A3LSMR750BCellular GSM/EDGE/UMTS Wrist Device with WLAN and Bluetooth

User manual SM-R750B Draft 6.1 Only for Approval Page 1 of 40 QUICK REFERENCE MANUAL Page 2 of 40 Support This guide provides you with the information you need to get started. For more information and additional support, please visit the Samsung.com support page: • Get support for your device online. • Review your device’s User Manual and troubleshooting FAQs. • Review troubleshooting solutions. NOTE: Devices and software are constantly evolving—the screen images and icons you see here are for reference only. NOTE: This device should only be used with firmware versions that have been approved for use by the carrier and the device manufacturer. If unauthorized firmware is placed on the device it will not function. For a list of compatible smartphones, please visit: www.samsung.com/us/galaxygearsupport Page 3 of 40 Device Functions NOTE: Swipe down on the display screen to go back from your current on-screen application or menu. Speaker Wristband Buckle Display/ Touch Screen Photo Page 4 of 40 FrameMicrophone 2Metal Pin Power/ Home Joint Microphone 1 Photo Page 5 of 40 Setting Up Your Device Charging the Device 1. Before turning on your Galaxy Gear™ for the first time, charge it fully. 2. In a single motion, slide and hold the switch to open the cover of the Charging cradle. 3. Carefully place the device onto the cradle, make sure to align the connector plates to the charging pins. 4. Firmly close the cover. 5. Connect the USB cable to the charging head. 6. Insert the USB cable connector into the charging cradle’s charger jack. 7. Plug the charging head into a standard AC power outlet. The device turns on and indicates its charge state. 8. When charging is finished, first unplug the charger’s power plug from the AC wall outlet, then disconnect the charger’s connector from the device. Page 6 of 40 Turning Your Device On and Off 1. To turn ON, press and hold the Power/Home key. 2. To turn OFF, press and hold Power/Home key. Photo Page 7 of 40 Connection Pairing the Devices Automatically 1. Activate NFC on the smartphone and turn on your Galaxy Gear. 2. Turn your Charging cradle around and tap it to the back of the smartphone (as previously shown). 3. Tap (Accept) on the Galaxy Gear screen, confirm the PIN codes match, and tap OK on your smartphone to confirm the pairing request. 4. Read the on-screen legal and disclaimer information and accept the terms and conditions to complete the process. 5. Read the on-screen tips and tap Close. 6. Verify the entry now shows “Connected” within the Gear Manager application and the icon appears at the top of your smartphone’s screen. NOTE: If the connection process fails, restart both devices and repeat the steps above. Page 8 of 40 Pairing the Devices Manually NOTE: Use this process if NFC automatic connection fails. 1. Activate Bluetooth on the smartphone, and then tap the previously installed (Gear Manager). 2. If the Gear Manager has not yet been used to pair a Gear, tap Connect manually g OK. - or - Tap the paired device from within the Paired Gear area of the screen and select Connect new Gear g OK g Connect manually. 3. Tap the listed on-screen GALAXY Gear device. 4. Tap (Accept) on the Galaxy Gear screen, confirm the PIN codes match, and tap OK on your smartphone to confirm the pairing request. 5. Read the on-screen legal and disclaimer information and accept the terms and conditions. 6. Read the on-screen tips and tap Close. 7. Verify the entry now shows “Connected” within Gear Manager and appears on the smartphone. NOTE: If the connection process fails, restart both devices and repeat the steps above. Page 9 of 40 Navigation & Gestures Waking the Device ¬Shake the Galaxy Gear on your wrist or press the Power/Home key. Screen Navigation SwipeTapDouble-tap • Swipe left or right across the Home screen to view the favorite functions . • Tap on the screen to select an on-screen item. • Double-tap the screen simultaneoulsy once with two fingers to: • Access the Brightness and Volume controls. • View Battery and Bluetooth connection status. Photo Photo Photo Page 10 of 40 Security Securing Your Galaxy Gear NOTE: Although Galaxy Gear can be paired and synchronized with your smartphone, it is not secured. It is recommended that you use the Gear Manager to change the default name of your Galay Gear. 1. From the Home (Clock) screen, swipe across the display and select () Apps g Settings g Privacy lock g Privacy lock. 2. Select Pattern and follow the on-screen instructions to create an unlock pattern. Finding My Smartphone 1. From the Home (Clock) screen, swipe across the Galaxy Gear display and select () Apps g Find my device g Start. 2. Once you have located the smartphone, touch and slide across the screen to turn off the alert. Page 11 of 40 Calling Features Making a Call 1. From the Home (Clock) screen, swipe across the display and select () Apps g Dialer. 2. Enter the number you wish to call and tap to place the call. • If you make a mistake while dialing, tap to clear the last digit. Touch and hold to clear the entire sequence. Making a Call using Logs 1. From the Home (Clock) screen, swipe across the display and select () Logs. 2. Tap an entry and select (Call). Sending a Call to the Device ¬From within an active call, tap () Send to Device. Page 12 of 40 Sending a Call to the Galaxy Gear ¬From within an active call screen on the smartphone, tap Headset (Bluetooth Headset Off) to turn the connection back on and send the call to the Galaxy Gear. Ending a Call ¬From within an active call, tap (End Call). Answering a Call ¬At the incoming call screen, touch and slide (Answer) across the screen to the right to answer. Rejecting a Call ¬At the incoming call screen, touch and slide (Reject) across the screen to the left to route the call to your voicemail system. Page 13 of 40 Messaging Viewing a New Message on Galaxy Gear ¬Tap the new on-screen notification. NOTE: To check notifications manually, swipe across the screen and tap Notifications. Replying to…

Text truncated - open the document above for the full version.

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: Sep. 12 2014 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. FCC ID: A3LSMR750B Sincerely, CHANHO, YOUN General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea Sep 12, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMR750B Gentlemen: We hereby provide the label statement letter for the above-mentioned device by the label statement policy of KDB 784748 D01. The label statement is as follows: The FCC ID label is located on the rear of the device. At this time the FCC ID is readily visible to the user. The label is permanently engraved by laser and not easily removed from the device. This st atement could not be included in the label. So we inform you of it through this letter. Should yo u hav e any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: Sep. 12, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSMR750B To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription 1 Block Diagram 2 Operational Description 3 Schematics PERMANENT 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, CHANHO, YOUN General Manager American QA Lab SAMSUNG Electronics America INC.

Label and Location Model: FCC ID: SM-R750B A3LSMR750B Label & Location: Top Back (Rear) of device Bottom

FCC ID: A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 1 of 31 0Y1408191749.A3L 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 08/20/14 - 08/26/14 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Document Serial No.: 0Y1408191749.A3L FCC ID: A3LSMR750B APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. DUT Type: Portable Wrist Device Application Type: Certification FCC Rule Part(s): CFR §2.1093 Model(s): SM-R750B 1 gm Head (W /kg) 10 gm Extremity (W /kg) TNBGSM/GPRS/EDGE 850824.20 - 848.80 MHz0.100.20 TNBUMTS 850826.40 - 846.60 MHz< 0.10.11 DTS2.4 GHz WLAN2412 - 2462 MHz0.110.24 DSSBluetooth2402 - 2480 MHz0.21 DTSBluetooth LE2402 - 2480 MHz 0.200.44 < 0.1 Band & ModeTx Frequency Equipment Class Simultaneous SAR per KDB 690783 D01v01r03: SAR N/A This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 1.7 of this report; for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. The SAR Tick is an initiative of the Mobile Manufacturers Forum (MMF). While a product may be considered eligible, use of the SAR Tick logo requires an agreement with the MMF. Further details can be obtained by emailing: [email protected]. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR EVALUATION REPORT FCC ID: A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 2 of 31 0Y1408191749.A3L 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 TABLE OF CONTENTS 1 DEVICE UNDER TEST ....................................................................................................................3 2 INTRODUCTION ..............................................................................................................................7 3 DOSIMETRIC ASSESSMENT .........................................................................................................8 4 TEST CONFIGURATION POSITIONS FOR WRIST-WORN DEVICES ..........................................9 5 RF EXPOSURE LIMITS ................................................................................................................ 10 6 FCC MEASUREMENT PROCEDURES ........................................................................................ 11 7 RF CONDUCTED POWERS ......................................................................................................... 14 8 SYSTEM VERIFICATION .............................................................................................................. 18 9 SAR DATA SUMMARY ................................................................................................................. 20 10 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS ......................................................... 23 11 SAR MEASUREMENT VARIABILITY ........................................................................................... 26 12 EQUIPMENT LIST ......................................................................................................................... 27 13 MEASUREMENT UNCERTAINTIES ............................................................................................ 28 14 CONCLUSION ............................................................................................................................... 29 15 REFERENCES .............................................................................................................................. 30 APPENDIX A: SAR TEST PLOTS APPENDIX B: SAR DIPOLE VERIFICATION PLOTS APPENDIX C: PROBE AND DIPOLE CALIBRATION CERTIFICATES APPENDIX D: SAR TISSUE SPECIFICATIONS APPENDIX E: SAR SYSTEM VALIDATION APPENDIX F: SAR TEST SETUP PHOTOGRAPHS FCC ID: A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 3 of 31 0Y1408191749.A3L 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 1 DEVICE UNDER TEST 1.1 Device Overview GSM/GPRS/EDGE 850Voice/Data824.20 - 848.80 MHz UMTS 850Voice/Data826.40 - 846.60 MHz 2.4 GHz WLANData2412 - 2462 MHz BluetoothData2402 - 2480 MHz Bluetooth LEData2402 - 2480 MHz Band & ModeTx Frequency Operating Modes 1.2 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values were scaled to the maximum allowed power to determine compliance per KDB Publication 447498 D01v05. Voice (dBm) 1 TX Slot 1 TX Slot 2 TX Slots 1 TX Slot 2 TX Slots Maximum33.033.030.525.525.5 Nominal32.532.530.025.025.0 Burst Average GMSK (dBm) GSM/GPRS/EDGE 850 Burst Average 8-PSK (dBm) Mode / Band 3GPP RMC Rel 99 3GPP HSDPA Rel 5 3GPP HSUPA Rel 6 Maximum23.022.022.0 Nominal22.521.521.5 Modulated Average (dBm) Mode / Band UMTS Band 5 (850 MHz) Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Maximum Nominal Bluetooth LE 7.0 6.5 Bluetooth 18.0 17.0 13.0 13.0 17.5 13.5 IEEE 802.11n (2.4 GHz) 13.5 Modulated Average (dBm) IEEE 802.11b (2.4 GHz) 17.5 IEEE 802.11g (2.4 GHz) Mode / Band FCC ID: A3LSMR750B SAR EV…

Text truncated - open the document above for the full version.

FCC ID: A3LSMR750B FCC Pt. 22 GPRS / EDGE / WCDMA MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 39 0Y1408191750.A3L 8/18 - 8/27/2014 Wrist Watch © 2014 PCTEST Engineering Laboratory, Inc. V 1.18 08/13/2014 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 8/18 - 8/27/2014 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab., Columbia, MD, USA Gyeonggi-do 443-742, Korea Test Report Serial No.: 0Y1408191750.A3L FCC ID: A3LSMR750B APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification Model(s): SM-R750B EUT Type: Wrist Watch FCC Classification: Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s): §2 §22(H) Test Procedure(s): ANSI/TIA-603-C-2004, KDB 971168 v02r01 Test Device Serial No.: identical prototype [S/N: 30E72] GPRS850824.2 - 848.8238KGXW0.01912.71 EDGE850824.2 - 848.8246KG7W0.0056.70 WCDMA850826.4 - 846.64M17F9W0.001-0.82 Emission Designator Tx Frequency (MHz) Mode ERP Max. Power (W) Max. Power (dBm) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 FCC ID: A3LSMR750B FCC Pt. 22 GPRS / EDGE / WCDMA MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 39 0Y1408191750.A3L 8/18 - 8/27/2014 Wrist Watch © 2014 PCTEST Engineering Laboratory, Inc. V 1.18 08/13/2014 TABLE OF CONTENTS FCC PART 22 MEASUREMENT REPORT .................................................................................................. 3 1.0 INTRODUCTION .............................................................................................................................. 4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY ............................................................................................................................. 4 2.0 PRODUCT INFORMATION .............................................................................................................. 5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 DEVICE CAPABILITIES....................................................................................................................... 5 2.3 TEST CONFIGURATION ..................................................................................................................... 5 2.4 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 3.0 DESCRIPTION OF TESTS .............................................................................................................. 6 3.1 EVALUATION PROCEDURE .............................................................................................................. 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS ....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 RADIATED MEASUREMENTS ............................................................................................................ 7 4.0 TEST EQUIPMENT CALIBRATION DATA ...................................................................................... 8 5.0 SAMPLE CALCULATIONS .............................................................................................................. 9 6.0 TEST RESULTS ............................................................................................................................. 10 6.1 SUMMARY ......................................................................................................................................... 10 6.2 OCCUPIED BANDWIDTH ................................................................................................................. 11 6.3 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL ............................................ 14 6.4 BAND EDGE EMISSIONS AT ANTENNA TERMINAL ...................................................................... 23 6.5 RADIATED POWER (ERP) ................................................................................................................ 26 6.6 RADIATED SPURIOUS EMISSIONS MEASUREMENTS ................................................................. 29 6.7 FREQUENCY STABILITY / TEMPERATURE VARIATION ............................................................... 34 7.0 CONCLUSION ................................................................................................................................ 39 FCC ID: A3LSMR750B FCC Pt. 22 GPRS / EDGE / WCDMA MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 39 0Y1408191750.A3L 8/18 - 8/27/2014 Wrist Watch © 2014 PCTEST Engineering Laboratory, Inc. V 1.18 08/13/2014 MEASUREMENT REPORT FCC Part 22 §2.1033 General Information APPLICANT: Samsung Electronics, Co. Ltd. APPLICANT ADDRESS: 129, Samsung-ro, Maetan dong, Yeongtong-gu, Suwon-si, Gyeonggi-do 443-742, Korea TEST SITE: PCTEST ENGINEER…

Text truncated - open the document above for the full version.

FCC ID:A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 1 of 3 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 APPENDIX F: SAR TEST SETUP PHOTOGRAPHS FCC ID:A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 2 of 3 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 SAR Test Setup Photo 1 - Front side at 1.0 cm SAR Test Setup Photo 2 - Back Side at 0.0 cm FCC ID:A3LSMR750B SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 3 of 3 08/20/14 - 08/26/14 Portable Wrist Device © 2014 PCTEST Engineering Laboratory, Inc. REV 14.0 M 07/21/2014 SAR Test Setup Photo 3 - Back Side at 0.0 cm (Side view) SAR Test Setup Photo 4 - Back Side at 0.0 cm (Holder view)

Samsung Electronics Co., Ltd. FCC ID: A3LSMR750B Model: SM-R750B Test Set-Up Photos EUT Type: Wrist Watch Page 1 of 3 © 2014 PCTEST Engineering Laboratory, Inc. TEST SETUP PHOTOGRAPHS Samsung Electronics Co., Ltd. FCC ID: A3LSMR750B Model: SM-R750B Test Set-Up Photos EUT Type: Wrist Watch Page 2 of 3 © 2014 PCTEST Engineering Laboratory, Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSMR750B Model: SM-R750B Test Set-Up Photos EUT Type: Wrist Watch Page 3 of 3 © 2014 PCTEST Engineering Laboratory, Inc.
