A3LSWP1200Wireless Internet Appliance - HomePAD Refrigerator

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 01, 2002
Application Purpose: Original Equipment
Date of Application: Dec 01, 2002
Equipment Note: Wireless Internet Appliance - HomePAD Refrigerator
Frequency Range: 2412.00000000 - 2462.00000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

February 4, 2002 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsun Electronics America

Block Diagram

TV Cable A/V Door PhoneLANWAN Ext Int Internal External (2) Residential Gateway Internet (3) Access Station DVD (VTR) (1) SMPS (1) SMPS AC 115V

Block Diagram

-14 - MOBIIS Specification for HomePad 4. Block Diagram [ HomePadBlock Diagram ] 2 2 SDRAM Cntroller North Bridge to PCI Controller South Bridge & Super I/O Controller South Bridge & Super I/O Controller X-Bus ZV - Port Wireless Lan (802.11b) Wireless Lan (802.11b) USB,IR,232C Address Decoder Address Decoder Charger BlockPower Fault Control Block 64Bit Dram Bus AC97 Con PCI Bus X-BUS

Cover Letter(s)

November 26, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSWP1200 Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Certification of the HomePAD Refrigerator. Attached are the applicant’s Letter of Authorization, measurement report test data and plots, FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, operational description, the user's manual, and the SAR Measurement Report. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.

Cover Letter(s)

January 17, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSWP1200 731 Confirmation No.: TC420083 Request for Tech. Info.: 12/27/2002 Correspondence Ref. Num.: 6354 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment provided in response to the request for technical information dated December 27, 2002. 1. Please find attached new block diagram. 2. Please find attached the complete schematic diagrams. 3. Please find attached the updated exhibits with all references to the Refrigerator removed in the internal and test set-up photographs. 4. Please find attached the revised page 11 in the EMC Report showing the maximum power of 0.063 W (18.0 dBm). 5. Please find attached the updated label with the Part 15 language. 6. We have updated the form 731 information and grant accordingly. 7. Please find attached the revised page 13 of the SAR report (system validation plots). 8. Please find attached the retest of Edge data as referenced in our previous response. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

External Photos

ID Label/Location Info

© 2002 PCTEST Lab SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

ID Label/Location Info

Internal Photos

© 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200)

Internal Photos

RF Exposure Info

December 2, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSWP1200 731 Confirmation No.: TC667269 (FCC ID: A3LHP2777AT) Request for Tech. Info.: 11/26/2002 (FCC ID: A3LHP2777AT) Correspondence Ref. Num.: 5988 (FCC ID: A3LHP2777AT) Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment provided in response to the request for technical information dated November 26, 2002 and November 27, 2002 requesting filing under two separate FCC ID’s. 1. The probe used for SAR evaluation was calibrated by the manufacturer on January 2002 under Appendix C in Supplement C (Tissue Dielectric Parameters) and IEEE P1528 Sec 4. The tolerance for permittivity was within the maximum 10% specification for frequencies between 2-3 GHz. The conductivity was within 5% of the target value. 2. Please find attached the SAR retest showing the localization of the SAR over the entire device. 3. Please find attached the SAR retest data for the edge of the device. 4. Please find attached an internal photograph indicating the location of the transmitting antenna on the HomePAD. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd. PCTEST SAR TEST REPORT SAR EVALUATION REPORT DATA EA : TC667269 Company Name: SAMSUNG FCC ID: A3LSWP1200 Model: SWP-1200 SAR Test Dates: 06/25 /2002 CRN: 5988 SAR DATA SUMMARY MEASUREMENT RESULTS (DSSS Body SAR – Web Pad Edge) FREQUENCY Begin / End POWER ‡ MHz Ch. Modulation (W) Battery Separation Distance (cm) Antenna Position SAR (W/kg) 2412 1 DSSS 0.063 0.063 STANDARD 1.5 INTERNAL 0.07 ANSI / IEEE C95.1 1992 - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population Muscle 1.6 W/kg (mW/g) averaged over 1 gram NOTES: 1. The test data reported are the worst-case SAR value with the antenna-head position set in a typical configuration. Test procedures used are according to FCC/OET Bulletin 65, Supp.C [July 2001]. 2. All modes of operation were investigated, and worst-case results are reported. 3. Battery is fully charged for all readings. ‡ Power Measured o Conducted o ERP x EIRP 4. SAR Measurement System o DASY3 x IDX o Phantom Configuration o Right Head x Flat Phantom o Left Head 5. SAR Configuration o Head x Body o Hand 6. Test Signal Call Mode x Software o Base Station Simulator SAR Data Report 02062503 Start : 25-Jun-02 10:30:16 am End : 25-Jun-02 10:38:00 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : SAMSUNG Model Number : SWP-1200 Serial Number : 4 Frequency : 2412 MHz Transmit Pwr : 0.063 W Antenna Type : Patch Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 52.000 Tissue Conductivity : 1.920 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Body CF=1; Amb. Temp= 22.3 'C; Liq. Temp=22.0 'C Area Scan - Max Peak SAR Value at x=-9.0 y=-40.0 = 0.07 W/kg Zoom Scan - Max Peak SAR Value at x=7.0 y=-31.0 z=0.0 = 0.26 W/kg Max 1g SAR at x=-2.0 y=-51.0 z=0.0 = 0.07 W/kg Max 10g SAR at x=-7.0 y=-45.0 z=0.0 = 0.06 W/kg 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 0.20 0.22 0.24 0.26 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:7.0 y:-31.0 1g SAR Values 0.06635 0.06558 0.06480 0.06403 0.06326 0.06249 0.06171 0.06094 0.06017 0.05939 0.05862 © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSWP1200 HomePAD Refrigerator (Model: SWP-1200)

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.220620324.A3L Test Dates: June 25, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 1 of 18 © 2002 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: SAMSUNG Electronics Co., Ltd. Dates of Tests: June 25, 2002 #271, Oseon-Dong, Gwangsan-Gu Test Report S/N: SAR.220620324.A3L Gwangju-City 506-723 KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: Mr. Gi-Hyeong Lee FCC ID: A3LSWP1200 APPLICANT: SAMSUNG Electronics Co., Ltd. EUT Type: HomePAD Refrigerator Tx Frequency: 2412 — 2462MHz Rx Frequency: 2412 — 2462MHz Max. RF Output Power: 0.063 W / 18.0 dBm EIRP (HomePAD) Max. SAR Measurement: 0.21W/kg Body SAR (HomePAD) Trade Name/Model(s): SAMSUNG SWP-1200 FCC Classification: Part 15 Spread Spectrum Transmitter (DSS) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001], 15.247 Application Type: Certification Antenna Type: Internal This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET bulletin 65 Supp. C (2001),and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220620369.A3L PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.220620324.A3L Test Dates: June 25, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 2 of 18 © 2002 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION ................................................................................................... 3 SAR DEFINITION.................................................................................................... 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware .................................................................................................... 4 System Electronics................................................................................................... 4 3. DASY3 E-FIELD PROBE SYSTEM............................................................................. 5 Probe Measurement System .................................................................................... 5 Probe Specifications................................................................................................ 5 4. Probe Calibration Process ....................................................................................... 6 Dosimetric Assessment Procedure........................................................................... 6 Free Space Assessment............................................................................................ 6 Temperature Assessment ......................................................................................... 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 7 SAM Phantom ......................................................................................................... 7 Brain & Muscle Simulating Mixture Characterization .............................................. 7 Device Holder ........................................................................................................ 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications..................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS .................................................. 9 Measurement Procedure ......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications .................................. 9 Body Holster /Belt Clip Configurations.................................................................. 10 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................... 11 Uncontrolled Environment .................................................................................... 11 Controlled Environment ........................................................................................ 11 11. MEASUREMENT UNCERTAINTIES ....................................................................... 12 12. SYSTEM VERIFICATION ....................................................................................... 13 Tissue Verification................................................................................................. 13 Test System Verification ........................................................................................ 13 13. SAR TEST DATA SUMMARY................................................................................. 14 See Measurement Result Data Pages ..................................................................... 14 Procedures Used To Establish Test Signal...........................................…

Text truncated - open the document above for the full version.

RF Exposure Info

SAR Data Report 02062504 Start : 25-Jun-02 10:48:46 am End : 25-Jun-02 10:56:37 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : SAMSUNG Model Number : SWP-1200 Serial Number : 4 Frequency : 2412 MHz Transmit Pwr : 0.063 W Antenna Type : Patch Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 52.000 Tissue Conductivity : 1.920 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Body CF=1; Amb. Temp= 22.3 'C; Liq. Temp=22.0 'C Area Scan - Max Peak SAR Value at x=-11.0 y=-9.0 = 0.14 W/kg Zoom Scan - Max Peak SAR Value at x=-12.0 y=-19.0 z=0.0 = 0.62 W/kg Max 1g SAR at x=-12.0 y=-20.0 z=0.0 = 0.21 W/kg Max 10g SAR at x=-10.0 y=-6.0 z=0.0 = 0.14 W/kg 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-12.0 y:-19.0 1g SAR Values 0.1201 0.1187 0.1174 0.1160 0.1146 0.1132 0.1118 0.1104 0.1090 0.1076 0.1062

RF Exposure Info

SAR Data Report 02062501 Start : 25-Jun-02 08:25:49 am End : 25-Jun-02 08:37:52 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : Validation Frequency : 2450 MHz Transmit Pwr : 0.250 W Antenna Type : Dipole Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Brain Tissue Dielectric : 39.400 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Brain Calibrated Dielectric : 37.100 Calibrated Conductivity : 1.840 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.400 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: 2450 MHz Validation SN: 146 CF=1; Amb. Temp.=22.0'C; Liq. Temp.=21.7'C Area Scan - Max Peak SAR Value at x=-1.0 y=-2.0 = 15.33 W/kg Zoom Scan - Max Peak SAR Value at x=-1.0 y=-2.0 z=0.0 = 25.43 W/kg Max 1g SAR at x=-1.0 y=-2.0 z=0.0 = 12.94 W/kg Max 10g SAR at x=-1.0 y=-2.0 z=0.0 = 8.67 W/kg Validation Results at 0.25 W: Peak Nominal = 26.0, Error: -2.38 % 1g Nominal = 13.1, Error: -1.20 % 10g Nominal = 8.5, Error: 2.00 % 2 4 6 8 10 12 14 16 18 20 22 24 26 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-1.0 y:-2.0 1g SAR Values 13.0 11.8 10.6 9.5 8.3 7.1 5.9 4.7 3.6 2.4 1.2

RF Exposure Info

PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.220620324.A3L Test Dates: June 25, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 13 of 18 © 2002 PCTEST Engineering Laboratory, Inc. 11. SYSTEM VERIFICATION Tissue Verification Table 12.1 Simulated Tissue Verification Test System Validation Prior to assessment, the system is verified to the ±10% of the specifications at 2450MHz by using the system validation kit(s). (Graphic Plots Attached) Table 12.2 System Validation MEASURED TISSUE PARAMETERS Date(s) 06/24/02 1900MHz Brain 1900MHz Muscle 2450MHz Brain 2450MHz Muscle Liquid Temperature (°C) 23.5 Target Measured Target Measured Target Measured Target Measured Dielectric Constant: ε 40.00 N /A 53.30 N /A 39.20 39.4 52.70 52.00 Conductivity: σ 1.400 N /A 1.520 N /A 1.800 1.88 1.950 1.920 SYSTEM DIPOLE VALIDATION TARGET & MEASURED System Validation Kit: D-2450S, S/N: 105 2450MHz Brain Targeted SAR 1g (mW/g) 13.100 Measured SAR 1g (mW/g) 12.94 Deviation (%) - 1.22 Figure 12.1 Dipole Validation Test Setup

RF Exposure Info

PCTEST SAR TEST REPORT SAR EVALUATION REPORT DATA EA : TC667269 Company Name: SAMSUNG FCC ID: A3LSWP1200 Model: SWP-1200 SAR Test Dates: 06/25 /2002 CRN: 5988 SAR DATA SUMMARY MEASUREMENT RESULTS (DSSS Body SAR – Web Pad Edge) FREQUENCY Begin / End POWER ‡ MHz Ch. Modulation (W) Battery Separation Distance (cm) Antenna Position SAR (W/kg) 2412 1 DSSS 0.063 0.063 STANDARD 1.5 INTERNAL 0.07 ANSI / IEEE C95.1 1992 - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population Muscle 1.6 W/kg (mW/g) averaged over 1 gram NOTES: 1. The test data reported are the worst-case SAR value with the antenna-head position set in a typical configuration. Test procedures used are according to FCC/OET Bulletin 65, Supp.C [July 2001]. 2. All modes of operation were investigated, and worst-case results are reported. 3. Battery is fully charged for all readings. ‡ Power Measured o Conducted o ERP x EIRP 4. SAR Measurement System o DASY3 x IDX o Phantom Configuration o Right Head x Flat Phantom o Left Head 5. SAR Configuration o Head x Body o Hand 6. Test Signal Call Mode x Software o Base Station Simulator SAR Data Report 02062503 Start : 25-Jun-02 10:30:16 am End : 25-Jun-02 10:38:00 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : SAMSUNG Model Number : SWP-1200 Serial Number : 4 Frequency : 2412 MHz Transmit Pwr : 0.063 W Antenna Type : Patch Antenna Posn. : Internal Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 52.000 Tissue Conductivity : 1.920 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT25 Probe Type : E Fld Triangle Frequency : 2450 MHz Tissue Type : Muscle Calibrated Dielectric : 49.200 Calibrated Conductivity : 1.950 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 16.500 Probe Sensitivity : 0.753 0.726 0.683 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Body CF=1; Amb. Temp= 22.3 'C; Liq. Temp=22.0 'C Area Scan - Max Peak SAR Value at x=-9.0 y=-40.0 = 0.07 W/kg Zoom Scan - Max Peak SAR Value at x=7.0 y=-31.0 z=0.0 = 0.26 W/kg Max 1g SAR at x=-2.0 y=-51.0 z=0.0 = 0.07 W/kg Max 10g SAR at x=-7.0 y=-45.0 z=0.0 = 0.06 W/kg 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 0.20 0.22 0.24 0.26 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:7.0 y:-31.0 1g SAR Values 0.06635 0.06558 0.06480 0.06403 0.06326 0.06249 0.06171 0.06094 0.06017 0.05939 0.05862

Test Report

PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220620618.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 1 of 31 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE SAMSUNG Electronics Co., Ltd. Dates of Tests: June 27, 2002 #271, Oseon-Dong, Gwangsan-Gu Test Report S/N: 15.220620618.A3L Gwangju-City, 506-723, KOREA Test Site: PCTEST Lab, Columbia MD Attention: Mr. Gi-Hyeong Lee FCC ID A3LSWP1200 APPLICANT SAMSUNG Electronics Co., Ltd. FCC Rule Part(s): § 15.247; ANSI C-63.4 (1992) Classification: Digital Transmission System (DTS) Max Output Power: 0.063 W / 18.0 dBm Conducted (HomePAD-Remote) Method/System: Direct Sequence System (DSS) Equipment Type: HomePAD Refrigerator Frequency Range: 2412 — 2462 MHz Model No(s).: SWP-1200 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63-4. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220620618.A3L PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620618.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 2 of 31 TABLE OF CONTENTS APPENDIX A – COVER LETTER APPENDIX B - ATTESTATION STATEMENT APPENDIX C - TEST REPORT SCOPE 3 INTRODUCTION (SITE DESCRIPTION) 4 PRODUCT INFORMATION 5 DESCRIPTION OF TESTS A. CONDUCTED EMISSIONS 6 B. RADIATED EMISSIONS 7 C. RESTRICTED BANDS 8 D. ANTENNA REQUIREMENT 9 E. DIRECT SEQUENCE BANDWIDTH 10 F. MAXIMUM PEAK POWER OUTPUT 11 G. POWER DENSITY 12 - 13 RADIATED MEASUREMENTS (FUNDAMENTAL & HARMONICS) 17 - 25 RADIATED MEASUREMENTS (RESTRICTED BAND) 25 - 29 LIST OF TEST EQUIPMENT 30 CONCLUSION 31 APPENDIX D - RECEIVER VERIFICATION REPORT APPENDIX E - TEST PLOTS APPENDIX F - FCC ID LABEL & LOCATION APPENDIX G - TEST SETUP PHOTOGRAPHS APPENDIX H - EXTERNAL PHOTOGRAPHS APPENDIX I - INTERNAL PHOTOGRAPHS APPENDIX J- BLOCK DIAGRAM(S) APPENDIX K - SCHEMATIC DIAGRAM(S) APPENDIX L - OPERATIONAL DESCRIPTION APPENDIX M - USER’S MANUAL APPENDIX N - SAR MEASUREMENT REPORT APPENDIX O - SAR TEST DATA APPENDIX P - SAR TEST SETUP PHOTOGRAPHS APPENDIX Q - DIPOLE VALIDATION APPENDIX R - PROBE CALIBRATION PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620618.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 3 of 31 MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2983(a) General Information Applicant Name: SAMSUNG Electronics Co., Ltd. Address: #271, Oseon-Dong, Gwangsan-Gu Gwangju-City, 506-723, KOREA Attention: Mr. Gi-Hyeong Lee • FCC ID: A3LSWP1200 • Class: Spread Spectrum Transceiver (DSS) • Type: HomePAD Refrigerator • Freq. Range: 2412 — 2462 MHz • Method/System: Direct Sequence System (DSS) • Model No(s): SWP-1200 • Max. RF Output Power: 0.063 W / 18.0 dBm Conducted • Rule Part(s): § 15.247 • Dates of Tests: June 27, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 220620618.A3L NOTE: The receiver portion was tested and complies with Part 15B under the verification procedure. PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620618.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LSWP1200 Page 4 of 31 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) and FCC Public Notice dated July 12, 1995 entitled “Guidance on Measurement for Direct Sequence Spread Spectrum Systems” were used in the measurement of Samsung Spread Spectrum HomePAD Refrigerator. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39 ° 11'15" N latitude and 76 ° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Locat…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jenni Chun(General Manager)

[email protected]973-808-6375Fax: 973-808-6361

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	63.00 mW

Grant Notes

Output power is EIRP. The device must not be co-located or operating in conjunction with any other antenna or transmitter except as indicated in the Certification filing. End-users must be provded with specific operating instructions for satisfying RF exposure compliance requirements. The highest reported Body SAR is: 0.21 W/kg.
