2BHDZ-TL-WF701wireless video door phone

FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID............................................. : CTA26050900703 2BHDZ-TL-WF701 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : May 23, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Dongguan Tianluo Electronic Technology Co.,Ltd Address............................................ : 201room, Block 4, Longchang Science Park No.26, Hantang Street, Dongcheng District, Dongguan,Guangdong, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : wireless video door phone Trade Mark ....................................... : N/A Manufacturer .................................... : Dongguan Tianluo Electronic Technology Co.,Ltd Model/Type reference ...................... : TL-WF701 Listed Models ................................... : TL-WF702, TL-WF703, TL-WF801, TL-WF802, TL-WF803, TL-AH701, TL-AH801 Rating ............................................... : Input: 5V 2.0A Battery: 3.7V 5000mAh 11.1Wh Result ............................................... : PASS Report No.: CTA26050900703 Page 2 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : wireless video door phone Model /Type : TL-WF701 Listed Models : TL-WF702, TL-WF703, TL-WF801, TL-WF802, TL-WF803, TL-AH701, TL-AH801 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. So the tests were performed on model TL-WF701 and the test results for the main test model can cover the listed models. Applicant : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park No.26, Hantang Street, Dongcheng District, Dongguan,Guangdong, China Manufacturer : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park No.26, Hantang Street, Dongcheng District, Dongguan,Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26050900703 Page 3 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 6 2.4 Modifications ............................................................................................................ 6 3 TEST ENVIRONMENT ....................................................................................................... 7 3.1 Address of the test laboratory .................................................................................. 7 3.2 Test Facility .............................................................................................................. 7 3.3 Statement of the measurement uncertainty ............................................................. 7 4 Test limit .............................................................................................................................. 8 4.1 Requirement ............................................................................................................ 8 4.2 MPE Calculation Method ......................................................................................... 8 4.3 Conducted Power Results ....................................................................................... 8 4.4 Manufacturing tolerance ........................................................................................ 10 4.5 Standalone MPE Result .........................................…

Text truncated - open the document above for the full version.

FCC ID: 2BHDZ-TL-WF701 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2BHDZ-TL-WF701 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3 Fig. 4

99 11G_Ant1_2412 11G_Ant1_2437 100 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 101 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 102 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 103 AppendixH:Emissions in Restricted Bands Test Result TestMo de Antenna ChName Frequency[MH z] Detector Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict 11B Ant1 Low 2412 AV 2310.000 -59.4 2.00 0.03 37.83 ≤54 PASS AV 2386.320 -53.69 2.00 0.03 43.54 ≤54 PASS AV 2390.000 -56.38 2.00 0.03 40.85 ≤54 PASS Peak 2310.000 -50.93 2.00 0.00 46.27 ≤74 PASS Peak 2388.270 -46.33 2.00 0.00 50.87 ≤74 PASS Peak 2390.000 -50.01 2.00 0.00 47.19 ≤74 PASS High 2462 AV 2483.500 -55.53 2.00 0.02 41.69 ≤54 PASS AV 2488.070 -53.78 2.00 0.02 43.44 ≤54 PASS AV 2500.000 -58.17 2.00 0.02 39.05 ≤54 PASS Peak 2483.500 -46.36 2.00 0.00 50.84 ≤74 PASS Peak 2488.070 -46.29 2.00 0.00 50.91 ≤74 PASS Peak 2500.000 -51.03 2.00 0.00 46.17 ≤74 PASS 11G Ant1 Low 2412 AV 2310.000 -59.69 2.00 1.25 38.76 ≤54 PASS AV 2389.440 -58.42 2.00 1.25 40.03 ≤54 PASS AV 2390.000 -58.8 2.00 1.25 39.65 ≤54 PASS Peak 2310.000 -52.08 2.00 0.00 45.12 ≤74 PASS Peak 2350.830 -48.4 2.00 0.00 48.80 ≤74 PASS Peak 2390.000 -51.22 2.00 0.00 45.98 ≤74 PASS High 2462 AV 2483.500 -57.93 2.00 1.25 40.52 ≤54 PASS AV 2483.560 -58.04 2.00 1.25 40.41 ≤54 PASS AV 2500.000 -58.96 2.00 1.25 39.49 ≤54 PASS Peak 2483.500 -49.92 2.00 0.00 47.28 ≤74 PASS Peak 2486.200 -48.08 2.00 0.00 49.12 ≤74 PASS Peak 2500.000 -50.08 2.00 0.00 47.12 ≤74 PASS 11N20 SISO Ant1 Low 2412 AV 2310.000 -60.04 2.00 1.12 38.28 ≤54 PASS AV 2383.460 -58.2 2.00 1.12 40.12 ≤54 PASS AV 2390.000 -58.99 2.00 1.12 39.33 ≤54 PASS Peak 2310.000 -51.97 2.00 0.00 45.23 ≤74 PASS Peak 2322.750 -48.83 2.00 0.00 48.37 ≤74 PASS Peak 2390.000 -51.59 2.00 0.00 45.61 ≤74 PASS High 2462 AV 2483.500 -58.42 2.00 1.06 39.84 ≤54 PASS 104 AV 2485.320 -58.03 2.00 1.06 40.23 ≤54 PASS AV 2500.000 -58.69 2.00 1.06 39.57 ≤54 PASS Peak 2483.500 -50.9 2.00 0.00 46.30 ≤74 PASS Peak 2497.090 -48.19 2.00 0.00 49.01 ≤74 PASS Peak 2500.000 -51.3 2.00 0.00 45.90 ≤74 PASS 11N40 SISO Ant1 Low 2422 AV 2310.000 -60.04 2.00 1.06 38.22 ≤54 PASS AV 2387.300 -57.41 2.00 1.06 40.85 ≤54 PASS AV 2390.000 -57.97 2.00 1.06 40.29 ≤54 PASS Peak 2310.000 -50.85 2.00 0.00 46.35 ≤74 PASS Peak 2381.450 -47.43 2.00 0.00 49.77 ≤74 PASS Peak 2390.000 -49.88 2.00 0.00 47.32 ≤74 PASS High 2452 AV 2483.500 -57.36 2.00 1.06 40.90 ≤54 PASS AV 2483.625 -56.82 2.00 1.06 41.44 ≤54 PASS AV 2500.000 -59.21 2.00 1.06 39.05 ≤54 PASS Peak 2483.500 -50.18 2.00 0.00 47.02 ≤74 PASS Peak 2491.875 -46.24 2.00 0.00 50.96 ≤74 PASS Peak 2500.000 -50 2.00 0.00 47.20 ≤74 PASS Note： 3. The Antenna Gain is compensated in the graph. 4. The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. 105 Test Graphs 11B_Ant1_Low_2412_AV 11B_Ant1_Low_2412_Peak 11B_Ant1_High_2462_AV 106 11B_Ant1_High_2462_Peak 11G_Ant1_Low_2412_AV 107 11G_Ant1_Low_2412_Peak 11G_Ant1_High_2462_AV 11G_Ant1_High_2462_Peak 108 11N20SISO_Ant1_Low_2412_AV 11N20SISO_Ant1_Low_2412_Peak 109 11N20SISO_Ant1_High_2462_AV 11N20SISO_Ant1_High_2462_Peak 11N40SISO_Ant1_Low_2422_AV 110 11N40SISO_Ant1_Low_2422_Peak 11N40SISO_Ant1_High_2452_AV 111 11N40SISO_Ant1_High_2452_Peak

66 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 67 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 68 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 69 AppendixC: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 14.46 ≤30.00 PASS 2437 14.66 ≤30.00 PASS 2462 14.78 ≤30.00 PASS 11G Ant1 2412 15.01 ≤30.00 PASS 2437 15.15 ≤30.00 PASS 2462 15.41 ≤30.00 PASS 11N20SISO Ant1 2412 14.88 ≤30.00 PASS 2437 15.20 ≤30.00 PASS 2462 15.16 ≤30.00 PASS 11N40SISO Ant1 2422 15.32 ≤30.00 PASS 2437 15.50 ≤30.00 PASS 2452 15.48 ≤30.00 PASS 70 AppendixD: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -11.67 ≤8.00 PASS 2437 -11.52 ≤8.00 PASS 2462 -10.98 ≤8.00 PASS 11G Ant1 2412 -17.61 ≤8.00 PASS 2437 -16.76 ≤8.00 PASS 2462 -15.66 ≤8.00 PASS 11N20SISO Ant1 2412 -16.23 ≤8.00 PASS 2437 -16.00 ≤8.00 PASS 2462 -16.45 ≤8.00 PASS 11N40SISO Ant1 2422 -18.50 ≤8.00 PASS 2437 -18.93 ≤8.00 PASS 2452 -18.89 ≤8.00 PASS 71 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 72 11G_Ant1_2412 11G_Ant1_2437 73 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 74 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 75 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 76 AppendixE:Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 2.43 -47.88 ≤-17.57 PASS High 2462 2.64 -53.66 ≤-17.36 PASS 11G Ant1 Low 2412 -1.45 -31.57 ≤-21.45 PASS High 2462 -1.16 -56.95 ≤-21.16 PASS 11N20SISO Ant1 Low 2412 -1.74 -32.41 ≤-21.74 PASS High 2462 -1.21 -57.8 ≤-21.21 PASS 11N40SISO Ant1 Low 2422 -4.81 -32.74 ≤-24.81 PASS High 2452 -4.51 -55.97 ≤-24.51 PASS 77 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 78 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 79 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 80 81 AppendixF:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 2.10 2.10 --- PASS 30~1000 2.10 -67.44 ≤-17.9 PASS 1000~26500 2.10 -55.21 ≤-17.9 PASS 2437 Reference 2.08 2.08 --- PASS 30~1000 2.08 -67.15 ≤-17.92 PASS 1000~26500 2.08 -54.99 ≤-17.92 PASS 2462 Reference 1.00 1.00 --- PASS 30~1000 1.00 -66.72 ≤-19 PASS 1000~26500 1.00 -53.8 ≤-19 PASS 11G Ant1 2412 Reference -2.73 -2.73 --- PASS 30~1000 -2.73 -67.2 ≤-22.73 PASS 1000~26500 -2.73 -55.37 ≤-22.73 PASS 2437 Reference -1.86 -1.86 --- PASS 30~1000 -1.86 -67.24 ≤-21.86 PASS 1000~26500 -1.86 -55.42 ≤-21.86 PASS 2462 Reference -1.62 -1.62 --- PASS 30~1000 -1.62 -67.08 ≤-21.62 PASS 1000~26500 -1.62 -55.44 ≤-21.62 PASS 11N20SISO Ant1 2412 Reference -2.08 -2.08 --- PASS 30~1000 -2.08 -68.19 ≤-22.08 PASS 1000~26500 -2.08 -55.39 ≤-22.08 PASS 2437 Reference -1.88 -1.88 --- PASS 30~1000 -1.88 -67.31 ≤-21.88 PASS 1000~26500 -1.88 -55.26 ≤-21.88 PASS 2462 Reference -1.81 -1.81 --- PASS 30~1000 -1.81 -68.22 ≤-21.81 PASS 1000~26500 -1.81 -54.99 ≤-21.81 PASS 11N40SISO Ant1 2422 Reference -4.86 -4.86 --- PASS 30~1000 -4.86 -62.39 ≤-24.86 PASS 1000~26500 -4.86 -55.85 ≤-24.86 PASS 2437 Reference -5.11 -5.11 --- PASS 30~1000 -5.11 -67.88 ≤-25.11 PASS 1000~26500 -5.11 -55.57 ≤-25.11 PASS 2452 Reference -4.48 -4.48 --- PASS 30~1000 -4.48 -67.46 ≤-24.48 PASS 1000~26500 -4.48 -55.97 ≤-24.48 PASS 82 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 83 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 84 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 85 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 86 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 87 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 88 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 89 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 90 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 91 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 92 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 93 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 94 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 95 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 96 11N40SISO_Ant1_2452_1000~26500 97 AppendixG: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] DC Factor [dB] T Factor [dB] 11B Ant1 2412 8.35 8.40 99.40 0.03 0.12 2437 8.35 8.40 99.40 0.03 0.12 2462 8.35 8.39 99.52 0.02 0.12 11G Ant1 2412 0.15 0.20 75.00 1.25 6.67 2437 0.15 0.20 75.00 1.25 6.67 2462 0.15 0.20 75.00 1.25 6.67 11N20SISO Ant1 2412 0.17 0.22 77.27 1.12 5.88 2437 0.17 0.22 77.27 1.12 5.88 2462 0.18 0.23 78.26 1.06 5.56 11N40SISO Ant1 2422 0.18 0.23 78.26 1.06 5.56 2437 0.18 0.22 81.82 0.87 5.56 2452 0.18 0.23 78.26 1.06 5.56 98 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462

35 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 36 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 37 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 38 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 39 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 40 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 41 11N40SISO_Ant1_2452_1000~26500 42 AppendixG: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] DC Factor [dB] T Factor [dB] 11B Ant1 2412 8.35 8.40 99.40 0.03 0.12 2437 8.35 8.40 99.40 0.03 0.12 2462 8.35 8.40 99.40 0.03 0.12 11G Ant1 2412 0.15 0.19 78.95 1.03 6.67 2437 0.14 0.19 73.68 1.33 7.14 2462 0.15 0.20 75.00 1.25 6.67 11N20SISO Ant1 2412 0.17 0.22 77.27 1.12 5.88 2437 0.18 0.23 78.26 1.06 5.56 2462 0.17 0.22 77.27 1.12 5.88 11N40SISO Ant1 2422 0.18 0.22 81.82 0.87 5.56 2437 0.18 0.23 78.26 1.06 5.56 2452 0.18 0.23 78.26 1.06 5.56 43 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 44 11G_Ant1_2412 11G_Ant1_2437 45 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 46 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 47 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 48 AppendixH:Emissions in Restricted Bands Test Result TestMo de Anten na ChNam e Frequency [MHz] Detect or Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict 11B Ant1 Low 2412 AV 2310.000 -59.79 2.00 0.03 37.44 ≤54 PASS AV 2385.930 -52.95 2.00 0.03 44.28 ≤54 PASS AV 2390.000 -55.95 2.00 0.03 41.28 ≤54 PASS Peak 2310.000 -52.52 2.00 0.00 44.68 ≤74 PASS Peak 2386.970 -45.29 2.00 0.00 51.91 ≤74 PASS Peak 2390.000 -46.92 2.00 0.00 50.28 ≤74 PASS High 2462 AV 2483.500 -55.45 2.00 0.03 41.78 ≤54 PASS AV 2487.960 -53.38 2.00 0.03 43.85 ≤54 PASS AV 2500.000 -58.81 2.00 0.03 38.42 ≤54 PASS Peak 2483.500 -48.34 2.00 0.00 48.86 ≤74 PASS Peak 2488.400 -44.49 2.00 0.00 52.71 ≤74 PASS Peak 2500.000 -50.21 2.00 0.00 46.99 ≤74 PASS 11G Ant1 Low 2412 AV 2310.000 -60.07 2.00 1.03 38.16 ≤54 PASS AV 2387.620 -58.62 2.00 1.03 39.61 ≤54 PASS AV 2390.000 -59.21 2.00 1.03 39.02 ≤54 PASS Peak 2310.000 -51.97 2.00 0.00 45.23 ≤74 PASS Peak 2381.510 -48.49 2.00 0.00 48.71 ≤74 PASS Peak 2390.000 -51.33 2.00 0.00 45.87 ≤74 PASS High 2462 AV 2483.500 -50.04 2.00 1.25 48.41 ≤54 PASS AV 2483.780 -49.73 2.00 1.25 48.72 ≤54 PASS AV 2500.000 -58.67 2.00 1.25 39.78 ≤54 PASS Peak 2483.500 -39.76 2.00 0.00 57.44 ≤74 PASS Peak 2485.210 -38.02 2.00 0.00 59.18 ≤74 PASS 49 Peak 2500.000 -48.98 2.00 0.00 48.22 ≤74 PASS 11N20 SISO Ant1 Low 2412 AV 2310.000 -60.05 2.00 1.12 38.27 ≤54 PASS AV 2386.970 -58.59 2.00 1.12 39.73 ≤54 PASS AV 2390.000 -59.18 2.00 1.12 39.14 ≤54 PASS Peak 2310.000 -52.82 2.00 0.00 44.38 ≤74 PASS Peak 2352.780 -48.69 2.00 0.00 48.51 ≤74 PASS Peak 2390.000 -51.28 2.00 0.00 45.92 ≤74 PASS High 2462 AV 2483.500 -58.68 2.00 1.12 39.64 ≤54 PASS AV 2488.400 -58.41 2.00 1.12 39.91 ≤54 PASS AV 2500.000 -59.69 2.00 1.12 38.63 ≤54 PASS Peak 2483.500 -49.64 2.00 0.00 47.56 ≤74 PASS Peak 2489.170 -48.38 2.00 0.00 48.82 ≤74 PASS Peak 2500.000 -50.31 2.00 0.00 46.89 ≤74 PASS 11N40 SISO Ant1 Low 2422 AV 2310.000 -60.35 2.00 0.87 37.72 ≤54 PASS AV 2389.400 -57.99 2.00 0.87 40.08 ≤54 PASS AV 2390.000 -58.22 2.00 0.87 39.85 ≤54 PASS Peak 2310.000 -51.05 2.00 0.00 46.15 ≤74 PASS Peak 2375.450 -48.61 2.00 0.00 48.59 ≤74 PASS Peak 2390.000 -50.34 2.00 0.00 46.86 ≤74 PASS High 2452 AV 2483.500 -58.14 2.00 1.06 40.12 ≤54 PASS AV 2484.375 -57.78 2.00 1.06 40.48 ≤54 PASS AV 2500.000 -59.3 2.00 1.06 38.96 ≤54 PASS Peak 2483.500 -49.61 2.00 0.00 47.59 ≤74 PASS Peak 2484.250 -47.72 2.00 0.00 49.48 ≤74 PASS Peak 2500.000 -50.67 2.00 0.00 46.53 ≤74 PASS Note： 1. The Antenna Gain is compensated in the graph. 2. The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. 50 Test Graphs 11B_Ant1_Low_2412_AV 11B_Ant1_Low_2412_Peak 11B_Ant1_High_2462_AV 51 11B_Ant1_High_2462_Peak 11G_Ant1_Low_2412_AV 52 11G_Ant1_Low_2412_Peak 11G_Ant1_High_2462_AV 11G_Ant1_High_2462_Peak 53 11N20SISO_Ant1_Low_2412_AV 11N20SISO_Ant1_Low_2412_Peak 54 11N20SISO_Ant1_High_2462_AV 11N20SISO_Ant1_High_2462_Peak 11N40SISO_Ant1_Low_2422_AV 55 11N40SISO_Ant1_Low_2422_Peak 11N40SISO_Ant1_High_2452_AV 56 11N40SISO_Ant1_High_2452_Peak 57 Appendix RF Test Data for 2.4GWIFI Module 2 AppendixA: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.200 2406.920 2417.120 0.5 PASS 2437 10.200 2431.920 2442.120 0.5 PASS 2462 10.200 2456.920 2467.120 0.5 PASS 11G Ant1 2412 15.600 2404.160 2419.760 0.5 PASS 2437 15.400 2429.440 2444.840 0.5 PASS 2462 15.880 2454.080 2469.960 0.5 PASS 11N20SISO Ant1 2412 16.840 2403.640 2420.480 0.5 PASS 2437 17.040 2428.400 2445.440 0.5 PASS 2462 16.520 2453.720 2470.240 0.5 PASS 11N40SISO Ant1 2422 35.440 2404.240 2439.680 0.5 PASS 2437 35.680 2419.160 2454.840 0.5 PASS 2452 35.520 2434.320 2469.840 0.5 PASS 58 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 59 11G_Ant1_2412 11G_Ant1_2437 60 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 61 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 62 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 63 AppendixB: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.401 2405.3267 2418.7277 --- --- 2437 13.405 2430.3131 2443.7181 --- --- 2462 13.421 2455.3046 2468.7256 --- --- 11G Ant1 2412 16.855 2403.6239 2420.4789 --- --- 2437 16.884 2428.5825 2445.4665 --- --- 2462 16.898 2453.5719 2470.4699 --- --- 11N20SISO Ant1 2412 17.833 2403.1176 2420.9506 --- --- 2437 17.830 2428.0869 2445.9169 --- --- 2462 17.901 2453.0701 2470.9711 --- --- 11N40SISO Ant1 2422 36.058 2404.0614 2440.1194 --- --- 2437 36.057 2419.11…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for 2.4GWIFI FCC ID : 2BHDZ-TL-WF701 Company : Dongguan Tianluo Electronic Technology Co.,Ltd EUT : wireless video door phone Model Number : TL-WF701 Report No. : CTA26050900701 Reviewed By : Eric Wang 2 Appendix RF Test Data for 2.4GWIFI Module 1 AppendixA: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.200 2406.920 2417.120 0.5 PASS 2437 10.200 2431.920 2442.120 0.5 PASS 2462 10.240 2456.920 2467.160 0.5 PASS 11G Ant1 2412 15.880 2404.080 2419.960 0.5 PASS 2437 15.800 2428.960 2444.760 0.5 PASS 2462 15.720 2454.240 2469.960 0.5 PASS 11N20SISO Ant1 2412 16.440 2403.960 2420.400 0.5 PASS 2437 16.480 2428.440 2444.920 0.5 PASS 2462 17.200 2453.480 2470.680 0.5 PASS 11N40SISO Ant1 2422 35.440 2404.240 2439.680 0.5 PASS 2437 35.280 2419.560 2454.840 0.5 PASS 2452 34.560 2434.960 2469.520 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 7 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 8 AppendixB: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.407 2405.3235 2418.7305 --- --- 2437 13.403 2430.3179 2443.7209 --- --- 2462 13.424 2455.3022 2468.7262 --- --- 11G Ant1 2412 16.941 2403.6061 2420.5471 --- --- 2437 16.847 2428.6120 2445.4590 --- --- 2462 16.802 2453.6617 2470.4637 --- --- 11N20SISO Ant1 2412 17.854 2403.0762 2420.9302 --- --- 2437 17.879 2428.0746 2445.9536 --- --- 2462 17.840 2453.0954 2470.9354 --- --- 11N40SISO Ant1 2422 36.019 2404.1271 2440.1461 --- --- 2437 36.064 2419.0860 2455.1500 --- --- 2452 36.067 2434.0860 2470.1530 --- --- 9 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 10 11G_Ant1_2412 11G_Ant1_2437 11 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 12 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 13 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 14 AppendixC: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 14.36 ≤30.00 PASS 2437 14.53 ≤30.00 PASS 2462 14.60 ≤30.00 PASS 11G Ant1 2412 13.93 ≤30.00 PASS 2437 14.05 ≤30.00 PASS 2462 14.12 ≤30.00 PASS 11N20SISO Ant1 2412 13.60 ≤30.00 PASS 2437 13.80 ≤30.00 PASS 2462 14.04 ≤30.00 PASS 11N40SISO Ant1 2422 13.99 ≤30.00 PASS 2437 14.28 ≤30.00 PASS 2452 14.23 ≤30.00 PASS 15 AppendixD: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -11.07 ≤8.00 PASS 2437 -10.79 ≤8.00 PASS 2462 -11.71 ≤8.00 PASS 11G Ant1 2412 -18.29 ≤8.00 PASS 2437 -18.47 ≤8.00 PASS 2462 -17.06 ≤8.00 PASS 11N20SISO Ant1 2412 -18.06 ≤8.00 PASS 2437 -15.73 ≤8.00 PASS 2462 -17.85 ≤8.00 PASS 11N40SISO Ant1 2422 -20.31 ≤8.00 PASS 2437 -20.81 ≤8.00 PASS 2452 -20.13 ≤8.00 PASS 16 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 17 11G_Ant1_2412 11G_Ant1_2437 18 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 19 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 20 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 21 AppendixE:Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 1.98 -46.73 ≤-18.02 PASS High 2462 2.06 -52.41 ≤-17.94 PASS 11G Ant1 Low 2412 -2.69 -33.53 ≤-22.69 PASS High 2462 -2.31 -48.72 ≤-22.31 PASS 11N20SISO Ant1 Low 2412 -2.97 -33.14 ≤-22.97 PASS High 2462 -2.54 -58.38 ≤-22.54 PASS 11N40SISO Ant1 Low 2422 -5.94 -33.94 ≤-25.94 PASS High 2452 -5.75 -57.48 ≤-25.75 PASS 22 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 23 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 24 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 25 26 AppendixF:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 1.05 1.05 --- PASS 30~1000 1.05 -68.15 ≤-18.95 PASS 1000~26500 1.05 -55.6 ≤-18.95 PASS 2437 Reference 1.66 1.66 --- PASS 30~1000 1.66 -67.46 ≤-18.34 PASS 1000~26500 1.66 -54.75 ≤-18.34 PASS 2462 Reference 1.56 1.56 --- PASS 30~1000 1.56 -67.63 ≤-18.44 PASS 1000~26500 1.56 -54.42 ≤-18.44 PASS 11G Ant1 2412 Reference -3.57 -3.57 --- PASS 30~1000 -3.57 -67.99 ≤-23.57 PASS 1000~26500 -3.57 -55.37 ≤-23.57 PASS 2437 Reference -3.27 -3.27 --- PASS 30~1000 -3.27 -68.5 ≤-23.27 PASS 1000~26500 -3.27 -55.87 ≤-23.27 PASS 2462 Reference -2.54 -2.54 --- PASS 30~1000 -2.54 -68.19 ≤-22.54 PASS 1000~26500 -2.54 -55.65 ≤-22.54 PASS 11N20SISO Ant1 2412 Reference -3.58 -3.58 --- PASS 30~1000 -3.58 -66.82 ≤-23.58 PASS 1000~26500 -3.58 -55.62 ≤-23.58 PASS 2437 Reference -2.82 -2.82 --- PASS 30~1000 -2.82 -51.28 ≤-22.82 PASS 1000~26500 -2.82 -55.98 ≤-22.82 PASS 2462 Reference -3.00 -3.00 --- PASS 30~1000 -3.00 -66.09 ≤-23 PASS 1000~26500 -3.00 -56.36 ≤-23 PASS 11N40SISO Ant1 2422 Reference -6.73 -6.73 --- PASS 30~1000 -6.73 -67.83 ≤-26.73 PASS 1000~26500 -6.73 -56.28 ≤-26.73 PASS 2437 Reference -5.86 -5.86 --- PASS 30~1000 -5.86 -68.07 ≤-25.86 PASS 1000~26500 -5.86 -55.96 ≤-25.86 PASS 2452 Reference -6.14 -6.14 --- PASS 30~1000 -6.14 -67.68 ≤-26.14 PASS 1000~26500 -6.14 -55.74 ≤-26.14 PASS 27 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 28 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 29 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 30 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 31 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 32 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 33 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 34 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART CTEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. ............................................ : CTA26050900701 2BHDZ-TL-WF701 Compiled by ( position+printedname+signature) .. : File administrators Zoey Cao Supervised by (position+printedname+signature) ... : Project Engineer Ace Chai Approved by (position+printedname+signature) ... : RF Manager Eric Wang Date of issue .................................... : May 23, 2026 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Dongguan Tianluo Electronic Technology Co.,Ltd Address ............................................ : 201room, Block 4, Longchang Science Park No.26, Hantang Street, Dongcheng District, Dongguan,Guangdong, China Test specification ........................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source o…

Text truncated - open the document above for the full version.
