2BPQQ-R405LQCOREXOM

Module Approval Request Letter Date: 2026/2/24 Subject: Module Approval FCC ID: 2BPQQ-R405LQ To Whom It May Concern: We, Sporton International Inc. Hsinchu Laboratory, are authorized by Coretronic Reality Inc. to have their state-of-the-art device approved under module approval authorization. The application of this module is specified to mobile host equipment. The requirements regulated in CFR47 Part 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip QCS 405. 3. The requirement of power supply regulation: The part number of the power regulator is QCS 405. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Company name : Sporton International Inc. Hsinchu Laboratory Company Address : No.8, Ln. 724, Bo’ai St., Zhubei City, Hsinchu County 302010, Taiwan (R.O.C.) Signature : Name : Leo Huang Job Title : Manager

Label and location On the surface of the EUT Label

RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 2 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 EUT General Information ....................................................................................................................... 5 1.2 Antenna Information ............................................................................................................................... 6 1.3 Table for Multiple Listing ........................................................................................................................ 8 1.4 Accessories ............................................................................................................................................ 8 1.5 Testing Location ..................................................................................................................................... 8 2 Maximum Permissible Exposure ........................................................................................................ 9 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 9 2.2 MPE Calculation Method ........................................................................................................................ 9 2.3 Calculated Result and Limit .................................................................................................................. 10 Photographs of EUT v01 RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 3 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 History of this test report Report No. Version Description Issued Date FA372511-04 01 Initial issue of report Feb. 23, 2026 RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 4 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Wendy Pan RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 5 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 2.4GHz WLAN 2400-2483.5 2412-2462 802.11b: DSSS (DBPSK, DQPSK, CCK) 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) VHT: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) 5GHz WLAN 5150-5250 5725-5850 5180-5240 5745-5825 802.11a/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 6 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1.2 Antenna Information Ant. Set Port Brand Model Name Antenna Type Connector Gain (dBi) 1 1 ALFA ARS-NT5B Dipole Antenna I-PEX Note 1 2 ALFA ARS-NT5B 3 ALFA ARS-NT5B 4 ALFA ARS-NT5B 2 1 SmartAnt CIR22-440330 Dipole Antenna I-PEX 2.0 2 SmartAnt CIR22-440330 2.0 3 SmartAnt CIR22-440330 2.0 4 SmartAnt CIR22-440330 2.0 Note 1: Ant. Set Port Antenna Gain (dBi) Cable Loss (dB) Net Gain (dBi) WLAN 2.4GHz WLAN 5GHz WLAN 2.4GHz WLAN 5GHz WLAN 2.4GHz WLAN 5GHz 1 1 5.0 5.0 1.3 2.4 3.7 2.6 2 5.0 5.0 1.3 2.4 3.7 2.6 3 5.0 5.0 1.3 2.4 3.7 2.6 4 5.0 5.0 1.3 2.4 3.7 2.6 Note 2: The above information was declared by manufacturer. Only the highest gain antenna was selected to test. Thus antenna set 1 were selected to perform the test and recorded in this report. For 2.4GHz function: IEEE 802.11b/g/n/VHT/ax (4TX/4RX): Port 1, Port 2, Port 3 and Port 4 can be used as transmitting/receiving antenna. Port 1, Port 2, Port 3 and Port 4 could transmit/receive simultaneously. For 5GHz function: IEEE 802.11a/n/ac/ax (4TX/4RX): Port 1, Port 2, Port 3 and Port 4 can be used as transmitting/receiving antenna. Port 1, Port 2, Port 3 and Port 4 could transmit/receive simultaneously. RADIO EXPOSURE TEST REPORT Report No. : FA372511-04 TEL : 886-3-656-9065 Page Number : 7 of 10 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Note 3: Directional gain information Type Maximum Output Power Power Spectral Density Non-BF Directional gain = Max.gain + array gain. For power measurements on IEEE 802.11 devices Array Gain = 0 dB (i.e., no array gain) for N ANT ≤ 4 …

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR372511-04AB TEL : 886-3-656-9065 Page Number : 2 of 34 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 9 1.3 Testing Location Information .................................................................................................................. 9 1.4 Measurement Uncertainty .................................................................................................................... 10 2 Test Configuration of EUT ................................................................................................................. 11 2.1 Test Channel Mode .............................................................................................................................. 11 2.2 The Worst Case Measurement Configuration ...................................................................................... 12 2.3 EUT Operation during Test .................................................................................................................. 14 2.4 Accessories .......................................................................................................................................... 14 2.5 Support Equipment ............................................................................................................................... 14 2.6 Test Setup Diagram ............................................................................................................................. 15 3 Transmitter Test Result ..................................................................................................................... 17 3.1 AC Power-line Conducted Emissions .................................................................................................. 17 3.2 Emission Bandwidth ............................................................................................................................. 19 3.3 Maximum Output Power ....................................................................................................................... 20 3.4 Power Spectral Density ........................................................................................................................ 23 3.5 Unwanted Emissions ............................................................................................................................ 26 4 Test Equipment and Calibration Data .............................................................................................. 31 Appendix A. Test Results of AC Power-l ine Conducted Emissions Appendix B. Test Results of Emission Bandwidth Appendix C. Test Results of Maximum Output Power Appendix D. Test Results of Power Spectral Density Appendix E. Test Results of Unwanted Emissions Appendix F. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR372511-04AB TEL : 886-3-656-9065 Page Number : 3 of 34 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 History of this test report Report No. Version Description Issued Date FR372511-04AB 01 Initial issue of report Feb. 23, 2026 RADIO TEST REPORT Report No. : FR372511-04AB TEL : 886-3-656-9065 Page Number : 4 of 34 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PA SS - 3.1 15.207 AC Power-line Conducted Emissions PA SS - 3.2 15.407(a) Emission Bandwidth PA SS - 3.3 15.407(a) Maximum Output Power PA SS - 3.4 15.407(a) Power Spectral Density PA SS - 3.5 15.407(b) Unwanted Emissions PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Wendy Pan RADIO TEST REPORT Report No. : FR372511-04AB TEL : 886-3-656-9065 Page Number : 5 of 34 FAX : 886-3-656-9085 Issued Date : Feb. 23, 2026 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Frequency (MHz) Channel Number 5150-5250 a, n (HT20), ac (VHT20), ax (HEW20) 5180-5240 36-48 [4] 5725-5850 5745-5825 149-165 [5] 5150-5250 n (HT40), ac (VHT40), ax (HEW40) 5190-5230 38-46 [2] 5725-5850 5755-5795 151-159 [2] Band Mode BWch (MHz) Nant 5.15-5.25GHz 802.11a 20 4TX 5.15-5.25GHz 802.11n HT20 20 4TX 5.15-5.25GHz 802.11ac VHT20 20 4TX 5.15-5.25GHz 802.11ax HEW20 20 4TX 5.15-5.25GHz 802.11n HT40 40 4TX 5.15-5.25GHz 802.11ac VHT40 40 4TX 5…

Text truncated - open the document above for the full version.

3F, No. 58, Park Avenue 2nd Rd., Science-based Industrial Park, Hsinchu 30075, Taiwan, R.O.C. Antenna Type : Dipole

Alfa Network Inc., http://www.alfa.com.tw contact: [email protected] Copyright @2014 Alfa Networks Inc. All Rights Reserved Changes to specifications and descriptions may change at any time without prior notice ARS-NT5B 2.4GHz + 5GHz Dual-Band 5dBi Dipole Antenna - RSMA Specification Frequency 2400 ~ 2500MHz 5150 ~ 5850MHz S.W.R ≦ 2.0 Antenna Gain 5dBi @ 2400~2500MHz 5dBi @ 5150~5850MHz Efficiency >81% @ 2400 ~ 2500MHz >73% @ 5150~5850MHz Polarization Linear Impedance 50 Ohm Connector RP-SMA male Environmental Operation Temperature: -40°C ~ +65°C Storage Temperature: -40°C ~ +80°C 4F.-1, No.106, Ruiguang Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Alfa Network Inc., http://www.alfa.com.tw contact: [email protected] Copyright @2014 Alfa Networks Inc. All Rights Reserved Changes to specifications and descriptions may change at any time without prior notice ARS-NT5B Alfa Network Inc., http://www.alfa.com.tw contact: [email protected] Copyright @2014 Alfa Networks Inc. All Rights Reserved Changes to specifications and descriptions may change at any time without prior notice ARS-NT5B
