JPL Scout 3100 U ser’s Manual DECT PTT The JPL Scout 3100 Wireless DECT PTT (Push-To-Talk) Headset delivers reliable wireless communication and seamless PTT functionality for public safety dispatch, air traffic control, radio operations, and simulation training. Designed for environments requiring secure transmissions, the advanced DECT wireless adapter ensures top-tier protection with DECT Security Level C. Supporting both analog and USB interfaces, the DECT PTT system offers flexible configurations for one or two independent portable devices, making it the ideal solution for mission-critical communications. Advantages  Enhanced Security : Complies with DECT Security Step C and features 256-bit AES encryption (FIPS 140-2) to ensure securecommunication in sensitive environments.  Superior Audio Quality : Delivers clear, reliable voice transmission with advanced DECT technology optimizedspecifically for voice communication.  Wireless Freedom : Operates without cables, providing up to 150 ft (50 m) of range using DECT wireless technology forincreased mobility and convenience.  Flexible Interface Support : Analog and USB interfaces ensure broad compatibility with both analog and VoIPcommunication systems, as well as training simulators. Specifications Connects to  Analog RJ12 female connector to 2-Plong (RJ12-to-PJ7)  USB connectors to PC or Voice Communication Consoles (USB-C) Wireless  DECT 6.0-North America: 1.92 ~1.93 GHz  DECT-Europe: 1.88 ~ 1.90 GHz  Range (Line-of-Sight): 150 ft / 50 m  Security: DECT Security Step C  Encryption: Military level FIPS 140-2 listed 256-AES encryption  Authentication: 128-bit AES Battery  Battery Capacity: 400 mAh  Talk time: up to 11 Hours with Narrowband audio  Extra battery with charging chamber  Charge Time: Quick Charge for 2~3 hours Receiving Frequency Response  User selectable option for wideband and narrowband audio  Wideband 50 ~ 7000 Hz for G.722 Codec Audio  Sampling Frequency: 16 KHz  Bit Rate 64 kb/s  Narrowband 300 ~ 3,400 Hz for G.711 Codec Audio  Sampling Frequency: 8 KHz  8 bits per sample  Bit Rate 64 kb/s  Algorithm Delay: 0.125 msec Available Headset  Compatible with all JPL QD type headsets  Compatible with Poly QD type headset Remote Unit Features  PTT buttons  Audio link On-Off button with LED  Detachable Belt Clip  Receiving volume Control  Two Remote Unit can be used simultaneously (Option) Base Unit Features  Two charging chambers  Sending and receiving volume controls  Status LEDs for Power, Battery Charging, audio Interface, and PTT  Pairing Button  Analog (RJ12), and USB connection ports  Operating temperature range: 40°F(+4°C) to 110°F(+49°C) USB Enumeration  The PTT button enumerates as following features depend on customer’s demands  Microphone Audio PTT  Button 1 of a single button game controller  Joystick Button 1  Keystroke of ‘p’ of a keyboard  Keystroke of any 101 QWERT keyboard  Mute button pressing and releasing for USB HID telephony command.  Any of USB HID commands upon customer’s request INTRODUCTION Base Station Remote USB-C Cord RJ12-to-PJ7 Cord RJ12-to-RJ12 Supervisor Cord Extra Battery USB-C Power Adapter What’s included Connection The USB-C adapter or PC’s USB port can be connected to ‘POWER USB C’ connector for base station’s power. When it is connec ted, the base station can be woken up and starts operation. There are two RJ12 ports on rear side. One can be used for RJ2-to-PJ7 cord connection and the other can be sued for RJ12-to-RJ12 supervisor cord. Power On Remote There are two ways to power up the remote unit Press the in-use LED/button. And the In-user light will be on. When the remote is powered off, it can be powered on if it is put on cradle. Charging Remote For charging remote, put it on cradle on the base station When the remote is on charging, three battery level Lights will be shown to indicate battery level. Charging extra battery and changing battery There is another charging cradle for the extra battery. The battery itself can be charged when it is on second cradle. There are two battery level indicators for the extra battery charging. When it is fully charged, two lights will be on. The battery on the remote can be changed without any power disconnection. There is backup battery inside of the remote and it can make the remote alive during battery exchanging. Click on battery button and slide down the battery. It can be removed, and the remote can be working for one Minute for battery exchanging. Base Unit LED Power-On LED When the power is on, the LED will be light on. USB LED When the mode is selected to USB, light on. Analog LED When the mode is selected to analog, light on Remote LED When the remote is connected to the base, light on PTT LED When the PTT button is pressed on the remote, light on Button Mode Button When the mode button is pressed, the mode is changed from analog to USB and vice versa. Microphone Mute When the microphone mute button is pressed, the microphone is muted and unmuted. Power USB-C USB-C power can be connected to this connector USB-C USB-C data / power can be connected to this connector RJ12 Both RJ12 connectors can be used for PJ-7 analog connector or supervisor cord connection Volume Microphone volume can be controlled with 15 steps Pair The pairing button can be used for pairing with the remote. On bottom side, there are 4 pole DIP switc hes. The options on the DIP switch are on the table below. DIP Switch Function Default 1 Gamepad Button 1 /Mic. Active Mic. Active 2 Mode button Enable / Disable Disable 3 Rx Volume High/Low Low 4 Wideband / Narrowband Audio Wideband Visual Indicator Battery Indicator Full Green / Yellow / Red LED will be turned on Mid Yellow / Red LED will be turned on Low Red LED will be turned on Warning Red LED will be flashing to show low battery warning Operating Instructions - Connect the USB-C cable to USB-C In port at base station. - Press the In-use button to get connection to the base …

Text truncated - open the document above for the full version.

Rev 1/26/2023 JPL Telecom LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-02-09 FCC ID: 2BFHC-SCOUT3100 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing JPL Telecom LLC certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. JPL Telecom LLC certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing JPL Telecom LLC certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: JPL Telecom LLC Address: JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States Contact Person: James Clarke Tel.: 3213001141 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-02-09 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BFHC-SCOUT3100) JPL Telecom LLC, the undersigned, hereby authorize JPL Telecom LLC to act as our designated agent for service of process, JPL Telecom LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. JPL Telecom LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: JPL Telecom LLC Contact Name: James Clarke Address: JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States Telephone No: 3213001141 Email: [email protected] FRN: 0034729418 Signature: James Clarke Agent Information: Company Name: JPL Telecom LLC Address:JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States FRN: 0034729418 Contact Name: James Clarke Telephone No: 3213001141 Email: [email protected] Signature: James Clarke

1. Antenna Description Antenna plate PCB antenna Market name/Model name JPL Scout 3100 Antenna Max. Gain Ant0: 0.16dBi Ant1: 0.16dBi Frequency Range 1920-1930MHz Connect Type Integer antenna VSWR 1.1 Manufacturer: JPL Telecom LLC Address: JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States 2. Picture of antenna Ant 0: Length=31mm Width1=13mm Width2=9m Ant 1: Length=35m Width1=13mm Width2=9mm Antenna Radiation Pattern ANT0: Radiation pattern—1925MHz Total Average Gain: 0.16dBi Phi 0 45 90 135 180 235 270 315 Gain -0.61 0.16 -0.24 -0.38 -0.45 -0.81 -0.76 -0.77 ANT1: Radiation pattern—1925MHz Total Average Gain: 0.16dBi Phi 0 45 90 135 180 235 270 315 Gain -0.67 0.16 -0.27 -0.36 -0.43 -0.66 -0.80 -0.62

JPL Telecom LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 10, 2026 Subject; Request for Confidentiality FCC ID: 2BFHC-SCOUT3100 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: James Clarke Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 JPL Telecom LLC Date：2026-02-09 Product Model Number: JPL Scout 3100 ; FCC ID：2BFHC-SCOUT3100 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: James Clarke Contact Listed on FCC Wesbite Title: Manager Email: [email protected] On behalf of: JPL Telecom LLC

Page 1 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 13 Photo 14 Page 8 of 8 Report No.: LGT26A042 Appendix - External Photographs of EUT Constructional Details Photo 15 Photo 16

Label This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 ANT Page 3 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 13 Photo 14 ANT Page 8 of 8 Report No.: LGT26A042 Appendix - Internal Photographs of EUT Constructional Details Photo 15 ANT

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 RF TEST REPORT Product Name: BASE: DECT PTT BASE Model Name: JPL Scout 3100 FCC ID: 2BFHC-SCOUT3100 Issued For : JPL Telecom LLC JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26A042HA06 Sample Received Date: Jan. 08, 2026 Date of Test: Jan. 08, 2026 ~ Jan. 29, 2026 Date of Issue: Jan. 29, 2026 Report No.: LGT26A042HA06 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: JPL Telecom LLC Address: JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States Manufacturer: JPL Telecom LLC Address: JPL Telecom LLC 445 W Merritt Avenue MERRITT ISLAND Florida 32953-4760 United States Product Name: BASE: DECT PTT BASE Trademark: N/A Model Name: JPL Scout 3100 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26A042HA06 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26A042HA06 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jan. 29, 2026 Initial Issue Report No.: LGT26A042HA06 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: DECT PTT BASE Test Model Name: JPL Scout 3100 Series Model: N/A Model Difference: N/A Frequency Bands: FP 1921.536-1928.448MHz Rating Input: Base: 5V/1A Hardware Version: REV01 Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report No.: LGT26A042HA06 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26A042HA06 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26A042HA06 Page 8 of 8 2.5 TEST RESULT Turn up Result Mode Turn up Power DECT_FP_ANT0 14.5±1dBm DECT_FP_ANT1 15.5±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (dBi) ANT Gain (gain of antenna in linear scale) Power Density (mW/cm²) Limit (mW/cm²) Ratio Result DECT_FP_ANT0 1928.448 15.50 35.48 0.16 1.04 0.007 1 0.007 Pass DECT_FP_ANT1 1928.448 16.50 44.67 0.16 1.04 0.009 1 0.009 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. 2. Antenna 0 and antenna 1 do not support simultaneous transmission. ※※※※※END OF THE REPORT※※※※※
