2BG4H-JY-05Bluetooth Digital Alarm Clock

Product Name Product Model JY - 05 Product Parameters Please read carefully before use Color Box, Product, Cable, User Manual. Packing List User Guide Thank you for your purchase. The product comes with a 12-month warranty period. If you have any issues about the product, please feel free to contact us at any time. Our email is: [email protected] Customer after-sale service Bluetooth Alarm Clock Step 1: Please connect the clock to power, it will automatically turn on Bluetooth.Clock bluetooth name is "JY-5 Clock". Step 2: Please turn on your phone's Bluetooth and locate the "JY-5 Clock" device to connect.The clock will automatically synchronize. Tip: First Bluetooth pairing requires permission to access information. Bluetooth Alarm Clock Input Voltage 5V Material ABS Light Power 3W Product Size 140 x 40 x 70 mm 3. Night Light Key Turn the power switch to "ON", The product is working normally. Turn the power switch to "OFF", The product will be shut down. 2. Power ON/OFF Switch 1. Auto Sync of Phone Time Long press "Alarm 1 Set" key for 1.5 seconds to enter the alarm clock 1 setting and the "hour" is flashing, then press + or – key to select. Then short press "Alarm 1 Set" key to enter the "minute" flashing, press + or – key to select. Lastly, short press "Alarm 1 Set" key or wait for 5 seconds to confirm the alarm and return to time display. If you want to check alarm clock 1, please short press "Alarm 1 Set", Alarm Clock 1 time will be displayed 3 seconds. Long press this button to turn on light. Short press this button to select light colors. Long press this button to turn off the night light. The light colors include RGB, colorful RGB, white, orange, yellow, purple, blue, light blue, green, red. Short press this button to reset the factory settings. Turn the alarm 1 switch to "ON", alarm 1 will turn on, and the indicator light for alarm 1 will turn on. Turn the alarm 1 switch to "OFF", alarm 1 will turn off, and the indicator light for alarm 1 will turn off. 4.Reset Key 5.Alarm Clock 1 Switch 6.Alarm Clock 1 Setting In the clock mode, short press "Snooze / Light Setting" Button to adjusts the brightness of display screen in 4 Levels: Brightest, Medium Bright, Slightly Bright, Dark. During alarm, press button except "Snooze / Light Setting" will turn off the alarm for the day. Long press "time setting" key for 1.5 seconds to enter the setting and the "hour" is flashing, then press + or – key to select. Then short press setting" key to enter the "minute" flashing, press + or – key to select. Then short press setting" key to enter the "week" flashing, press + or – key to select. Lastly, short press " key or wait for 5 seconds to confirm the time and return to time display. In time display mode, short press this key to switch between 12 or 24 hour format. time "time "time "time setting 7.Time Setting 8. Tunes Setting (Volume/Ringtone setting) Long press "Tunes " key for 1.5 seconds to enter the tunes setting and the "Volume" is flashing, then press + or – key to select. Then short press "Tunes " key to enter the "Ringtone" flashing, press + or – key to select. Lastly, short press "Tunes " key or wait for 5 seconds to confirm the ringtone and return to time display. If you want to check Volume and Ringtone, please short press "Tunes ", Volume and Ringtone will be displayed 5 seconds. There are 8 ringtones. Including Beep, Birdsong, Rooster Crowing, Bonfire, Canon Piano, Alice Piano, Piano Information, Telephone Ringtone. Setting Setting Setting Setting Turn the alarm 2 switch to "ON", alarm 2 will turn on, and the indicator light for alarm 2 will turn on. Turn the alarm 2 switch to "OFF", alarm 2 will turn off, and the indicator light for alarm 2 will turn off. 9. Snooze / Light Setting When the alarm goes off and the "Snooze / Light Setting" Button is pressed, the indicator light on the clock alarm will flash. The alarm will temporarily stop until 9 minutes. The Snooze function is set to a maximum of 3 times, after which the alarm for the day will be turned off. If the "Snooze / Light Setting" button is not pressed, the alarm will turn off for the day after 30 minutes of ringing. 10.Up Key In the clock mode, The time separator does not flash by default. Long press the "UP" button for 1.5 seconds to switch to flashing. In setup mode, cooperate with modifying parameters. In setup mode, cooperate with modifying parameters. In the clock mode, Long press this key for 1.5 seconds to switch between Celsius or Fahrenheit format. 11.Down Key 12.Alarm Clock 2 Setting 13.Alarm Clock 2 Switch If the product battery is out of power, the battery indicator light will flash. If product still doesn't charge, product will automatically shut down. Time memory protection function activated. 14.Power off time memory protect function 15.Temperature Sensor Measure temperature. Try to avoid touching the temperature sensor as much as possible. 16.Unpair Bluetooth Long press the + and - for 2 seconds to cancel bluetooth pairing. Long press "Alarm 2 Set" key for 1.5 seconds to enter the alarm clock 2 setting and the "hour" is flashing, then press + or – key to select. Then short press "Alarm 2 Set" key to enter the "minute" flashing, press + or – key to select. Lastly, short press "Alarm 2 Set" key or wait for 5 seconds to confirm the alarm and return to time display. If you want to check alarm clock 2, please short press "Alarm 2 Set", Alarm Clock 2 time will be displayed 3 seconds. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digit…
