A3LSCHI829Portable Handset

User manual SCH-I829 Draft 6.1 2012-09-08 Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information Refer to—pages with related information; for example: p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [ ](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or perman…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea December 3, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSCHI829 Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the device will be marketed without the battery installed. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 November 6, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Samsung Electronics hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): SCH-I829 We affirm that between SIEMIC and Samsung Electronics, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 November 6, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: A3LSCHI829 We hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, pursuant to Public Notice DA 04- 1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

Label and Location Samsung Phone Model: SCH-I829 FCC ID: A3LSCHI829 Label: Location: Top Back plate of device Bottom Label is placed inside of the battery compartment. Label

SAMSUNG ELECTRONICS CO., LTD. PORTABLE HANDSET Model: SCH-I829 Issued Date: Dec 11th, 2012 Report No.: SL12112003-SAM-001_FCC (SAR) Rev1.0 (This report supersedes: SL12112003-SAM-001_FCC (SAR)) This Test Report is Issued Under the Authority of: David Zhang Compliance Engineer Choon Sian Ooi Engineering Reviewer Modifications made to the product : None This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of SAMSUNG ELECTRONICS CO., LTD. Model : SCH-I829 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 Serial# SL12112003-SAM-001_FCC (SAR) Rev1.0 Issue Date Dec 11th, 2012 Page 2 of 95 www.siemic.com REDIT SIEMIC SIEM Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom , SAR Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom , SAR Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety , SAR Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety, SAR Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report of SAMSUNG ELECTRONICS CO., LTD. Model : SCH-I829 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 Serial# SL12112003-SAM-001_FCC (SAR) Rev1.0 Issue Date Dec 11th, 2012 Page 3 of 95 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of SAMSUNG ELECTRONICS CO., LTD. Model : SCH-I829 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 Serial# SL12112003-SAM-001_FCC (SAR) Rev1.0 Issue Date Dec 11th, 2012 Page 4 of 95 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ............................................................................................................. 6 2 TECHNICAL DETAILS .................................................................................................................................................. 7 3 INTRODUCTION ........................................................................................................................................................... 8 4 SAR MEASUREMENT SETUP ....................................................................................................................................... 9 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT ............................................................................................................ 19 6 SYSTEM AND LIQUID VALIDATION ............................................................................................................................ 20 7 TYPE A MEASUREMENT UNCERTAINTY ................................................................................................................... 28 8 OUTPUT POWER VERIFICATION................................................................................................................................ 30 9 SAR TEST RESULTS .................................................................................................................................................. 33 ANNEX A. TEST INSTRUMENT & METHOD......................................................................................................................... 65 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................................... 66 ANNEX C CALIBRATION REPORTS .................................................................................................................................. 68 Title: RF Test Report of SAMSUNG ELECTRONICS CO., LTD. Model : SCH-I829 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 Serial# SL12112003-SAM-001_FCC (SAR) Rev1.0 Issue Date Dec 11th, 2012 Page 5 of 95 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of SAMSUNG ELECTRONICS CO., LTD. Model : SCH-I829 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 Serial# SL12112003-SAM-001_FCC (SAR) Rev1.0 Issue Date Dec 11th, 2012 Page 6 of 95 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programmed was to demonstrate compliance of the SAMSUNG ELECTRONICS CO., LTD. Model: SCH-I829 against the current Stipulated Standards. The Portable Handset has demonstrated compliance with the C95.1, IEEE 1528, OET Bulletin 65 Supplement C , Safety Code 6 and EN 62209-2: 2010 . The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : Portable Handset Model No : SCH-I829 Serial No : FJ-302-A H/W version : I829.04 S/W version : I829KELJ1 BB Chip : MSM8625/ESC6270 Wi-Fi Chipset : AR6005G Bluetooth Chipset : CSR8810 IMEI : N/A Input Power : 3.7VDC Maximum Conducted Output Power to Antenna :…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS CO., LTD. Portable Handset Model: SCH-I829 Issued Date : November 29th ,2012 Report No.: SL12112003-SAM-001(Part 24E) (This report supersedes: None ) Modifications made to the product : None This Test Report is Issued Under the Authority of: Choon Sian Ooi Test Engineer David Zhang Engineering Reviewer This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 2 of 64 www.siemic.com Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 3 of 64 www.siemic.com This page has been left blank intentionally. Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 4 of 64 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ................................................................................................................ 6 2 TECHNICAL DETAILS ...................................................................................................................................................... 7 4 TEST SUMMARY ............................................................................................................................................................. 9 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ........................................................................................ 10 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................................... 29 ANNEX B EUT PHOTOGRAPHS ............................................................................................................................................ 34 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ...................................................................................................... 34 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ...................................................................................................... 34 ANNEX D USER MANUAL, BLOCK & CIRCUIT DIAGRAM ..................................................................................................... 38 ANNEX E SIEMIC ACCREDITATION ...................................................................................................................................... 39 Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 5 of 64 www.siemic.com This page has been left blank intentionally. Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 6 of 64 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programme was to demonstrate compliance of the Samsung Electronics Co., Ltd., Portable Handset, and Model: SCH-I829 against the current Stipulated Standards. The Portable Handset have demonstrated compliance with the FCC Part 24E. Applicant & EUT Information Applicant Information Applicant / Client Samsung Electronics Co., Ltd. 416 Maetan 3-Dong , Yeongtong-guSuwon-si, Gyeonggi-do Manufacturer1 Samsung Electronics Co., Ltd. 94-1, Imsu-dong, Gumi-si, Gyengsangbuk-do, 730-722, Republic of Korea Samsung Electronics HuiZhou Co., Ltd. 516229, Chenjiang Town, HuiZhou City, Guangdong Province, China EUT Information EUT Description : Portable Handset Model Name : SCH-I829 Serial No : N/A Input Power : 3.7Vdc Frequency : Bluetooth (2402MHz-2480MHz) 2412~2472MHz (20MHz bandwidth) GSM 1900:1850.2-1909.8MHz Radiated power : Bluetooth: 7.53dBm, 802.11b:15.90dBm, 802.11g: 13.28dBm, 802.11n20: 11.11dBm, GSM: 31.93dBm (EIRP) Modulation : Bluetooth: GFSK, π/4QDPSK, 8-DPSK WLAN b/g/n : DSSS/OFDM GSM/GRPS: GMSK EDGE: 8-PSK Classification Per Stipulated Test Standard : PCS Licensed Transmitter Held to Ear (PCE) Antenna PCS: HIL-01C34-0000AA, Antenna Gain: -0.84dBi Bluetooth/ WLAN: 1.99 dBi Title: RF Test Report Portable Handset Model : SCH-I829 To FCC Part 24E Serial# SL12112003-SAM-001(Part 24E) Issue Date November 29th ,2012 Page 7 of 64 www.siemic.com 2 TECHNICAL DETAILS Laboratory performing the tests SIEMIC Laboratories 775 Montague Expressway Milpitas, California 95025, USA Da…

Text truncated - open the document above for the full version.

Radiated Emission Radiated Emission Test Setup (30MHz – 1GHz) Radiated Emission Test Setup (30MHz – 1GHz) Radiated Emission Test Setup (Above 1GHz) Radiated Emission Test Setup (above 1GHz) Frequency Stability

Test Setup View – Left Cheek Position Test Setup View – Left Tilt Position Test Setup View – Right Cheek Position Test Setup View – Right Tilt Position Test Setup View – Back (LCD down) Position Test Setup View – Front (LCD Up) Position Test Setup View – Top Position Test Setup View – Bottom Position Test Setup View – Left Position Test Setup View – Right Position
