Limit modular approval declaration letter We ,RF-LINK INTERNATIONAL LIMITED apply limited modular approval for Product Name: bluetooth module Model : CPR9851S FCC ID: A5LCPR9851S According to 996369 D01 Module Equip Auth Guide v01r04 and 15.212 requirement: 1) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; Answer : No, no shield 2) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; Answer :Yes ;All inputs to the modules are buffered through logic or microprocessor inputs. 3)The modular transmitter must have its own power supply regulation. Answer :Yes ;A low drop out regulator is used for modular power supply regulation. 4) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); Answer :Yes ; Device is equipped with PCB antenna. (5) The module must demonstrate compliance in a stand-alone configuration; Answer : NO ,distance between modular and all AEs are shorter than 10cm ,refer to setup photo. (6) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements); Answer :Yes ; The modular has a permanent fixed label, and below statement was listed in the User’s Manual; The host device must be labelled to display the FCC ID of the module Contains FCC ID: A5LCPR9851S (7) The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; Answer :Yes ; The module comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee, Refer to test report and user manual . (8) The module must comply with RF exposure requirements Answer :Yes ; Transmitter meets MPE calculation of 47 CFR 1.1307 . Refer to MPE Reports and Refer to modular installation manual RF-LINK INTERNATIONAL LIMITED Xianglong Fang/Manager
RF-LINK INTERNATIONAL LIMITED Jan.29, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:_____ A5LCPR9851S _______ Product Name:___ bluetooth module _______ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Jan.7, 2015 By: Signature Printed Title: Manager On behalf of : RF-LINK INTERNATIONAL LIMITED Telephone: 0755-83703679
External Photos VIEW OF EUT‐1 Antenna VIEW OF EUT‐2 VIEW OF EUT‐3 VIEW OF EUT‐4
FCCIDLabelLocation FCC ID:A5LCPR9851S
Internal Photos VIEW OF EUT-1 Antenna VIEW OF EUT-2 VIEW OF EUT-3 VIEW OF EUT-4
RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√ f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2402 MHz 7.18dBm(5.22mW) output power] (5.22mW /5mm) ·[√2.402(GHz)]= 1.62<3.0 for 1-g SAR Then SAR evaluation is not required
