2BDR5-101TDigital Wireless Backup Camera System Camera

Digital Wireless Backup Camera System Camera Model: VT101TX Digital Wireless Backup Camera System Monitor Model:VT101RX 44.5 mm 44.5 mm Camera: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interfer- ence that may cause undesired operation. FCC Radiation Exposure Statement: The equipment complies with FCC Radiation exposure limits set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. FCC Warning: Monitor: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body. Specific Absorption Rate (SAR) information: This device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: device has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the phone kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. ISED Statement Monitor: English: This device contains licence-exempt transmitter(s)/receiv- er(s) that comply with Innovation, Science and Economic Development Canada’ s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. French:Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux CNR exempts de licence d’Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas causer d’interférences. (2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement indésirable de l’appareil. This device complies with RSS 102 of the RF exposure guideline. Cet appareil est conforme à la norme RSS 102 de la directive sur l'exposi- tion aux RF. This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed an…

Text truncated - open the document above for the full version.

FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 7 1#Adapter Appearance Photo 8 2#Adapter Appearance

FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Appendix I Label Appendix II Label Location

FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 9 Internal of EUT Photo 10 Internal of EUT FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 11 Appearance of PCB Photo 12 Appearance of PCB WIFI Ant FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 13 Appearance of PCB Photo 14 Appearance of PCB FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo 15 Appearance of PCB Photo 16 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202604-0230-4 Page: 1 of 8 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: 2BDR5-101T Report No. : TBR-C-202604-0230-4 Applicant : Videotimes Technology (Hubei) Co.,Ltd Equipment Under Test (EUT) EUT Name : Digital Wireless Backup Camera System Camera Model No. : VT101 TX Series Model No. : VT101,VT101-2,VT101-3,VT101-4,VT101TX,HB101,HB101-2, HB101-3,HB101-4,HB101TX,VXH101,VXH101-2,VXH101-3, VXH101-4,VXH101TX,JA101,JA101-2,JA101-3,JA101-4,JA101TX, FK101,FK101-2,FK101-3,FK101-4,FK101TX,BG101,BG101-2, BG101-3,BG101-4,BG101TX,CF101,CF101-2,CF101-3,CF101-4, CF101TX,VV101,VV101-2,VV101-3,VV101-4,VV101TX,OD101, OD101-2,OD101-3,OD101-4,OD101TX,BL101,BL101-2,BL101-3, BL101-4,BL101TX,101,101-2,101-3,101-4,101TX Brand Name : N/A Sample ID : HC-C-202604-0230-01-01 Receipt Date : 2026-05-08 Test Date : 2026-05-08 to 2026-05-29 Issue Date : 2026-05-29 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202604-0230-4 Page: 2 of 8 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. METHOD OF MEASUREMENT FOR FCC............................................................................ 7 5. TEST RESULT............................................................................................................................ 8 Report No.: TBR-C-202604-0230-4 Page: 3 of 8 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202604-0230-4 Rev.01 Initial issue of report 2026-05-29 Report No.: TBR-C-202604-0230-4 Page: 4 of 8 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Videotimes Technology (Hubei) Co.,Ltd Address : B5-1, B5-2, Electronic Information Industry Park, Wuxue, Huanggang, Hubei, China Manufacturer : Videotimes Technology (Hubei) Co.,Ltd Address : B5-1, B5-2, Electronic Information Industry Park, Wuxue, Huanggang, Hubei, China 1.2 General Description of EUT (Equipment Under Test) EUT Name : Digital Wireless Backup Camera System Camera Models No. : VT101 TX, VT101,VT101-2,VT101-3,VT101-4,VT101TX,HB101, HB101-2,HB101-3,HB101-4,HB101TX,VXH101,VXH101-2, VXH101-3,VXH101-4,VXH101TX,JA101,JA101-2,JA101-3, JA101-4,JA101TX,FK101,FK101-2,FK101-3,FK101-4,FK101TX, BG101,BG101-2,BG101-3,BG101-4,BG101TX,CF101,CF101-2, CF101-3,CF101-4,CF101TX,VV101,VV101-2,VV101-3,VV101-4, VV101TX,OD101,OD101-2,OD101-3,OD101-4,OD101TX,BL101, BL101-2,BL101-3,BL101-4,BL101TX,101,101-2,101-3,101-4, 101TX Model Different : All these models are identical in the same PCB, layout and electrical circuit, The only difference is model name, brand name and product name. Product Description : Operation Frequency: 2.4G Wi-Fi: 2412MHz~2462MHz Modulation Type: 802.11b: DSSS (DQPSK, DBPSK, CCK) 802.11g: OFDM (BPSK, QPSK,16QAM, 64QAM) 802.11n: OFDM (QPSK, BPSK, 16QAM, 64QAM) 802.11ax: OFDMA (BPSK, QPSK,16QAM, 64QAM, 1024QAM) Antenna Gain: 4.03dBi dipole Antenna Power Rating : 1#Adapter:(K25E120200U) Input: 100-240V~, 50/60Hz 0.6A Output: 12.0V⎓2.0A 2#Adapter:(A923-120200W-US4) Input: 100-240V~, 50/60Hz 0.7A Output: 12.0V⎓2.0A Software Version : TX:1.1.3 Hardware Version : 1.0 Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: TBR-C-202604-0230-4 Page: 5 of 8 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202604-0230-4 Page: 6 of 8 www.cotecna-toby.com TB-RF-073-3.1 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements fo…

Text truncated - open the document above for the full version.

ShenZhen XinErSheng Technology Co.,Ltd SPECIFICATION FOR APPROVAL CUSTOMER Product 2.4G 4dBi white SMA antenna, RP-SMA male (female pin) Manufacturers of Material XESANT12B13465 Customer Part Number W1-1301-3465-001-01 D A TE2023/08/ 11 V E R S I O NA/0 That Customers: ORGANIZERCHECKAPPROVAL ShenZhen XinErSheng Technology Co.,Ltd ORGANIZERCHECKAPPROVAL BiaoLiSenAmy Company address ： Floor 3, Building D, No.96 Lingxia Road, Fuyong Fenghuang Fourth Industrial Zone, Baoan District, Shenzhen Phone number：0755-33881455 Email:[email protected] Fax NO.：0755-33233276 ShenZhenXinErShengTechnologyCo.,Ltd Maintechnicalparametersoftheproduct Maintechnicalspecifications FrequencyRange(MHZ)2400-2500 Impedance(Ω) 50 ± 10 Gain(dBi) 4.0±0.5 ReTurnLoss(dB) ≤ -10 VSWR ≤1.92 Polarization1W ConnectorTypeLinearVertical PhysicalProperties AntennaBasecopper OperatingTemp -20°C-+60°C StorageTemp -20°C-+70°C ShenZhenXinErShengTechnologyCo.,Ltd Productdrawing ShenZhenXinErShengTechnologyCo.,Ltd Networkanalyzertestreport： SWR ShenZhenXinErShengTechnologyCo.,Ltd 2D、3DRaditationPattern 2.4GGain(Peak):3.92dBiEfficiency:68.7% 2.45GGain(Peak):4.03dBiEfficiency:69.2% 2.5GGain(Peak):3.95dBiEfficiency:68.3%

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 1 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Digital Wireless Backup Camera System Camera Test Model: VT101 TX Sample ID: HC-C-202604-0230-01-01 Environmental Conditions Temperature: 25.6°C Relative Humidity: 48.6% Test Voltage: DC 12V Test Engineer: Lily zhang Note: For a more detailed features description, please refer to the report TBR-C-202604-0230-5 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 2 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power .......................................................................................................................................... 10 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 18 5. Maximum Power Spectral Density Level ................................................................................................................................... 25 6. Band Edge ................................................................................................................................................................................... 32 7. Conducted RF Spurious Emission ............................................................................................................................................. 41 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 3 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT ax(VHT20) 2412 Ant1 98.2 0.08 1.02 NVNT ax(VHT20) 2437 Ant1 98.4 0.07 1.02 NVNT ax(VHT20) 2462 Ant1 98.2 0.08 1.02 NVNT b 2412 Ant1 99.76 0.01 0.12 NVNT b 2437 Ant1 99.82 0.01 0.12 NVNT b 2462 Ant1 99.82 0.01 0.12 NVNT g 2412 Ant1 98.84 0.05 0.73 NVNT g 2437 Ant1 98.84 0.05 0.74 NVNT g 2462 Ant1 98.84 0.05 0.74 NVNT n(HT20) 2412 Ant1 98.76 0.05 0.79 NVNT n(HT20) 2437 Ant1 98.76 0.05 0.79 NVNT n(HT20) 2462 Ant1 98.6 0.06 0.79 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 4 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Test Graphs Duty Cycle NVNT ax(VHT20) 2412MHz Ant1 Duty Cycle NVNT ax(VHT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 5 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Duty Cycle NVNT ax(VHT20) 2462MHz Ant1 Duty Cycle NVNT b 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 6 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Duty Cycle NVNT b 2437MHz Ant1 Duty Cycle NVNT b 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 7 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Duty Cycle NVNT g 2412MHz Ant1 Duty Cycle NVNT g 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 8 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Duty Cycle NVNT g 2462MHz Ant1 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 9 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202604-0230-5 Page: 10 of 53 FCC ID: 2BDR5-101T TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT ax(VHT20) 2412 Ant1 15.45 0.08 15.53 30 Pass NVNT ax(VHT20) 2437 Ant1 15.35 0.07 15.42 30 Pass NVNT ax(VHT20) 2462 Ant1 15.42 0.08 15.5 30 Pass NVNT b 2412 Ant1 16.59 0.01 16.6 30 Pass NVNT b 2437 Ant1 16.63 0.01 16.64 30 Pass NVNT b 2462 Ant1 16.74 0.01 16.75 30 Pass NVNT g 2412 Ant1 15.35 0.05 15.4 30 Pass NVNT g 2437 Ant1 15.25 0.05 15.3 30 Pass NVNT g 2462 Ant1 15.48 0.05 15.53 30 Pass NVNT n(HT20) 2412 Ant1 15.33 0.05 15.38 30 Pass NVNT n(HT20) 2437 Ant1 15.35 0.05 15.4 30 Pass NVNT n(HT20) 2462 Ant1 15.5 0.06 15.56 30 Pass Shenzhen Toby Technology Co., Ltd…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202604-0230-5 Page: 1 of 57 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BDR5-101T Report No. : TBR-C-202604-0230-5 Applicant : Videotimes Technology (Hubei) Co.,Ltd Equipment Under Test (EUT) EUT Name : Digital Wireless Backup Camera System Camera Model No. : VT101 TX Series Model No. : VT101,VT101-2,VT101-3,VT101-4,VT101TX,HB101,HB101-2, HB101-3,HB101-4,HB101TX,VXH101,VXH101-2,VXH101-3, VXH101-4,VXH101TX,JA101,JA101-2,JA101-3,JA101-4,JA101TX, FK101,FK101-2,FK101-3,FK101-4,FK101TX,BG101,BG101-2, BG101-3,BG101-4,BG101TX,CF101,CF101-2,CF101-3,CF101-4, CF101TX,VV101,VV101-2,VV101-3,VV101-4,VV101TX,OD101, OD101-2,OD101-3,OD101-4,OD101TX,BL101,BL101-2,BL101-3, BL101-4,BL101TX,101,101-2,101-3,101-4,101TX Brand Name : N/A Sample ID : HC-C-202604-0230-01-01&HC-C-202604-0230-02-01 Receipt Date : 2026-05-08 Test Date : 2026-05-08 to 2026-05-29 Issue Date : 2026-05-29 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202604-0230-5 Page: 2 of 57 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION TEST ........................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup........................................................................................................................... 13 5.3 Test Procedure .................................................................................................................. 13 5.4 Deviation From Test Standard......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit ................................................................................................... 14 6.2 Test Setup........................................................................................................................... 15 6.3 Test Procedure .................................................................................................................. 16 6.4 Deviation From Test Standard......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data............................................................................................................................. 17 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 18 7.1 Test Standard and Limit ................................................................................................... 18 7.2 Test Setup........................................................................................................................... 18 7.3 Test Procedure .................................................................................................................. 19 7.4 Deviation From Test Standard......................................................................................... 20 7.5 EUT Operating Mode .........................................…

Text truncated - open the document above for the full version.

FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Appendix V EUT Test Photographs Photo of Setup for Conducted Emission(AC POWER) Photo of Setup for Radiated Emission (30MHz~1GHz) FCC ID:2BDR5-101T www.cotecna-toby.com TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) Conducted Measurements Test -----END OF REPORT-----
