2BOMA-FP1247Fixed luminaires

Good Earth Lighting,Inc.
Fixed luminaires - FCC ID 2BOMA-FP1247 - Good Earth Lighting,Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 31, 2025
Application Purpose
Original Equipment
Equipment Note
Fixed luminaires
Frequency Range
2402.00000000 - 2480.00000000
Company
Good Earth Lighting,Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model / Model / Modelo #: FP1247-AL5-24LFW-G Required/ Nécessaire/ Obligatorio Hardware kit* / Trousse de quincaillerie* / Kit de aditamentos* DDx3CCx4AAx2BBx4EEx4FFx2 1/8 in. 3 mm LED Flat Panel Panneau plat à DEL Panel de luces LED plano Mounting plate Plaque de montage Placa de montaje * Actual hardware may differ from illustration * La quincaillerie incluse peut être différente de l’illustration. * Los aditamentos reales pueden diferir de los que se muestran en la ilustración. Support wire hooks Crochets des fils de support Ganchos de alambre de soporte SAVE AND ATTACH RECEIPT HERE 2 ft. x 2 ft. SMART LED Flat Panel (Page 1) Panneau plat à DEL de 0,6 m x 0,6 m (Page 2) Panel plano de luces LED de 0,6 m x 0,6 m (Página 4) WARNINGS AND CAUTIONS WARNING: SHUT OFF POWER AT THE CIRCUIT BREAKER OR FUSE PANEL BEFORE REMOVING THE OLD FIXTURE OR INSTALLING A NEW ONE. SHUT OFF POWER AT THE CIRCUIT BREAKER OR FUSE PANEL BEFORE REMOVING THE OLD FIXTURE OR INSTALLING A NEW ONE. Read entire installation procedure before you begin and save instructions for future reference. HIS FIXTURE IS DIMMABLE BY SPECIFIC FORWARD PHASE ELECTRONIC (TRIAC) DIMMERS. Dimmers tested to be compatible with this fixture are the Lutron: Skylark® SCL-153P*, Diva® DVCL-153P*, Maestro® MACL-153M*, Toggler® TGCL-153P*, Lumea® LECL-153P*, Caseta® PD-6WCL*, Eaton Halo® SAL06P*. (This list of dimmers does not imply any guarantee or warranty of compatibility with a particular application. Dimmers not listed do not imply non-compatibility.) If unsure if the electrical box is properly grounded, or the box is plastic and has no ground wire, or are unfamiliar with the methods of properly grounding fixture, consult a qualified electrician. IMPORTANT SAFETY INFORMATION 1. Do not look directly at LEDs for extended period of time. 2. For INDOOR use only. 3. Turn power off before servicing. 4. Do not leave bare wires exposed. 5. For electrical requirements, see fixture. Minimum 90°C supply conductors. INSTALLATION 1 2 Remove mounting plate from LED panel by sliding into the direction of the slots closest to the mounting screws (AA), and then lifting up. Hold the mounting plate up to the junction box in the desired fixture mounting orientation. Pull black, white and ground supply wires from electrical box through the hole in center of mounting plate. Ground wires can be either green/yellow or bare copper. Attach mounting plate to the electrical box using mounting screws (AA) provided. Open the Latch on one side of the frame. TURN POWER OFF AT BREAKER BOX/FUSE BOX. TURN WALL SWITCH TO JUNCTION BOX OFF 3A 3B WOOD: Locate the open holes for mounting at the corners of the mounting plate and drill 1/8 in. pilot hole in the center. If a wooden stud is encountered, use the wood screws (BB) and washers (EE) provided to secure the mounting plate directly to stud. DRYWALL: Using a 18 in. drill bit, drill a pilot hole at each mark for both sides of the mounting bracket. If no stud is encountered, use a 3/8 in. drill bit and drill a hole for the ceiling anchors (CC). Pinch the ceiling anchor (CC) sides together and insert it into the hole. Push or tap the ceiling anchor (CC) into place until the underside is against the ceiling. Align the mounting bracket with the anchors and drive wood screws (BB) and washers (EE) into place. 1 2 AAx2 3/8 in. 9.5 mm It may be necessary to carefully tap the end of the drywall anchor to get it fully into place. BBx4 CCx4 DRYWALLWOOD 3A3B EEx4 BBx4 EEx4 1/8 in. 3 mm Wood installation shown** DDx3 4 5 Hold fixture up to secured mounting plate and attach the two support wire hooks from the backside and the one from the front side of fixture to the specially designed slots in the mounting plate to temporarily hold fixture for wiring. Fixture must be properly grounded. Connect fixture ground wire to ground wire in electrical box using a wire nut (DD). Ground wires can be either green/yellow or bare copper. Connect black supply lead to black fixture wire and white supply lead to white fixture wire using wire nuts (DD). Secure the wire nuts properly to prevent the wires from coming loose. Use cable ties (FF) to secure loose fixture wires to one another in the center of the mounting plate to keep them from getting in the way during fixture mounting. Push excess wire back into the electrical box. 4 5 6A 6B 6A 6B Keeping the support wire hooks attached to the mounting plate, lift up the LED panel, being careful not to scratch ceiling. Align and insert the 2 metal tabs (on the same side of the mounting plate as the support wires) into the corresponding slots on the LED panel. While keeping the first 2 metal tabs inserted, pivot the panel up and insert the 2 remaining tabs on the opposite side. Slide panel until tabs are locked into place. Note that the direction will be either left or right, depending on panel orientation. Lock the tab into place using the latch. Slowly release fixture, making sure it stays in place. 7 6C FCC STATEMENT: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipm…

Text truncated - open the document above for the full version.

External Photos

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 4 Appendix - External Photos for GZCR2509001502LM Test Model No.: FP1247-BLK-48LFW-G SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 4 - End of the Appendix -

ID Label/Location Info

2025-12-12 615-00-02729 镭射 镭射 B 李朝坚 刘耀臻 熊高俊 1225-50 Suitable for operation in ambient not exceeding 40 °C Convient pour un fonctionnement dans une ambiance n’excédant pas 40 °C Apto para funcionamiento en un ambiente que no exceda de 40 °C FP1247-AL5- 24LFW-G WIFI VERSION FCC ID: 2BOMA-FP1247

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 4 Appendix - Internal Photos for GZCR2509001502LM Test Model No.: FP1247-BLK-48LFW-G SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 4 BT/Wi-Fi ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 4 - End of the Appendix -

RF Exposure Info

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 1 of 9 FCC ID: 2BOMA-FP1247 RF EXPOSURE EVALUATION REPORT Application No.: GZCR2509001502LM Applicant:Good Earth Lighting, Inc. Address of Applicant:2100 Golf Road, Suite 460, Rolling Meadows, IL 60008, USA Manufacturer:MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Manufacturer:(58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Factory:MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Factory:(58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Product Name:Fixed luminaires Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : KDB 447498 D01 V06 47 CFR Part 1.1310 Date of Receipt: 2025-09-23 Date of Evaluation: 2025-11-07 Date of Issue: 2025-11-07 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2509001502042025-11-07Original Authorized for issue by: Allen Zhou/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB 447498 D01 V06 KDB 447498 D01 V0647 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on the appearance of color and packaging. Therefore, only one model FP1247-BLK-48LFW-G was evaluated in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:AC 120V,60Hz Cable(s):AC mains cable:2 wires 1.0m unshielded RF Parameter: Please refer to test report GZCR250900150202 for BLE details Please refer to test report GZCR250900150203 for 2.4GHz Wi-Fi details Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 2.0 Report No.: GZCR250900150204 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of …

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150202 Page: 1 of 60 FCC ID: 2BOMA-FP1247 TEST REPORT Application No.: GZCR2509001502LM Applicant: Good Earth Lighting, Inc. Address of Applicant: 2100 Golf Road, Suite 460, Rolling Meadows, IL 60008, USA Manufacturer: MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Manufacturer: (58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Factory: MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Factory: (58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Product Name: Fixed luminaires Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2025-09-23 Date of Test: 2025-10-31 to 2025-11-07 Date of Issue: 2025-11-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150202 Page: 2 of 60 Revision Record Version Report No. Date Remark 01 GZCR250900150202 2025-11-07 Original Authorized for issue by: Allen Zhou/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150202 Page: 3 of 60 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2020) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2020) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. N/A: Not applicable. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on the appearance of color and packaging. Therefore, only one model FP1247-BLK-48LFW-G was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150202 Page: 4 of 60 3 Contents Page 1 Cover Page ................................................................................................................................................. 1 2 Test Summary ............................................................................................................................................ 3 3 Contents ..................................................................................................................................................... 4 4 General Information ................................................................................................................................... 6 4.1 Details of E.U.T. .................................................................................................................................. 6 4.2 Description of Support Units ............................................................................................................... 6 4.3 Measurement Uncertainty ................................................................................................................... 7 4.4 Test Location ....................................................................................................................................... 7 4.5 Test Facility ......................................................................................................................................... 8 4.6 Deviation from Standards .................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ............................................................................................ 8 5 Equipment List ........................................................................................................................................... 9 6 Radio Spectrum Technical Requirement .............................................................................................. 11 6.1 Antenna Requirement ....................................................................................................................... 11 6.1.1 Test Requirement: ........................................................................................................................ 11 6.1.2 Conclusion ...........................................................................................................…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 1 of 85 FCC ID: 2BOMA-FP1247 TEST REPORT Application No.: GZCR2509001502LM Applicant: Good Earth Lighting, Inc. Address of Applicant: 2100 Golf Road, Suite 460, Rolling Meadows, IL 60008, USA Manufacturer: MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Manufacturer: (58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Factory: MEKO INTELLIGENT (CAMBODIA) CO., LTD. Address of Factory: (58km, National 3th Highway), VEAS POU VILLAGE KHVAV COMMUNE, SAMRONG DISTRICT, TAKEO PROVINCE, KINGDOM OF CAMBODIA Product Name: Fixed luminaires Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2025-09-23 Date of Test: 2025-10-31 to 2025-11-07 Date of Issue: 2025-11-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 2 of 85 Revision Record Version Report No. Date Remark 01 GZCR250900150203 2025-11-07 Original Authorized for issue by: Allen Zhou/Project Engineer Approved By Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 3 of 85 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2020) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2020) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. N/A: Not applicable. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: FP1247-BLK-48LFW-G, FP1247-AL5-24LFW-G According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on the appearance of color and packaging. Therefore, only one model FP1247-BLK-48LFW-G was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 4 of 85 3 Contents Page 1 Cover Page ................................................................................................................................................. 1 2 Test Summary ............................................................................................................................................ 3 3 Contents ..................................................................................................................................................... 4 4 General Information ................................................................................................................................... 6 4.1 Details of E.U.T. .................................................................................................................................. 6 4.2 Description of Support Units ............................................................................................................... 6 4.3 Measurement Uncertainty ................................................................................................................... 7 4.4 Test Location ....................................................................................................................................... 7 4.5 Test Facility ......................................................................................................................................... 8 4.6 Deviation from Standards .................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ............................................................................................ 8 5 Equipment List ........................................................................................................................................... 9 6 Radio Spectrum Technical Requirement .............................................................................................. 11 6.1 Antenna Requirement ....................................................................................................................... 11 6.1.1 Test Requirement: ........................................................................................................................ 11 6.1.2 Conclusion ...........................................................................................................…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 84 of 85 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 2.0 Report No.: GZCR250900150203 Page: 85 of 85 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV - End of the Report -

Test Report

LY22-008 REV1.0 客户名称 Customer Name: 品名规格Product Name:2.4G WiFi Antenna L=37mm 零件编号Part No.: LYA10137A 样品数量 Quantity: 0 Pcs 送样日期 Approve Date: 2025-12-12 版本 Version: V0 工程确认: 核准 工程 制作 签章 Approval Quality Engineer 客户确认: 核准 研发 品质 签章 确认结果: □ 合格 □ 不合格 □ 其它 No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 本测试报告属于东莞市蓝一通讯科技有限公司和相关客户文件,请妥善保管,在没有我们公 司允许的情况下,任何人都不能重新向公众公布的权利。 This test report belongs to DongguanLanyi CommunicationTechnology Co.,Ltd. and related customer documents. Please keep it properly. Without the permission of our company and related customers, no one has the right to re disclose it to the public. 1.0 实物图(Physical drawing) 2.0 Electrical Properties 1.1 中心频率(Center Frequency)..................... 2.4-2.5GHz 1.2 馈电阻抗(impedance)................................. 50ohm 1.3 电压驻波比(VSWR).................................... <2.0:1MAX 1.4 回波损耗(Return Loss)........................... -10dB Max 1.5 最大增益(Peak Gain)................................. 2.4-2.5GHz ≤2dBi Peak Gain 1.6 极化(Polarization) ................................. Linear 1.7 天线接口(Interface)................................. IPEX 1.8 天线尺寸(Size)........................ Ø 1.13mm×37mm Mechanical Specification: 2.0 工作温度(Operation Temperature)........................... -40°C- +80°C No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 3.0测试设备(Test equipment) 我司产品的测试环境为 SATIMO SG24 3D 暗室, 所用设备为安捷伦 E5071C 网络分析仪和 8960 综测仪。 No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 4.0图纸 Mechanical Drawing (Unit: mm) No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 5.0 Return Loss, SWR No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 6.0 Efficiency&Gain 7.0 2D R adiation Pattern No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City LY22-008 REV1.0 No. 33, Zhenxing Road, Yangkengtang, Dalang Town, Dongguan City

Test Setup Photos

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 1 of 4 Appendix - Test Setup Photos for GZCR250900150202 & GZCR250900150203 Test Model No.: FP1247-BLK-48LFW-G SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 2 of 4 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Emissions which fall in the restricted bands & Radiated Spurious Emissions Above 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 3 of 4 Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 4 of 4 - End of the Appendix -

Contact Information

Applicant

Luke Toppel
[email protected]Fax: 847-808-1133

Technical Contact

Good Earth Lighting,Inc.Luke Toppel
[email protected]Fax: 847-808-1133

2100 Golf Road, Suite 460, · Rolling Meadows, Illinois, 60008 · United States

Test Firm

SGS-CSTC Standards Technical Services Co., Ltd.Bonnie Liao
[email protected]

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz1.40 mW
215C2.41 GHz - 2.46 GHz28.60 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is conducted. Device is an 802.11b/g/n device and enabled for 2.4GHz band as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz bandwidth modes.
