2BSW8-ROCK2PROSmart Phone

HONG KONG LELEGAO TECHNOLOGY CO.,LIMITED

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jan 16, 2026
Application Purpose: Original Equipment
Equipment Note: Smart Phone
Frequency Range: 704.00000000 - 711.00000000
Company: HONG KONG LELEGAO TECHNOLOGY CO.,LIMITED
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

Report No.: STS2511195W25_Appendix SA 143 / 709 n7 SCS=15kHz DFT 256QAM BW=5MHz Channel=500500 RB=25@0 n7 SCS=15kHz DFT 64QAM BW=15MHz Channel=507000 RB=75@0 Report No.: STS2511195W25_Appendix SA 144 / 709 n7 SCS=15kHz DFT 256QAM BW=5MHz Channel=507000 RB=25@0 n7 SCS=15kHz DFT 256QAM BW=5MHz Channel=513500 RB=25@0 Report No.: STS2511195W25_Appendix SA 145 / 709 n7 SCS=15kHz DFT 64QAM BW=15MHz Channel=501500 RB=75@0 n7 SCS=15kHz DFT 64QAM BW=20MHz Channel=512000 RB=100@0 Report No.: STS2511195W25_Appendix SA 146 / 709 n7 SCS=15kHz DFT 64QAM BW=20MHz Channel=507000 RB=100@0 n7 SCS=15kHz DFT 64QAM BW=15MHz Channel=512500 RB=75@0 Report No.: STS2511195W25_Appendix SA 147 / 709 n7 SCS=15kHz DFT 64QAM BW=20MHz Channel=502000 RB=100@0 n7 SCS=15kHz DFT 64QAM BW=5MHz Channel=500500 RB=25@0 Report No.: STS2511195W25_Appendix SA 148 / 709 n7 SCS=15kHz DFT 64QAM BW=5MHz Channel=507000 RB=25@0 n7 SCS=15kHz DFT 64QAM BW=5MHz Channel=513500 RB=25@0 Report No.: STS2511195W25_Appendix SA 149 / 709 n7 SCS=15kHz DFT BPSK BW=15MHz Channel=501500 RB=75@0 n7 SCS=15kHz DFT BPSK BW=15MHz Channel=507000 RB=75@0 Report No.: STS2511195W25_Appendix SA 150 / 709 n7 SCS=15kHz DFT BPSK BW=15MHz Channel=512500 RB=75@0 n7 SCS=15kHz DFT BPSK BW=20MHz Channel=502000 RB=100@0 Report No.: STS2511195W25_Appendix SA 151 / 709 n7 SCS=15kHz DFT BPSK BW=20MHz Channel=507000 RB=100@0 n7 SCS=15kHz DFT BPSK BW=5MHz Channel=500500 RB=25@0 Report No.: STS2511195W25_Appendix SA 152 / 709 n7 SCS=15kHz DFT BPSK BW=5MHz Channel=513500 RB=25@0 n7 SCS=15kHz DFT BPSK BW=20MHz Channel=512000 RB=100@0 Report No.: STS2511195W25_Appendix SA 153 / 709 n7 SCS=15kHz DFT BPSK BW=5MHz Channel=507000 RB=25@0 n7 SCS=15kHz DFT QPSK BW=15MHz Channel=501500 RB=75@0 Report No.: STS2511195W25_Appendix SA 154 / 709 n7 SCS=15kHz DFT QPSK BW=15MHz Channel=507000 RB=75@0 n7 SCS=15kHz DFT QPSK BW=15MHz Channel=512500 RB=75@0 Report No.: STS2511195W25_Appendix SA 155 / 709 n7 SCS=15kHz DFT QPSK BW=20MHz Channel=512000 RB=100@0 n7 SCS=15kHz DFT QPSK BW=20MHz Channel=502000 RB=100@0 Report No.: STS2511195W25_Appendix SA 156 / 709 n7 SCS=15kHz DFT QPSK BW=20MHz Channel=507000 RB=100@0 n7 SCS=15kHz DFT QPSK BW=5MHz Channel=500500 RB=25@0 Report No.: STS2511195W25_Appendix SA 157 / 709 n7 SCS=15kHz DFT QPSK BW=5MHz Channel=507000 RB=25@0 n7 SCS=15kHz DFT QPSK BW=5MHz Channel=513500 RB=25@0 Report No.: STS2511195W25_Appendix SA 158 / 709 n77(3450-3550) SCS=30kHz DFT 16QAM BW=100MHz Channel=633332 RB=270@0 n77(3450-3550) SCS=30kHz DFT 16QAM BW=100MHz Channel=633334 RB=270@0 Report No.: STS2511195W25_Appendix SA 159 / 709 n77(3450-3550) SCS=30kHz DFT 16QAM BW=10MHz Channel=630334 RB=24@0 n77(3450-3550) SCS=30kHz DFT 16QAM BW=10MHz Channel=633334 RB=24@0 Report No.: STS2511195W25_Appendix SA 160 / 709 n77(3450-3550) SCS=30kHz DFT 16QAM BW=10MHz Channel=636332 RB=24@0 n77(3450-3550) SCS=30kHz DFT 16QAM BW=50MHz Channel=635000 RB=128@0 Report No.: STS2511195W25_Appendix SA 161 / 709 n77(3450-3550) SCS=30kHz DFT 256QAM BW=100MHz Channel=633332 RB=270@0 n77(3450-3550) SCS=30kHz DFT 16QAM BW=50MHz Channel=631668 RB=128@0 Report No.: STS2511195W25_Appendix SA 162 / 709 n77(3450-3550) SCS=30kHz DFT 16QAM BW=50MHz Channel=633334 RB=128@0 n77(3450-3550) SCS=30kHz DFT 256QAM BW=100MHz Channel=633334 RB=270@0 Report No.: STS2511195W25_Appendix SA 163 / 709 n77(3450-3550) SCS=30kHz DFT 256QAM BW=10MHz Channel=630334 RB=24@0 n77(3450-3550) SCS=30kHz DFT 256QAM BW=10MHz Channel=633334 RB=24@0 Report No.: STS2511195W25_Appendix SA 164 / 709 n77(3450-3550) SCS=30kHz DFT 256QAM BW=10MHz Channel=636332 RB=24@0 n77(3450-3550) SCS=30kHz DFT 64QAM BW=100MHz Channel=633332 RB=270@0 Report No.: STS2511195W25_Appendix SA 165 / 709 n77(3450-3550) SCS=30kHz DFT 256QAM BW=50MHz Channel=631668 RB=128@0 n77(3450-3550) SCS=30kHz DFT 256QAM BW=50MHz Channel=633334 RB=128@0 Report No.: STS2511195W25_Appendix SA 166 / 709 n77(3450-3550) SCS=30kHz DFT 256QAM BW=50MHz Channel=635000 RB=128@0 n77(3450-3550) SCS=30kHz DFT 64QAM BW=10MHz Channel=636332 RB=24@0 Report No.: STS2511195W25_Appendix SA 167 / 709 n77(3450-3550) SCS=30kHz DFT 64QAM BW=10MHz Channel=633334 RB=24@0 n77(3450-3550) SCS=30kHz DFT 64QAM BW=100MHz Channel=633334 RB=270@0 Report No.: STS2511195W25_Appendix SA 168 / 709 n77(3450-3550) SCS=30kHz DFT 64QAM BW=10MHz Channel=630334 RB=24@0 n77(3450-3550) SCS=30kHz DFT 64QAM BW=50MHz Channel=631668 RB=128@0 Report No.: STS2511195W25_Appendix SA 169 / 709 n77(3450-3550) SCS=30kHz DFT 64QAM BW=50MHz Channel=633334 RB=128@0 n77(3450-3550) SCS=30kHz DFT 64QAM BW=50MHz Channel=635000 RB=128@0 Report No.: STS2511195W25_Appendix SA 170 / 709 n77(3450-3550) SCS=30kHz DFT BPSK BW=100MHz Channel=633332 RB=270@0 n77(3450-3550) SCS=30kHz DFT BPSK BW=10MHz Channel=633334 RB=24@0 Report No.: STS2511195W25_Appendix SA 171 / 709 n77(3450-3550) SCS=30kHz DFT BPSK BW=100MHz Channel=633334 RB=270@0 n77(3450-3550) SCS=30kHz DFT BPSK BW=10MHz Channel=630334 RB=24@0 Report No.: STS2511195W25_Appendix SA 172 / 709 n77(3450-3550) SCS=30kHz DFT BPSK BW=10MHz Channel=636332 RB=24@0 n77(3450-3550) SCS=30kHz DFT BPSK BW=50MHz Channel=635000 RB=128@0 Report No.: STS2511195W25_Appendix SA 173 / 709 n77(3450-3550) SCS=30kHz DFT BPSK BW=50MHz Channel=631668 RB=128@0 n77(3450-3550) SCS=30kHz DFT BPSK BW=50MHz Channel=633334 RB=128@0 Report No.: STS2511195W25_Appendix SA 174 / 709 n77(3450-3550) SCS=30kHz DFT QPSK BW=10MHz Channel=633334 RB=24@0 n77(3450-3550) SCS=30kHz DFT QPSK BW=100MHz Channel=633332 RB=270@0 Report No.: STS2511195W25_Appendix SA 175 / 709 n77(3450-3550) SCS=30kHz DFT QPSK BW=100MHz Channel=633334 RB=270@0 n77(3450-3550) SCS=30kHz DFT QPSK BW=10MHz Channel=630334 RB=24@0 Report No.: STS2511195W25_Appendix SA 176 / 709 n77(3450-3550) SCS=30kHz DFT QPSK BW=50MHz Channel=631668 RB=128@0 n77(3450-3550) SCS=30kHz DFT QPSK BW=50MHz Channel=633334 RB=128@0 Report No.: STS2511195W25_Appendix SA 177 / 709 n77(3450-3550) SCS=30kHz DFT QPSK BW=10MHz Channel=636332 RB=24@0 n77(3450-3550) SCS=30kHz DFT QPSK BW=50MHz Chann…

Text truncated - open the document above for the full version.

Test Setup Photos

TR_STS2511195H02_SAR_SAR Setup photos for FCC ID: 2BSW8-ROCK2PRO Right Touch Right Tilt Left Touch Left Tilt Body Front side(separation distance is 10mm) Body Back side(separation distance is 10mm) Body Left side(separation distance is 10mm) Body Right side(separation distance is 10mm) Body Bottom side(separation distance is 10mm) Body Top side(separation distance is 10mm)

Test Setup Photos

Page 1 of 3 FCC ID:2BSW8-ROCK2PRO Setup photo 4G RF Conduction Page 2 of 3 FCC ID:2BSW8-ROCK2PRO 5G RF Conduction Page 3 of 3 FCC ID:2BSW8-ROCK2PRO RE (Below 1GHz) RE (Above 1GHz)

Test Report

Report No.: STS2511195W25_Appendix SA 1 / 709 3 Peak-to-Average Ratio for NR FR1 Band SCS (kHz) Bandwidth (MHz) UL Channel RB Allocation Modulation Result (dB) high Limit (dB) Verdict n2 15 5 370500 25@0 DFT BPSK 4.99 13 PASS n2 15 5 370500 25@0 DFT QPSK 5.14 13 PASS n2 15 5 370500 25@0 DFT 16QAM 5.34 13 PASS n2 15 5 370500 25@0 DFT 64QAM 5.66 13 PASS n2 15 5 370500 25@0 DFT 256QAM 6.23 13 PASS n2 15 5 376000 25@0 DFT BPSK 4.75 13 PASS n2 15 5 376000 25@0 DFT QPSK 4.87 13 PASS n2 15 5 376000 25@0 DFT 16QAM 5.16 13 PASS n2 15 5 376000 25@0 DFT 64QAM 5.40 13 PASS n2 15 5 376000 25@0 DFT 256QAM 6.02 13 PASS n2 15 5 381500 25@0 DFT BPSK 4.84 13 PASS n2 15 5 381500 25@0 DFT QPSK 4.86 13 PASS n2 15 5 381500 25@0 DFT 16QAM 5.06 13 PASS n2 15 5 381500 25@0 DFT 64QAM 5.36 13 PASS n2 15 5 381500 25@0 DFT 256QAM 5.85 13 PASS n2 15 15 371500 75@0 DFT BPSK 5.25 13 PASS n2 15 15 371500 75@0 DFT QPSK 5.45 13 PASS n2 15 15 371500 75@0 DFT 16QAM 5.42 13 PASS n2 15 15 371500 75@0 DFT 64QAM 5.54 13 PASS n2 15 15 371500 75@0 DFT 256QAM 6.04 13 PASS n2 15 15 376000 75@0 DFT BPSK 4.78 13 PASS n2 15 15 376000 75@0 DFT QPSK 4.99 13 PASS n2 15 15 376000 75@0 DFT 16QAM 5.18 13 PASS n2 15 15 376000 75@0 DFT 64QAM 5.36 13 PASS n2 15 15 376000 75@0 DFT 256QAM 6.00 13 PASS n2 15 15 380500 75@0 DFT BPSK 4.86 13 PASS n2 15 15 380500 75@0 DFT QPSK 5.10 13 PASS n2 15 15 380500 75@0 DFT 16QAM 5.34 13 PASS n2 15 15 380500 75@0 DFT 64QAM 5.41 13 PASS n2 15 15 380500 75@0 DFT 256QAM 5.41 13 PASS n2 15 20 372000 100@0 DFT BPSK 5.39 13 PASS n2 15 20 372000 100@0 DFT QPSK 5.49 13 PASS n2 15 20 372000 100@0 DFT 16QAM 5.79 13 PASS n2 15 20 372000 100@0 DFT 64QAM 5.91 13 PASS Report No.: STS2511195W25_Appendix SA 2 / 709 n2 15 20 372000 100@0 DFT 256QAM 6.11 13 PASS n2 15 20 376000 100@0 DFT BPSK 5.12 13 PASS n2 15 20 376000 100@0 DFT QPSK 5.20 13 PASS n2 15 20 376000 100@0 DFT 16QAM 5.45 13 PASS n2 15 20 376000 100@0 DFT 64QAM 5.81 13 PASS n2 15 20 376000 100@0 DFT 256QAM 5.93 13 PASS n2 15 20 380000 100@0 DFT BPSK 5.26 13 PASS n2 15 20 380000 100@0 DFT QPSK 5.41 13 PASS n2 15 20 380000 100@0 DFT 16QAM 5.76 13 PASS n2 15 20 380000 100@0 DFT 64QAM 5.83 13 PASS n2 15 20 380000 100@0 DFT 256QAM 6.35 13 PASS n26(814-824) 15 5 163300 25@0 DFT BPSK 3.12 13 PASS n26(814-824) 15 5 163300 25@0 DFT QPSK 3.59 13 PASS n26(814-824) 15 5 163300 25@0 DFT 16QAM 4.11 13 PASS n26(814-824) 15 5 163300 25@0 DFT 64QAM 4.56 13 PASS n26(814-824) 15 5 163300 25@0 DFT 256QAM 5.64 13 PASS n26(814-824) 15 5 163800 25@0 DFT BPSK 3.20 13 PASS n26(814-824) 15 5 163800 25@0 DFT QPSK 3.68 13 PASS n26(814-824) 15 5 163800 25@0 DFT 16QAM 4.29 13 PASS n26(814-824) 15 5 163800 25@0 DFT 64QAM 4.71 13 PASS n26(814-824) 15 5 163800 25@0 DFT 256QAM 5.77 13 PASS n26(814-824) 15 5 164300 25@0 DFT BPSK 3.48 13 PASS n26(814-824) 15 5 164300 25@0 DFT QPSK 4.10 13 PASS n26(814-824) 15 5 164300 25@0 DFT 16QAM 4.61 13 PASS n26(814-824) 15 5 164300 25@0 DFT 64QAM 5.13 13 PASS n26(814-824) 15 5 164300 25@0 DFT 256QAM 6.12 13 PASS n26(814-824) 15 10 163800 50@0 DFT BPSK 3.47 13 PASS n26(814-824) 15 10 163800 50@0 DFT QPSK 3.75 13 PASS n26(814-824) 15 10 163800 50@0 DFT 16QAM 4.24 13 PASS n26(814-824) 15 10 163800 50@0 DFT 64QAM 4.69 13 PASS n26(814-824) 15 10 163800 50@0 DFT 256QAM 5.69 13 PASS n26(824-849) 15 5 165300 25@0 DFT BPSK 3.47 13 PASS n26(824-849) 15 5 165300 25@0 DFT QPSK 4.03 13 PASS n26(824-849) 15 5 165300 25@0 DFT 16QAM 4.57 13 PASS n26(824-849) 15 5 165300 25@0 DFT 64QAM 5.16 13 PASS n26(824-849) 15 5 165300 25@0 DFT 256QAM 6.10 13 PASS Report No.: STS2511195W25_Appendix SA 3 / 709 n26(824-849) 15 5 167300 25@0 DFT BPSK 3.43 13 PASS n26(824-849) 15 5 167300 25@0 DFT QPSK 4.02 13 PASS n26(824-849) 15 5 167300 25@0 DFT 16QAM 4.56 13 PASS n26(824-849) 15 5 167300 25@0 DFT 64QAM 5.14 13 PASS n26(824-849) 15 5 167300 25@0 DFT 256QAM 6.08 13 PASS n26(824-849) 15 5 169300 25@0 DFT BPSK 3.83 13 PASS n26(824-849) 15 5 169300 25@0 DFT QPSK 4.63 13 PASS n26(824-849) 15 5 169300 25@0 DFT 16QAM 5.08 13 PASS n26(824-849) 15 5 169300 25@0 DFT 64QAM 5.70 13 PASS n26(824-849) 15 5 169300 25@0 DFT 256QAM 6.47 13 PASS n26(824-849) 15 15 166300 75@0 DFT BPSK 3.84 13 PASS n26(824-849) 15 15 166300 75@0 DFT QPSK 4.18 13 PASS n26(824-849) 15 15 166300 75@0 DFT 16QAM 4.63 13 PASS n26(824-849) 15 15 166300 75@0 DFT 64QAM 5.16 13 PASS n26(824-849) 15 15 166300 75@0 DFT 256QAM 5.99 13 PASS n26(824-849) 15 15 167300 75@0 DFT BPSK 3.84 13 PASS n26(824-849) 15 15 167300 75@0 DFT QPSK 4.27 13 PASS n26(824-849) 15 15 167300 75@0 DFT 16QAM 4.77 13 PASS n26(824-849) 15 15 167300 75@0 DFT 64QAM 5.26 13 PASS n26(824-849) 15 15 167300 75@0 DFT 256QAM 6.02 13 PASS n26(824-849) 15 15 168300 75@0 DFT BPSK 4.22 13 PASS n26(824-849) 15 15 168300 75@0 DFT QPSK 4.86 13 PASS n26(824-849) 15 15 168300 75@0 DFT 16QAM 5.35 13 PASS n26(824-849) 15 15 168300 75@0 DFT 64QAM 5.77 13 PASS n26(824-849) 15 15 168300 75@0 DFT 256QAM 6.36 13 PASS n26(824-849) 15 20 166800 100@0 DFT BPSK 3.96 13 PASS n26(824-849) 15 20 166800 100@0 DFT QPSK 4.58 13 PASS n26(824-849) 15 20 166800 100@0 DFT 16QAM 5.02 13 PASS n26(824-849) 15 20 166800 100@0 DFT 64QAM 5.46 13 PASS n26(824-849) 15 20 166800 100@0 DFT 256QAM 6.06 13 PASS n26(824-849) 15 20 167300 100@0 DFT BPSK 4.04 13 PASS n26(824-849) 15 20 167300 100@0 DFT QPSK 4.72 13 PASS n26(824-849) 15 20 167300 100@0 DFT 16QAM 5.13 13 PASS n26(824-849) 15 20 167300 100@0 DFT 64QAM 5.52 13 PASS n26(824-849) 15 20 167300 100@0 DFT 256QAM 6.16 13 PASS n26(824-849) 15 20 167800 100@0 DFT BPSK 4.26 13 PASS n26(824-849) 15 20 167800 100@0 DFT QPSK 5.01 13 PASS Report No.: STS2511195W25_Appendix SA 4 / 709 n26(824-849) 15 20 167800 100@0 DFT 16QAM 5.53 13 PASS n26(824-849) 15 20 167800 100@0 DFT 64QAM 5.85 13 PASS n26(824-849) 15 20 167800 100@0 DFT 256QAM 6.47 13 PASS n41 30 10 500202 24@0 DFT BPSK 3.68 13 PASS n41 30 10 500202 24@0 DFT QPSK 4.51 13 PASS n41 30 10 500202 24@0 DFT 16QAM 5.36 13 PASS n41 30 10 500202 24@0 DFT 64QAM 5.66 13 PASS n41 30 10 500202 24@0 DFT 256QAM 6.28 13 PASS n…

Text truncated - open the document above for the full version.

Test Report

Report No.: STS2511195W03_Appendix WCDMA 1 03 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict HSDPA Band2 Subtest1 9262 1852.4 3.04 13 PASS HSDPA Band2 Subtest1 9400 1880 3.08 13 PASS HSDPA Band2 Subtest1 9538 1907.6 3.07 13 PASS HSUPA Band2 Subtest1 9262 1852.4 3.43 13 PASS HSUPA Band2 Subtest1 9400 1880 3.50 13 PASS HSUPA Band2 Subtest1 9538 1907.6 3.47 13 PASS WCDMA Band2 9262 1852.4 2.88 13 PASS WCDMA Band2 9400 1880 2.97 13 PASS WCDMA Band2 9538 1907.6 2.95 13 PASS HSDPA Band5 Subtest1 4132 826.4 2.54 13 PASS HSDPA Band5 Subtest1 4182 836.4 2.72 13 PASS HSDPA Band5 Subtest1 4233 846.6 2.62 13 PASS HSUPA Band5 Subtest1 4132 826.4 3.40 13 PASS HSUPA Band5 Subtest1 4182 836.4 3.37 13 PASS HSUPA Band5 Subtest1 4233 846.6 3.39 13 PASS WCDMA Band5 4132 826.4 2.38 13 PASS WCDMA Band5 4182 836.4 2.59 13 PASS WCDMA Band5 4233 846.6 2.45 13 PASS HSDPA Band2 Subtest1 Channel=9262 Report No.: STS2511195W03_Appendix WCDMA 2 HSDPA Band2 Subtest1 Channel=9400 HSDPA Band2 Subtest1 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 3 HSUPA Band2 Subtest1 Channel=9262 HSUPA Band2 Subtest1 Channel=9400 Report No.: STS2511195W03_Appendix WCDMA 4 HSUPA Band2 Subtest1 Channel=9538 WCDMA Band2 Channel=9262 Report No.: STS2511195W03_Appendix WCDMA 5 WCDMA Band2 Channel=9400 WCDMA Band2 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 6 HSDPA Band5 Subtest1 Channel=4132 HSDPA Band5 Subtest1 Channel=4182 Report No.: STS2511195W03_Appendix WCDMA 7 HSDPA Band5 Subtest1 Channel=4233 HSUPA Band5 Subtest1 Channel=4132 Report No.: STS2511195W03_Appendix WCDMA 8 HSUPA Band5 Subtest1 Channel=4182 HSUPA Band5 Subtest1 Channel=4233 Report No.: STS2511195W03_Appendix WCDMA 9 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Report No.: STS2511195W03_Appendix WCDMA 10 WCDMA Band5 Channel=4233 04 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict HSDPA Band2 Subtest1 9262 1852.4 4183.173 4714.795 PASS HSDPA Band2 Subtest1 9400 1880 4183.218 4693.890 PASS HSDPA Band2 Subtest1 9538 1907.6 4189.349 4684.170 PASS HSUPA Band2 Subtest1 9262 1852.4 4198.120 4725.379 PASS HSUPA Band2 Subtest1 9400 1880 4193.645 4717.134 PASS HSUPA Band2 Subtest1 9538 1907.6 4187.444 4693.583 PASS WCDMA Band2 9262 1852.4 4166.702 4694.087 PASS WCDMA Band2 9400 1880 4173.192 4694.065 PASS WCDMA Band2 9538 1907.6 4183.312 4717.695 PASS HSDPA Band5 Subtest1 4132 826.4 4172.937 4682.239 PASS HSDPA Band5 Subtest1 4182 836.4 4158.928 4672.169 PASS HSDPA Band5 Subtest1 4233 846.6 4148.725 4680.899 PASS HSUPA Band5 Subtest1 4132 826.4 4138.378 4672.325 PASS HSUPA Band5 Subtest1 4182 836.4 4158.459 4662.596 PASS HSUPA Band5 Subtest1 4233 846.6 4119.809 4632.998 PASS WCDMA Band5 4132 826.4 4156.980 4716.659 PASS WCDMA Band5 4182 836.4 4171.051 4678.722 PASS WCDMA Band5 4233 846.6 4167.185 4721.843 PASS HSDPA Band2 Subtest1 Channel=9262 Report No.: STS2511195W03_Appendix WCDMA 11 HSDPA Band2 Subtest1 Channel=9400 HSDPA Band2 Subtest1 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 12 HSUPA Band2 Subtest1 Channel=9262 HSUPA Band2 Subtest1 Channel=9400 Report No.: STS2511195W03_Appendix WCDMA 13 HSUPA Band2 Subtest1 Channel=9538 WCDMA Band2 Channel=9262 Report No.: STS2511195W03_Appendix WCDMA 14 WCDMA Band2 Channel=9400 WCDMA Band2 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 15 HSDPA Band5 Subtest1 Channel=4132 HSDPA Band5 Subtest1 Channel=4182 Report No.: STS2511195W03_Appendix WCDMA 16 HSDPA Band5 Subtest1 Channel=4233 HSUPA Band5 Subtest1 Channel=4132 Report No.: STS2511195W03_Appendix WCDMA 17 HSUPA Band5 Subtest1 Channel=4182 HSUPA Band5 Subtest1 Channel=4233 Report No.: STS2511195W03_Appendix WCDMA 18 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4182 Report No.: STS2511195W03_Appendix WCDMA 19 WCDMA Band5 Channel=4233 05 Band edge Report No.: STS2511195W03_Appendix WCDMA 20 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict HSDPA Band2 Subtest1 9262 1852.4 1850.00 -25.51 -13 PASS HSDPA Band2 Subtest1 9538 1907.6 1910.00 -25.03 -13 PASS HSUPA Band2 Subtest1 9262 1852.4 1850.00 -25.95 -13 PASS HSUPA Band2 Subtest1 9538 1907.6 1910.00 -25.08 -13 PASS WCDMA Band2 9262 1852.4 1850.00 -24.35 -13 PASS WCDMA Band2 9538 1907.6 1910.00 -23.57 -13 PASS HSDPA Band5 Subtest1 4132 826.4 824.00 -20.48 -13 PASS HSDPA Band5 Subtest1 4233 846.6 849.00 -20.61 -13 PASS HSUPA Band5 Subtest1 4132 826.4 824.00 -25.52 -13 PASS HSUPA Band5 Subtest1 4233 846.6 849.00 -26.14 -13 PASS WCDMA Band5 4132 826.4 824.00 -17.59 -13 PASS WCDMA Band5 4233 846.6 849.00 -18.49 -13 PASS HSDPA Band2 Subtest1 Channel=9262 HSDPA Band2 Subtest1 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 21 HSUPA Band2 Subtest1 Channel=9262 HSUPA Band2 Subtest1 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 22 WCDMA Band2 Channel=9262 WCDMA Band2 Channel=9538 Report No.: STS2511195W03_Appendix WCDMA 23 HSDPA Band5 Subtest1 Channel=4132 HSDPA Band5 Subtest1 Channel=4233 Report No.: STS2511195W03_Appendix WCDMA 24 HSUPA Band5 Subtest1 Channel=4132 HSUPA Band5 Subtest1 Channel=4233 Report No.: STS2511195W03_Appendix WCDMA 25 WCDMA Band5 Channel=4132 WCDMA Band5 Channel=4233 Report No.: STS2511195W03_Appendix WCDMA 26 06 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict HSDPA Band2 Subtest1 9262 1852.4 18322.52 -23.24 -13 PASS HSDPA Band2 Subtest1 9400 1880 18337.50 -23.86 -13 PASS HSDPA Band2 Subtest1 9538 1907.6 18430.36 -23.32 -13 PASS HSUPA Band2 Subtest1 9262 1852.4 18468.30 -23.50 -13 PASS HSUPA Band2 Subtest1 9400 1880 18176.24 -23.71 -13 PASS HSUPA Band2 Subtest1 9538 1907.6 18480.28 -23.43 -13 PASS WCDMA Band2 9262 1852.4 18432.85 -23.47 -13 PASS WCDMA Band2 9400 1880 18413.88 -23.29 -13 PASS WCDMA Band2 9538 1907.6 18380.43 -23.43 -13 PASS HSDPA Band5 Subtest1 4132 826.4 2919.80 -29.25 -13 PASS HSDPA Band5 Subtest1 4182 836.4 2495.08 -28.48 -13 PASS HSDPA Band5 Subtest1 4233 846.6 2507.05 -29.04 -13 PASS HSUPA…

Text truncated - open the document above for the full version.

Test Report

Report No.: STS2511195W03_Appendix LTE 281 Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 QPSK BW=5MHz Channel=20625 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 282 Band66 16QAM BW=1.4MHz Channel=131979 RB Size=6 Position=#0 Band66 16QAM BW=1.4MHz Channel=132665 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 283 Band66 16QAM BW=10MHz Channel=132022 RB Size=50 Position=#0 Band66 16QAM BW=10MHz Channel=132622 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 284 Band66 16QAM BW=15MHz Channel=132047 RB Size=75 Position=#0 Band66 16QAM BW=15MHz Channel=132597 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 285 Band66 16QAM BW=20MHz Channel=132072 RB Size=100 Position=#0 Band66 16QAM BW=20MHz Channel=132572 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 286 Band66 16QAM BW=3MHz Channel=131987 RB Size=15 Position=#0 Band66 16QAM BW=3MHz Channel=132657 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 287 Band66 16QAM BW=5MHz Channel=131997 RB Size=25 Position=#0 Band66 16QAM BW=5MHz Channel=132647 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 288 Band66 QPSK BW=1.4MHz Channel=131979 RB Size=6 Position=#0 Band66 QPSK BW=1.4MHz Channel=132665 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 289 Band66 QPSK BW=10MHz Channel=132022 RB Size=50 Position=#0 Band66 QPSK BW=10MHz Channel=132622 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 290 Band66 QPSK BW=15MHz Channel=132047 RB Size=75 Position=#0 Band66 QPSK BW=15MHz Channel=132597 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 291 Band66 QPSK BW=20MHz Channel=132072 RB Size=100 Position=#0 Band66 QPSK BW=20MHz Channel=132572 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 292 Band66 QPSK BW=3MHz Channel=131987 RB Size=15 Position=#0 Band66 QPSK BW=3MHz Channel=132657 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 293 Band66 QPSK BW=5MHz Channel=131997 RB Size=25 Position=#0 Band66 QPSK BW=5MHz Channel=132647 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 294 Band7 16QAM BW=10MHz Channel=20800 RB Size=50 Position=#0 Band7 16QAM BW=10MHz Channel=21400 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 295 Band7 16QAM BW=15MHz Channel=20825 RB Size=75 Position=#0 Band7 16QAM BW=15MHz Channel=21375 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 296 Band7 16QAM BW=20MHz Channel=20850 RB Size=100 Position=#0 Band7 16QAM BW=20MHz Channel=21350 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 297 Band7 16QAM BW=5MHz Channel=20775 RB Size=25 Position=#0 Band7 16QAM BW=5MHz Channel=21425 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 298 Band7 QPSK BW=10MHz Channel=20800 RB Size=50 Position=#0 Band7 QPSK BW=10MHz Channel=21400 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 299 Band7 QPSK BW=15MHz Channel=20825 RB Size=75 Position=#0 Band7 QPSK BW=15MHz Channel=21375 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 300 Band7 QPSK BW=20MHz Channel=20850 RB Size=100 Position=#0 Band7 QPSK BW=20MHz Channel=21350 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 301 Band7 QPSK BW=5MHz Channel=20775 RB Size=25 Position=#0 Band7 QPSK BW=5MHz Channel=21425 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 302 06 Out-of-band emissions Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict Band12 1.4 23017 6 #0 QPSK 2099.05 -25.86 -13 PASS Band12 1.4 23017 6 #0 16QAM 2099.05 -26.49 -13 PASS Band12 1.4 23095 6 #0 QPSK 2123.28 -26.55 -13 PASS Band12 1.4 23095 6 #0 16QAM 2122.64 -25.37 -13 PASS Band12 1.4 23173 6 #0 QPSK 2146.23 -26.90 -13 PASS Band12 1.4 23173 6 #0 16QAM 2146.86 -29.24 -13 PASS Band12 3 23025 15 #0 QPSK 2102.24 -30.49 -13 PASS Band12 3 23025 15 #0 16QAM 2103.51 -32.29 -13 PASS Band12 3 23095 15 #0 QPSK 2123.28 -31.21 -13 PASS Band12 3 23095 15 #0 16QAM 2122.00 -29.22 -13 PASS Band12 3 23165 15 #0 QPSK 2143.68 -30.73 -13 PASS Band12 3 23165 15 #0 16QAM 2145.59 -32.43 -13 PASS Band12 5 23035 25 #0 QPSK 3.27 -32.84 -13 PASS Band12 5 23035 25 #0 16QAM 3.26 -32.65 -13 PASS Band12 5 23095 25 #0 QPSK 2121.36 -32.53 -13 PASS Band12 5 23095 25 #0 16QAM 3.27 -32.75 -13 PASS Band12 5 23155 25 #0 QPSK 3.27 -32.79 -13 PASS Band12 5 23155 25 #0 16QAM 2137.94 -30.94 -13 PASS Band12 10 23060 50 #0 QPSK 3.27 -32.84 -13 PASS Band12 10 23060 50 #0 16QAM 3.27 -32.82 -13 PASS Report No.: STS2511195W03_Appendix LTE 303 Band12 10 23095 50 #0 QPSK 3.30 -33.51 -13 PASS Band12 10 23095 50 #0 16QAM 3.27 -33.14 -13 PASS Band12 10 23130 50 #0 QPSK 3.28 -33.17 -13 PASS Band12 10 23130 50 #0 16QAM 3.27 -32.90 -13 PASS Band17 5 23755 25 #0 QPSK 2120.09 -32.43 -13 PASS Band17 5 23755 25 #0 16QAM 2123.28 -32.87 -13 PASS Band17 5 23790 25 #0 QPSK 2134.11 -33.14 -13 PASS Band17 5 23790 25 #0 16QAM 2130.29 -32.42 -13 PASS Band17 5 23825 25 #0 QPSK 3.29 -33.31 -13 PASS Band17 5 23825 25 #0 16QAM 2140.49 -33.17 -13 PASS Band17 10 23780 50 #0 QPSK 3.27 -32.94 -13 PASS Band17 10 23780 50 #0 16QAM 3.28 -32.87 -13 PASS Band17 10 23790 50 #0 QPSK 3.27 -32.83 -13 PASS Band17 10 23790 50 #0 16QAM 3.28 -32.97 -13 PASS Band17 10 23800 50 #0 QPSK 3.29 -33.26 -13 PASS Band17 10 23800 50 #0 16QAM 3.27 -33.08 -13 PASS Band2 1.4 18607 6 #0 QPSK 0.54 -22.63 -13 PASS Band2 1.4 18607 6 #0 16QAM 0.53 -24.37 -13 PASS Band2 1.4 18900 6 #0 QPSK 0.53 -24.50 -13 PASS Band2 1.4 18900 6 #0 16QAM 0.54 -24.53 -13 PASS Band2 1.4 19193 6 #0 QPSK 0.53 -24.23 -13 PASS Band2 1.4 19193 6 #0 16QAM 0.53 -24.31 -13 PASS Band2 3 18615 15 #0 QPSK 1.79 -31.21 -13 PASS Band2 3 18615 15 #0 16QAM 0.45 -31.13 -13 PASS Band2 3 18900 15 #0 QPSK 0.45 -31.88 -13 PASS Band2 3 18900 15 #0 16QAM 3.28 -32.07 -13 PASS Band2 3 19185 15 #0 QPSK 0.45 -31.47 -13 PASS Band2 3 19185 15 #0 16QAM 3.26 -31.89 -13 PASS Band2 5 18625 25 #0 QPSK 3.42 -30.76 -13 PASS Band2 5 18625 25 #0…

Text truncated - open the document above for the full version.

Test Report

Report No.: STS2511195W03_Appendix LTE 141 Band2 16QAM BW=20MHz Channel=18700 RB Size=100 Position=#0 Band2 16QAM BW=20MHz Channel=18900 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 142 Band2 16QAM BW=20MHz Channel=19100 RB Size=100 Position=#0 Band2 16QAM BW=3MHz Channel=18615 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 143 Band2 16QAM BW=3MHz Channel=18900 RB Size=15 Position=#0 Band2 16QAM BW=3MHz Channel=19185 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 144 Band2 16QAM BW=5MHz Channel=18625 RB Size=25 Position=#0 Band2 16QAM BW=5MHz Channel=18900 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 145 Band2 16QAM BW=5MHz Channel=19175 RB Size=25 Position=#0 Band2 QPSK BW=1.4MHz Channel=18607 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 146 Band2 QPSK BW=1.4MHz Channel=18900 RB Size=6 Position=#0 Band2 QPSK BW=1.4MHz Channel=19193 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 147 Band2 QPSK BW=10MHz Channel=18650 RB Size=50 Position=#0 Band2 QPSK BW=10MHz Channel=18900 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 148 Band2 QPSK BW=10MHz Channel=19150 RB Size=50 Position=#0 Band2 QPSK BW=15MHz Channel=18675 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 149 Band2 QPSK BW=15MHz Channel=18900 RB Size=75 Position=#0 Band2 QPSK BW=15MHz Channel=19125 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 150 Band2 QPSK BW=20MHz Channel=18700 RB Size=100 Position=#0 Band2 QPSK BW=20MHz Channel=18900 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 151 Band2 QPSK BW=20MHz Channel=19100 RB Size=100 Position=#0 Band2 QPSK BW=3MHz Channel=18615 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 152 Band2 QPSK BW=3MHz Channel=18900 RB Size=15 Position=#0 Band2 QPSK BW=3MHz Channel=19185 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 153 Band2 QPSK BW=5MHz Channel=18625 RB Size=25 Position=#0 Band2 QPSK BW=5MHz Channel=18900 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 154 Band2 QPSK BW=5MHz Channel=19175 RB Size=25 Position=#0 Band4 16QAM BW=1.4MHz Channel=19957 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 155 Band4 16QAM BW=1.4MHz Channel=20175 RB Size=6 Position=#0 Band4 16QAM BW=1.4MHz Channel=20393 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 156 Band4 16QAM BW=10MHz Channel=20000 RB Size=50 Position=#0 Band4 16QAM BW=10MHz Channel=20175 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 157 Band4 16QAM BW=10MHz Channel=20350 RB Size=50 Position=#0 Band4 16QAM BW=15MHz Channel=20025 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 158 Band4 16QAM BW=15MHz Channel=20175 RB Size=75 Position=#0 Band4 16QAM BW=15MHz Channel=20325 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 159 Band4 16QAM BW=20MHz Channel=20050 RB Size=100 Position=#0 Band4 16QAM BW=20MHz Channel=20175 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 160 Band4 16QAM BW=20MHz Channel=20300 RB Size=100 Position=#0 Band4 16QAM BW=3MHz Channel=19965 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 161 Band4 16QAM BW=3MHz Channel=20175 RB Size=15 Position=#0 Band4 16QAM BW=3MHz Channel=20385 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 162 Band4 16QAM BW=5MHz Channel=19975 RB Size=25 Position=#0 Band4 16QAM BW=5MHz Channel=20175 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 163 Band4 16QAM BW=5MHz Channel=20375 RB Size=25 Position=#0 Band4 QPSK BW=1.4MHz Channel=19957 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 164 Band4 QPSK BW=1.4MHz Channel=20175 RB Size=6 Position=#0 Band4 QPSK BW=1.4MHz Channel=20393 RB Size=6 Position=#0 Report No.: STS2511195W03_Appendix LTE 165 Band4 QPSK BW=10MHz Channel=20000 RB Size=50 Position=#0 Band4 QPSK BW=10MHz Channel=20175 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 166 Band4 QPSK BW=10MHz Channel=20350 RB Size=50 Position=#0 Band4 QPSK BW=15MHz Channel=20025 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 167 Band4 QPSK BW=15MHz Channel=20175 RB Size=75 Position=#0 Band4 QPSK BW=15MHz Channel=20325 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 168 Band4 QPSK BW=20MHz Channel=20050 RB Size=100 Position=#0 Band4 QPSK BW=20MHz Channel=20175 RB Size=100 Position=#0 Report No.: STS2511195W03_Appendix LTE 169 Band4 QPSK BW=20MHz Channel=20300 RB Size=100 Position=#0 Band4 QPSK BW=3MHz Channel=19965 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 170 Band4 QPSK BW=3MHz Channel=20175 RB Size=15 Position=#0 Band4 QPSK BW=3MHz Channel=20385 RB Size=15 Position=#0 Report No.: STS2511195W03_Appendix LTE 171 Band4 QPSK BW=5MHz Channel=19975 RB Size=25 Position=#0 Band4 QPSK BW=5MHz Channel=20175 RB Size=25 Position=#0 Report No.: STS2511195W03_Appendix LTE 172 Band4 QPSK BW=5MHz Channel=20375 RB Size=25 Position=#0 Band41 16QAM BW=10MHz Channel=39700 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 173 Band41 16QAM BW=10MHz Channel=40620 RB Size=50 Position=#0 Band41 16QAM BW=10MHz Channel=41540 RB Size=50 Position=#0 Report No.: STS2511195W03_Appendix LTE 174 Band41 16QAM BW=15MHz Channel=39725 RB Size=75 Position=#0 Band41 16QAM BW=15MHz Channel=40620 RB Size=75 Position=#0 Report No.: STS2511195W03_Appendix LTE 175 Band41 16QAM BW=15MHz Channel=41515 RB S…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Xiuying Zou

[email protected]Fax: 75532909320

Technical Contact

FCC US Agent, LLCTim Payne

[email protected]

3722 Illinois Avenue · Saint Charles, Illinois, 60174 · United States

Test Firm

SHENZHEN STS TEST SERVICES CO.,LTD.Bovey Yang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	824.2 MHz - 848.8 MHz	2.5645 W	250KGXW	2.5ppm
2	22H	824.2 MHz - 848.8 MHz	442.60 mW	254KG7W	2.5ppm
3	24E	1.85 GHz - 1.91 GHz	765.60 mW	249KGXW	2.5ppm
4	24E	1.85 GHz - 1.91 GHz	343.60 mW	258KG7W	2.5ppm
5	24E	1.85 GHz - 1.91 GHz	164.40 mW	4M20F9W	2.5ppm
6	22H	826.4 MHz - 846.6 MHz	406.40 mW	4M17F9W	2.5ppm
7	24E	1.86 GHz - 1.90 GHz	151.70 mW	18M1G7D	2.5ppm
8	24E	1.86 GHz - 1.90 GHz	127.40 mW	17M9W7D	2.5ppm
9	27	1.72 GHz - 1.75 GHz	193.60 mW	18M0G7D	2.5ppm
1	27	1.72 GHz - 1.75 GHz	165.20 mW	18M0W7D	2.5ppm
11	22H	829 MHz - 844 MHz	359.70 mW	9M01G7D	2.5ppm
12	22H	829 MHz - 844 MHz	295.80 mW	9M00W7D	2.5ppm
13	27	2.51 GHz - 2.56 GHz	229.10 mW	18M0G7D	2.5ppm
14	27	2.51 GHz - 2.56 GHz	232.30 mW	18M0W7D	2.5ppm
15	27	704 MHz - 711 MHz	375.80 mW	9M01G7D	2.5ppm
16	27	704 MHz - 711 MHz	306.20 mW	9M00W7D	2.5ppm
17	27	709 MHz - 711 MHz	389.00 mW	8M99G7D	2.5ppm
18	27	709 MHz - 711 MHz	302.70 mW	9M00W7D	2.5ppm
19	27	2.51 GHz - 2.68 GHz	269.20 mW	17M9G7D	2.5ppm
2	27	2.51 GHz - 2.68 GHz	304.10 mW	18M0W7D	2.5ppm
21	27	1.72 GHz - 1.77 GHz	194.50 mW	18M0G7D	2.5ppm
22	27	1.72 GHz - 1.77 GHz	154.20 mW	18M0W7D	2.5ppm
23	24E	1.86 GHz - 1.90 GHz	172.00 mW	18M9G1D	2.5ppm
24	24E	1.86 GHz - 1.90 GHz	155.00 mW	18M9W1D	2.5ppm
25	22H	834 MHz - 839 MHz	205.00 mW	18M8G1D	2.5ppm
26	22H	834 MHz - 839 MHz	206.00 mW	18M8W1D	2.5ppm
27	27	2.51 GHz - 2.56 GHz	165.00 mW	18M8G1D	2.5ppm
28	27	2.51 GHz - 2.56 GHz	164.00 mW	18M8W1D	2.5ppm
29	9	819 MHz - 819 MHz	324.00 mW	18M8G1D	2.5ppm
3	9	819 MHz - 819 MHz	343.00 mW	18M8W1D	2.5ppm
31	22H	831.5 MHz - 841.5 MHz	413.00 mW	18M8G1D	2.5ppm
32	22H	831.5 MHz - 841.5 MHz	398.00 mW	18M8W1D	2.5ppm
33	27	2.60 GHz - 2.60 GHz	509.00 mW	96M9G1D	2.5ppm
34	27	2.60 GHz - 2.60 GHz	533.00 mW	96M9W1D	2.5ppm
35	27	1.73 GHz - 1.76 GHz	264.00 mW	38M9G1D	2.5ppm
36	27	1.73 GHz - 1.76 GHz	247.00 mW	38M9W1D	2.5ppm
37	27	3.50 GHz - 3.50 GHz	450.00 mW	97M0G1D	2.5ppm
38	27	3.50 GHz - 3.50 GHz	306.00 mW	96M9W1D	2.5ppm
39	27	3.75 GHz - 3.93 GHz	437.00 mW	97M0G1D	2.5ppm
4	27	3.75 GHz - 3.93 GHz	333.00 mW	97M0W1D	2.5ppm
41	27	3.50 GHz - 3.50 GHz	458.00 mW	97M0G1D	2.5ppm
42	27	3.50 GHz - 3.50 GHz	302.00 mW	97M0W1D	2.5ppm
43	27	3.75 GHz - 3.75 GHz	436.00 mW	97M0G1D	2.5ppm
44	27	3.75 GHz - 3.75 GHz	342.00 mW	96M9W1D	2.5ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for frequencies below 1GHz and EIRP for frequencies above 1GHz. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.0 cm separation between the device and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission use conditions is 0.14W/kg, 0.77W/kg, 0.77W/kg and 0.96W/kg respectively. This device also contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
