2BCK5TLV20Tedee Lock GO

INSTALLATION GUIDE AND USER MANUAL Read installation guide and user manual. Learn how to use your device in a safe and proper manner. www.tedee.com 2 CONTENT QUICK START WITH TEDEE GO SAFETY INFORMATION safety guidelines / warnings charging and maintenance guidelines / warnings SET OF ITEMS - WHAT’S IN THE BOX? ACTIVATION CODE SETUP - 5 EASY INSTALLATION STEPS step 1: INSTALL ADAPTER (OPTIONAL) step 2: INSTALL TEDEE GO step 3: REMOVE BATTERY PROTECTIVE TABS step 4: DOWNLOAD THE TEDEE APP, CREATE A NEW ACCOUNT AND LOG IN step 5: USE THE TEDEE APP TO ACTIVATE AND CALIBRATE YOUR TEDEE GO LOCK DEINSTALLATION OF TEDEE GO BATTERY REPLACEMENT FACTORY RESET ADDITIONAL AND TECHNICAL INFORMATION technical specifications radio frequency software LED signals legal / environmental notes warranty technical support 3 4 4 5 7 8 9 9 11 13 14 15 16 18 19 20 20 21 21 22 24 24 25 www.tedee.com 3 QUICK START WITH TEDEE GO Tedee GO is a smart door lock that can be fitted to any euro-profile cylinder, with a double-clutch (panic function) feature. Tedee GO allows you to unlock the door, share access, and check all activities remotely. This manual will give you an overview of the basic features of Tedee lock and will help you walk through the setup in five easy steps. TEDEE GO SETUP - GO TO PAGE 9 ATTENTION: Tedee GO is only compatible with euro profile cylinders equipped with a double clutch function (panic function), allowing the door to be unlocked from both sides with a key, with both keys inserted in the cylinder, as shown in the figure on the left. If you are unable to determine whether your cylinder has a double-clutch function, please contact Tedee support. INSTALL ADAPTER (OPTIONAL) INSTALL TEDEE GO GET TEDEE APP REMOVE BATTERY TABS ACTIVATE AND CALIBRATE YOUR LOCK 12435 4 SAFETY INFORMATION SAFETY GUIDELINES / WARNINGS WARNING: Read all safety guidelines and warnings provided below. Failure to follow them may result in electric shock, fire, and / or serious injury. DO NOT DO MOVING PARTS • Do not modify or disassemble the device, except as provided in the instructions (battery replacement/removal of protective tabs). • Do not self-service any part of the device. • Do not use outdoors, intended for indoor use only. • Do not immerse the device in any liquid or expose it to moisture. • Do not use the device near an extreme heat source or open fire. • Do not use the device in an environment of a high humidity or dust levels, as well as pollution degree II. • Do not insert any conductive objects in device openings and gaps. • The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. Children should be supervised not to play with the appliance. • The device cannot be used as the only mean of access control to rooms or premises that require increased access control. • If repairs are required, please contact Tedee technical support. • Use only the batteries provided or recommended by Tedee. • Read the installation guide and learn how to start working with your lock, how to add it to your Tedee app and how to pair it with other Tedee devices. You can also follow the link: https://tedee.com/support-3/manuals/ • Because you can operate the device remotely, it is not recommended to keep your hands on the housing. www.tedee.com 5 BATTERY SAFETY GUIDELINES / WARNINGS Battery-powered Tedee GO lock includes non-rechargeable and non-user-serviceable batteries. DO NOT • Do not mix old and new batteries. • Do not touch leaking batteries. • Do not short circuit batteries or insert them incorrectly. • Do not use batteries that appear to be leaking, discolored, rusty, deformed; emit an odor; or are otherwise abnormal. • Do not expose the batteries to fire or high temperature. Do not leave or store batteries in hot places such as near an oven, stove, direct sunlight, or other heat sources. • Do not immerse batteries in water or allow them to come into contact with water. • Do not disassemble, puncture, modify, drop, throw, or cause other unnecessary shocks to batteries. • Do not place batteries in a microwave oven, or into any other high-pressure container. • Do not carry loose batteries in a pocket or purse with other metal objects. • Do not charge the non-rechargeable batteries included in your Tedee GO set. Do not overcharge rechargeable batteries (if applicable). • Do not put batteries in the mouth and do not swallow them. If swallowed, contact your local medical help immediately. • Neither Tedee Sp. z o.o. nor our retailers assume any liability for failures to comply with these warnings and safety guidelines. By purchasing this device, the buyer assumes all risks associated with LiPo batteries. If you do not agree with these conditions, return the device immediately before use. CR-123 CR-123 RECOMMENDED BATTERIES To power your Tedee GO lock, you need to use 3x CR-123/123A batteries or 3x CR-123 rechargeable batteries. We only allow to use 3V CR123/123A batteries or 3.7V CR123 rechargeable batteries. WARNING: You can permanently damage the device while trying to use or install the batteries or rechargeable batteries exceeding 3/3.7V respectively. 6 Other information • The cleansing pad included with the device contains highly flammable isopropyl alcohol, which may cause serious eye irritation and drowsiness or dizziness if inhaled. Keep it away from direct heat/fire/ignition sources and avoid contact with eyes or inhalation. Wash hands with soap after use. If eye irritation occurs, rinse carefully with water. If inhaled, go out into the fresh air and make breathing comfortable. Seek medical advice if irritation/breathing problems persist. • Dispose the devices in accordance with your local regulations. If possible, recycle. • Do not dispose the device as a household waste and do not burn it. • This device is safe to use under normal and reasonably foreseeable misuse op…

Text truncated - open the document above for the full version.

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND CFR 47 §2.911 (d)(5) Attestation Date: 08-17-2023 FCC ID: 2BCK5TLV20 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA 1. Tedee Sp. z o.o. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Tedee Sp. z o.o. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

UL International (UK) LtdULID-018088 issue 1 CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: 10-09-2023 FCC ID: 2BCK5TLV20 To:Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Tedee(“the applicant”)as required by section 2.911(d)(7), designatesthe followingagent, located in the United States,for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Robert Jablonski Recharge Consulting LLC 13809 Research Blvd STE 500, Austin, TX 78750 [email protected] Sincerely yours, Name:Wojciech Wojas Job Title:Legal & Compliance Counsel Company Name:Tedee

UL International (UK) LtdULID-018088 issue 1FCC Agent Attestation letter template CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation Date: 10-09-2023 FCC ID: 2BCK5TLV20 To:Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC US Agent Recharge Consulting LLC FRN: 0034332874 Robert Jablonski 13809 Research Blvd STE 500, Austin, TX 78750 [email protected] This letteris to confirm that we have accepted the responsibility to act as US Agent on behalf of Tedee Sp. z o. o.(“the applicant”) for the above referenced FCC ID. Weare aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7)and Report and Order FCC 22-84 paragraph 63. Sincerely yours, Robert Jablonski President Recharge Consulting LLC

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND 08.17.2023 Telecommunication Certification Body UL International (UK) Ltd Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Authorisation Letter To whom it may concern This is to certify that Tedee Sp. z o.o. hereby authorises UL International (UK) Ltd. to act as the TCB for the application of the Tedee Lock GO, TLV2.0, FCC ID: 2BCK5TLV20 to the FCC. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours faithfully, Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

Contact us: www.tedee.com [email protected] (+48) 22 185 78 18 Tedee Sp. z o.o. Karola Bohdanowicza 21/57 02-127 Warszawa POLAND 15. 09.2023 Telecommunication Certification Body UL International (UK) Ltd Units 1-3, Horizon Wade Road Kingsland Business Park Basingstoke Hampshire RG24 8AH United Kingdom Subject: Permanent Confidentiality Request Certification Application FCC ID: FCC ID: 2BCK5TLV20 To w hom it may concern Pursuant to Sections 0.457(d) and 0.459 of CFR 47, Tedee Sp. z o.o. request that the following information, provided to support the FCC application for the Tedee Lock GO, TLV2. 0, FCC ID: 2BCK5TLV20 to be held permanently confidential: •Schematics •Block Diagrams •Operational Description The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. This information should not be available for public disclosure for an indefinite period of time. Yours faithfully Name: Wojciech Wojas Job Title: Compliance Counsel Company Name: Tedee Sp. z o.o.

A1 Scale: FCC ID Label and Location FCC ID: 2BCK5TLV20 Label Location Label Area: This outline drawing shows the label located in the side of the device packaging. The label is visible to the user at the point of device unpacking (Product packaging view) 1. Serial number of the device 2. Device Type 3. Device Name 4. Production year 5. FCC ID 6. Manufactuer's logo 7. Manufacturer's address Due to lack of space on the only label-compatible surface of the device, FCC ID was placed on the product packaging and inside product manual provided to each end user. Additional information on page 2 below. Quick to install. Easy to love. Just pop it on your lock* It will take you just a few minutes. See how it works! Power with replaceable batteries Lasting up to 9 months if used up to 8 times per day. Enter in a new way Compatible with Tedee smart bridge and keypad. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Tedee Sp. z o.o. is under license. Other trademarks and trade names are those of their respective owners. Google is a trademark of Google LLC. Google Assistant is not available in certain languages and countries. * To use Tedee GO, you'll need a specific type of door lock that supports euro-profile, double-clutch cylinders. This type of lock allows you to insert the keys from both sides of the door, and turning one key will make the second key turn as well. Additional Information Due to lack of space on the only label-compatible surface of the device, FCC ID was placed on the product packaging and inside product manual provided to each end user. (Rear View) FCC ID Label and Location FCC ID: 2BCK5T LV20

RF Exposure Analysis FCC ID: 2BCK5TLV20 Analysis for FCC portable use Standalone SAR test exclusion considerations are defined in KDB 447498D01 (v06) Chapter 4.3.1 where the 1-g head or body and 10-g extremity SAR exclusion threshold is defined by the following formula: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] *[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR •f(GHz) is the RF channel transmit frequency in GHz •Power and distance are rounded to the nearest mW and mm before calculation •The result is rounded to one decimal place for comparison For the Lock GO: The Operating frequency is 2402 –2480MHz The maximum conducted output power is +8.0dBm (6.3mW). Applying the above data using the given KDB 447498 D01 formula, andapplying aminimum separation distance of 5mm, the following results: (6.3mW / 5 mm) x √2.48 GHz = 2.0(i.e.: ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR) This demonstrates the Lock GO meets the criteria for 1-g head/ body and 10-g extremity SAR test exemption.

UL International (UK) LTD Unit 1-4 Horizon, Kingsland Business Park, Wade Road, Basingstoke, Hampshire, RG24 8AH, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP14880601-2516A Customer : Tedee Sp. z.o.o. Model No. : TLV2.0 FCC ID : 2BCK5TLV20 Technology : Bluetooth – Low Energy Test Standard(s) : FCC Parts 15.209(a) & 15.247 Test Laboratory : UL International (UK) Ltd, Basingstoke, Hampshire, RG24 8AH, United Kingdom 1. This test report shall not be reproduced except in full, without the written approval of UL International (UK) Ltd. 2. The results in this report apply only to the sample(s) tested. 3. The sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 2.0 supersedes all previous versions. Date of Issue: 27 October 2023 Checked by: Ben Mercer Lead Project Engineer, Radio Laboratory Company Signatory: Sarah Williams RF Operations Leader, Radio Laboratory The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by UL International (UK) Ltd is under licence. Other trademarks and trade names are those of their respective owners. TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 2 of 30 Customer Information Company Name: Tedee Sp. z.o.o. Address: UI. Karola Bohdanowicza 21/57, 02-127 Warsaw, Poland Report Revision History Version Number Issue Date Revision Details Revised By 1.0 23/10/2023 Initial Version Ben Mercer 2.0 27/10/2023 TCB requested updates Ben Mercer TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 3 of 30 Table of Contents Customer Information ................................................................................................................... 2 Report Revision History ................................................................................................................ 2 Table of Contents ........................................................................................................................... 3 1 Attestation of Test Results ........................................................................................................ 4 1.1 Description of EUT 4 1.2 General Information 4 1.3 Summary of Test Results 5 1.4 Deviations from the Test Specification 5 2 Summary of Testing ................................................................................................................... 6 2.1 Facilities and Accreditation 6 2.2 Methods and Procedures 6 2.3 Calibration and Uncertainty 7 2.4 Test and Measurement Equipment 8 3 Equipment Under Test (EUT) ................................................................................................... 10 3.1 Identification of Equipment Under Test (EUT) 10 3.2 Modifications Incorporated in the EUT 10 3.3 Additional Information Related to Testing 11 3.4 Description of Available Antennas 11 3.5 Description of Test Setup 12 4 Antenna Port Test Results ....................................................................................................... 16 4.1 Transmitter Minimum 6 dB Bandwidth 16 4.2 Transmitter Maximum Peak Output Power 19 5 Radiated Test Results .............................................................................................................. 21 5.1 Transmitter Radiated Emissions <1 GHz 21 5.2 Transmitter Radiated Emissions >1 GHz 23 5.3 Transmitter Band Edge Radiated Emissions 26 TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 4 of 30 1 Attestation of Test Results 1.1 Description of EUT The equipment under test was a smart lock for accessing doors. 1.2 General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Section 15.247 Specification Reference: 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Section 15.209 Site Registration: FCC: 685609 FCC Lab. Designation No.: UK2011 Location of Testing: Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, G24 8AH, United Kingdom Test Dates: 19 September 2023 to 05 October 2023 TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 5 of 30 1.3 Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.247(a)(2) Transmitter Minimum 6 dB Bandwidth Part 15.247(b)(3) Transmitter Maximum Peak Output Power Part 15.247(e) Transmitter Power Spectral Density Note 1 Part 15.247(d) & 15.209(a) Transmitter Radiated Emissions Part 15.247(d) & 15.209(a) Transmitter Band Edge Radiated Emissions Key to Results = Complied = Did not comply Note(s): 1. In accordance with ANSI C63.10 Section 11.10.1, PSD measurements are not required if the maximum conducted output power is less than the PSD limit of 8 dBm / 3 kHz. The PSD level is therefore deemed to be equal to the measured output power. 1.4 Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516A VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 6 of 30 2 Summary of Testing 2.1 Facilities and Accreditation The test site and measurement facilities used to collect data are located at Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, RG24 8AH, United Kingdom. The following table identifies which facilities were utilised for radiated emission measurements documented in this report. Specific facilities are also identified in the test results sections. Site 1 X Site 2 - Site 17 X UL International (UK) Ltd is accredited by the United Kingdom Accreditation Service (UKAS). UK…

Text truncated - open the document above for the full version.

UL International (UK) Ltd Unit 1-4 Horizon, Kingsland Business Park, Wade Road, Basingstoke, Hampshire, RG24 8AH, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP14880601-2516B Customer : Tedee Sp. z.o.o. Model No. : TLV2.0 FCC ID : 2BCK5TLV20 Test Standard(s) : Antenna Gain Measurement (Derived from FCC Part 15.247(b)(3)) 1. This test report shall not be reproduced except in full, without the written approval of UL International (UK) Ltd. 2. The results in this report apply only to the sample(s) tested. 3. The sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 2.0 supersedes all previous versions. Date of Issue: 27 October 2023 Checked by: Ben Mercer Lead Project Engineer, Radio Laboratory Company Signatory: Sarah Williams RF Operations Leader, Radio Laboratory This laboratory is accredited by the United Kingdom Accreditation Service (UKAS). UKAS is one of the signatories to the International Laboratory Accreditation Co- operation (ILAC) Arrangement for the mutual recognition of test reports. The tests reported herein have been performed in accordance with its terms of accreditation. TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516B VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 2 of 14 UL International (UK) Ltd Customer Information Company Name: Tedee Sp. z.o.o. Address: UI. Karola Bohdanowicza 21/57, 02-127 Warsaw, Poland Report Revision History Version Number Issue Date Revision Details Revised By 1.0 23/10/2023 Initial Version Ben Mercer 2.0 27/10/2023 TCB requested updates Ben Mercer TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516B VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 UL International (UK) Ltd Page 3 of 14 Table of Contents Customer Information ................................................................................................................... 2 Report Revision History ................................................................................................................ 2 Table of Contents ........................................................................................................................... 3 1. Attestation of Test Results ....................................................................................................... 4 1.1. Description of EUT 4 1.2. General Information 4 1.3. Summary of Test Results 4 1.4. Deviations from the Test Specification 4 2. Summary of Testing .................................................................................................................. 5 2.1. Facilities and Accreditation 5 2.2. Methods and Procedures 5 2.3. Measurement Uncertainty & Decision Rule 6 2.4. Test and Measurement Equipment 7 3. Equipment Under Test (EUT) .................................................................................................... 8 3.1. Identification of Equipment Under Test (EUT) 8 3.2. Modifications Incorporated in the EUT 8 3.3. Additional Information Related to Testing 9 3.4. Description of Available Antennas 9 3.5. Description of Test Setup 10 4. Test Results .............................................................................................................................. 12 4.1. Transmitter Maximum Peak Output Power (Conducted) 12 4.2. Transmitter Maximum Peak Output Power (Radiated) 13 TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516B VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 Page 4 of 14 UL International (UK) Ltd 1. Attestation of Test Results 1.1. Description of EUT The equipment under test was a smart lock for accessing doors. 1.2. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) – Section 15.247 Site Registration: 685609 Lab. Designation No.: UK2011 Location of Testing: Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, G24 8AH, United Kingdom Test Dates: 19 September 2023 to 17 October 2023 1.3. Summary of Test Results FCC Reference (47CFR) Measurement Part 15.247(b)(3) / ANSI C63.10 Annex G Antenna Gain Results: Frequency (MHz) Conducted Output Power (dBm) Radiated Output Power (dBm) Antenna Gain (dBi) 2402 7.39 0.98 -6.41 2440 7.38 1.84 -5.54 2480 7.38 1.58 -5.80 Notes: 1. Antenna gain in dBi was calculated in accordance with ANSI C63.10 G.3: EIRP = P T + G T - L C Rearranged to: G T = EIRP + L C - P T LC is ignored since there is no cable connected between transmitter and antenna. 1.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516B VERSION 2.0 ISSUE DATE: 27 OCTOBER 2023 UL International (UK) Ltd Page 5 of 14 2. Summary of Testing 2.1. Facilities and Accreditation The test site and measurement facilities used to collect data are located at Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, RG24 8AH, United Kingdom. The following table identifies which facilities were utilised for radiated emission measurements documented in this report. Specific facilities are also identified in the test results sections. Site 1 X Site 2 - Site 17 - UL International (UK) Ltd is accredited by UKAS. The tests reported herein have been performed in accordance with its terms of accreditation. 2.2. Methods and Procedures Reference: ANSI C63.10-2013 Title: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices Reference: KDB 558074 D01 15.247 Meas Guidance v05r02, April 2, 2019 Title: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating Under Section 15.247 of the FCC Rules TEST REPORT SERIAL NO: UL-RPT-RP14880601-2516B VERSION 2.0 ISSU…

Text truncated - open the document above for the full version.

Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 Test Setup Photographs for the TLV2.0 1. Radiated Emissions 1.1 Configuration 1: < 30 MHz Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 1.2 Configuration 2: 30 MHz to 1 GHz Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 1.3 Configuration 3: > 1 GHz Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 2. Conducted Tests Photo 1 Photo 2

Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 Test Setup Photographs for the TLV2.0 1. Antenna Gain 1.1 Configuration 1: Radiated Photo 1 Photo 2 Tedee Sp. z.o.o. FCC ID: 2BCK5TLV20 UL-RPT-RP14880601-2516 1.2 Configuration 2: Conducted Photo 1 Photo 2
