SGH-T339 Series PORTABLE Triple-BAND MOBILE PHONE User Manual Please read this manual before operating your phone, and keep it for future reference. T339_UVHB2_CH_021408_F1 Intellectual Property All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers. Samsung Telecommunications America (STA), LLC Headquarters:Customer Care Center: 1301 E. Lookout Drive1000 Klein St. Richardson, TX 75082Plano, TX 75074 Toll Free Tel: 1.888.987.HELP (4357) Internet Address: http://www.samsungusa.com © 2008 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc. and its related entities. Do you have questions about your Samsung Mobile Phone? For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at: www.samsungwireless.com/support GH68-17342A Printed in Korea Openwave ® is a registered Trademark of Openwave, Inc. RSA ® is a registered Trademark of RSA Security, Inc. Disclaimer of Warranties; Exclusion of Liability EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS. 1 Table of Contents Section 1: Getting Started .............................................. 4 Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . . . . 10 Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Section 2: Understanding Your Phone ......................... 13 Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Open View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Closed View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 View Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Section 3: Wi-Fi ............................................................ 20 Introducing Your T-Mobile HotSpot @Home Capable Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Connecting to Wi-Fi for the First Time . . . . . . . . . . . . . . . . . . . 21 Using Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Connecting to Wi-Fi Networks . . . . . . . . . . . . . . . . . . . . . . . . . 23 Get Security Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Use Get Security Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Add New Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Add From Available Network Option . . . . . . . . . . . . . . . . . . . . 31 Create Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 T-Mobile Wi-Fi Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Section 4: Call Functions ............................................. 34 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Adjusting the Call Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Selecting Functions and Options . . . . . . . . . . . . . . . . . . . . . . 39 Muting or Sending Key Tones . . . . . . . . . . . . . . . . . . . . . . . . . 42 Section 5: Menu Navigation ......................................... 45 Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Sectio…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: February 29, 2008 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, http Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSGHT339 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics PERMANENT 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Steve Kim General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 DATE : February 26, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: HAC filing FCC ID: A3LSGHT339 Gentlemen: We, Samsung Electronics, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Steve Kim General Manager American QA Lab SAMSUNG Electronics America INC. SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220

From: 함재준 Sent: Tuesday, March 11, 2008 12:46 AM To: PCTEST TCB Subject: Re: Questions Regarding FCC ID: A3LSGHT339 Attachments: SGH-T339 Wifi 인증관련SPEC SHEET(영문판)_20080119.pdf Page 1 of 3Samsung Enterprise Portal mySingle 3/11/2008 Dear Gregory, For the question #1, the WLAN is not capable of simultaneous transmission with the GSM/EDGE transmitter. Best Regards Geoffrey ------- Original Message ------- Sender : PCTEST TCB<[email protected]> Date : 2008-03-07 08:38 (GMT+09:00) Title : Questions Regarding FCC ID: A3LSGHT339 To: Mr. David Kim / Samsung Electronics Co., Ltd. From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: A3LSGHT339 Applicant: Samsung Electronics Co., Ltd. Correspondence Reference Number: A3L80118 Confirmation Number: 802250118-21 Date of Original Email: March 6, 2008 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Is the WLAN capable of simultaneous transmission with the GSM/EDGE transmitter? The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] Page 2 of 3Samsung Enterprise Portal mySingle 3/11/2008 This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. ------------------------------------------------ Geoffrey Ham Regulatory Compliance Group SAMSUNG ELECTRONICS CO.,LTD. ------------------------------------------------- Information in this email and any attachments is confidential and intended solely for the use of the individual(s) to whom it is addressed or otherwise directed. Please note that any views or opinions presented in this email are solely those of the author and do not necessarily represent those of the Company. Page 3 of 3Samsung Enterprise Portal mySingle 3/11/2008

1. main ant photo 2. WiFi ant photo 3. BT ant photo 4. the distance between the antennas 56mm 57mm 3mm

of 42 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SGH-T339 FCC ID (Requested): A3LSGHT339 Job No: FF-014 Report No: FF-014-S1 Date issued: Apr.03, 2008 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By DK LEE - Test Engineer Authorized By JH NAM - Technical Manager Contents 1. GENERAL INFORMATION............................................................................................................. 3 2. DESCRIPTION OF DEVICE ........................................................................................................... 3 3. DESCRIPTION OF TEST EQUIPMENT ......................................................................................... 4 3.1 SAR Measurement Setup ......................................................................................................4 3.2 E-field Probe .......................................................................................................................... 6 3.3 SAM Phantom ........................................................................................................................ 8 3.4 Brain & Muscle Simulating Mixture Characterization ............................................................. 8 3.5 Device Holder for Transmitters ..............................................................................................9 3.6 Validation Dipole .................................................................................................................... 9 3.7 Equipment Calibration.......................................................................................................... 10 4. SAR MEASUREMENT PROCEDURE ......................................................................................... 11 5. DESCRIPTION OF TEST POSITION ........................................................................................... 12 5.1 SAM Phantom Shape...........................................................................................................12 5.2 Cheek/Touch Position .......................................................................................................... 12 5.3 EAR/Tilt 15° Position ............................................................................................................ 14 5.4 Body Holster/Belt Clip Configurations.................................................................................. 15 6. MEASUREMENT UNCERTAINTY................................................................................................ 17 7. SYSTEM VERIFICATION ............................................................................................................. 20 7.1 Tissue Verification ................................................................................................................ 20 7.2 Test System Validation ......................................................................................................... 20 8. SAR MEASUREMENT RESULTS ................................................................................................ 21 8.1 Measurement Results(GSM850 Right Head SAR - Touch) ................................................. 23 8.2 Measurement Results(GSM850 Right Head SAR - Tilt) ...................................................... 24 8.3 Measurement Results(GSM850 Left Head SAR - Touch).................................................... 25 8.4 Measurement Results(GSM850 Left Head SAR - Tilt)......................................................... 26 8.5 Measurement Results(GPRS850 Body SAR without Holster) ............................................. 27 8.6 Measurement Results(GSM1900 Right Head SAR - Touch) ............................................... 28 8.7 Measurement Results(GSM1900 Right Head SAR - Tilt) .................................................... 29 8.8 Measurement Results(GSM1900 Left Head SAR - Touch).................................................. 30 8.9 Measurement Results(GSM1900 Left Head SAR - Tilt)....................................................... 31 8.10 Measurement Results(GPRS1900 Body SAR without Holster)......................................... 32 8.11 Measurement Results(WLAN Right Head SAR - Touch) ................................................... 33 8.12 Measurement Results(WLAN Right Head SAR - Tilt) ........................................................ 34 8.13 Measurement Results(WLAN Left Head SAR - Touch) ..................................................... 35 8.14 Measurement Results(WLAN Left Head SAR - Tilt) .......................................................... 36 8.15 Measurement Results(WLAN Body SAR without Holster)................................................. 37 9. CONCLUSION .............................................................................................................................. 38 10. REFERENCES ............................................................................................................................ 39 1. GENERAL INFORMATION Test Sample : Dual-Band GSM/EDGE 850/1900 Phone with Bluetooth and WLAN Model Number : SGH-T339 Serial Number : Identical prototype (S/N : # FF-014-A) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : HJ JUNG Phone : +82-31-301-0993 Fax : +82-31-279-4288 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Feb.05, 2008 ~ Feb.12, 2008 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.2 ~ 848.8 MHz (GSM850) 1850.20 ~ 1909.80 MHz (GSM1900) 2400 ~ 2483.5 MHz (WLAN) 2402 ~ 2480 MHz (Bluetooth) Rx Freq. Range : 869.2 ~ 893.8 MHz (GSM850) 1930.20 ~ 1989.80 MHz (GSM1900) 2400 ~ 2483.5 MHz (WLAN) 2402 ~ 2480 MHz (Bluetooth) Antenna Manufact…
