A5M-A20270DL0LCD Monitor

Lenovo Qreator 27 User Guide Product numbers A20270DL0 66B7-RCC1-WW 66B7-RBC1-WW 66B7-RAC1-WW First Edition (July 2020) © Copyright Lenovo 2020. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure. LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered pursuant a General Services Administration "GSA" contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925. i Contents Safety information ..........................................................................................iv General Safety guidelines ..............................................................................................iv Chapter 1.Getting started ............................................................................1-1 Shipping contents ........................................................................................................1-1 Notice for use ................................................................................................................1-2 Product overview ..........................................................................................................1-2 Setting up your monitor ...............................................................................................1-4 Chapter 2.Adjusting and using your monitor ............................................2-1 Comfort and accessibility ............................................................................................2-1 Arranging your work area ............................................................................................2-1 Positioning and viewing your monitor .......................................................................2-1 Quick tips for healthy work habits ..............................................................................2-2 Adjusting your monitor image .....................................................................................2-3 Selecting a supported display mode ........................................................................2-17 Understanding power management ..........................................................................2-18 Caring for your monitor .............................................................................................2-19 Detaching the monitor base and stand ....................................................................2-19 Wall Mounting (Optional) ...........................................................................................2-19 Chapter 3.Reference information ................................................................3-1 Monitor specifications ..................................................................................................3-1 Troubleshooting ............................................................................................................3-3 Manually installing the monitor driver ........................................................................3-5 Appendix A. Service and Support ..............................................................A-1 ii Registering your option ..............................................................................................A-1 Online technical support .............................................................................................A-1 Telephone technical support .....................................................................................A-1 Appendix B.Notices .....................................................................................B-1 Recycling information .................................................................................................B-2 Trademarks ...................................................................................................................B-3 Power cords and power adapters ..............................................................................B-3 iii Safety information General Safety guidelines For tips to help you use your computer safely, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. DANGER To avoid shock hazard: • Do not remove the covers. • Do not operate this product unless the stand is attached. • Do not connect or disconnect this product during an electrical storm. • The power cord plug must be connected to a properly wired and grounded power outlet. • Any equipment to which this product will be attached must also be connected to properly wired and grounded power outlets. • To isolate the monitor from the electrical supply, you must remove the plug from the power outlet. The power outlet should be easily accessible. To take special precautions to avoid the introduction of hazards when operating, installing, servicing, transporting or storing equipment, the necessary instructions shall be made available. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Handling: • If your monitor weighs more than 18 kg (39.68 lb), it is recommended that it be moved or lifted by two people. iv Chapter 1.Getting started This User’s Guide provides detailed operation instructions for the user. For quick instruction overview, please see the Setup Poster for brief information. Shipping contents The product package should include the following items: ■Information Flyer ■Lenovo Limited Warranty Booklet ■Stand ■Base ■Flat Panel Monitor ■Power Cord ■Adapter ■USB Type C Cable ■HDMI Cable ■DisplayPort Cable ■Screw x 2pcs ■Screwdriver Lenovo Limited Warranty HDMI 1-1 Qreator 27 Flat Panel Monitor User’s Guide Notice for use To set up your monitor, please see the illustrations below. Note…

Text truncated - open the document above for the full version.

Lenovo (Beijing) Limited 201-H2-6, Floor2, Building2, No.6 Shangdi, West Road. Haidian District Beijing China 053019 – 12 Authority to Act as Agent Date: August 25, 2020 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: _____ Audix Technology（Shenzhen Co., Ltd._____ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: _____2021/4/30____ By: __________________________ ____ Yang Liu_________ (Signature 1 ) (Print name) Title: _Compliance Engineer On behalf of: _Lenovo (Beijing) Limited_ (Company Name) Telephone: +86-10-58867473________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Lenovo (Beijing) Limited 201-H2-6, Floor2, Building2, No.6 Shangdi, West Road. Haidian District Beijing China 053019 – 12 Request for Confidentiality Date: August 25, 2020 Subject: Confidentiality Request for: _____FCC ID: A5M- A20270DL0____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 9.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 2 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual _____ Lenovo (Beijing) Limited__ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of _____ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: ___________ /Compliance Engineer ______ Yang.liu________ (Signature/Title 3 ) (Print name) 2 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 21 of 27 8. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 22 of 27 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 23 of 27 Figure 5 General Appearance of the EUT Figure 6 General Appearance of the EUT

Label Location

frances.li Jun-03-20 备注Remark: LENOVO Qreator 27 label label Part NO.: 内销中文字体要求高度1.8mm以上 Yes No 针对带有UL logo的标签，其厂家须在 最小包装上标示UL Recognized Component Mark 公司名称， 型号及 UL file no. 捷联电子（福建）有限公司 TPV Electronics (Fujian) Co., Ltd. 地址(Add)：中国福建省福清市元洪路上郑 Shangzheng,Yuanhong Road, Fuqing City, Fujian Province, China 电话(Tel)：+86-591-85285555 85285559 传真(Fax)：+86-591-85285447 郵編(Postcode)：350301 条码印刷: barcode print: 1.所有条码读码等级：C级及以上， 客户有特殊要求除外； REVISION VERSION A 安规签核Safety parts: Yes No NOTE: 1. Printing as the above drawing. 印刷版面见上图。 2. Dimension: (Tolerance:+0/-0.2mm),3R=1mm,as the above drawing. 尺寸：+/-0.2mm,3R=1mm。 3.Material:50#PET with gule on the backside (material must be certified by UL laboratory) 材质：50#PET带不干背胶(材质需经过UL认证) 4. 5. Stickiness strength :Cut label into 25mm width ,one end paste on the plate , with 180 ° direction pulling the other end of the tape, the pull is stickiness strength. With stickiness strength instrument for testing. 粘力：将 label切成25mm宽，一端粘贴于钢板上，以180°方向的力拉胶带另一端，所得拉力即为粘力。 用粘力测试仪进行测试。 6.The normal temperature test: The range of temperature on plate is -20～100 ° C . In 80 ～100 ° C to maintain 8 hours , the label should not be warp,delamination,frothy and so on. The range of temperature on plastic and carton is -20 ～65 ° C. In 65 ° C to maintain 8 hours ,the label should not be warp, delamination,frothy and so on. 正常耐温测试： 在钢板上耐温范围为-20～100°C，在80～100°C保持8小时后不翘角不分层不脱落不起泡等。 在塑胶、纸箱上耐温范围为-20～65°C， 在65°C保持8小时后不翘角不分层不脱落不起泡等。 7.Temperature and humidity cycle test : Cycle conditions(stick on texture(PET) , stick on texture/carton(art paper): In temperature of -20 ～65 ° C and humidity of 30～90% to maintain 96 hours , the label should not be warp, delamination,frothy and so on. 耐温湿度循环测试：循环条件(贴在塑胶咬花面(PET)贴在塑胶咬花面/纸箱(铜板纸))：温度-20～65°C， 湿度30～90％，时间 96小时后不翘角不分层不脱落不起泡等。 8. Printing ink can not have overflow and printing color can not be uneven etc. 印刷不可有溢墨及颜色不均等不良现象 9. Packing style: coil and there should be a toothed hole between the link of two pieces 包装方式：卷状，连接处打齿孔。 10.The content in the frame printed by the factory barcode group and the specific content provided by SS. 框内内容由厂内打印，具体内容由业务提供。 11.3mm should be left between the link of two pieces.Around the edge of paper distance is 3mm. 两张连接处距离3mm，左右边离型纸3mm。 12. 贴附位置：后壳 13.其它测试要求详见（FQ-背胶类产品测试检验规格） 底色：透明色； 字体：白色 J40G027N608XXA J40G027N608XXA 100100 40 2.71 2.71 40 2.71 2.71 Qreator 27 Serial Number\ 序列号\序列號： MTM : 2020.07.10 Date of Manufacture\ \生产日期\ 生產日期： 警語: 使用過度恐傷害視力。 LED backlight 制 造 商: 联想(北京)有限公司 地 址: 北京市海淀区上地西路6号2幢2层201-H2-6 1S65FCMAR1WWV1000001 CAN ICES-3(B)/NMB-3(B) EU contact address:Lenovo (Slovakia),Landererova 12, 811 09 Bratislava,Slovakia J40G027N-608-XXA V10000001 65FC-****-ww 6.20kg LENOVO A20270DL0 R-R-TPF-A20270DL0 생산지:중국 1670-0088 연락처: 상호명: 한국레노버 유한회사 기자재의):(A20270DL0) 신청인:TPV Electronics(Fujian) Co., Ltd.(for Korea) 제조자: L&T Display Technology(Fujian)Ltd.(for Korea) J40G027E-608-XXA 0000068886 49020 20 FCC ID: A5M-A20270DL0 IC ID: 5903G-A20270DL0 Complies with IMDA Standards DA107035 0000068882 适用的电源适配器请参阅说明书。 For applicable power supplies see user manual. Voir le manuel d’utilisateur pour les courants d’alimentation applicables. موارد الطاقة المدعومة ارجع إلى دليل المستخدم للتعر ف على 型號 型号모델명 Type/Model : A20270DL0 電流 电流전류 Current : 8.5A 電壓 电压전압 Tegangan Voltage : 20V

AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 24 of 27 Figure 7 Inside of the EUT Figure 8 Inside of the EUT AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 25 of 27 Figure 9 Inside of the EUT Figure 10 Inside of the EUT AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 26 of 27 Figure 11 Inside of the EUT Figure 12 Inside of the EUT AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 27 of 27 Figure 13 Inside of the EUT Figure 14 Adapter AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20160 Page 28 of 27 Figure 15 Adapter THE END

AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 1 of 8 RF Exposure Evaluation TEST REPORT for Lenovo (Beijing) Limited LCD Monitor Model No.: A20270DL0 Brand Name: Lenovo FCC ID: A5M- A20270DL0 Prepared for : Lenovo (Beijing) Limited 201-H2-6, Floor2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Kefeng Road, Science & Technology Park, Nanshan District , Shenzhen, Guangdong, China Tel: (0755) 26639496 Fax: (0755) 26632877 Report Number ： ACS-F20161 Date of Test ： Aug.11,2020 Date of Report ： Aug.24,2020 AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 2 of 8 TABLE OF CONTENTS Description Page REPORT VERIFICATION .................................................................................................................. 3 1. GENERAL INFORMATION ........................................................................................................ 4 1.1. Description of Equipment Under Test .............................................................................................. 4 1.2. Test Facility ...................................................................................................................................... 5 1.3. Measurement Uncertainty (95% confidence levels, k=2) ................................................................. 5 2. RF EXPOSURE REQUIREMENT ............................................................................................... 6 2.1. GENERAL INFORMATION ........................................................................................................... 6 2.2. LIMIT ............................................................................................................................................... 6 3. ASSESS RESULTS ...................................................................................................................... 7 4. PHOTOGRAPHS .......................................................................................................................... 8 AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M - A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 4 of 8 1. GENERAL INFORMATION 1.1. Description of Equipment Under Test Applicant Lenovo (Beijing) Limited Applicant Address 201-H2-6, Floor2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China Manufacturer Lenovo (Beijing) Limited Manufacturer Address 201-H2-6, Floor2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China Factory TPV Electronics (Fujian) Co., Ltd. Factory Address Rongqiao Economic and Technological Development Zone, Fuqing City, Fujian Province, P.R. China. Product LCD Monitor Model No. A20270DL0 Brand Lenovo Adapter Manufacturer: Lenovo; M/N: ADP-170CB B Input: AC 100-240V 50-60Hz, 2.5A Output: DC 20V, 8.5A Radio Frequency 127.7kHz Modulation Type FSK Sample Type Prototype production Date of Receipt Jul.14,2020 Date of Test Aug.11,2020 AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 5 of 8 1.2. Test Facility Site Description Name of Firm : Audix Technology (Shenzhen) Co., Ltd. No. 6, Kefeng Road, Science & Technology Park, Nanshan District , Shenzhen, Guangdong, China RF Anechoic Chamber : Dimensions are: [L]10m × [W]5.5m × [H]5m EMC Lab. : Accredited by DAkkS, Germany Registration No: D-PL-12151-01-00 Valid Date: Dec.07, 2021 : Accredited by NVLAP, USA NVLAP Code: 200372-0 Valid Date: Mar.31, 2021 Certificated by FCC, USA Designation No: CN5022 Valid Date: Mar.31, 2021 1.3. Measurement Uncertainty (95% confidence levels, k=2) Test Item Uncertainty Uncertainty for Radiated Spurious Emission test in RF chamber 3.7dB(30MHz-1000MHz) 3.3dB(1GHz-26.5GHz) Uncertainty for test site temperature and humidity 0.6°C 3% AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 6 of 8 2. RF EXPOSURE REQUIREMENT 2.1. GENERAL INFORMATION For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of 15 cm. E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63 A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. This device meeting all of the following requirements, so the PGA is not required. (1) Power transfer frequency is less than 1 MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. 2.2. LIMIT Basic Restrictions Reference levels Basic restrictions for electric, magnetic and electromagnetic fields (0Hz to 300GHz) AUDIX Technology (Shenzhen) Co., Ltd. FCC ID: A5M- A20270DL0 Audix Technology (Shenzhen) Co., ltd.. Report No. ACS-F20161 Page 7 of 8 3. ASSESS RESULTS EUT: LCD Monitor M/N: A20270DL0 Test date: 2020-08-11 Pressure: 102.5±1.0 kpa Humidity: 52.7±3.0% Tested by: L…
