2BDR5-90TSmart Wi-Fi Baby Camera

Videotimes Technology (Hubei) Co.,Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 18, 2026
Application Purpose: Original Equipment
Equipment Note: Smart Wi-Fi Baby Camera
Frequency Range: 2402.00000000 - 2480.00000000
Company: Videotimes Technology (Hubei) Co.,Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

ShenZhenXinErShengTechnologyCo.,Ltd SPECIFICATIONFORAPPROVAL Customernane：BeiNaiTe Productname ：2.4G2.5DBintegratedantennawhite CustomerPartW1-1301-0080-002-04 Number : Manufacturersof Material:SFANT12A13479 Deliverquantity ： 5PCS MarkCheckExamineand approve Datelanded Biao LisenAmy 2022.12.22 ThatCustomers： AcknowledgeCheckExamineand approve Datelanded Company addressFloor 3, Building D, No.96 Lingxia Road, Fuyong Fenghuang Fourth Industrial Zone, Baoan District, Shenzhen Phone number0755-33881455 Fax NO.0755-33233276 ShenZhenXinErShengTechnologyCo.,Ltd Maintechnicalparametersoftheproduct Maintechnicalspecifications FrequencyRange(MHZ)2400-2483 Impedance(Ω) 50±10 Gain(dBi) 30 . 5 ReTurnLoss(dB) ≤ -10 VSWR ≤ 2.0 AdmittedPower1W PolarizationLinearVertical ConnectorTypeIPEX PhysicalProperties AntennaBaseTPE OperatingTemp -20 °C -+60 °C StorageTemp -20 °C -+70 °C Listofrawmaterials： Serial mumber NameTextureQuantityUnitRemark 1StemcasingTPE1PCS 2Onthefixed seat PC+PBT1PCS 3Underthe fixedseat PC+PBT1PCS 4Wirerod1.13Gray1PCS 5CopperpipeZincalloy1PCS ShenZhenXinErSheng（SuFei）TechnologyCo.,Ltd Productdrawing ShenZhenXinErShengTechnologyCo.,Ltd Networkanalyzertestreport： 1.SWR： 2.returnloss ShenZhenXinErShengTechnologyCo.,Ltd 2D、3DRaditationPattern 2.4GGain(Peak):2.85dBiEfficiency:61.5% 2.45GGain(Peak):3.05dBiEfficiency63.2% 2.5GGain(Peak):2.93dBiEfficiency:60.7%

Test Setup Photos

FCC ID:2BDR5-90T www.cotecna-toby.com TB-RF-073-3.1 Appendix V EUT Test Photographs Photo of Setup for Conducted Emission(AC POWER) Photo of Setup for Radiated Emission (30MHz~1GHz) FCC ID:2BDR5-90T www.cotecna-toby.com TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) Conducted Measurements Test (AB6031X-44P2) FCC ID:2BDR5-90T www.cotecna-toby.com TB-RF-073-3.1 Conducted Measurements Test (AB6032X-6PE) -----END OF REPORT-----

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0277-51 Page: 1 of 35 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BDR5-90T Report No. : TBR-C-202512-0277-51 Applicant : Videotimes Technology (Hubei) Co.,Ltd Equipment Under Test (EUT) EUT Name : Smart Wi-Fi Baby Camera Model No. : VXH9085 Series Model No. : HB90TX HBXXXXX(H, B, X represent different customer names that are not the same.) Brand Name : N/A Sample ID : HC-C-202512-0277-01-01&HC-C-202512-0277-02-01 Receipt Date : 2026-01-04 Test Date : 2026-01-04 to 2026-02-25 Issue Date : 2026-02-25 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0277-51 Page: 2 of 35 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION TEST ........................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup........................................................................................................................... 13 5.3 Test Procedure .................................................................................................................. 13 5.4 Deviation From Test Standard......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit ................................................................................................... 14 6.2 Test Setup........................................................................................................................... 15 6.3 Test Procedure .................................................................................................................. 16 6.4 Deviation From Test Standard......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data............................................................................................................................. 17 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 18 7.1 Test Standard and Limit ................................................................................................... 18 7.2 Test Setup........................................................................................................................... 18 7.3 Test Procedure .................................................................................................................. 19 7.4 Deviation From Test Standard......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data............................................................................................................................. 20 8. BANDWIDTH TEST................................................................................................................. 21 8.1 Test Standard and Limit ....................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202512-0277-5 Page: 1 of 32 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BDR5-90T Report No. : TBR-C-202512-0277-5 Applicant : Videotimes Technology (Hubei) Co.,Ltd Equipment Under Test (EUT) EUT Name : Smart Wi-Fi Baby Camera Model No. : VXH9085 Series Model No. : HB90TX HBXXXXX(H, B, X represent different customer names that are not the same.) Brand Name : N/A Sample ID : HC-C-202512-0277-01-01&HC-C-202512-0277-02-01 Receipt Date : 2026-01-04 Test Date : 2026-01-04 to 2026-02-25 Issue Date : 2026-02-25 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Lily zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202512-0277-5 Page: 2 of 32 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION ...................................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup........................................................................................................................... 13 5.3 Test Procedure .................................................................................................................. 13 5.4 Deviation From Test Standard......................................................................................... 14 5.5 EUT Operating Mode ........................................................................................................ 14 5.6 Test Data............................................................................................................................. 14 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 15 6.1 Test Standard and Limit ................................................................................................... 15 6.2 Test Setup........................................................................................................................... 16 6.3 Test Procedure .................................................................................................................. 17 6.4 Deviation From Test Standard......................................................................................... 18 6.5 EUT Operating Mode ........................................................................................................ 18 6.6 Test Data............................................................................................................................. 18 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 19 7.1 Test Standard and Limit ................................................................................................... 19 7.2 Test Setup........................................................................................................................... 19 7.3 Test Procedure .................................................................................................................. 20 7.4 Deviation From Test Standard......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data............................................................................................................................. 20 8. BANDWIDTH TEST................................................................................................................. 21 8.1 Test Standard and Limit .................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 1 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Smart Wi-Fi Baby Camera Test Model: VXH9085 (AB6032X-6PE) Sample ID: HC-C-202512-0277-01-01 Environmental Conditions Temperature: 24.4°C Relative Humidity: 51% Test Voltage: DC 5V Test Engineer: Lily zhang Note: For a more detailed features description, please refer to the report TBR-C-202512-0277-51 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 2 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power .......................................................................................................................................... 10 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 18 5. Maximum Power Spectral Density Level ................................................................................................................................... 25 6. Band Edge ................................................................................................................................................................................... 32 7. Conducted RF Spurious Emission ............................................................................................................................................. 41 8. Restrict Band ............................................................................................................................................................................... 54 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 3 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Ant1 98.26 0.08 0.12 NVNT b 2437 Ant1 98.23 0.08 0.12 NVNT b 2462 Ant1 98.23 0.08 0.12 NVNT g 2412 Ant1 97.18 0.12 0.73 NVNT g 2437 Ant1 97.04 0.13 0.73 NVNT g 2462 Ant1 97.18 0.12 0.73 NVNT n(HT20) 2412 Ant1 96.99 0.13 0.78 NVNT n(HT20) 2437 Ant1 96.99 0.13 0.78 NVNT n(HT20) 2462 Ant1 96.99 0.13 0.78 NVNT n(HT40) 2422 Ant1 94.13 0.26 1.56 NVNT n(HT40) 2437 Ant1 94.13 0.26 1.56 NVNT n(HT40) 2452 Ant1 94.12 0.26 1.56 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 4 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 5 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT b 2462MHz Ant1 Duty Cycle NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 6 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT g 2437MHz Ant1 Duty Cycle NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 7 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 8 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Duty Cycle NVNT n(HT40) 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 9 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT40) 2437MHz Ant1 Duty Cycle NVNT n(HT40) 2452MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 10 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 15 30 Pass NVNT b 2437 Ant1 15.58 30 Pass NVNT b 2462 Ant1 15.59 30 Pass NVNT g 2412 Ant1 15.28 30 Pass NVNT g 2437 Ant1 14.97 30 Pass NVNT g 2462 Ant1 14.88 30 Pass NVNT n(HT20) 2412 Ant1 14.32 30 Pass NVNT n(HT20) 2437 Ant1 15.81 30 Pass NVNT n(HT20) 2462 Ant1 14.3 30 Pass NVNT n(HT40) 2422 Ant1 11.7 30 Pass NVNT n(HT40) 2437 Ant1 12.25 30 Pass NVNT n(HT40) 2452 Ant1 12.29 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Bui…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 1 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Smart Wi-Fi Baby Camera Test Model: VXH9085 (AB6031X-44P2) Sample ID: HC-C-202512-0277-01-01 Environmental Conditions Temperature: 24.6°C Relative Humidity: 52% Test Voltage: DC 5V Test Engineer: Lily zhang Note: For a more detailed features description, please refer to the report TBR-C-202512-0277-51 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 2 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power .......................................................................................................................................... 10 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 18 5. Maximum Power Spectral Density Level ................................................................................................................................... 25 6. Band Edge ................................................................................................................................................................................... 32 7. Conducted RF Spurious Emission ............................................................................................................................................. 41 8. Restrict Band ............................................................................................................................................................................... 54 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 3 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Ant1 98.37 0.07 0.12 NVNT b 2437 Ant1 98.35 0.07 0.12 NVNT b 2462 Ant1 98.35 0.07 0.12 NVNT g 2412 Ant1 99.93 0 0.08 NVNT g 2437 Ant1 99.93 0 0.08 NVNT g 2462 Ant1 99.93 0 0.08 NVNT n(HT20) 2412 Ant1 99.93 0 0.09 NVNT n(HT20) 2437 Ant1 99.93 0 0.09 NVNT n(HT20) 2462 Ant1 99.93 0 0.09 NVNT n(HT40) 2422 Ant1 99.81 0.01 0.19 NVNT n(HT40) 2437 Ant1 99.81 0.01 0.19 NVNT n(HT40) 2452 Ant1 99.81 0.01 0.19 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 4 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 5 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT b 2462MHz Ant1 Duty Cycle NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 6 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT g 2437MHz Ant1 Duty Cycle NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 7 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 8 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Duty Cycle NVNT n(HT40) 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 9 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 Duty Cycle NVNT n(HT40) 2437MHz Ant1 Duty Cycle NVNT n(HT40) 2452MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.toby-lab.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202512-0277-51 Page: 10 of 63 FCC ID: 2BDR5-90T TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 12.24 30 Pass NVNT b 2437 Ant1 12.63 30 Pass NVNT b 2462 Ant1 12.76 30 Pass NVNT g 2412 Ant1 12.39 30 Pass NVNT g 2437 Ant1 12.96 30 Pass NVNT g 2462 Ant1 12.99 30 Pass NVNT n(HT20) 2412 Ant1 11.39 30 Pass NVNT n(HT20) 2437 Ant1 11.88 30 Pass NVNT n(HT20) 2462 Ant1 11.88 30 Pass NVNT n(HT40) 2422 Ant1 9.24 30 Pass NVNT n(HT40) 2437 Ant1 10.5 30 Pass NVNT n(HT40) 2452 Ant1 9.72 30 Pass Note: The duty factor has been compensated in the chart. Shenzhen Toby Technology Co.,…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Chris Liu(CEO)

[email protected]Fax: N/A

Technical Contact

Americas Compliance Consulting LLC dba iCertifiPaul A Preston

[email protected]

5809 US-2, Suite B Albeni Plaza Priest River, · United States

Test Firm

Shenzhen Toby Technology Co., Ltd.Ray Lai

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.90 mW
2	15C	2.41 GHz - 2.46 GHz	38.10 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is average conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
