RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Antenna gain: 1.5dBi 802.11b Channel Channel Frequency (MHz) Output Peak power (dBm) Output Peak power (mW) gain of antenna in linear scale G Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 1 2412.00 15.31 33.9625 1.4125 0.0095 1 6 2437.00 15.64 36.6438 1.4125 0.0103 1 11 2462.00 15.42 34.8337 1.4125 0.0098 1 FCC ID : A5JC20313 802.11g Channel Channel Frequency (MHz) Output Peak power (dBm) Output Peak power (mW) gain of antenna in linear scale G Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 1 2412.00 16.60 45.7088 1.4125 0.0129 1 6 2437.00 16.26 42.2669 1.4125 0.0119 1 11 2462.00 16.17 41.4000 1.4125 0.0116 1 802.11n HT20 Channel Channel Frequency (MHz) Output Peak power (dBm) Output Peak power (mW) gain of antenna in linear scale G Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 1 2412.00 15.95 39.3550 1.4125 0.0111 1 6 2437.00 15.84 38.3707 1.4125 0.0108 1 11 2462.00 15.67 36.8978 1.4125 0.0104 1 802.11n HT40 Channel Channel Frequency (MHz) Output Peak power (dBm) Output Peak power (mW) gain of antenna in linear scale G Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 3 2422.00 14.60 28.8403 1.4125 0.0081 1 6 2437.00 14.43 27.7332 1.4125 0.0078 1 9 2452.00 14.34 27.1644 1.4125 0.0076 1

TRF No:FCC 15.247/A Page 1 of 102 Report No: ES130307060E ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO CANADIAN RSS 210 ISSUE 8 REQUIREMENTS OF +CAM Pro/+CAM Pro HD MODEL No.: QCP-A200 FCC ID: A5JC20313 REPORT NO: ES130307060E ISSUE DATE: May 9, 2013 Prepared for Quadrant Technology(Shenzhen)Co., LTD 3rd floor, 7th building Hongfa JiaTeLi Hi-Tech park of shixin village, shiyan Town, Shenzhen City, Guangdong Province, China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No:FCC 15.247/A Page 2 of 102 Report No: ES130307060E Applicant: Quadrant Technology(Shenzhen)Co., LTD 3rd floor, 7th building Hongfa JiaTeLi Hi-Tech park of shixin village, shiyan Town, Shenzhen City, Guangdong Province, China Manufacturer: Quadrant Technology(Shenzhen)Co., LTD 3rd floor, 7th building Hongfa JiaTeLi Hi-Tech park of shixin village, shiyan Town, Shenzhen City, Guangdong Province, China Product Description: +CAM Pro/+CAM Pro HD Model Number: QCP-A200 File Number: ES130307060E Date of Test: March 7, 2013 to May 9, 2013 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : March 7, 2013 to May 9, 2013 Prepared by : Jessie Hu/Editor Reviewer : King Wang/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No:FCC 15.247/A Page 3 of 102 Report No: ES130307060E Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................................................ 5 1.1 PRODUCT DESCRIPTION.................................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT(S)................................................................................................................. 5 1.3 TEST METHODOLOGY....................................................................................................................................... 6 1.4 SPECIAL ACCESSORIES...................................................................................................................................... 6 1.5 EQUIPMENT MODIFICATIONS............................................................................................................................ 6 1.6 TEST FACILITY.................................................................................................................................................. 6 2. SYSTEM TEST CONFIGURATION ................................................................................................................... 7 2.1 EUT CONFIGURATION....................................................................................................................................... 7 2.2 EUT EXERCISE................................................................................................................................................. 7 2.3 TEST PROCEDURE............................................................................................................................................. 7 2.4 CONFIGURATION OF TESTED SYSTEM............................................................................................................... 7 3. DESCRIPTION OF TEST MODES ..................................................................................................................... 9 4. SUMMARY OF TEST RESULTS....................................................................................................................... 10 5. CONDUCTED EMISSIONS TEST.................................................................................................................... 11 5.1 MEASUREMENT PROCEDURE.......................................................................................................................... 11 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 11 5.4 MEASUREMENT EQUIPMENT USED................................................................................................................. 11 5.4 CONDUCTED EMISSION LIMIT......................................................................................................................... 11 5.5 MEASUREMENT RESULT.................................................................................................................................. 12 6. RADIATED EMISSION TEST ........................................................................................................................... 15 6.5 MEASUREMENT PROCEDURE.......................................................................................................................... 15 6.5 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 15 6.5 MEASUREMENT EQUIPMENT USED................................................................................................................. 16 6.4 RADIATED EMISSION LIMIT............................................................................................................................. 16 6.5 MEASUREMENT RESULT.................................................................................................................................. 18 7. OCCUPIED BANDWIDTH TEST ............................................................................................…
