A3LSCHA212Single-Mode Cellular CDMA Phone
Samsung Electronics Co Ltd
Click to zoom
Application Details
- Equipment Class
- TNE - Licensed Non-Broadcast Transmitter Held to Ear
- Date of Grant
- Aug 14, 2001
- Application Purpose
- Original Equipment
- Date of Application
- May 10, 2001
- Equipment Note
- Single-Mode Cellular CDMA Phone
- Frequency Range
- 824.70000000 - 848.31000000
- Company
- Samsung Electronics Co Ltd
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 12. USER'S MANUAL For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1.0 cm. from the body. To maintain compliance with FCC RF exposure guidelines, use only belt-clips, holsters or similar accessories that maintain a 1.0 cm. separation distance between the userβs body and the back of the phone, including the antenna, whether extended or retracted. The use of third-party belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure guidelines, and should be avoided. WARNING! Read this information before using your phone CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001
Users Manual
CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001
Attestation Statements
May 01,2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsung Electronics America May 01, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Samsung Electronics Co., Ltd. FCC ID: A3LSCHA212 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSCHA212) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. May 01, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSCHA212 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652.
Attestation Statements
June 8, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER Β§22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSCHA212), using the Automatic A/B Roaming β Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a β9-1-1β call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned.
Cover Letter(s)
May 01, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSCHA212 Part 22 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 22 Certification of the following Single-Mode Cellular CDMA Phone: FCC ID: A3LSCHA212 TRADE / MODEL(s): SAMSUNG SCH-A212 EUT TYPE: Non-Broadcast transmitter Held to Ear (TNE) Tx Freq. Range: 824.70 β 848.31 MHz Rx Freq. Range: 869.70 β 893.31 MHz Max. RF Output Power: 0.374 W ERP (25.733 dBm) Attached is the applicantβs Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Wallace Oh Engineering Manager SAMSUNG American QA Lab
Cover Letter(s)
July 5, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSCHA212 731 Confirmation No.: 100975 Correspondence Reference No.: 19649 Request for Tech. Info.: 6/15/01 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated June 15, 2001. 1. Please find attached the signed E911 Statement. 2. Please find attached a clearer version of the schematics. 3. Please find attached the data points for the standard battery to compare with the data for the extended battery. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
Cover Letter(s)
July 20, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSCHA212 731 Confirmation No.: 100975 Correspondence Reference No.: 19946 Request for Tech. Info.: 7/13/01 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated July 20, 2001. 1. Please find attached a clearer version of the schematics. 2. Please find attached the SAR data points for the standard battery to compare with the data for the extended battery. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
Cover Letter(s)
August 7, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSCHA212 731 Confirmation No.: 100975 Correspondence Reference No.: 20057 Request for Tech. Info.: 7/25/01 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated July 25, 2001. 1. Please find attached the data points on the hand and body configurations for the standard and extended battery. 2. Both Batteries (extended and standard) were tested with a 1cm separation from the flat phantom. 3. The photo shows the standard battery, which is the worst-case condition for body SAR. 4. We would like to confirm that there is no belt clip included, please refer to page 75 (accessories page) in the users manual. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
External Photos
Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone
ID Label/Location Info
© 2001PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SCH-A212 FCC ID: A3LSCHA212 MADE IN KOREA
Internal Photos
Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone
Operational Description
CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 RETRACTABLE BOTTOM HELICAL ANTENNA VENDOR : SB TELCOM. CO. LTD ELECTRICAL DATA Freq. Band CDMA Band Transmit Band : 824 ~ 849 MHz Receive Band : 869 ~ 894 MHz Impedance Normal Value : 50 VSWR(Free Space) Retracted Less than 2.5 : 1 Extended Less than 2.5 : 1 Gain Retracted Greater than -4dBd Extended Greater than -3dBd (dBd:dBrelativetoadipole) Maximum Lobe Tilt Retracted 90 Extended 90
Parts List/Tune Up Info
CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 VENDOR LOCATIONVENDOR CODEDESCRIPTION MATSUSITAF302ETSD836MB2Z1DUPLEXER QUALCOMMU609MSM 3100C-208FPBGAMobile Station Modem ALPSOSC402UCVA3-112AVCO TIU402LMX2332LSLBTMXPLL KYOSERAOSC401KT18-DCV28A-19.68M-TVCTCXO QUALCOMMU302IFR3000-48BCCF-TRIFR3000 QUALCOMMU204RFT3100-32BCCPF-MTRFT3100 INFINEONU361CMY212BDOWN CONVERTER RFMDU360RF2366TR13LNA CONNEXANTU201RM912Power Amp Module QUALCOMMU501TWL2213PM1000 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 List of Equipment - DC Power Supply -TestJig - Test Cable - CDMA Mobile Station Test Set HP8924C, HP83236A, CMD-80, etc - Spectrum Analyzer(include CDMA Test Mode) HP8596E Configuration of Test CAUTION : The test jig and data cable has a voltage drop of 0.15V at FM Max power output, you'd better set the DC power supply is 3.8V for normal test condition. (Nominal voltage of battery is 3.8V at cellular phone) CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 TEST CABLE DESCRIPTION FOR SCH-A212 1. TEST CABLE 2. TEST CABLE CONNECTIONS 1 MHC 172 2 RF CABLE (1.4dB Loss for CDMA800 and AMPS, 2.1dB Loss for PCS) 3BNC CONNECTOR (RF) 4PLUG CONNECT TO SCH-A212 5DATA CABLE 6Dsub 25PIN CONNECTOR (DATA) CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 3. Dsub 25 PIN CONNECTOR PIN DESCRIPTION (TEST CABLE 1, BACK SIDE) DATA DESCRIPTION Dsub CONN. PIN NO. DATA DESCRIPTION Dsub CONN. PIN NO. V_F12,21DP_RX_DATA8 DGND2,4,6,13,19HP_PWR9 BATT15,16,22RI10 C_F3,20CD11 TX_AUDIO5RTS14 DP_TX_DATA7CTS17 RX_AUDIO1DTR18 4. CONVERSION TABLE OF FREQUENCY vs CHANNEL TYPECHANNEL CONVERSION EQUATION REMARK TX FREQUENCY 1 N 799 990 N 1023 F=0.03 N + 825.00 F=0.03 (N-1023) + 825.00 N ; CH NUMBER F ; FREQUENCY (AMPS/CDMA) RX FREQUENCY 1 N 799 990 N 1023 F=0.03 N + 870.00 F=0.03 (N-1023) + 870.00 CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 Change to Test Mode A. To change the phone's state from Normal Mode to Test Mode, You should enter the following keys. :Press[MENU+#] B. The command "2 1" is mode and channel change. "20383" Mode:CDMA Channel number and Push the [ OK ] key to save. C. The command 0 1" is Suspend. D. To finish the Test Mode, You should enter the command " 0 2". Channel Selection and Tx Power Output Level Control 1. CDMA A. Enter to Test Mode [ MENU + # ] B. The command "2 1" is mode and channel change "20383" Mode:CDMA Channel number Push the [ OK ] key to save. C. "0 1" : Suspend. D. "0 2 0 3 8 3 '#' " : Set to '0383' channel. E. "0 7" : Carrier On. F. "3 4" : Spread spectrum to 1.23MHz band width. G."71***":AdjustRFpowerlevel . Set the acurate power with press 'SEND'(power growing up) or 'END'(power growing down). "* * *" means AGC level and AGC level range is from 000 to 511. CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 2. CDMA TEST ITEMSPROCEDURE 1. PREPARANCESet test equipments up. [ MENU + # ] : Enter the Test Mode "0 1" : Suspend Confirm that the phone is in the "CDMA Mode". (If not CDMA Mode, Use Test Command "020""2XXXX" and Push the [ save ] Key to "OK", and enter "0 2" to restart) If you select a wrong key, press "CLR", then enter new command. To exit the Test Mode at any time, just press [0 2]. 2. FREQUENCY ACCURACY "0 1" : Suspend. "0 2 0 3 8 3 '#' " : Set channel to 383. "0 7" : Carrier On. "3 4" : Spread spectrum. "71300'#'":SetAGClevel. Measure the TX frequency : 836.49MHz 300Hz. 3. OCCUPIED CDMA BANDWIDTH "0 1" : Suspend. "0 2 0 3 8 3 '#' " : Set channel to 383. "0 7" : Carrier On. "3 4" : Spread spectrum. "71XXX'#'":EnterAGCCode(XXX)toadjustRFOutputPower. Measure the bandwidth (spec: 1.23MHz). 4. LIMITATIONS ON EMISSIONS "0 1" : Suspend. "0 2 0 3 8 3 '#' " : Set channel to 383. "0 7" : Carrier On. "3 4" : Spread spectrum. "71XXX'#'":EnterAGCCode(XXX)toadjustRFOutputPower. Measure the spurious at F C 900kHz, F C 1.98MHz, 2F C, 3F C, 1/2F C . spec: F C 900kHz below 42dBc/30kHz F C 1.98MHz below 54dBc/30kHz Outside Receive Band 43+10log (PY) PY: Mean Output Power in watts CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 NAM PROGRAMMING NAM features can be programmed as follows: Notes: - If you enter the NAM program mode, each item shows the currenly stored data. Go to the next item by pressing OK . - You can modify the data by entering a new data. - If you enter a wrong digit, press CLR to delete the last digit. Press and hold CLR to delete all digits. - To scroll items backwards or forwards, press the VOLUME button on the left side of the phone. (1)General Setup LCD DisplayKey inFunction MENU #-selects NAM programming NAM Program 1:General 2.NAM1 Setup 3:NAM2 Setup 1-Choose 'General' ESN B0000000 Volume -Electronic Serial Number of the phone is displayed CAI version 3 Volume -Common Air Interface version is displayed 13K/EVRC/8K 13K voice * or # OK Vocoder sample rate - changes the status. -stores it. - 8K is not supported. SCM 01101010 Volume -Station Class Mark displays the power class, transmission, slotted class, dual mode. Lock Code 0000 Volume 4-digit code OK Lock code, current ststus is displayed -to change, enter new code. -stores it Slot Mode Yes * or # OK Slot mode. 'Yes' indicates the slot mode. - changes the status. -stores it. Slot Index 2 Volume 0-7 OK Slot mode index. The higher,the longer sleeping time - to change, enter new one. -stores it CONFIDENTIAL SCH-A212 (Single band CDMA) April 28, 2001 LCD Display Key inFunction NAM Program 1:General 2.NAM1 Setup 3:NAM2 setup 2-Choose 'NAM1 Setup' CDMA TEL NO. 3003003000 number OK MIN1,MIN2 is displayed -to change, enter new one. -stores it. IMSI MCC 000 number OK IMSI Moble Country Code,current code is displayed. -to change, enter new one. -stores it. IMSI MNC 00 number OK IMSI Moble Network Code,current code iβ¦
Text truncated - open the document above for the full version.
RF Exposure Info
SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.910 mW/g, SAR (10g): 0.613 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.1013 [824.70MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 8.41E-2 2.52E-1 4.20E-1 5.89E-1 7.57E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.993 mW/g, SAR (10g): 0.662 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.1013 [824.70MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 9.62E-2 2.89E-1 4.81E-1 6.73E-1 8.66E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.14 mW/g, SAR (10g): 0.760 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0363 [835.89MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 1.06E-1 3.19E-1 5.31E-1 7.44E-1 9.57E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.36 mW/g, SAR (10g): 0.911 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0363 [835.89MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 1.31E-1 3.94E-1 6.56E-1 9.18E-1 1.18E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.907 mW/g, SAR (10g): 0.606 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0777 [848.31MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 8.67E-2 2.60E-1 4.34E-1 6.07E-1 7.80E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.970 mW/g, SAR (10g): 0.647 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0777 [848.31MHz] Conducted Power = 24.5dBm; Flip = Open Test Date -- 05/02/2001 SAR Tot [mW/g] 9.58E-2 2.87E-1 4.79E-1 6.71E-1 8.62E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: Ο = 0.95 mho/m Ξ΅ r = 56.2 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.388 mW/g, SAR (10g): 0.262 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.1013 [824.70MHz]; Flip = Closed Conducted Power = 24.5dBm; Spacing = 1.0cm from flat phantom to phone, w/o beltclip or holster Test Date -- 05/02/2001 SAR Tot [mW/g] 3.56E-2 1.07E-1 1.78E-1 2.49E-1 3.20E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: Ο = 0.95 mho/m Ξ΅ r = 56.2 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.597 mW/g, SAR (10g): 0.390 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.1013 [824.70MHz]; Flip = Closed Conducted Power = 24.5dBm; Spacing = 1.0cm from flat phantom to phone, w/o beltclip or holster Test Date -- 05/02/2001 SAR Tot [mW/g] 5.46E-2 1.64E-1 2.73E-1 3.82E-1 4.91E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: Ο = 0.95 mho/m Ξ΅ r = 56.2 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.394 mW/g, SAR (10g): 0.265 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0363 [835.89MHz]; Flip = Closed Conducted Power = 24.5dBm; Spacing = 1.0cm from flat phantom to phone, w/o beltclip or holster Test Date -- 05/02/2001 SAR Tot [mW/g] 3.42E-2 1.03E-1 1.71E-1 2.39E-1 3.08E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: Ο = 0.95 mho/m Ξ΅ r = 56.2 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.639 mW/g, SAR (10g): 0.435 mW/g SAMSUNG Cellular CDMA Only Phone Model:SCH-A212 Cellular CDMA Mode, Ch.0363 [835.89MHz]; Flip = Closed Conducted Power = 24.5dBm; Spacing = 1.0cm from flat phantom to phone, w/o beltclip or holster Test Date -- 05/02/2001 SAR Tot [mW/g] 5.73E-2 1.72E-1 2.87E-1 4.01E-1 5.16E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSCHA212 -- Cellular CDMA Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: Ο = 0.95 mho/m Ξ΅ r = 56.2 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.386 mW/g, SAβ¦
Text truncated - open the document above for the full version.
RF Exposure Info
Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone Β© 2001 PCTEST Lab FCC ID: A3LSCHA212 (Tx 824-849 MHz) NVLAP Lab Code: 100431-0 SAMSUNG Single-Mode Cellular CDMA Phone
RF Exposure Info
Β© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road β’ Columbia, MD 21045 β’ U.S.A. TEL (410) 290-6652 β’ FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG Electronics Co., Ltd. Dates of Tests: May 02-04, 2001 146 Maetun-3 Dong, Paldal-Ku, Test Report S/N: SAR.210501266.A3L Suwon City, Kyungki-Do, KOREA 441-742 Test Site: PCTEST Lab, Columbia, MD USA Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSCHA212 APPLICANT SAMSUNG Electronics Co., Ltd. EUT Type: Single-Mode Cellular CDMA Internet Phone Tx Frequency: 824.70 β 848.31 MHz Rx Frequency: 869.70 β 893.31 MHz Max. RF Output Power: 0.374 W ERP (25.733 dBm) Max. SAR Measurement(s): 1.360 W/kg (1g) Cellular CDMA Head SAR; 0.639 W/kg (1g) Cellular CDMA Body SAR; 0.671 W/kg (10g) Cellular CDMA Hand SAR; Trade Name/Model(s): SAMSUNG SCH-A212 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) Application Type: Certification Serial Number: n/a (pre production) FCC Rule Part(s): 2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210501266.A3L SAR Measurement Report FCC Part 22 Certification Β© 2001 PCTEST Lab i Table of Contβ¦
Text truncated - open the document above for the full version.
Contact Information
Applicant
Jenni Chun(General Manager)
Technical Contact
PCTEST Engineering Laboratory, Inc.Randy Ortanez
[email protected]410-290-6652
6660-B Dobbin Road Β· Columbia, Maryland Β· United States
Non-Technical Contact
PCTEST Engineering Laboratory, Inc.Randy Ortanez
[email protected]410-290-6652
Test Firm
PCTEST Engineering Laboratory, Inc.Randy Ortanez
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 22.901(d) | 824.7 MHz - 848.31 MHz | 374.00 mW | 1M25F9W | 2.5000000000 ppm |
