2BQLG-CM-CRCWireless winch remote control system for vehicle

第 1 页 共 2 页 Electric winch wireless controller instructions A, Features Overview This wireless remote control firing frequency of 315MHz, the control range of more than 25 m, used in electric winch wireless control. B, The wireless remote control parameters 1, Working voltage: DC3V, 2 pcs CR2032 battery. 2, The working current: 25mA ± 5mA 3, Transmitting frequency: 315MHz 4, The transmit power: <10dBm 5, Standby current: <5uA C, Using The remote controller have 1 key button and a switch. Press and hold the key button more than 3 seconds, the remote powered on, while the LED indicator lights. Then press and hold on the switch to "OUT" or "IN" side, it will trigger 315 MHz high frequency ASK modulation unit to transmit the address code and key value. The high-frequency signal emitted by the antenna. When the remote control has been powered on, press and hold the key button more than 3 seconds, the remote control is turned off, while LED is off. If there is no key operation within 50 seconds, it will automatically shut down. D, Installation and function 1,Disconnect Power to the winch 2,Confirm that the plug is the correct type for this winch and plug it in 3.Select an area for the receiver on the vehicle close enough to the winch to allow cable connection 4.Investigate the chosen area to make sure no components will be damaged by installation. 5.Permanently (optional) mount the remote control receiver to the vehicle using appropriat e ha rdware (not included). 6.Preare the winch for operation as explained in its manual 7.Reconnect winch’s power 第 2 页 共 2 页 8.Release the clutch handle and pull out about 10 feet of wire rope Leave the wire rope laying on the ground and stay clear of the wire rope and hook 9.Reengage the clutch handle 10.Watch the spool and wire rope and briefly, press the out button on the remote control to verify that the cable feeds out WARNING! If the cable does not feed out ,check and correct the winch’s wiring. Retest after correction. 11.Watch the spool and wire rope and briefly press the in button on the remote control to verify that the cable retracts WARNING! If the cable does not feed out ,check and correct the winch’s wiring .Retest BOTH functions after correction. 12.If the remote operates the winch properly, it is ready for use. 13.After use, disconnect control box from winch to prevent accidental operation E, Wiring diagram F,WARNING! To prevent serious injury 1. Disconnect control box from winch before service and after every use. WINCH CAN OPERATE SUDDENLY AT ANY TIME WHILE CONNECTED. 2. Stand clear of winch, fairlead, and wire rope while connected. Keep bystanders away. 3. Only operate controls when winch and entire wire rope is within view. 4. Use with vehicle mounted recovery winches only. Do not use for any other application. 5. Confirm control box mounting location has no wire or components that can be damaged drilling. 6. Read winch manual before use. FCC Statement Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ·Reorient or relocate the receiving antenna. ·Increase the separation between the equipment and receiver. ·Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ·Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. The device has been evaluated to meet general RF exposure requirement. The device can be used in an uncontrolled environment without restriction. 手动阀是方法暗室

ReportNo.:AB25060072FW Page1of3 AppendixBExternalPhotos ReportNo.:AB25060072FW Page2of3 ReportNo.:AB25060072FW Page3of3

Annex of Test Report Annex J. Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location FCC ID:2BQLG-CM-CRC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ReportNo.:AB25060072FW Page 1 of 5 AppendixCEUTInternalPhotos IntegralAntenna ReportNo.:AB25060072FW Page 2 of 5 ReportNo.:AB25060072FW Page 3 of 5 ReportNo.:AB25060072FW Page 4 of 5 ReportNo.:AB25060072FW Page 5 of 5

AiboStandardTechnology(Shenzhen)Co.,Ltd. 101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark,TianliaoCommunity,YutangStreet,Guangming District,ShenzhenCity,GuangdongProvince,China Tel.:+(86)075585250797E-mail:[email protected]:www.Aibonorm.com FCCTESTREPORT ReportNo. ............................................. : AB25060072FW01 FCCID...................................................: 2BQLG-CM-CRC Applicant................................................: ChimaWinch(Thailand)Co.,Ltd Address ................................................. : No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Manufacturer......................................: ChimaWinch(Thailand)Co.,Ltd Address..............................................: No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province ProductName ...................................... : Wirelesswinchremotecontrolsystemforvehicle TradeMark............................................: / TestModel.............................................: CM-CRC(TX) AdditionalModel(s) .............................. : SKU#56504 Standard................................................: FCC47CFR§1.1310 FCC47CFR § 2.1093 KDB447498D01GeneralRFExposureGuidancev06 DateofReceipt....................................:2025.07.03 DateofIssue ........................................ :2025.08.14 TestResult............................................:Pass Compiledby: (PrintedName+Signature) HuaijieLi Supervisedby: (PrintedName+Signature) JayLiu Approvedby: (PrintedName+Signature) MicCheng TestingLaboratoryName ................... :AiboStandardTechnology(Shenzhen)Co.,Ltd. Address.................................................:101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark, TianliaoCommunity,YutangStreet,GuangmingDistrict,Shenzhen City,GuangdongProvince,China Thistestreportmaybeduplicatedcompletelyforlegalusewiththeapprovaloftheapplicant.Itshouldnotbe reproducedexceptinfull,withoutthewrittenapprovalofourlaboratory.Theclientshouldnotuseittoclaim productendorsementbyAibo.Thetestresultsinthereportonlyapplytothetestedsample.Thetestreport shallbeinvalidwithoutallthesignaturesoftestingengineers,reviewerandapprover.Anyobjectionsmustbe raisedtoAibowithin15dayssincethedatewhenthereportisreceived.Itwillnotbetakenintoconsideration beyondthislimit.Thetestreportmerelycorrespondtothetestsample. ReportNo.:AB25060072FW02 FCCTESTREPORT TestResultPositive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:AB25060072FW02 2025.08.14 Dateofissue EUT......................................... : Wirelesswinchremotecontrolsystemforvehicle TestModel.............................. : CM-CRC(TX) Applicant...............................:ChimaWinch(Thailand)Co.,Ltd Address...................................:No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Telephone...............................:/ Fax..........................................:/ Manufacturer......................... : ChimaWinch(Thailand)Co.,Ltd Address...................................:No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Telephone...............................:/ Fax..........................................:/ ReportNo.:AB25060072FW02 REPORTVERSION VersionNo.IssueDateDescription 012025.08.14InitialIssue ReportNo.:AB25060072FW02 TABLEOFCONTENTS 1.GENERALINFORMATION...................................................................................................................................5 1.1.GENERALDESCRIPTIONOFEUT..................................................................................................................5 1.2.DESCRIPTIONOFSUPPORTEQUIPMENT...................................................................................................6 1.3.DESCRIPTIONOFEXTERNALI/O...................................................................................................................6 1.4.GENERALDESCRIPTIONOFAPPLIEDSTANDARDS...............................................................................7 1.5.DESCRIPTIONOFTESTFACILITY.................................................................................................................7 2.RFEXPOSUREEVALUATION............................................................................................................................8 2.1LIMIT..........................................................................................................................................................................8 2.2EVALUATIONRESULT...............................................................................................................................................9 2.3CONCLUSION............................................................................................................................................................9 ReportNo.:AB25060072FW02 1.GENERALINFORMATION 1.1.GENERALDESCRIPTIONOFEUT ProductName:Wirelesswinchremotecontrolsystemforvehicle TradeMark:/ TestModel:CM-CRC(TX) AdditionalModel(s):SKU#56504 ModelDifference:AllmodelsarethesamecircuitandRFmodule,exceptthemodelname. HardwareVersion: / SoftwareVersion: / PowerSupply:DC3.0VFromBattery TestSample(s)Number:AB25060072-01(EngineerSample) RadioSpecificationSubjecttothisReport OperatingFrequency:315MHz ModulationType:ASK ChannelNumber(s):1 AntennaType: IntegralAntenna AntennaGain:0dBi ReportNo.:AB25060072FW02 1.2.DESCRIPTIONOFSUPPORTEQUIPMENT DescriptionManufacturerModelSerialNumberSuppliedby \\\\\ 1.3.DESCRIPTIONOFEXTERNALI/O I/OPortDescriptionQuantityCable \\\ \1\ ReportNo.:AB25060072FW02 1.4.GENERALDESCRIPTIONOFAPPLIEDSTANDARDS Thetestswereperformedaccordingtofollowingstandards: FCCCFR47part11.1310-Radiofrequencyradiationexposurelimits. FCCCFR47part22.1093-Radiofrequencyradiationexposureevaluation:portabledevices FCCKDB447498D01GeneralRFExposureGuidancev06-MobileandPortableDevice…

Text truncated - open the document above for the full version.

FCCID:2BQLG-CM-CRCReportNo.:AB25060072FW01 AiboStandardTechnology(Shenzhen)Co.,Ltd. 101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark,TianliaoCommunity,YutangStreet, GuangmingDistrict,ShenzhenCity,GuangdongProvince,China Tel.:+8675585250797E-mail:[email protected]:www.aibonorm.com FCCTESTREPORT ReportNo..............................................:AB25060072FW01 FCCID ................................................... :2BQLG-CM-CRC Applicant ................................................ :ChimaWinch(Thailand)Co.,Ltd Address ................................................. :No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Manufacturer......................................:ChimaWinch(Thailand)Co.,Ltd Address..............................................:No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province ProductName.......................................:Wirelesswinchremotecontrolsystemforvehicle TradeMark............................................:/ TestModel.............................................:CM-CRC(TX) AdditionalModel(s) .............................. :SKU#56504 Standard ................................................ :FCC47CFRPart15SubpartC(Part15.231) DateofReceipt .................................... :2025.07.03 DateofTestDate.................................:2025.07.03-2025.07.15 DateofIssue........................................:2025.07.15 TestResult ............................................ :Pass Compiledby: (PrintedName+Signature) HuaijieLi Supervisedby: (PrintedName+Signature) DavidHuang Approvedby: (PrintedName+Signature) JayLiu TestingLaboratoryName...................:AiboStandardTechnology(Shenzhen)Co.,Ltd. Address ................................................. :101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark, TianliaoCommunity,YutangStreet,GuangmingDistrict,Shenzhen City,GuangdongProvince,China Thistestreportmaybeduplicatedcompletelyforlegalusewiththeapprovaloftheapplicant.Itshouldnotbe reproducedexceptinfull,withoutthewrittenapprovalofourlaboratory.Theclientshouldnotuseittoclaim productendorsementbyAibo.Thetestresultsinthereportonlyapplytothetestedsample.Thetestreport shallbeinvalidwithoutallthesignaturesoftestingengineers,reviewerandapprover.Anyobjectionsmustbe raisedtoAibowithin15dayssincethedatewhenthereportisreceived.Itwillnotbetakenintoconsideration beyondthislimit.Thetestreportmerelycorrespondtothetestsample. FCCID:2BQLG-CM-CRCReportNo.:AB25060072FW01 Page2of24 AiboStandardTechnology(Shenzhen)Co.,Ltd. FCCTESTREPORT TestResultPositive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:AB25060072FW01 2025.07.15 Dateofissue EUT......................................... : Wirelesswinchremotecontrolsystemforvehicle TestModel.............................. : CM-CRC(TX) Applicant...............................:ChimaWinch(Thailand)Co.,Ltd Address...................................:No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Telephone...............................:/ Fax..........................................:/ Manufacturer......................... : ChimaWinch(Thailand)Co.,Ltd Address...................................:No.299/9,Moo7,BuengSub-district,SrirachaDistrict,Chonburi Province Telephone...............................:/ Fax..........................................:/ FCCID:2BQLG-CM-CRCReportNo.:AB25060072FW01 Page3of24 AiboStandardTechnology(Shenzhen)Co.,Ltd. REPORTVERSION VersionNo.IssueDateDescription 012025.07.15InitialIssue FCCID:2BQLG-CM-CRCReportNo.:AB25060072FW01 Page4of24 AiboStandardTechnology(Shenzhen)Co.,Ltd. TABLEOFCONTENTS 1.GENERALINFORMATION...........................................................................................................................................5 1.1.GENERALDESCRIPTIONOFEUT........................................................................................................................................5 1.2.DESCRIPTIONOFSUPPORTEQUIPMENT..........................................................................................................................6 1.3.DESCRIPTIONOFEXTERNALI/O.......................................................................................................................................6 1.4.GENERALDESCRIPTIONOFAPPLIEDSTANDARDS............................................................................................................7 1.5.DESCRIPTIONOFTESTFACILITY........................................................................................................................................7 1.6.MEASUREMENTUNCERTAINTY........................................................................................................................................8 1.7.ENVIRONMENTALCONDITIONS.......................................................................................................................................8 1.8.DESCRIPTIONOFTESTMODES.........................................................................................................................................9 2.SUMMARYOFTESTRESULT...................................................................................................................................10 3.MEASUREMENTINSTRUMENTSLIST ...................................................................................................................11 4.RADIATEDEMISSIONMEASUREMENT.................................................................................................................12 4.1.LIMITOFRADIATEDEMISSIONMEASUREMENT............................................................................................................12 4.2TESTPROCEDURES...........................................................................................................................................................12 4.3TESTSETUP...............................…

Text truncated - open the document above for the full version.

1. AntennaDescription: Antenna typePCBantenna ModelCM-MRC(TX) Frequencyrange315 MHz ManufacturerChima Winch (Thailand)Co., Ltd No.299/9,Moo 7, Bueng Sub-district,Sriracha District, ChonburiProvince Gain2.73 dBi 2. AntennaPhoto: We, Chima Winch (Thailand) Co., Ltd, states that All measurements were performed radiated and therefore additional antenna gain documentation is not required.

ReportNo.:AB25060072FW Page1of3 AppendixATestPhotos RadiatedEmissionTestView1 ReportNo.:AB25060072FW Page2of3 RadiatedEmissionTestView2 ReportNo.:AB25060072FW Page3of3 RFConductedTestView1
