2BHFB-MATE-01Nocpix Remote Control

NOCPIX REMOTE CONTROL Quick Start Guide 1.0 The MATE series supports Remote function, when you receive a new MATE, Remote and MATE are already connected in factory. If you replace a new Remote accessories in the future, Remote needs to be connected to MATE again. Connection 1. Power on MATE, press and hold the M and Down buttons simultaneously for 10 seconds, and then the remote controller will automatically connect to the MATE. 2. The remote icon will appear in the bottom left corner, indicating that remote has been successfully connected to MATE. FCC Statement FCC ID: 2BHFB-MATE-01 Labeling requirements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Information to the user Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. a) Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate. b) Even used batteries may cause severe injury or death. c) Call a local poison control center for treatment information. d) Compatible battery type: LIR2032H. e) Nominal battery voltage: 3.7V f) Non-rechargeable batteries are not to be recharged. g) Do not force discharge, recharge, disassemble, heat above the manufacturer’s specified temperature rating, or incinerate. Doing so may result in injury due to venting, leakage, or explosion resulting in chemical burns. hEnsure the batteries are installed corectly according to polarity (+and-) iDo not mix old and new batteries, different brands or types of batteries, such as alkaline, carbon-zinc, or rechargeable batteries. j)Remove and immediately recycle or dispose of batteries from equipment not used for an extended period of time according to local regulations. k) Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep them away from children. • INGESTION HAZARD: This product contains a button cell or coin battery. • DEATH or serious injury can occur if ingested. • A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours. • KEEP new and used batteries OUT OF REACH Of CHILDREN • Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body. WARNING Inlumen Technologies Co., Ltd. [email protected] Room 806, A1, Phase 3, Innovation Industrial Park, High-tech Zone, Hefei City, Anhui Province, China. www.nocpix.com

Compliance Certification Services (Kunshan) Inc. Page: 1 of 5 External Photos for KSCR2604000835AT Compliance Certification Services (Kunshan) Inc. Page: 2 of 5 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 5 Compliance Certification Services (Kunshan) Inc. Page: 4 of 5 Compliance Certification Services (Kunshan) Inc. Page: 5 of 5 - End of the Appendix -

标签： MATE 2 遥控器标签粘贴指导文件 料号 版本 单位 比例 v1.0 mm 1:1 1.0 居中对齐 粘贴要求： 1.位置：按照图纸指示位置 2.公差：≤0.2mm 居中对齐 料号：3100401601 料号：3100401964 ID Center.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Internal Photos for KSCR2604000835AT Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 - End of the Appendix -

Report No.: KSCR260400083502 Page: 1 of 9 TRF No. CONN_001 A_Jun 1st ,2026 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2604000835AT FCC ID: 2BHFB-MATE-01 Applicant: Inlumen Technologies Co., Ltd. Address of Applicant: Room 806, A1, Phase 3, Innovation Industrial Park,High-tech Zone, Hefei City, Anhui Province, China. Manufacturer: Inlumen Technologies Co., Ltd. Address of Manufacturer: Room 806, A1, Phase 3, Innovation Industrial Park,High-tech Zone, Hefei City, Anhui Province, China. Factory: ImTorch Innovation Technology Co., Ltd. Address of Factory: Room 301, 3rd Floor, Building A, No. 1777, Jimingshan Road, Chengxiqiao Community Service Center, High-tech Zone, Hefei City, Anhui Province, China. Equipment Under Test (EUT): EUT Name: Nocpix Remote Control Model No.: IMRC-1 Trade Mark Nocpix Standard(s) : FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2026-04-16 Date of Test: 2026-05-04 to 2026-05-06 Date of Issue: 2026-06-08 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: KSCR260400083502 Page: 2 of 9 TRF No. CONN_001 A_Jun 1st ,2026 Revision Record Version Description Date Remark 00 Original 2026-06-08 / Authorized for issue by: Tested By Eric_Liu /Project Engineer Approved By Terry Hou /Reviewer Report No.: KSCR260400083502 Page: 3 of 9 TRF No. CONN_001 A_Jun 1st ,2026 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Details of E.U.T. ......................................................................................................................... 4 3.3 Test Location .............................................................................................................................. 5 3.4 Test Facility ................................................................................................................................ 5 4 FCC Radiofrequency radiation exposure limits ............................................................................ 6 4.1 Blanket 1 mW Blanket Exemption .............................................................................................. 6 4.2 MPE-based Exemption .............................................................................................................. 6 4.3 SAR-based Exemption ............................................................................................................... 7 5 Measurement and Calculation ......................................................................................................... 9 5.1 Maximum transmit power ........................................................................................................... 9 5.1 RF Exposure Calculation ........................................................................................................... 9 Report No.: KSCR260400083502 Page: 4 of 9 TRF No. CONN_001 A_Jun 1st ,2026 3 General Information 3.1 General Description of E.U.T. Power supply: DC 3.7V by battery Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Zigbee Operation Frequency: 2405MHz to 2480MHz Modulation Type: O-QPSK Number of Channels: 16 Channel Spacing: 5MHz Antenna Type: Chip Antenna Antenna Gain: 1.69dBi (Provided by the manufacturer) Report No.: KSCR260400083502 Page: 5 of 9 TRF No. CONN_001 A_Jun 1st ,2026 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g., max. internal working frequency, antenna gain, cable loss, etc) is provided by the applicant. (If applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (If applicable). 3. Sample source: sent by customer. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). • FCC (Designation Number: CN1172) Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. • ISED (CAB Identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 2324E • VCCI (Member No:1938) The 3m and 10m Semi-anechoic chamber and Shielded Room of Compliance Certification Services (Kunshan) Inc. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-20134, R-11600, C-11707, T-11499, G-10216 respectively. Report No.: KSCR260400083502 Page: 6 of 9 TRF No. CONN_001 A_Jun 1st ,2026 4 FCC Radiofrequency radiation exposure limits Test exemptions apply for devices used in general population/uncontrolled exposure environments, according to the SAR-based, or MPE-based exemption thresholds. 4.1 Blanket 1 mW Blanket Exemption The 1 mW Blanket Exemption of §1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power …

Text truncated - open the document above for the full version.

Description: 3216 2.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. For more information: Pulse Worldwide HeadquartersPulse/Larsen AntennasEurope HeadquartersPulse (Suzhou) Wireless Products Co, Inc. 15255 Innovation Drive #100Pulse GmbH & Do, KG99 HuoJuRoad(#29 Bldg,4 th Phase San Diego, CA 92128Vancouver, WA 98683Zeppelinstrasse15Suzhou New District USAUSAHerrenberg, Germany Jiangsu Province, Suzhou 215009 PR China Tel:1-858-674-8100Tel: 1-360-944-7551 - Tel: 49 7032 7806 0 Tel: 86 512 6807 9998 18110 SE 34 th St Bldg2 Suite 250 Features: Applications: •Size : 3.05x1.55x0.55 mm •Omni-directional Radiation •Tape & reel automaicmounting •Reflow process compatible •RoHScompliant •2.4GHz WiFidevice •Bluetooth gadget •Zigbeedevice •ISM band equipment 1 ELECTRICAL SPECIFICATIONS Working Frequency2.45 GHz Bandwidth200MHz(Typ.) Return Loss6.5 dB(Min.) PolarizationLinear Azimuth BeamwidthOmni-directional Peak Gain1.69 dBi(Typ.) Impedance50 Ω Operating Temperature-40~105 °C Maximum Power 1 W Termination Ni/ Sn(Environmentally-Friendly Leadless) Resistance to Soldering Heats 260 °C , 10sec. NOTE 1. The specification is defined on Pulse evaluation board In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 32162.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A 2 MECHANICALDRAWING Dimension L (mm)3.05 ± 0.10 W (mm)1.55 ± 0.10 T (mm)0.55 ± 0.10 A(mm)0.40 ± 0.10 Terminal nameFunction S1FeedingPoint S2GND In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 32162.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A 3 LAYOUT OF EVALUATION BOARD Outlookand dimension of evaluation board In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 32162.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A 4 LAYOUT OF EVALUATION BOARD Dimension of footprint Radiation pattern Frequency= 2.45 GHz Max gain = 1.69 dBi MEG (mean effective gain)= -1.00 dBi Directivity (dB) = 2.18 Efficiency = -0.49dB, 89.33% In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 32162.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A 5 ELECTRICAL PERFORMANCES Return loss Maker data 1. 2.39GHz, -10.00dB 2. 2.45GHz, -16.48dB 3. 2.50GHz, -10.00dB In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 32162.4-2.5GHz Chip Antenna PART NUMBER: ANT3216A063R2400A 6 REFERENCE DESIGN OF MATCHING CIRCUIT Outlookand dimension of matching circuit 5 6 Clearance Definition : Size = 5.0 * 6.0 mm Soldering Pads Dimension Footprint : In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information ofPulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reprod…

Text truncated - open the document above for the full version.

Report No.: KSCR260400083501 Page: 1 of 54 TRF No. CONN_001 A_Jun 1st ,2026 TEST REPORT Application No.: KSCR2604000835AT FCC ID: 2BHFB-MATE-01 Applicant: Inlumen Technologies Co., Ltd. Address of Applicant: Room 806, A1, Phase 3, Innovation Industrial Park,High-tech Zone, Hefei City, Anhui Province, China. Manufacturer: Inlumen Technologies Co., Ltd. Address of Manufacturer: Room 806, A1, Phase 3, Innovation Industrial Park,High-tech Zone, Hefei City, Anhui Province, China. Factory: ImTorch Innovation Technology Co., Ltd. Address of Factory: Room 301, 3rd Floor, Building A, No. 1777, Jimingshan Road, Chengxiqiao Community Service Center, High-tech Zone, Hefei City, Anhui Province, China. Equipment Under Test (EUT): EUT Name: Nocpix Remote Control Model No.: IMRC-1 Trade Mark: Nocpix Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2026-04-16 Date of Test: 2026-05-04 to 2026-05-06 Date of Issue: 2026-06-08 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: KSCR260400083501 Page: 2 of 54 TRF No. CONN_001 A_Jun 1st ,2026 Revision Record Version Description Date Remark 00 Original 2026-06-08 / Authorized for issue by: Prepared By Eric_Liu/Project Engineer Approved By Terry Hou /Reviewer Report No.: KSCR260400083501 Page: 3 of 54 TRF No. CONN_001 A_Jun 1st ,2026 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.10.5 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 & 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Maximum Conducted Output Power ANSI C63.10 (2020) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectral Density ANSI C63.10 (2020) Section 11.10.3 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Report No.: KSCR260400083501 Page: 4 of 54 TRF No. CONN_001 A_Jun 1st ,2026 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 Test Summary ......................................................................................................................................... 3 3 Contents ................................................................................................................................................... 4 4 General Information ................................................................................................................................ 5 4.1 Details of E.U.T. ............................................................................................................................... 5 4.2 Power level setting using in test ....................................................................................................... 5 4.3 Description of Support Units ............................................................................................................ 5 4.4 Measurement Uncertainty ................................................................................................................ 6 4.5 Test Location .................................................................................................................................... 7 4.6 Test Facility ...................................................................................................................................... 7 4.7 Deviation from Standards ................................................................................................................. 7 4.8 Abnormalities from Standard Conditions .......................................................................................... 7 5 Equipment List ........................................................................................................................................ 8 6 Radio Spectrum Technical Requirement .............................................................................................. 9 6.1 Antenna Requirement ...................................................................................................................... 9 7 Radio Spectrum Matter Test Results .................................................................................................. 10 7.1 Radiated Emissions which fall in the restricted bands ................................................................... 10 7.2 Radiated Spurious Emissions Below 1GHz ................................................................................... 21 7.3 Radiated Spurious Emissions Above 1GHz ................................................................................... 25 7.4 Maximum Conducted Output Power .............................................................................................. 33 7.5 Minimum 6dB Bandwidth................................................................................................................ 34 7.6 Power Spectral Density .................................................................................................................. 35 7.7 Conducted Band Edges Measurement .......................................................................................... 36 7.8 Conducted Spurious Emission…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2604000835AT Test Model No.: IMRC-1 Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo RF Conducted setup RF Radiated setup (Below 1GHz) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 RF Radiated setup (Above 1GHz) - End of the Appendix -
