A5M-SE01Lenovo Pen Pro for Googlebook

Lenovo Pen Pro for Googlebook Quick Start Guide & Safety, Warranty Lenovo Pen Pro for Googlebook (for selected models) Depending on the model, your Chromebook might come with a Lenovo USI Pen Pro (hereinafter referred to as "the pen" in this section). The pen offers you smoother and more authentic writing experience, featuring realistic sound and vibration feedback. When not in use, the pen can be magnetically attached to your Chromebook. Figure 1. Overview of the pen Figure 2. Attachment position of the pen © Copyright Lenovo 1 2 Item Description 1. Pen top Erase text or drawings 2. Magnets and NFC (Near Field Communication) sensing area Attach the pen to the Chromebook and charge the pen Notes: • The pen contains magnets. Keep a safe distance away from devices and objects that might be affected by magnets, such as credit cards. The magnet is not visible from the outside of the pen. • The pen supports wireless charging through NFC. 3. Side switch area When the stylus is powered on, the area can be used to activate Bluetooth broadcasting and other button functions. 4. Pen tip Click, tap, write or sketch on the screen Notes: • Attach the pen to your Chromebook using the flat edge of the pen. • The illustrations are for your reference only. Initial setup of the pen When you use your Lenovo USI Pen Pro for the first time, the following steps are for your reference. Step 1. Attach the pen to your Chromebook for pen charging and activation. Step 2. Connect the pen to Bluetooth. The pen will start Bluetooth broadcasting when it is activated successfully. A pop-up will appear on your Chromebook prompting you to connect the pen to Bluetooth. Alternatively, you may follow the steps below to connect to Bluetooth. a. Go to Start menu, and select Settings ➙ Bluetooth & devices ➙ Bluetooth. b. Turn on the Bluetooth toggle. c. Select Devices ➙ Add devices ➙ Bluetooth to find the pen and select it. Note: You can view the pen's charging status in the Bluetooth Settings. Features of the pen The pen offers many features in addition to natural haptic feedback, low latency and effortless writing experience. Gesture Feature Tap once on the screen with the pen tip Select or open an item Double-tap the side switch Screenshot Squeeze the side switch area and release it, and then draw a loop around the content on the screen Search Swipe up or down in the side switch area Page up or down Squeeze and hold the side switch area for a few seconds Activate Bluetooth broadcasting 2 Note: The features may vary depending on your model and Operation System version. Choking hazard warning DANGER CHOKING HARZARD—The pen contains a small component (the tip). Keep the pen out of reach of children under three years old and individuals who have a tendency to place inedible objects in their mouths. 2 Important safety and handling information Plastic bag notice Danger: Plastic bags can be dangerous. Keep plastic bags away from babies and children to avoid danger of suffocation. Safety instructions for parents and adult supervisors The device is not a toy. As with all electrical products, precautions should be observed during handling and using of electrical products to reduce the risk of electric shock. If parents choose to allow children to use the device, they should caution his or her child about the potential hazard while using and handling the mobile device. Parents should inspect the mobile device periodically for damage. Routinely check this mobile device to ensure that the device is working properly and is safe for children to use. Internal rechargeable battery warning Danger: Do not attempt to replace the internal rechargeable lithium-ion battery. Replacing the original battery with an incompatible type may result in an increased risk of personal injury or property damage due to explosion, excessive heat, or other risks. Remplacer la batterie d'origine par un type incompatible peut entraîner un risque accru de blessures corporelles ou de dommages matériels en raison d'une explosion, d'une chaleur excessive ou d'autres risques. Do not attempt to disassemble or modify the battery. Attempting to do so can cause a harmful explosion or battery fluid leakage. When disposing of the battery, comply with all relevant local ordinances or regulations. Do not dispose the battery in municipal waste. Dispose used batteries according to the instructions. The battery contains a small amount of harmful substances. To avoid injury: • Keep the battery away from open flames or other heat sources. • Do not expose the battery to water, rain, or other corrosive liquids. • Do not leave the battery in an environment with extremely high temperature. • Avoid short-circuiting the battery. • Do not leave the battery in an environment with extremely low air pressure. It may result in an explosion or the leakage of flammable liquid or gas from the battery. To extend battery life, we recommend charging the battery to at least 30% to 50% capacity each time, and recharging it every three months to prevent over discharge. 2 EurAsia compliance mark Energy efficiency mark India plastic waste management Lenovo India Pvt Ltd Regn. No. BO-03-000-06-AABCI3372H-22 Thickness > than 50 microns XXX-XXXXXXX 2 Warranty and support information Lenovo Limited Warranty notice This product is covered by the terms of the Lenovo Limited Warranty (LLW), version L5050010I02 08/2011. Read the LLW at https://www.lenovo.com/warranty/llw_02. You can view the LLW in a number of languages from this Web site. Warranty information Lenovo provides a warranty period for your device. To check the warranty status of your device purchase upgrades, go to https://support.lenovo.com/warrantylookup, and then select the product on-screen instructions. Get support Visiting Lenovo’s support website (https://support.lenovo.com) with the device serial number to get more Lenovo support options. Consult Lenovo Community by visiting http://forums.lenovo.com 2 Environmental, recycling, and disposal i…

Text truncated - open the document above for the full version.

Lenovo (Beijing) Limited Date: 5/18/2026 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: A5M-SE01 Grantee FRN: 0032905564 1. Lenovo (Beijing) Limited certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Lenovo (Beijing) Limited certifies that, the device does not have cybersecurity and / or anti- virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, identified on the Covered List installed on the device, nor will it be installed by the applicant anytime after certification. 3. Lenovo (Beijing) Limited (“the applicant”) certifies that the RF device is not a router “produced in a foreign country”. 4. Lenovo (Beijing) Limited certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Yang Liu Job Title: Product Manager Company Name: Lenovo (Beijing) Limited

Grantee FRN: 0032905564

Lenovo (Beijing) Limited Date: 8/6/2025 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a)fulfill the requirements for the scope of certification requested, including implementing any appropriate changes requested by UL Verification Services Telecommunications Certification Body (TCB) and / or the FCC; b)supply any and all information needed for the evaluation of the products for which certification is sought; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)not use our product certification in such a manner as to bring the TCB or FCC into disrepute and to not make any statement regarding product certification which the TCB or FCC may consider misleading or unauthorized; e)discontinue use of all advertising matter that contains any reference thereto and complies with any and all actions required by the FCC upon suspension or cancellation of certification; f)use certification only to indicate that products are certified in conformity with specified standards; g)endeavor to ensure that no certificate or report or any part thereof is used in a misleading manner, and any copies of the grants/certificates shall be reproduced in their entirety; h)comply with the requirements of the TCB and FCC, including the use of marks and label information prescribed for the scope of certification, when making reference to product certification in communication media such as documents, brochure or advertisements; i)comply with the requirements for certification, supply any information needed for evaluation of products to be certified and, where applicable, make provision for the participation of observers; j)ensure that products marketed under the scope of the requested certification continue to comply with the certification requirements; k)provide a sample of a production unit for testing within 30 days of the request should this product be selected as part of either the TCB’s or the FCC’s market surveillance requirements; l)keep a record of all complaints relating to product’s compliance with requirements of relevant standard; make records available to UL or FCC when requested; take appropriate action with respect to such complaints and any deficiencies found in the product that affect compliance with requirements for certification; document the actions taken with respect to complaints and/or deficiencies; m)inform the TCB immediately of any changes that may affect its ability to comply with the certification requirements. This authorization is valid until further written notice from the applicant. Sincerely Yours, Company Name: Lenovo (Beijing) Limited Contact Name: Yang Liu Title of Person: Product Manager Address: 201-H2-6, Floor2, Building 2, No. 6 Shangdi West Road, Haidian District, Beijing, China

Lenovo (Beijing) Limited Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A5M-SE01 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Company Name: Lenovo (Beijing) Limited Contact Name: Yang Liu Title of Person: Product Manager Address: 201-H2-6, Floor2, Building 2, No. 6 Shangdi West Road, Haidian District, Beijing, China Date: 5/1 8/2026

External Photographs Page 2 of 3 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Page 3 of 3 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch.

Label Location: Label Location Label: Note: Because the pen is round, So it is difficult to printed the FCC/IC ID clearly on the pen through silk-screen printing technology. The FCC/IC ID will be placed on a removable label affixed to the product body, and the FCC/IC ID will also be printed in user manual.

Internal Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Ceramic antenna

FCC ID: A5M-SE01 According to 447498 D04 Interim General RF Exposure Guidance v01, 2.1.4 MPE-Based Exemption An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power.10 For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). B.4 SAR-based Exemption SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time- averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). The example values shown in Table B.2 are for illustration only. 1. SAR test exclusion threshold for 2.402GHz~2.480GHz is 3 mW. Max Tune-up Power [dBm] Max Tune-up Power [mW] Antenna Gain [dBi] EIRP [dBm] ERP [dBm] ERP [mW] Limit [mW] Conclusion 2 1.6 2 4 1.85 1.53 3.00 No SAR is required. - When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2. Conclusion: No SAR is required.

QR/RD-P01-06B SPECIFICATION DaxianCommunicationTechnologyLimited 深圳市大显科技有限公司 ShenzhenDaxianTechnologyCo.,Ltd. 产品规格书 客户陶瓷型号 项目名称客户料号 制作柯芬结构设计李志恩 品质经理胡子寅技术总监张磊 日期 客户确认： 装配是否符合贵司要求：□OK□NG 深圳市大显科技有限公司 ShenzhenTopantTechnologyCo.,Ltd. 深圳市龙岗区布吉镇吉华路513号上水径村（国防培训 基地对面）达成工业园综合楼7楼 TEL:0755-28576002 FAX:0755-84276383 上海分部：上海市张江高科技园区集成电路产业区龙东 大道3000号8号楼201室 TEL:021-61630552 FAX:755-84276383 BujiTown,LonggangDistrict,Shenzhen,China JihuaRoad513,ShangshuijingVillage(opposite thenationaldefensetrainingbase)Dacheng IndustrialPark,Building7。 TEL:0755-28576002 FAX:0755-84276383 Room201,Building8,LongDongRoad3000#,Semiconductor IndustryPark,ZhangJiangHitechZone,ShangHai TEL:021-61630552 FAX:755-84276383 / / 陶 瓷 天 线 RFECA3216060A19C3C / 2021-1-13 Page 1 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 RFECA Series – RoHS Compliance CERAMIC ANTENNA Halogens Free Product 2.4 GHz ISM Band RF Application P/N: RFECA3216060A19C3C *Contents in this sheet are subject to change without prior notice. Page 2 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 FEATURES 1. Surface Mounted Devices with a small dimension of 3.2 X 1.6 X 0.6 mm 3 meet future miniaturization trend. 2. High stability in Temperature / Humidity Change. 3. Superb performance to place on the middle of PCB edge and excellent peak/ average gain observed by field test application. APPLICATIONS 1. ISM Band 2.4GHz applications. 2. Bluetooth.. CONSTRUCTION DIMENSIONS Figure Symbol Dimension (mm) L 3.10 ± 0.20 W 1.60 ± 0.20 T 0.60 ± 0.10 A 0.25 ± 0.20 PIN Connection 1 Feeding 2 Soldering terminal Page 3 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 SOLDER LAND PATTERN DESIGN Type-1: Empty Space 6.45 mm x 4.0 mm Figure (Empty Space 6.45 mm x 4.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-1 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 2.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Page 4 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 Type-2: Empty Space 3.0 mm x 8.0 mm Figure (Empty Space 3.0 mm x 8.0 mm) The limited size for ECA3216 is L>30mm and D>6mm Land Pattern TYPE-2 TEST BOARD ELECTRONIC CHARACTERISTICS *Note 1. Central Frequency should be defined after customers’ application approval. Item Specification Working Frequency Range 2.4GHz~2.4835GHz (Note-1) Gain 2 dBi (Typical) VSWR 3.0 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50 Power Capacity 3 W max. Maximum Input Power 5 Watts for 5 minutes Page 5 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 Antenna on Type-1 Test Board (Empty Space 6.45 mm x 4.0 mm, 90 mm x 40 mm Ground & Thickness 0.8 mm) Antenna S11 on Type-1 Test Board Antenna VSWR on Type-1 Test Board 1.84 @ 2.40 GHz 1.23 @ 2.45 GHz 1.90 @ 2.50 GHz -10.57 dB @ 2.40 GHz -19.42 dB @ 2.45 GHz -10.13 dB @ 2.50 GHz Page 6 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 Antenna on Type-2 Test Board (Empty Space 3.0 mm x 8.0 mm, 90 mm x 40 mm Ground & Thickness 0.8 mm) Antenna S11 on Type-2 Test Board Antenna VSWR on Type-2 Test Board 2.76 @ 2.40 GHz 1.09 @ 2.45 GHz 2.55 @ 2.50 GHz -6.57 dB @ 2.40 GHz -30.81 dB @ 2.45 GHz -7.18 dB @ 2.50 GHz Page 7 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 RADIATION PATTERN Radiation Pattern and Gain were dependent on measurement board design. The specification of RFECA3216060A19C3C antenna was measured based on the PCB size and installation position as shown in the below figure Test Board. Antenna on Type-1 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 -0.18 -1.35 0.88 -1.72 -0.20 -2.31 2450 1.02 -0.42 1.71 -0.96 0.48 -1.61 2500 0.05 -0.90 0.97 -1.39 0.38 -1.83 Page 8 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 Antenna on Type-2 Test Board ZX plane ZY plane XY plane Frequency [MHz] Max Value [dB] Average [dB] Max Value [dB] Average [dB] Max Value [dB] Average [dB] 2400 -0.82 -1.83 0.27 -2.11 -0.58 -2.55 2450 0.94 -0.79 1.58 -1.15 0.47 -1.72 2500 -0.64 -1.10 0.35 -1.66 -0.44 -1.99 Page 9 of 12 ASC_RFECA3216060A19C3C_V01 Jul. 2020 RELIABILITY TEST Test item Test condition / Test method Specification Solderability JIS C 0050-4.6 JESD22-B102D *Solder bath temperature：235  5C *Immersion time：2  0.5 sec Solder：Sn3Ag0.5Cu for lead-free At least 95% of a surface of each terminal electrode must be covered by fresh solder. Leaching (Resistance to dissolution of metallization) IEC 60068-2-58 *Solder bath temperature：260  5C *Leaching immersion time：30  0.5 sec Solder : SN63A Loss of metallization on the edges of each electrode shall not exceed 25%. Resistance to soldering heat JIS C 0050-5.4 *Preheating temperature：120~150°C, 1 minute. *Solder temperature：2705C *Immersion time：101 sec Solder：Sn3Ag0.5Cu for lead-free Measurement to be made after keeping at room temperature for 242 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Loss of metallization on the edges of each electrode shall not exceed 25%. Drop Test JIS C 0044 Customer’s specification. *Height：75 cm *Test Surface：Rigid surface of concrete or steel. *Times：6 surfaces for each units；2 times for each side. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Vibration JIS C 0040 *Frequency：10Hz~55Hz~10Hz(1min) *Total amplitude：1.5mm *Test times：6hrs.(Two hrs each in three mutually perpendicular directions) No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Adhesive Strength of Termination JIS C 0051- 7.4.3 *Pressurizing force…

Text truncated - open the document above for the full version.

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. CFR 47 FCC PART 15 SUBPART C ISED RSS-247 Issue 4 TEST REPORT For Lenovo Pen Pro for Googlebook MODEL NUMBER: SE01 REPORT NUMBER: 4792176677-1-RF-1 FCC ID: A5M-SE01 IC: 5903G-SE01 ISSUE DATE: April 30, 2026 Prepared for FCC: Lenovo (Beijing) Limited IC: LENOVO CHINA FCC Address: 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road,Haidian District, Beijing, China IC Address: No.6 Chuang Ye Road, Shangdi Information Industry Haidan District, Beijing 100085 China Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Room 101, Building 2, No.4, Information Road, Songshan Lake, Dongguan, Guangdong, China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4792176677-1-RF-1 Page 2 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 April 30, 2026 Initial Issue REPORT NO.: 4792176677-1-RF-1 Page 3 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) RSS-GEN Clause 6.8 Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 RSS-GEN Clause 8.8 N/A Conducted Output Power ANSI C63.10-2020, Clause 11.9.1.2 & 11.9.2.3.1 FCC Part 15.247 (b)(3) RSS-247 Clause 6.3.2 Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 & 6.9.3 FCC Part 15.247 (a)(2) RSS-247 Clause 6.3.1 (a) RSS-Gen Clause 6.7 Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.2 FCC Part 15.247 (e) RSS-247 Clause 6.3.1 (b) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) RSS-247 Clause 6.6 Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.12 FCC Part 15.247 (d) FCC Part 15.205/15.209 RSS-247 Clause 6.6 RSS-GEN Clause 8.9 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass Note: 1. N/A: In this whole report not applicable. 2. For FCC, ANSI C63.10:2020 + Cor.1:2023 is also considered for the corresponding test item which is needed. 3. For ISED, this report is also performed according to ANSI C63.10-2020 + Cor.1-2023 + C63.10a-2024 + Errata to C63.10a-2024 standards. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C ISED RSS-247 Issue 4> when <Simple Acceptance> decision rule is applied. Decision rule for statement of conformity: The measurement uncertainty is not taken into account for statement of conformity. REPORT NO.: 4792176677-1-RF-1 Page 4 of 79 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS ...................................................................................... 6 2. TEST METHODOLOGY .......................................................................................................... 7 3. FACILITIES AND ACCREDITATION ...................................................................................... 7 4. CALIBRATION AND UNCERTAINTY ..................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................ 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................. 8 5. EQUIPMENT UNDER TEST .................................................................................................... 9 5.1. DESCRIPTION OF EUT ............................................................................................. 9 5.2. CHANNEL LIST .......................................................................................................... 9 5.3. MAXIMUM POWER .................................................................................................... 9 5.4. TEST CHANNEL CONFIGURATION ....................................................................... 10 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 10 5.6. DESCRIPTION OF AVAILABLE ANTENNAS .......................................................... 10 5.7. SUPPORT UNITS FOR SYSTEM TEST .................................................................. 11 6. MEASURING EQUIPMENT AND SOFTWARE USED ......................................................... 12 7. ANTENNA PORT TEST RESULTS ...................................................................................... 14 7.1. CONDUCTED OUTPUT POWER ............................................................................ 14 7.2. 6DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ........................................ 15 7.3. POWER SPECTRAL DENSITY ............................................................................... 17 7.4. CONDUCTED BAND EDGE AND SPURIOUS EMISSION...................................... 18 7.5. DUTY CYCLE ...................................…

Text truncated - open the document above for the full version.

Appendix II Setup Photographs RADIATED RF MEASUREMENT SETUP (ABOVE 1 GHz) MEASUREMENT POSITION MEASUREMENT POSITION (X axis) MEASUREMENT POSITION (Y axis) MEASUREMENT POSITION (Z axis) RADIATED RF MEASUREMENT SETUP (30MHz~1GHz) RADIATED RF MEASUREMENT SETUP (Below 30MHz)
