2BH7FM85505G Mobile Wi-Fi

Applicant Declaration QSF27-14-04 Rev 1.1 Jan 17, 2024 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name TP-Link Systems Inc. Address 10 Mauchly, Irvine, CA 92618 FRN 0035788017 Grantee Code 2BH7F FCC ID 2BH7FM8550 Authorized Contact Name Sarah Wang Contact Email [email protected] Contact Phone (626) 333-0234 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [TP-Link Systems Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [TP-Link Systems Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2024-09-09 Print Name: Sarah Wang Title: Product Compliance Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Statement and explanations M8550 is a 5G Mobile Wi-Fi indoor products with a certification module (module RG520N-NA (Module FCC ID:XMR2023RG520NNA,Date of Grant:05/07/2023)) . The 5G Sub-6 GHz LGA Module is installed in the host, which has no impact on the RF performance. Considering that the antenna is designed for the host, when the module is integrated into the host, we perform EMC tests on the host and re-test the RSE and conducted power in the RF. Since the WLAN function is added to the whole machine, the WLAN of the whole machine is tested completely. Please refer to the corresponding laboratory test results. Standard Test Plan Module Reference Report Part 15B/15C/15E Full test NA Part 22/24/27/90/96 Only retest RSE and check power 2303RSU050-U1 2303RSU050-U2 2303RSU050-U3 2303RSU050-U5 2303RSU050-U6 2303RSU050-U7 2303RSU050-U8 2303RSU050-U9 2303RSU050-U10 2303RSU050-U11 Part 2.1901 Reassessment NA The frequency bands available for the M8550 are as follows LTE:B2/4/5/7/12/13/14/ 25/26/30/41/48/66/71 NR:N2/5/12/14/25/30/41/48/66/71/77 LTE CA:2C/5B/7C/41C/48C/66B/66C ENDC:DC_5A_N2A;DC_14A_N2a;DC_30A_n2A;DC_12A_n2A;DC_66A_n2A;DC_71A_n2A; DC_13A_n2A;DC_7A_n2A;DC_4A_n2A;DC_13A_n5A;DC_2A_n5A；DC_12A_n5A;DC_30A_n5A; DC_66A_n5A;DC_7A_n5A;DC_48A_n5A;DC_5A_n7A;DC_5A_n7A;DC_66A_n7A;DC_71A_n7A; DC_13A_n7A;DC_2A_n7A;DC_4A_n7A;DC_2A_n12A;DC_2A_n12A;DC_2A_n12A;DC_7A_n12A; DC_5A_n12A;DC_48A_n12A;DC_2A_n14A;DC_30A_n14A;DC_66A_n14A;DC_66A_n25A; DC_12A_n25A;DC_48A_n25A;DC_7A_n25A;DC_71A_n25A;DC_5A_n25A;DC_5A_n25A; DC_5A_n25A;DC_2A_n30A;DC_5A_n30A;DC_12A_n30A;DC_14A_n30A;DC_66A_n30A; DC_66A_n38A;DC_2A_n38A;DC_12A_n38A;DC_4A_n38A;DC_5A_n38A;DC_71A_n38A; DC_2A_n41A;DC_66A_n41A;DC_25A_n41A;DC_26A_n41A;DC_5A_n41A;DC_4A_n41A; DC_12A_n41A;DC_12A_n41A;DC_12A_n41A;DC_71A_n41A;DC_2A_n48A;DC_5A_n48A; DC_13A_n48A;DC_66A_n48A;DC_66A_n48A;DC_2A_n66A;DC_5A_n66A;DC_5A_n66A; DC_14A_n66A;DC_30A_n66A;DC_71A_n66A;DC_48A_n66A;DC_48A_n66A;DC_2A_n71A; DC_2A_n71A;DC_5A_n71A;DC_7A_n71A;DC_48A_n71A;DC_48A_n71A;DC_7A_n77A; DC_7A_n77A;DC_7A_n77A;DC_13A_n77A;DC_66A_n77A;DC_12A_n77A;DC_14A_n77A; DC_30A_n77A;DC_25A_n77A;DC_71A_n77A;DC_7A_n78A;DC_38A_n78A;DC_38A_n78A; DC_38A_n78A;DC_2A_n78A;DC_12A_n78A;DC_13A_n78A;DC_41A_n78A;DC_4A_n78A; DC_71A_n78A;DC_26A_n78A;DC_26A_n78A WIFI 2.4G/5G/6G b/a/g/n/ac/ax 160M 2*2 TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Should you have any question or comment regarding this matter , Please have my best attention. Sincerely yours Date: 2024/9/24.. Name:  Sarah Wang.. Signature:  .

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-09-09 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2BH7F TP-Link Systems Inc. certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0034878967 Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Contact Person: Sarah Wang Tel.: (626) 333-0234 Sincerely, Printed Name: Sarah Wang Job Position: Product Compliance Manager Email: [email protected]

TP-Link Systems Inc. Date: 2024-09-09 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2BH7FM8550 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with TP-Link Systems Inc. This authorization is valid until further written notice from the applicant. Name (Printed): Sarah Wang Title: Product Compliance Manager Signature: On behalf of Company: TP-Link Systems Inc. Telephone: (626) 333-0234

TP-Link Systems Inc. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Regarding: Confidentiality Request regarding application for FCC ID: 2BH7FM8550 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions NII Software Security Info BOM Tune up The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Signature: Printed Name: Sarah Wang Title: Product Compliance Manager Company Name: TP-Link Systems Inc.

C B A 2 C 345678 B E D D A 9 1 7202510955 12345 E 6789 Model: M8550 5G Mobile Wi-Fi Power: 5V 3A, 9V 2A, 12V 1.5A Default Access: http://tplinkmifi.net MADE IN CHINA FCC ID: 2BH7FM8550 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N:XXXXXXXXXXXXXUS/1.0 MAC:XX-XX-XX-XX-XX-XX IMEI:XXXXXXXXXXXXXXX Wireless Password/PIN: XXXXXXXX SSID:TP-Link_XXXX_5G TP-Link Systems Inc.10 Mauchly, Irvine, CA 92618 Micro SDNano SIM 3mm 27.3mm Open the Card Slot Label Location

` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 1 of 11 Authorized Signature: Cloud Peng Technical Manager TEST REPORT Application No.: SUCR2404000127MO Applicant: TP-Link Systems Inc. Address of Applicant: 10 Mauchly, Irvine, CA 92618 Manufacturer: TP-Link Systems Inc. Address of Manufacturer: 10 Mauchly, Irvine, CA 92618 EUT Description: 5G Mobile Wi-Fi Model No.: M8550 Trade Mark: tp-link FCC ID: 2BH7FM8550 Standards: 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 Date of Receipt: 2024/04/23 Date of Issue: 2024/09/02 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 2 of 11 1 Version Revision Record Version Chapter Date Modifier Remark 01 2024/09/02 Original Prepared By (Nick Hu) / Test Engineer Checked By (Stone Gu) / Reviewer ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 3 of 11 Contents 1 Version ......................................................................................................................... 2 2 General Information ...................................................................................................... 4 2.1 Client Information .................................................................................................. 4 2.2 Test Facility ........................................................................................................... 4 2.3 General Description of EUT ................................................................................... 5 3 RF Exposure Evaluation ............................................................................................... 7 3.1 RF Exposure Compliance Requirement ................................................................ 7 3.1.1 Limits ................................................................................................................. 7 3.1.2 Test Procedure .................................................................................................. 8 3.1.3 EUT RF Exposure Evaluation ............................................................................ 8 3.1.4 Exposure calculations for multiple sources ...................................................... 11 ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 4 of 11 2 General Information 2.1 Client Information Applicant: TP-Link Systems Inc. Address of Applicant: 10 Mauchly, Irvine, CA 92618 Manufacturer: TP-Link Systems Inc. Address of Manufacturer: 10 Mauchly, Irvine, CA 92618 2.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6336.01) SGS-CSTC STANDARDS TECHNICAL SERVICES (SUZHOU) CO., LTD. is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 6336.01. • Innovation, Science and Economic Development Canada SGS-CSTC STANDARDS TECHNICAL SERVICES (SUZHOU) CO., LTD. has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0120. IC#: 27594. • FCC –Designation Number: CN1312 SGS-CSTC STANDARDS TECHNICAL SERVICES (SUZHOU) CO., LTD. has been recognized as an accredited testing laboratory. Designation Number: CN1312. Test Firm Registration Number: 717327 ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 5 of 11 2.3 General Description of EUT EUT Description: 5G Mobile Wi-Fi Model No.: M8550 Trade Mark: tp-link Hardware Version: V1.0 Software Version: V1.0 Antenna Type: Internal Antenna Power Class: Class 2: LTE Band 41; LTE CA_41C; NR Band n41; NR Band n77; Class 1.5: UL MIMO NR Band n41; UL MIMO NR Band n77; Feature: UL 2*2 MIMO: NR Band n41; NR Band n48; NR Band n77; Antenna Gain: LTE Band 2: 1.72dBi LTE Band 4: 1.56dBi LTE Band 5: -0.98dBi LTE Band 7: 1.98dBi LTE Band 12: 2.6dBi LTE Band 13: 2.9dBi LTE Band 14: 2.85dBi LTE Band 25: 1.72dBi LTE Band 26: 0.46dBi LTE Band 30: 0.89dBi LTE Band 41: 2.27dBi LTE Band 48: 0.98dBi LTE Band 66: 1.56dBi LTE Band 71: 1.95dBi LTE CA_2C: 1.72dBi LTE CA_5B: -0.98dBi LTE CA_7C: 1.98dBi LTE CA_41C: 2.27dBi LTE CA_48C: 0.98dBi LTE CA_66B: 1.56dBi LTE CA_66C: 1.56dBi NR Band n2: 1.72dBi NR Band n5: -0.98dBi NR Band n12: 2.6dBi NR Band n14: 2.85dBi NR Band n25: 1.72dBi NR Band n30: 0.89dBi NR Band n41 (MIMO): 2.27dBi NR Band n48 (MIMO): 0.98dBi NR Band n66: 1.56dBi NR Band n71: 1.95dBi NR Band n77 (MIMO): 2.11dBi 2.4G WIFI: 3.98dBi(Ant1); 3.98dBi(Ant2); 5150 MHz to 5250 MHz: 3.96dBi(Ant1); 3.96dBi(Ant2); 5250 MHz to 5350 MHz: 3.95dBi(Ant1); 3.95dBi(Ant2); 5470 MHz to 5725 MHz: 3.9dBi(Ant1); 3.9dBi(Ant2); 5725 MHz to 5850 MHz: 3.93dBi(Ant1); 3.93dBi(Ant2); ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUCR240400012708 Rev.: 01 Page: 6 of 11 5925 MHz to 6425 MHz: 3.97dBi(Ant1); 3.97dBi(Ant2); 6425 MHz to 6525 MHz: 3.92dBi(Ant1); 3.92dBi(Ant2); 6525 MHz to 6875 MHz: 3.92dBi(Ant1); 3.92dBi(Ant2); 6875 MHz to 7125 MHz: 4.2dBi(Ant1); 4.2dBi(Ant2); LTE CA: LTE CA_2C; LTE CA_5B; LTE CA_7C; LTE CA_41C; LTE CA_48C; LTE CA_66C; LTE CA_66B; ENDC: DC_5A_n2A;DC_14A_n2A;DC_30A_n2A;DC_12A_n2A;DC_66A_n2A; DC_71A_n2A;DC_13A_n2A;DC_7A_n2A;DC_4A_n2A;DC_13A_n5A; DC_2A_n5A;DC_12A_n5A;DC_30A_n5A;DC_66A_n5A;DC_7A_n5A; DC_48A_n5A;DC_5A_n7A;DC_5A_n7A;DC_66A_n7A;DC_71A_n7A; DC_13A_n7A;DC_2A_n7A;DC_4A_n7A;DC_2A_n12A;DC_2A_n12A; DC_2A_n12A;DC_7A_n12A;DC_5A_n12A;DC_48A_n12A;DC_2A_n14A; DC_30A_n14A;DC_66A_n14A;DC_66A_n25A;DC_12A_n25A;DC_48A_n25A; DC_7A_n25A;DC_71A_n25A;DC_5A_n25A;DC_5A_n25A;DC_5A_n25A; DC_2A_n30A;DC_5A_n30A;DC_12A_n30A;DC_14A_n30A;DC_66A_n30A; DC_2A_n41A;DC_66A_n41A;DC_25A_n41A;DC_26A_n41A;DC_5A_n41A; DC_4A_n41A;DC_12A_n41A;DC_12A_n41A;DC_12A_n41A; DC_71A_n41A;DC_2A_n48A;DC_5A_n48A;DC_13A_n48A;DC_66A_n48A; DC_66A_n48A;DC_2A_n66A;DC_5A_n66A;DC_5A_n66A;DC_14A_…
