A3LSTHN375Dual-Mode Cellular (AMPS/TDMA) Phone

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: Mar 06, 2002
Application Purpose: Original Equipment
Date of Application: Dec 27, 2001
Equipment Note: Dual-Mode Cellular (AMPS/TDMA) Phone
Frequency Range: 824.04000000 - 848.97000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Printed in Korea Code No. : GH68-xxxxxA English. 11/2001. Rev. 1.0 ELECTRONICS World Wide Webhttp://www.samsungmobile.com TDMA MOBILE TELEPHONE STH-N375 Draft version (2001/11/6) * Some contents in this manual may differ from your phone depending on the software of the phone or your service provider. Please, be sure to read thismanual before using your phone.And keep the manual afterreading it and use any time youhave a question. ii i FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) ofthe United States with its action in Report and Order FCC 96-326adopted an updated safety standard for human exposure to radiofrequency electromagnetic energy emitted by FCC regulatedtransmitters. Those guidelines are consistent with the safetystandard previously set by both U.S. and international standardsbodies. The design of this phone complies with the FCCguidelines and these international standards. Use only the supplied or an approved antenna. Unauthorizedantennas, modifications, or attachments could impair call quality,damage the phone, or result in violation of FCC regulations.Do not use the phone with a damaged antenna. If a damagedantenna comes into contact with the skin, a minor burn mayresult. Please contact your local dealer for replacement antenna.Body-worn OperationThis device was tested for typical body-worn operations usingthe optional belt-clip/holster placed 0.78 inches ( 2.0 cm) from the body. To comply with FCC RF exposure requirements, a minimumseparation distance of 0.78 inches ( 2.0 cm) must be maintained between the user’s body and the phone, including the antenna.The use of third-party belt-clips/ holsters with no metalliccomponents that provide the minimum separation distance of0.78 inches ( 2.0 cm) can be used to satisfy FCC RF exposure requirements. The use of non-tested accessories or other body-worn operations may not comply with FCC RF exposurerequirements and should be avoided. Contact your local dealerfor optional accessory items. Vehicle Mounted External Antenna (optional, ifavailable.)A minimum separation distance of 7.9 inches (20cm) must bemaintained Between a person and the vehicle mounted externalantenna to satisfy FCC RF exposure requirements.For more information about RF exposure, please visit the FCCwebsite at www .fcc.gov SAR Information & FCC ID Labeling THIS MODEL PHONE MEETS THE GOVERNMENT’SREQUIREMENTS FOR EXPOSURE TO RADIO WAVES.Your wireless phone is a radio transmitter and receiver. It isdesigned and manufactured not to exceed the emission limits forexposure to radiofrequency (RF) energy set by the FederalCommunications Commission of the U.S. Government. Theselimits are part of comprehensive guidelines and establishpermitted levels of RF energy for the general population. Theguidelines are based on standards that were developed byindependent scientific organizations through periodic andthorough evaluation of scientific studies. The standards include asubstantial safety margin designed to assure the safety of allpersons, regardless of age and health.The exposure standard for wireless mobile phones employs aunit of measurement know as the Specific Absorption Rate, orSAR. The SAR limit set by the FCC is 1.6W/kg.* Tests for SARare conducted using standard operating positions specified bythe FCC with the phone transmitting at its highest certifiedpower level in all tested frequency bands. Although the SAR isdetermined at the highest certified power level, the actual SARlevel of the phone while operating can be well below themaximum value. This is because the phone is designed tooperate at multiple power levels so as to use only the powerrequired to reach the network. In general, the closer you are to awireless base station antenna, the lower the power output.Before a phone model is available for sale to the public, it mustbe tested and certified to the FCC that it does not exceed thelimit established by the government-adopted requirement forsafe exposure. The tests are performed in positions and locations(e.g., at the ear and worn on the body) as required by the FCC foreach model. The highest SAR value for this model phone whentested for use at the ear is 1.484 W/kg and when worn on the body, as described in this user guide, is 1.240 W/kg . (Body-worn measurements differ among phone models, depending uponavailable accessories and FCC requirements). While there maybe differences between the SAR levels of various phones and atvarious positions, they all meet the government requirement forsafe exposure. 1 ContentsUnpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Your PhonePhone Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Service Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Getting Started Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Switching the Phone On/Off . . . . . . . . . . . . . . . . . . . . . 17 Locking Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 General Functions Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Making a Call from the Phonebook . . . . . . . . . . . . . . . . 20 Redialing the Last Number . . . . . . . . . . . . . . . . . . . . . . 20 Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Viewing Missed Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Quick-switching to Silent Mode . . . . . . . . . . . . . . . . . . . . 24 Selecting Functions and OptionsUsing the Soft Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Selecting Functions and Options . . . . . . . . . . . . . . . . . . . 26 Example: Setting the Display Language . . . . . . . . …

Text truncated - open the document above for the full version.

Users Manual

In addition, you can obtain the following accessories foryour phone from your local SAMSUNG dealer:• Desktop charger • Hands-free kit• Standard/Extended battery• Cigarette lighter adapter• Ear-microphone• Leather case 7 6 Travel Charger Handset User’s Manual Use sensiblyUse only in the normal position (to ear). Do not touchthe antenna unnecessarily when the phone isswitched on.Accessories and batteriesUse only SAMSUNG-approved accessories andbatteries. Use qualified serviceOnly qualified service personnel must repairequipment. Unpacking Your package contains the following items. Battery Hand Strap

Users Manual

99 98 Tests for SAR are conducted using standard operatingpositions specified by the FCC with the phonetransmitting at its highest certified power level in alltested frequency bands. Although the SAR isdetermined at the highest certified power level, theactual SAR level of the phone while operation can bewell below the maximum value. This is because thephone is designed to operate at multiple power levelsso as to use only the power required to reach thenetwork. In general, the closer you are to a wirelessbase station antenna, the lower the power output. Before a phone model is available for sale to thepublic, it must be tested and certified to the FCC that itdoes not exceed the limit established by thegovernment-adopted requirement for safe exposure.The tests are performed in positions and locations(e.g., at the ear and worn on the body) as required bythe FCC for each model. (Body-worn measurementsdiffer among phone models, depending upon availableaccessories and FCC requirements). While there maybe differences between the SAR levels of variousphones and at various positions, they all meet thegovernment requirement for safety exposure. HHe ea al lt th h a an nd d S Sa af fe et ty y I In nf fo or rm ma at ti io on n Health and SafetyInformation Exposure to Radio Frequency (RF) SignalsYour mobile phone is a radio transmitter and receiver.It is designed and manufactured not to exceed theemission limits for exposure to radio frequency (RF)energy set by the Federal CommunicationsCommission of the U.S. Government. These limits arepart of comprehensive guidelines and establishpermitted levels of RF energy for the generalpopulation. Those guidelines are consistent with thesafety standard previously set by both U.S. andinternational standards bodies:• American National Standards Institute (ANSI) IEEE. C95.1-1992 • National Council on Radiation Protection and Measurement (NCRP). Report 86 • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996 • Ministry of Health (Canada), Safety Code 6.The standards include a substantial safety margindesigned to assure the safety of all persons,regardless of age and health.The exposure standard for wireless mobile phonesemploys a unit of measurement known as theSpecific Absorption Rate, or SAR. The SAR limit setby the FCC is 1.6W/kg. * * In the U.S. and Canada, the SAR limit for mobile phones used by the publicis 1.6 watts/kg(w/kg) averaged over on gram of tissue. The standardincorporates a substantial margin of safety to give additional protection forthe public and to account for any variations in measurements.

Attestation Statements

November 21, 2001 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc, to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc, on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21, U.S.C. 853(a) We hereby certify that the Handheld Portable Cellular Telephone (FCC ID: A3LSTHN375, MODELS: STH-N375) is so designed that it complies with all the requirements for ESN protection specified in Section 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, temper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. November 21, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSTHN375 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652. November 21, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER §22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSTHN375), using the Automatic A/B Roaming – Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned.

Attestation Statements

November 21, 2001 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 In re: SAMSUNG ELECTRONICS FCC ID: A3LSTHN375 (Models: STH-N375) FCC Part 22 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, SAMSUNG hereby requests confidentiality of the attachments (Block Diagrams, Circuit Diagrams, Circuit Descriptions, Parts List, Tune-up Procedure, and Antenna Specifications) for the subject application. These documents contain detailed system and equipment description and related information about the product that SAMSUNG considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, SAMSUNG considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market.

Cover Letter(s)

December 27, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSTHN375 Part 22 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 22 Certification of the following Dual-Mode Cellular (AMPS/TDMA) Phone: FCC ID: A3LSTHN375 TRADE / MODEL(s): SAMSUNG STH-N375 EUT TYPE: Licensed Non-Broadcast Transmitter Held to Ear (TNE) Tx Freq. Range: 824.04 — 848.97 MHz (AMPS) 824.04 — 848.97 MHz (TDMA) Rx Freq. Range: 869.04 — 893.97 MHz (AMPS) 869.04 — 893.97 MHz (TDMA) Max. RF Output Power: 0.500 W ERP AMPS (26.983 dBm) / 0.511 W ERP TDMA (27.083 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN affidavit, E911 compliance statement, RF measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Wallace Oh Engineering Manager SAMSUNG American QA Lab

Cover Letter(s)

February 28, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSTHN375 731 Confirmation No.: EA494162 Correspondence Reference No.: 21878 Request for Tech. Info.: 1/29/02 Dear Stan: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated January 29, 2002. 1. Please find the attached audio frequency response and audio low pass filter data. 2. Please find the attached modulation limiting data. 3. Please find the attached SAR test data with corrected crest factors. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

Cover Letter(s)

March 4, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSTHN375 731 Confirmation No.: EA494162 Correspondence Reference No.: 22151 Request for Tech. Info.: 3/04/02 Dear Stan: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated March 4, 2002. 1. Please find the attached revised pages 12 and 13 of the test report. 2. Please find the attached SAR test data summary page. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

External Photos

ID Label/Location Info

© 2001PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) SAMSUNG ELECTRONICS CO., LTD. MODEL NO: STH-N375 FCC ID: A3LSTHN375 MADE IN KOREA SAMSUNG ELECTRONICS CO., LTD

Internal Photos

RF Exposure Info

SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.10 mW/g, SAR (10g): 0.702 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0991 [824.04MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 1.02E-1 3.07E-1 5.12E-1 7.17E-1 9.22E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.41 mW/g, SAR (10g): 0.887 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0383 [836.49MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 1.40E-1 4.20E-1 7.01E-1 9.81E-1 1.26E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.37 mW/g, SAR (10g): 0.831 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0799 [848.97MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 1.22E-1 3.66E-1 6.10E-1 8.54E-1 1.10E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.746 mW/g, SAR (10g): 0.499 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0991 [824.04MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Ear/15degree Tilt position Test Date -- 11/21/2001 SAR Tot [mW/g] 6.85E-2 2.06E-1 3.43E-1 4.79E-1 6.17E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.23 mW/g, SAR (10g): 0.778 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0383 [836.49MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Ear/15degree Tilt position Test Date -- 11/21/2001 SAR Tot [mW/g] 1.09E-1 3.27E-1 5.45E-1 7.63E-1 9.81E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.805 mW/g, SAR (10g): 0.545 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0799 [848.97MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Left Head Phantom, Ear/15degree Tilt position Test Date -- 11/21/2001 SAR Tot [mW/g] 7.62E-2 2.29E-1 3.81E-1 5.33E-1 6.86E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Right Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.965 mW/g, SAR (10g): 0.604 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0991 [824.04MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Right Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 7.79E-2 2.34E-1 3.90E-1 5.45E-1 7.01E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Right Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.28 mW/g, SAR (10g): 0.779 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0383 [836.49MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Right Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 9.67E-2 2.90E-1 4.83E-1 6.77E-1 8.70E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Right Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.19 mW/g, SAR (10g): 0.723 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0799 [848.97MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Right Head Phantom, Cheek/Touch position Test Date -- 11/21/2001 SAR Tot [mW/g] 9.00E-2 2.70E-1 4.50E-1 6.30E-1 8.10E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Right Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.597 mW/g, SAR (10g): 0.396 mW/g SAMSUNG TriMode Model: STH-N375 FM Mode, Ch.0991 [824.04MHz]; Standard Battery; Flip = open Conducted Power = 26.5dBm; Right Head Phantom, Ear/15degree Tilt position Test Date -- 11/21/2001 SAR Tot [mW/g] 5.21E-2 1.56E-1 2.61E-1 3.65E-1 4.69E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID: A3LSTHN375 -- FM Head SAR Generic Twin Phantom; Right Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.905 mW/g, SAR (10g): 0.607 mW/g…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN375 (Model: STH-N375) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA)

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD.Dates of Tests: November 21 & 26, 2001 416 Maetan-3 Dong, Paldal-Gu, Suwon CityTest Report S/N: SAR.211119657.A3L Gyungki-Do, KOREA 442-742Test Site: PCTEST Lab, Columbia, MD USA Attn: Wallace Oh, General Manager FCC ID A3LSTHN375 APPLICANT SAMSUNG ELECTRONICS CO., LTD. EUT Type:Dual-Mode Cellular (AMPS/TDMA) Phone Tx Frequency:824.04 – 848.97 MHz (AMPS) 824.04 – 848.97 MHz (TDMA) Rx Frequency:869.04 – 893.97 MHz (AMPS) 869.04 – 893.97 MHz (TDMA) Max. RF Output Power:0.500 W ERP AMPS (26.983 dBm) / 0.511 W ERP TDMA (27.083 dBm) Max. SAR Measurement:1.41mW/g AMPS Head SAR; 1.07mW/g AMPS Body SAR; .496mW/g TDMA Head SAR; .508mW/g TDMA Body SAR Trade Name/Model(s):STH-N375 FCC Classification:Licensed Non-Broadcast Transmitter Held to Ear (TNE) FCC Rule Part(s):§2.1093; FCC/OET Bulletin Supplement C [July 2001] Application Type:Certification This wireless portable device has been shown to be capable of continued compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 and IEEE Std. 1528 (Draft Aug.2000). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 211119.A3L SAR Measurement ReportFCC Part 24/22 Certification © 2001 PCTEST Labi Table of Contents 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5-6 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 HEAD SAR TEST POSITIONS OF THE PHONE 10 10.1 BODY SAR TEST SETUP11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-23 14.1 SAR TEST EQUIPMENT LIST 24 15.1 CONCLUSION 25 16.1 REFERENCES 26 Test Report S/N: SAR.21119657.A3LSAR Measurement Report Test Date(s): November 21 & 26, 2001FCC Part 24/22 Certification © 2001 PCTEST LabSAMSUNG FCC ID: A3LSTHN375 (Model: STH-N375)1 Dual-Mode Cellular Phone (AMPS/TDMA) SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name:SAMSUNG ELECTRONICS CO., LTD. Address:416 Maetan-3 Dong, Paldal-Gu, Suwon City Attention:Gyungki-Do, KOREA 442-742 Wallace Oh, General Manager • EUT Type:Dual-Mode Cellular (AMPS/TDMA) Phone • Trade Name / Model:STH-N375 • FCC IDENTIFIER:A3LSTHN375 • Tx Frequency:824.04 – 848.97 MHz (AMPS) 824.04 – 848.97 MHz (TDMA) • Rx Frequency:869.04 – 893.97 MHz (AMPS) 869.04 – 893.97 MHz (TDMA) • FCC Classification:Licen…

Text truncated - open the document above for the full version.
