A3LSMP600Portable WiFi Tablet with Bluetooth and ANT+

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: August 30, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSMP600 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description PERMANENT 3 Schematics 4 External Photos 5 Internal Photos 6 Test-Setup Photos SHORT-TERM 7 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea August 29, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSM P600 Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID label is located on the rear of the device with the battery installed. At this time the FCC ID is readily visible to the user. The label is permanently engraved by laser and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 External Photos EUT Type: Tablet Computer Page 1 of 4 © 2013 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 External Photos EUT Type: Tablet Computer Page 2 of 4 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 External Photos EUT Type: Tablet Computer Page 3 of 4 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 External Photos EUT Type: Tablet Computer Page 4 of 4 © 2013 PCTEST Engineering Laboratory Inc.

Label and Location Samsung Model: SM-P600 FCC ID: A3LSMP600 Label: Location: Top Back of device Bottom FCC ID is printed on bottom of the device

SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 1 of 11 © 2013 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 2 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 3 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 4 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 5 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 6 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 7 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 8 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 9 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 10 of 11 © 2013 PCTEST Engineering Laboratory Inc. SAMSUNG ELECTRONICS FCC ID: A3LSMP600 Model: SM-P600 Internal Photos EUT Type: Tablet Computer Page 11 of 11 © 2013 PCTEST Engineering Laboratory Inc.

FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 1 of 21 0Y1308121575.A3L 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 08/16/13 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Document Serial No.: 0Y1308121575.A3L FCC ID: A3LSMP600 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. DUT Type: Portable Tablet Application Type: Certification FCC Rule Part(s): CFR §2.1093 Model(s): SM-P600 Test Device Serial No.: Pre-Production [S/N: 89] DTS2.4 GHz WLAN2412 - 2462 MHz13.22 DTS5.8 GHz WLAN5745 - 5825 MHz7.50 NII5.2 GHz WLAN5180 - 5240 MHz7.44 NII5.3 GHz WLAN5260 - 5320 MHz7.50 NII5.5 GHz WLAN5500 - 5700 MHz7.50 DSS/DTSBluetooth2402 - 2480 MHz6.11 1 gm Body (W/kg) 1.06 N/A SAR Band & ModeTx Frequency Measured Conducted Power [dBm] Equipment Class Note: Powers in the above table represent output powers for the SAR test configurations and may not represent the highest output powers for all configurations for each mode. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 1.7 of this report; for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR EVALUATION REPORT FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 2 of 21 0Y1308121575.A3L 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 TABLE OF CONTENTS 1 DEVICE UNDER TEST ....................................................................................................................3 2 INTRODUCTION ..............................................................................................................................6 3 DOSIMETRIC ASSESSMENT .........................................................................................................7 4 RF EXPOSURE LIMITS ...................................................................................................................8 5 FCC MEASUREMENT PROCEDURES ...........................................................................................9 6 RF CONDUCTED POWERS ......................................................................................................... 10 7 SYSTEM VERIFICATION .............................................................................................................. 14 8 SAR DATA SUMMARY ................................................................................................................. 15 9 SAR MEASUREMENT VARIABILITY ........................................................................................... 16 10 EQUIPMENT LIST ......................................................................................................................... 17 11 MEASUREMENT UNCERTAINTIES ............................................................................................ 18 12 CONCLUSION ............................................................................................................................... 19 13 REFERENCES .............................................................................................................................. 20 APPENDIX A: SAR TEST PLOTS APPENDIX B: SAR DIPOLE VERIFICATION PLOTS APPENDIX C: PROBE AND DIPOLE CALIBRATION CERTIFICATES APPENDIX D: SAR TISSUE SPECIFICATIONS APPENDIX E: SAR SYSTEM VALIDATION APPENDIX F: SAR TEST SETUP PHOTOGRAPHS FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 3 of 21 0Y1308121575.A3L 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 1 DEVICE UNDER TEST 1.1 Device Overview 2.4 GHz WLANData2412 - 2462 MHz 5.8 GHz WLANData5745 - 5825 MHz 5.2 GHz WLANData5180 - 5240 MHz 5.3 GHz WLANData5260 - 5320 MHz 5.5 GHz WLANData5500 - 5700 MHz BluetoothData2402 - 2480 MHz ANT+Data2402 - 2480 MHz Band & ModeOperating ModesTx Frequency 1.2 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values were scaled to the maximum allowed power to determine compliance per KDB Publication 447498 D01v05. Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal IEEE 802.11ac (5 GHz 80MHz BW 7.5 7.0 Bluetooth 9.5 9.0 IEEE 802.11n (5 GHz) 7.5 Bluetooth LE 6.5 IEEE 802.11n (2.4 GHz) 11.5 IEEE 802.11a (5 GHz) 7.5 Modulated Average (dBm) IEEE 802.11b (2.4 GHz) 13.5 IEEE 802.11g (2.4 GHz) Mode / Band 13.0 12.0 11.0 7.0 7.0 6.0 12.5 FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 4 of 21 0Y1308121575.A3L 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 1.3 DUT Antenna Locations To p Left Bottom 2.4 GHz WIFI/BT and 5 GHz WIFI Tx/Rx Ant GPS Rx Ant 243 mm 172 mm Right Front View of DUT Note: Exact antenna dimensions and separation distances are shown in the Technical Descriptions in the FCC Filing. Figure 1-1 DUT Antenna Locations Table 1-1 Sid…

Text truncated - open the document above for the full version.

FCC ID: A3LSMP600 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 20 0Y1308121578.A3L August 22, 2013 Tablet Computer © 2013 PCTEST Engineering Laboratory, Inc. v2.0 6/17/2013 Company Name: Date of Testing: Samsung Electronics Co., Ltd. August 22, 2013 129, Samsung-ro, Yeongtong-gu Test Site/Location: Suwon-city, Gyeonggi-do, 443-803 PCTEST Lab. Columbia, MD, USA Republic of Korea Test Report Serial No.: 0Y1308121578.A3L FCC ID: A3LSMP600 COMPANY: Samsung Electronics Co., Ltd. Model(s): SM-P600 EUT Type: Tablet Computer Type of Device: Client Only Device, No Radar Detection Capability Frequency Range: 5260 – 5320 MHz (UNII-II Band) 5500 – 5700 MHz (UNII-III Band) Output Power: 5.623 mW (7.50 dBm) Conducted (802.11a UNII Band II) 5.623 mW (7.50 dBm) Conducted (802.11a UNII Band III) FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15.407(UNII) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC 06-96 Appendix B Compliance Measurement Procedures for Unlicensed-National Information Infrastructure Devices Operating in the 5.25 – 5.35 GHz and 5.47 – 5.725 GHz Bands Incorporating Dynamic Frequency Selection. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.407 / IC RSS-210 DFS FCC ID: A3LSMP600 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 20 0Y1308121578.A3L August 22, 2013 Tablet Computer © 2013 PCTEST Engineering Laboratory, Inc. v2.0 6/17/2013 TABLE OF CONTENTS FCC PART 15.407 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION ...................................................................................................................................... 4 1.1 SCOPE ........................................................................................................................................................... 4 1.2 EVALUATION PROCEDURE ......................................................................................................................... 4 1.3 SUMMARY OF TEST RESULTS ................................................................................................................... 4 2.0 PRODUCT INFORMATION ..................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION......................................................................................................................... 5 2.2 EUT CAPABILITIES ....................................................................................................................................... 5 2.3 MODIFICATIONS ........................................................................................................................................... 5 3.0 DESCRIPTION OF DYNAMIC FREQUENCY SELECTION TEST ......................................................... 6 3.1 APPLICABILITY ............................................................................................................................................. 6 3.2 REQUIREMENTS .......................................................................................................................................... 6 3.3 DFS DETECTION THRESHOLD VALUES .................................................................................................... 8 3.4 PARAMETERS OF DFS TEST SIGNALS ...................................................................................................... 8 3.5 PROCEDURE ................................................................................................................................................ 9 4.0 TEST EQUIPMENT ................................................................................................................................ 11 4.1 ADDITIONAL EQUIPMENT ......................................................................................................................... 11 5.0 TEST PLOTS AND DATA - UNII BAND II ............................................................................................. 12 6.0 TEST PLOTS AND DATA - UNII BAND III ............................................................................................ 16 7.0 CONCLUSION ....................................................................................................................................... 20 FCC ID: A3LSMP600 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 20 0Y1308121578.A3L August 22, 2013 Tablet Computer © 2013 PCTEST Engineering Laboratory, Inc. v2.0 6/17/2013 DFS MEASUREMENT REPORT FCC Part 15.407 § 2.1033 General Information APPLICANT: Samsung Electronics Co., Ltd. APPLICANT ADDRESS: 129, Samsung-ro, Yeongtong-gu Suwon-city, Gyeonggi-do, 443-803, Republic of Korea TEST SITE: PCTEST ENGINEERING LABORATORY, INC. TEST SITE ADDRESS: 7185 Oakland Mills Road, Columbia, MD 21046 USA FCC RULE PART(S): Part 15.407(h) BASE MODEL: SM-P600 FCC ID: A3LSMP600 Test Device Serial No.: BT/Wifi cond. Production Pre-Production Engineering DEVICE CLASSIFICATION: Client Only, No Radar Detection DATE(S) OF TEST: August…

Text truncated - open the document above for the full version.

FCC ID: A3LSMP600 FCC Pt. 15.407 802.11a/n/ac UNII MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 87 0Y1308121577.A3L August 13 - 29, 2013 Tablet Computer © 2013 PCTEST Engineering Laboratory, Inc. V 2.3 05/07/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. August 13 - 29, 2013 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Test Report Serial No.: 0Y1308121577.A3L FCC ID: A3LSMP600 APPLICANT: Samsung Electronics, Co. Ltd. Application Type: Certification Model(s): SM-P600 EUT Type: Tablet Computer FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15.407 Test Procedure(s): KDB 789033 v01r03, KDB 644545 v01r01 Max. Power (mW) Max. Power (dBm) 1205180 - 52405.4957.40 2205260 - 53205.6237.50 3205500 - 57005.6237.50 1205180 - 52405.2727.22 2205260 - 53205.5857.47 3205500 - 57005.5987.48 1405190 - 52305.4837.39 2405270 - 53105.2607.21 3405510 - 56705.6237.50 18052105.5467.44 28052905.6237.50 38055305.5467.44 802.11ac 802.11n Channel Bandwidth (MHz) 802.11a 802.11n Conducted Power Mode Tx Frequency (MHz) UNII Band This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 789033 v01r03 and KDB 644545 v01r01. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.407 (UNII) FCC ID: A3LSMP600 FCC Pt. 15.407 802.11a/n/ac UNII MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 87 0Y1308121577.A3L August 13 - 29, 2013 Tablet Computer © 2013 PCTEST Engineering Laboratory, Inc. V 2.3 05/07/2013 TABLE OF CONTENTS FCC PART 15.407 MEASUREMENT REPORT .................................................................................................. 3 1.0 INTRODUCTION ...................................................................................................................................... 4 1.1 SCOPE ........................................................................................................................................................... 4 1.2 PCTEST TEST LOCATION ............................................................................................................................ 4 2.0 PRODUCT INFORMATION ..................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION......................................................................................................................... 5 2.2 DEVICE CAPABILITIES ................................................................................................................................. 5 2.3 TEST CONFIGURATION ............................................................................................................................... 5 2.4 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ...................................................................................... 5 2.5 LABELING REQUIREMENTS ........................................................................................................................ 5 3.0 DESCRIPTION OF TEST ........................................................................................................................ 6 3.1 EVALUATION PROCEDURE ......................................................................................................................... 6 3.2 AC LINE CONDUCTED EMISSIONS ............................................................................................................. 6 3.3 RADIATED EMISSIONS ................................................................................................................................ 7 4.0 ANTENNA REQUIREMENTS .................................................................................................................. 8 5.0 TEST EQUIPMENT CALIBRATION DATA .............................................................................................. 9 6.0 TEST RESULTS .................................................................................................................................... 10 6.1 SUMMARY ................................................................................................................................................... 10 6.2 26DB BANDWIDTH MEASUREMENT – 802.11A/N/AC .............................................................................. 11 6.3 UNII OUTPUT POWER MEASUREMENT – 802.11A/N/AC ........................................................................ 28 6.4 PEAK POWER SPECTRAL DENSITY – 802.11A/N/AC .............................................................................. 30 6.5 PEAK EXCURSION RATIO – 802.11A/N/AC ............................................................................................... 46 6.6 FREQUENCY STABILITY ............................................................................................................................ 50 6.7 RADIATED SPURIOUS EMISSION MEASUREMENTS .............................................................................. 53 6.8 RADIATED BAND EDGE MEASUREMENTS (20MHZ BW) ........................................................................ 61 6.9 RADIATED BAND EDGE MEASUREMENTS (40MHZ BW) …

Text truncated - open the document above for the full version.

FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 1 of 2 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 APPENDIX F: SAR TEST SETUP PHOTOGRAPHS FCC ID: A3LSMP600 SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 2 of 2 08/16/13 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 SAR Test Setup Photo 1 – Back side at 0.0 cm SAR Test Setup Photo 2 – Right Edge at 0.0 cm
