2BM2F-DV03SPORTS CAMERA

Thumb Camera operating instruction Read the instructions carefully before using this product The specification is for reference only. The actual operation is subject to the actual object. 1、product mix product description 1）Lens 2) Power/Switch/Menus 3) OK/Lock Lens 2) Power/Switch/Menus 3) OK/Lock 4）Take a photo, press the down button, or long-press the mirror 5) Charging port 6) TF card slot 7) Reset button 2. Introduction to buttons and interfaces 1. power switch 1) Press and hold to turn the device on/off; 2) Tap to switch between video/recording and menu interfaces; 3) Tap to return to the previous level. 2. OK key 1）Confirm key; 2）Press to record. Hold to lock or unlock the video. 3）Record on the recording interface. 4）In playback mode, tap to play/pause videos or recordings. To view photos, videos, or recordings, long-press to open the delete, lock, or unlock menu (photos and recordings are not locked). 3. Take photo or press down 1）Record mode. Tap to take a photo. Press and hold to switch to mirror view. 2）Menu mode: tap to switch up or down. 3）Press to switch between photo, video, and audio files in playback mode. 4. Reset button When the machine has a screen flower, abnormal crash and other situations, use a pinhole thing to short tap to force the shutdown. 5. Charging and data ports 1）Interface type: Type-C 2）Used to connect an external power source to charge the battery or provide working power. 3）Used to connect PC data transmission and PC camera; Note: Do not remove or insert cards during device operation. III. Basic Introduction and Operation Instructions 1. Power on and off Press and hold the power button for 2 seconds to turn the device on or off. 2. Video mode To turn on the device in power-off mode, press and hold the power button. 1) Press the down button to take a photo; long press to mirror the lens view; 2) Press the OK button to record, then press again to end and save the recording. While recording, long-press the OK button to lock/unlock the current video. 4) Press the power button to switch between recording mode and menu mode. 3. Recording Mode To turn on the device, long-press the power button. To enter recording mode, press the power button. 1）Tap OK to record, then tap again to end and save the recording. 2）Press the power button to switch to menu or recording mode. 4. Menu To turn on the device in off mode, press and hold the power button. Double-tap the power button to enter the menu. Tap the down button to select a function, then tap OK to proceed. WiFi: Prompt for WiFi download QR code, name, and password. Exit by pressing the power button. Settings: Tap the Down button to select settings, then tap OK to save changes. Playback: 1) Press the 'Down' button to select a file type, then press the 'OK' button to proceed. 2) Press and hold the 'Down' button to quickly switch between files; 3）Press and hold the OK button to open the delete menu (video files have a lock/unlock menu). 4）To play or pause while viewing a video or recording, press the OK button. 5) Press the power button to return to the previous level. Format: To format the memory card, press the OK button. 5.WiFi pattern To enable WiFi, download and install the Record Wind app on your smartphone. Note: For Android, scan the QR code in the 'Network' section of your device or scan the QR code below. For iOS, search for 'Record Wind' in the Apple Store to download. Enable WiFi: In the recording interface, double-tap the power button to access the menu, then select WiFi to turn it on. Install and use WiFi: Connection steps: 1) After turning on the device, press the power button twice to enter the menu, then click WiFi to connect and turn on the Wi-Fi. 2) Upon connecting to the WiFi, the screen will display the app download QR code along with the WiFi name and password, indicating that the connection is active. 3) Open the downloaded app, select "Add Device", go to the Wi-Fi settings, find the Wi-Fi name displayed on the device, enter the password, and the connection will be established. Turn off WiFi: After enabling WiFi, press the power button to return to the previous level to turn off WiFi. 6.USB pattern The device connects to the computer via a USB cable. Upon automatic startup, the screen displays three options: 'Memory', 'PC Camera', and 'Video Mode'. Memory: Access and view video or photo files in this mode PC Camera: This mode allows you to use your computer camera. Video mode: Only charging. 4、Product Specifications resolution ratio 4K、2K、1080P Record video 1 minute, 3 minutes, 5 minutes Video pre-record Close, Open volume control Low, Medium, High keypad tone Close, open time set user-defined language Simplified Chinese, English, Traditional Chinese, French, German, Japanese, Korean, Russian, Italian, Portuguese, Spanish a-c cycle 50Hz、60Hz Auto-Save 3 minutes, 5 minutes, 10 minutes Reset system Confirm, cancel Video format ts Photo format jpg Recording format mp3 software release DV03-WIFI-GC2083-NV3030B-220250915-V2.0. 42 Motherboard model DV03_V521_V01 Master model V521 display screen 1.97 inch image sensor 2080 supply USB 5V / Lithium battery 3.7V electricity Standby current Battery 4.0V standby 14.5uA Low battery Low battery warning and shutdown at 3.71V Power consumption Battery power consumption ≤1.728W, USB 5V power consumption ≤4.465W Note: This product reserves the right to change its design and specifications without prior notice. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this…

Text truncated - open the document above for the full version.

Dongguan Alaike Electronics Co., LTD Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2025/11/21 U.S. Agent Designation Dongguan Alaike Electronics Co., LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BM2F-DV03): Name and company of U.S. agent: GLOCERTS TECHNOLOGY INC Physical U.S. address of agent: 19784 SUNKISSED RIDGE DR RIVERSIDE, CA 92507 United States FRN of U.S. agent: 0036339737 Email address of U.S. agent: [email protected] GLOCERTS TECHNOLOGY INC acknowledges their obligation to accept service of process on behalf of Dongguan Alaike Electronics Co., LTD Dongguan Alaike Electronics Co., LTD with the FRN [0036436400] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature An Wu Manager Dongguan Alaike Electronics Co., LTD Signature Huiying Fan Director GLOCERTS TECHNOLOGY INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

FCC ID: 2BM2F-DV03 External Photos of the EUT FCC ID: 2BM2F-DV03 FCC ID: 2BM2F-DV03

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : 2BM2F-DV03

FCC ID: 2BM2F-DV03 Internal Photos of the EUT FCC ID: 2BM2F-DV03 ANT FCC ID: 2BM2F-DV03 FCC ID: 2BM2F-DV03 FCC ID: 2BM2F-DV03

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : CTA25102301602 2BM2F-DV03 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Oct. 25, 2025 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Dongguan Alaike Electronics Co., LTD Address............................................ : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : SPORTS CAMERA Trade Mark ........................................ N/A Manufacturer .................................... : Dongguan Alaike Electronics Co., LTD Model/Type reference ...................... : DV03 Listed Models ................................... : N/A Ratings ............................................. : Input: 5V1.0A Battery: 3.7V 700mAh 2.59Wh Result ............................................... : PASS Report No.: CTA25102301602 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : SPORTS CAMERA Model /Type : DV03 Listed Models : N/A Applicant : Dongguan Alaike Electronics Co., LTD Address : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Manufacturer : Dongguan Alaike Electronics Co., LTD Address : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25102301602 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 Conducted Power Results ....................................................................................... 7 4.3 Manufacturing tolerance .......................................................................................... 8 4.4 Evaluation Result ..................................................................................................... 8 4.5 Simultaneous Transmission for SAR Exclusion ...................................................... 8 5 Conclusion ........................................................................................................................... 8 Report No.: CTA25102301602 Page 4 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed a…

Text truncated - open the document above for the full version.

深圳市绎芯电子科技有限公司 Shenzhen yixin Electronic Technology Co.,Ltd Page number 1-10 规 格 书 for 客户料号 本公司料号 YX-ALK-DV03手持DV-V1.0 编制：曾小凤审核：温世豪 日期： 2025.10.24 深圳市绎芯电子科技有限公司 深圳市光明区凤凰街道南太云创谷2栋201 邮箱：[email protected] 电话: 17898458992 Add: Room 201, Building 2, Nantai Cloud Innovation Valley, Fenghuang Street, Guangming District, Shenzhen ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number2-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber2-10 目录 规格书 ....................................................................................................................................1 深圳市绎芯电子科技有限公司................................................................................................1 目录 ............................................................................................................................................2 1. 双方确认 .................................................................................................................................3 2. 一般事项 .................................................................................................................................4 3. 产品一般规格 .........................................................................................................................4 4. 产品规格明细 .........................................................................................................................5 4.1 产品结构参数 ......................................................................................................................5 4.2 产品电性能测试数据 .........................................................................................................7 5. 产品包装方式 .......................................................................................................................9 6. 文档履历 .............................................................................................................................11 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number3-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber3-10 1.双方确认 1.1客户确认签字 客户：有限公司 客户部门/职位确认人签字确认日期 硬件/射频 结构 项目经理 商务/采购 审核 1.2 绎芯科技确认签字 部门/职位确认人签字确认日期 天线工程师 结构工程师 项目经理 QA 审核 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number4-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber4-10 2.一般事项 2.1 适用范围 本规格书只适用于 2.2使用温度范围 本产品使用温度范围-20~+65°C 2.3保存温度范围 本产品保存于-30~+75°C 3.产品一般规格 NO.ITEMSDETAILS 1机型 2频段2400-2500MHz 3VSWR≤2.0 4阻抗50Ω 5天线类型单极子 6天线实现形式FPC 7天线图片 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number5-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber5-10 4.产品规格明细 5.4.1产品结构参数 6.4.11产品物料组成： 序号材料规格(MM) 1FPC黑色 2同轴线线总长45mm，φ0.81黑色线材 4.12 外观 产品外观良好，无伤痕、汗迹、突起等严重影响外观缺陷。 4.13 结构尺寸 参考产品图纸: ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number6-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber6-10 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number7-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber7-10 4.2产品电性能测试数据 4.21测试环境及仪器设备 测试环境： 温度：10°C——+30°C 相对湿度：≤80%（+40°C） 大气压力：750mmkg±30mmkg 测试设备： 网络分析仪 KEYSIGHTE5071C 多探头微波暗室 4.22产品电性能测试数据： 产品的S11图： Marker2400MHz2450MHz2500MHz Returnloss1.621.702.26 VSWR-12.38-11.80-8.39 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number8-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber8-10 4.23增益、效率及辐射方向图 频率（MHz）Gain（dBi）Efficiency（%） 24001.6832.45 24501.6632.85 25001.6933.80 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number9-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber9-10 辐射方向图频率点 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number10-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber10-10 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number11-8 深圳市绎芯电子科技有限公司 ShenzhenyixinElectronicTechnologyCo.,Ltd Pagenumber11-10 5.产品包装方式 包装方式： 自封袋包装，每包200PCS。 6.文档履历 文件编号 DocumentNo. 日期 ReleaseDate 2025/10/24 编制 Author Hungjie 复核 Review WH 文件历次表 RevisedHistory DateVersionRevisedRecord 2025/101.00NewProject

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA25102301601 2BM2F-DV03 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Oct. 25, 2025 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Dongguan Alaike Electronics Co., LTD Address ............................................ : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : SPORTS CAMERA Trade Mark ....................................... : N/A Manufacturer .................................... : Dongguan Alaike Electronics Co., LTD Model/Type reference ...................... : DV03 Listed Models ................................... : N/A Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Ratings ............................................. : Input: 5V1.0A Battery: 3.7V 700mAh 2.59Wh Result ............................................... : PASS Report No.: CTA25102301601 Page 2 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : SPORTS CAMERA Model /Type : DV03 Listed Models : N/A Applicant : Dongguan Alaike Electronics Co., LTD Address : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Manufacturer : Dongguan Alaike Electronics Co., LTD Address : Room 701, Building 1, No.56 Zifeng Street, Dalingshan Town, Dongguan City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA25102301601 Page 3 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 5 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility........................................................................................................................................ 7 3.3 Environmental conditions ..................................................................................................…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for 2.4GWIFI FCC ID : 2BM2F-DV03 Company : Dongguan Alaike Electronics Co., LTD EUT : SPORTS CAMERA Model Number : DV03 Report No. : CTA25102301601 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 9.200 2407.440 2416.640 0.5 PASS 2437 9.480 2432.120 2441.600 0.5 PASS 2462 8.840 2457.480 2466.320 0.5 PASS 11G Ant1 2412 16.320 2403.880 2420.200 0.5 PASS 2437 16.360 2428.880 2445.240 0.5 PASS 2462 16.360 2453.840 2470.200 0.5 PASS 11N20SISO Ant1 2412 17.320 2403.400 2420.720 0.5 PASS 2437 17.200 2428.480 2445.680 0.5 PASS 2462 17.160 2453.440 2470.600 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 7 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.935 2405.5684 2418.5034 --- --- 2437 12.918 2430.5710 2443.4890 --- --- 2462 12.955 2455.5386 2468.4936 --- --- 11G Ant1 2412 16.538 2403.7706 2420.3086 --- --- 2437 16.638 2428.7002 2445.3382 --- --- 2462 16.604 2453.7026 2470.3066 --- --- 11N20SISO Ant1 2412 17.433 2403.3343 2420.7673 --- --- 2437 17.464 2428.3031 2445.7671 --- --- 2462 17.439 2453.3145 2470.7535 --- --- 8 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 9 11G_Ant1_2412 11G_Ant1_2437 10 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11 11N20SISO_Ant1_2462 12 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 7.21 ≤30.00 PASS 2437 7.91 ≤30.00 PASS 2462 7.69 ≤30.00 PASS 11G Ant1 2412 5.88 ≤30.00 PASS 2437 6.48 ≤30.00 PASS 2462 6.63 ≤30.00 PASS 11N20SISO Ant1 2412 6.26 ≤30.00 PASS 2437 6.74 ≤30.00 PASS 2462 6.89 ≤30.00 PASS 13 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -21.63 ≤8.00 PASS 2437 -21.75 ≤8.00 PASS 2462 -21.03 ≤8.00 PASS 11G Ant1 2412 -28.52 ≤8.00 PASS 2437 -28.17 ≤8.00 PASS 2462 -27.78 ≤8.00 PASS 11N20SISO Ant1 2412 -28.09 ≤8.00 PASS 2437 -27.65 ≤8.00 PASS 2462 -27.43 ≤8.00 PASS 14 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 15 11G_Ant1_2412 11G_Ant1_2437 16 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 17 11N20SISO_Ant1_2462 18 Appendix E: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 -6.90 -54.75 ≤-26.9 PASS High 2462 -6.84 -57.67 ≤-26.84 PASS 11G Ant1 Low 2412 -14.88 -51.03 ≤-34.88 PASS High 2462 -14.00 -55.89 ≤-34 PASS 11N20SISO Ant1 Low 2412 -14.66 -52.4 ≤-34.66 PASS High 2462 -13.57 -56.83 ≤-33.57 PASS 19 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 20 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 21 11N20SISO_Ant1_High_2462 22 Appendix F: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference -7.09 -7.09 --- PASS 30~1000 -7.09 -61.76 ≤-27.09 PASS 1000~26500 -7.09 -45.48 ≤-27.09 PASS 2437 Reference -5.99 -5.99 --- PASS 30~1000 -5.99 -60.16 ≤-25.99 PASS 1000~26500 -5.99 -46.15 ≤-25.99 PASS 2462 Reference -7.42 -7.42 --- PASS 30~1000 -7.42 -61.57 ≤-27.42 PASS 1000~26500 -7.42 -46.44 ≤-27.42 PASS 11G Ant1 2412 Reference -15.16 -15.16 --- PASS 30~1000 -15.16 -64.08 ≤-35.16 PASS 1000~26500 -15.16 -45.37 ≤-35.16 PASS 2437 Reference -14.67 -14.67 --- PASS 30~1000 -14.67 -63.93 ≤-34.67 PASS 1000~26500 -14.67 -45.99 ≤-34.67 PASS 2462 Reference -13.69 -13.69 --- PASS 30~1000 -13.69 -64.11 ≤-33.69 PASS 1000~26500 -13.69 -46.49 ≤-33.69 PASS 11N20SISO Ant1 2412 Reference -15.23 -15.23 --- PASS 30~1000 -15.23 -65.44 ≤-35.23 PASS 1000~26500 -15.23 -45.27 ≤-35.23 PASS 2437 Reference -14.73 -14.73 --- PASS 30~1000 -14.73 -63.72 ≤-34.73 PASS 1000~26500 -14.73 -45.93 ≤-34.73 PASS 2462 Reference -14.79 -14.79 --- PASS 30~1000 -14.79 -64.42 ≤-34.79 PASS 1000~26500 -14.79 -46.07 ≤-34.79 PASS 23 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 24 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 25 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 26 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 27 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 28 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 29 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 30 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000

31 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 32 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 33 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 34 Appendix G: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11G Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 11N20SISO Ant1 2412 20.00 20.00 100.00 2437 20.00 20.00 100.00 2462 20.00 20.00 100.00 35 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 36 11G_Ant1_2412 11G_Ant1_2437 37 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 38 11N20SISO_Ant1_2462

FCC ID: 2BM2F-DV03 Test Setup Photos of the EUT FCC ID: 2BM2F-DV03
