 3 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 SOLDER LAND PATTERN DESIGN Type-1: Empty Space 8.0mm x 3.0 mm Figure (Empty Space 8.0 mm x 3.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-1 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 2.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Approval sheet Page 4 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Type-2: Empty Space 6.3mm x 4.0 mm Figure (Empty Space 6.3 mm x 4.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-2 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 2.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Approval sheet Page 5 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-1 Test Board ( Empty Space 8x3 mm &Thick ness 0.8mm) Antenna S11 on Type-1 Test Board Antenna VSWR on Type-1 Test Board 1.782 @ 2.40 GHz 1.328 @ 2.45 GHz 1.816 @ 2.50 GHz -11.0208 dB @ 2.40 GHz -17.0222 dB @ 2.45 GHz -10.7612 dB @ 2.50 GHz Approval sheet Page 6 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-2 Test Board ( Empty Space 6.3x4 mm &Thick ness 0.8mm) Antenna S11 on Type-2 Test Board Antenna VSWR on Type-2 Test Board 1.453 @ 2.40 GHz 1.216 @ 2.45 GHz 1.732 @ 2.50 GHz -14.6741 dB @ 2.40 GHz -20.2120 dB @ 2.45 GHz -11.4374 dB @ 2.50 GHz Approval sheet Page 7 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RADIATION PATTERN Radiation Pattern and Gain were dependent on measurement board design. The specification of RFECA3216060A1T antenna was measured based on the PCB size and installation position as shown in the below figure Test Board. Antenna on Type-1 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 0.29 -3.32 1.82 -0.51 1.49 -2.87 2450 0.55 -2.88 2.09 -0.21 1.95 -2.48 2500 -0.15 -3.44 1.82 -0.62 1.82 -2.73 Approval sheet Page 8 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Antenna on Type-2 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 1.57 -2.83 1.95 -0.76 1.10 -2.93 2450 1.70 -2.62 2.02 -0.62 1.57 -2.61 2500 1.46 -2.82 1.90 -0.71 1.75 -2.68 Approval sheet Page 9 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 RELIABILITY TEST Test item Test condition / Test method Specification Solderability JIS C 0050-4.6 JESD22-B102D *Solder bath temperature：235  5C *Immersion time：2  0.5 sec Solder：Sn3Ag0.5Cu for lead-free At least 95% of a surface of each terminal electrode must be covered by fresh solder. Leaching (Resistance to dissolution of metallization) IEC 60068-2-58 *Solder bath temperature：260  5C *Leaching immersion time：30  0.5 sec Solder : SN63A Loss of metallization on the edges of each electrode shall not exceed 25%. Resistance to soldering heat JIS C 0050-5.4 *Preheating temperature：120~150°C, 1 minute. *Solder temperature：2705C *Immersion time：101 sec Solder：Sn3Ag0.5Cu for lead-free Measurement to be made after keeping at room temperature for 242 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Loss of metallization on the edges of each electrode shall not exceed 25%. Drop Test JIS C 0044 Customer’s specification. *Height：75 cm *Test Surface：Rigid surface of concrete or steel. *Times：6 surfaces for each units；2 times for each side. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Vibration JIS C 0040 *Frequency：10Hz~55Hz~10Hz(1min) *Total amplitude：1.5mm *Test times：6hrs.(Two hrs each in three mutually perpendicular directions) No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Adhesive Strength of Termination JIS C 0051- 7.4.3 *Pressurizing force： 5N(≦0603)；10N(>0603) *Test time：10±1 sec No remarkable damage or removal of the termination. Approval sheet Page 10 of 12 ASC_RFECA3216060A1T_V09 Aug. 2018 Bending test JIS C 0051- 7.4.1 The middle part of substrate shall be pressurized by means of the pressurizing rod at a rate of about 1 mm/s per second until the deflection becomes 1mm/s and then pressure shall be maintained for 51 sec. Measurement to be made after keeping at room temperature for 242 hours No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Temperature cycle JIS C 0025 1. 30…

Text truncated - open the document above for the full version.

Tedee Sp. z.o.o. FCC ID: 2BCK5TBV10 UL-RPT-14880601 UL International (UK) Ltd 1 Test Setup Photographs for the TBV1.0 1. Radiated Emissions 1.1 Configuration 1: < 30 MHz Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TBV10 UL-RPT-14880601 UL International (UK) Ltd 2 1.2 Configuration 2: 30 MHz to 1 GHz Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TBV10 UL-RPT-14880601 UL International (UK) Ltd 3 1.3 Configuration 3: > 1 Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TBV10 UL-RPT-14880601 UL International (UK) Ltd 4 2. AC Conducted Emissions Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TBV10 UL-RPT-14880601 UL International (UK) Ltd 5 3. Conducted Tests Photo 1 Photo 2
